2. INTRODUCTION
The OCTAVE and MATLAB is the one of the most programming language. It is simple to
learn about the language. The main of these programming language is to visualization
the data become a graph.
There are no big different between OCTAVE and MATLAB. However, the MATLAB has
more complete function compared to OCTAVE.
Also, OCTAVE is OPEN SOURCE software
https://www.gnu.org/software/octave/ https://www.mathworks.com/videos/programming-with-matlab-
86354.html
sharing.auliakhalqillah.com
3. INTRODUCTION
In OCTAVE and MATLAB have 4 panels, such as:
Command Window
Workspace = The whole variables will be store in the workspace
Current Folder = The active directory
Text Editor = To write full script (like atom, notepad++, Xcode, etc)
In this note, we will use the command window to write the basic code of
OCTAVE/MATLAB programming language. After the all of the basic
code has been understood, we will explain how to write the full code
using the OCTAVE/MATLAB programming language.
sharing.auliakhalqillah.com
4. USING COMMAND WINDOW:
VARIABLE
You can type the command bellow in your Command Window:
>> 5
ans = 5
When you type the command above, the output is ans = 5. The ans is name of
variable what you typed before. If you type as the command bellow:
>> x = 5
x = 5
The x is the new name of variable what you typed.
sharing.auliakhalqillah.com
5. USING COMMAND WINDOW:
VARIABLE
If you add the (;) in the end of variable
>> x = 5;
The output variable doesn’t appear in the Command Window and it will
be stored in the Workspace
sharing.auliakhalqillah.com
6. USING COMMAND WINDOW:
OPERATION OF MATH
The simple operation of math in OCTAVE/MATLAB programming
language is as follows:
>> x = 5;
>> y = 10;
>> z = x + y
z = 15
Operation Symbol
add +
substraction -
multiplication *
division /
sharing.auliakhalqillah.com
7. USING COMMAND WINDOW:
CONSTANTS
In the OCTAVE/MATLAB programming language has a predefined
constants, such as:
Symbol Syntax information
𝜋 pi pi = 3.1416...
Imaginary i atau j 0 + 1i
epsilon eps 2.2204e-16
Infinity inf unlimited
- NaN no value
comment % to write some note in the code
sharing.auliakhalqillah.com
8. USING COMMAND WINDOW:
FUNCTION OF MATH
In the OCTAVE/MATLAB programming language has a predefined
function, such as:
Symbol Syntax
sin x sin(x)
cos x cos(x)
arcsin x asin(x)
arccos x acos(x)
ex exp(x)
log10 x log10(x)
log2 x log2(x)
𝑥 sqrt(x)
sharing.auliakhalqillah.com
9. USING COMMAND WINDOW:
FUCNTION OF MATH
Example
>> x = pi/2;
>> sin(x)
ans = 1
>> cos(x)
ans = 6.1232e-17
>> asin(x)
ans = 1.5708 - 1.0232i
>> acos(x)
ans = 0.00000 + 1.02323i
Example
>> exp(x)
ans = 4.8105
>> log10(x)
ans = 0.19612
>> log2(x)
ans = 0.65150
>> sqrt(x)
ans = 1.2533
>> log10(sin(x))
ans = 0
sharing.auliakhalqillah.com
10. USING COMMAND WINDOW:
VECTOR
>> x = [1 2] % Term 1
x =
1 2
>> x = [1;2] % Term 2
x =
1
2
Term 1 have the output horizontally or as the row
Term 2 have the output vertically or as the column
sharing.auliakhalqillah.com
11. USING COMMAND WINDOW:
VECTOR
If you want to make the vector (e.g. 1, 2, 3, ...., etc), you can type the command
as follows:
>> x = [1 2 3 4 5 6 7 8 9 10] % Row vector
x =
1 2 3 4 5 6 7 8 9 10
>> x = [1;2;3;4;5] % Column vector
x =
1
2
3
4
5
sharing.auliakhalqillah.com
12. USING COMMAND WINDOW:
VECTOR
You can generate the vector using linspace
Term 1 => x = linspace(start, end)
>> x = linspace(1,2);
The vector will be start from 1 to 2 with the default of data length is 100. This
output will be as a row vector. To produce the column vector, you can type:
>> x = linspace(1,2)’;
The output will be stored in Workspace
sharing.auliakhalqillah.com
13. USING COMMAND WINDOW:
VECTOR
The another term of linspace is:
Term 2 => linspace(start, end, N)
>> x = linspace(1,2,10);
The vector will be start from 1 to 2 with length of data is 10.
The another one term to generate the vector:
Term 3 => x = start:end
>> x = 1:10
x =
1 2 3 4 5 6 7 8 9 10
sharing.auliakhalqillah.com
15. USING COMMAND WINDOW:
FUNCTION AND OPERATION OF VECTOR
Symbol Syntax Information
ak a(k) The component k-th of vector a
an a(end) The last component of vector a
𝑎 =
𝑘=1
𝑛
𝑎 𝑘
1/2
norm(a) normalization of vector
ab a*b multiplication of vector
max{ak}k=1, .. n max(a) maximum value of vector a
max{ak}k=1, .. N min(a) minimum value of vector a
n(a) length(a) size of vector a
𝑘=1
𝑛
𝑎 𝑘
sum(a) The summation of vector a
𝑘=1
𝑛
𝑎 𝑘
prod(a) The multiplication of vector a
sharing.auliakhalqillah.com
16. USING COMMAND WINDOW:
FUNCTION AND OPERATION OF VECTOR
Symbol Syntax Information
𝑘=1
𝑛
𝑎 𝑘 𝑏 𝑘
dot(a,b) dot product between vector a and b
(a1b1, ....., anbn) a.*b multiplication between components
Example:
>> x = [3 2 5];
>> y = [4 1 6];
>> length(x)
ans = 3
>> length(y)
ans = 3
Example:
>> norm(x)
ans = 6.1644
>> dot(x,y)
ans = 44
>> z = x.*y
z =
12 2 30
Example
>> max(x)
ans = 5
>> max(y)
ans = 6
sharing.auliakhalqillah.com
17. USING COMMAND WINDOW:
MATRIX
To produce the matrix, you can type:
>> x = [1 2 3;4 5 6;7 8 9]
x =
1 2 3
4 5 6
7 8 9
The output is the example of matrix with size 3 x 3. The sign of (;) as the new
row for the matrix.
sharing.auliakhalqillah.com
18. USING COMMAND WINDOW:
MATRIX
INDEX OF MATRIX
Columns
𝐴 =
𝑎1 𝑎2 𝑎3
𝑎4 𝑎5 𝑎6
𝑎7 𝑎9 𝑎10
Rows
In OCTAVE/MATLAB index of matrix can be written as A(i,j), where the i
as the row and j as the column
sharing.auliakhalqillah.com
19. USING COMMAND WINDOW:
MATRIX
EXAMPLE
>> A = [1 2 3;4 5 6;7 8 9]
A =
1 2 3
4 5 6
7 8 9
If you want to take the element
from the third row and the second
column of the matrix A, you can
type:
>> AA = A(3,2)
AA = 8
EXAMPLE
>> A = [1 2 3;4 5 6;7 8 9]
A =
1 2 3
4 5 6
7 8 9
If you want to take the
element from the first column,
you can type:
>> AA = A(:,1)
AA =
1
4
7
sharing.auliakhalqillah.com
20. PENGGUNAAN COMMAND WINDOW:
MATRIKS
EXAMPLE
>> A = [1 2 3;4 5 6;7 8 9]
A =
1 2 3
4 5 6
7 8 9
If you want to take the
element from first row and
second row, you can type:
>> AA = A(1:2,:)
AA =
1 2 3
4 5 6
EXAMPLE
>> A = [1 2 3;4 5 6;7 8 9]
A =
1 2 3
4 5 6
7 8 9
If you want to take the
element second column and
third column, you can type:
>> AA = A(:,2:3)
AA =
2 3
5 6
8 9
sharing.auliakhalqillah.com
21. USING COMMAND WINDOW:
MATRIX OPERATION
The operation of math in matrix as follows:
ADDITION (+),
SUBSTRACTION(-),
MULTIPLICATION (*),
MULTIPLICATION BETWEEN ELEMENT(.*),
POWER (^),
TRANSPOSE (‘),
LEFT DIVISION (),
RIGHT DIVISION (/).
EXAMPLE
>> A = [1 2 3;4 5 6;7 8 9];
>> B = [2 4 6;8 10 12; 1 2 3];
>> C = A+B % Add
C =
3 6 9
12 15 18
8 10 12
>> C = A-B % Substrac
C =
-1 -2 -3
-4 -5 -6
6 6 6
sharing.auliakhalqillah.com
22. USING COMMAND WINDOW:
MATRIX OPERATION
Example
>> C = A^2 % Power
C =
30 36 42
66 81 96
102 126 150
>> C = A’ % Transpose
C =
1 4 7
2 5 8
3 6 9
Example
>> C = A*B % Multiplication
C =
21 30 39
54 78 102
87 126 165
>> C = A.*B % Element Multiplication
C =
2 8 18
32 50 72
7 16 27
sharing.auliakhalqillah.com
23. USING COMMAND WINDOW:
MATRIX OPERATION
LEFT DIVISION () => C = AB = A-1B
RIGHT DIVISION (/) => C = A/B = AB-1
Example:
>> A = [1 2 3;4 5 6;7 8 9];
>> B = [2 4 6;8 10 12; 1 2 3];
>> C = AB % LEFT DIVISION
C =
-2.305556 -3.611111 -4.916667
-0.055556 -0.111111 -0.166667
2.194444 3.388889 4.583333
sharing.auliakhalqillah.com
24. USING COMMAND WINDOW:
MATRIX OPERATION
>> C = A/B % RIGHT DIVISION
C =
4.0000e-01 1.5266e-16 2.0000e-01
4.8190e-16 5.0000e-01 3.8806e-16
-4.0000e-01 1.0000e+00 -2.0000e-01
SPECIFICALLY IN THE CASE OF MATRIX RULES, APPLICABLE
REQUIREMENTS FOR ANALYSIS OF MATRICES. WHERE THE REQUIREMENT
OF MATRIX MULTIPLICATION IS : THE NUMBER OF COLUMNS IN MATRICES
A = NUMBER OF LINES IN B MATRICES
THANK YOU AND GOOD LUCK
Source: Matematika Numerik dengan Implementasi Matlab, Julan Hernadi, Penerbit Andi (2012)
