1. Android Wear Essen-als
Improve your Android skills, building watch faces

2. What you should know about
Android Wear

3. Android Wear
• Android SDK
• Specific wear APIs in external libraries (support:wearable,
play-services-wearable)
• All devices are compa>ble with API 23 (minSdkVersion 23)
• Only a few devices are compa>ble with API > 23 ("Android Wear
2.0")

4. Crea%ng a wear app
h"ps://developer.android.com/training/building-wearables.html

5. Crea%ng a wear app
• Ac$vity
• AndroidManifest.xml
• LayoutInflater
• You know the stuff...

6. Crea%ng a watch face
h"ps://developer.android.com/training/wearables/watch-faces/index.html

7. Crea%ng a watch face
1. Create a class that extends
CanvasWatchFaceService.Engine
2. Create a Service that extends CanvasWatchFaceService and
override onCreateEngine
Prefer OpenGL ES instead of the Canvas API ?
Use Gles2WatchFaceService instead

8. Create a watch face project

10. Ba#ery usage

12. AMOLED

13. Interac(ve mode (default)

14. Ambient mode / Low-bit Ambient

15. Low-bit Ambient / Ambient

16. Burn-in effect

17. Burn-in effect
h"ps://en.wikipedia.org/wiki/Screen_burn-in

18. Burn-in effect

19. Burn-in effect

20. Avoid burn-in
• Do not draw large areas of pixels in ambient mode
• Do not place content within 10 pixels of the edge of the screen

21. I'm bored, can I see some code?

22. class Engine extends CanvasWatchFaceService.Engine {
Paint paint;
@Override void onCreate(SurfaceHolder holder) {
paint = new Paint();
paint.setTextSize(80_DIP);
paint.setStyle(Style.FILL);
paint.setColor(Color.MAGENTA);
paint.setTextAlign(Align.CENTER);
paint.setAntiAlias(true);
}
@Override void onDraw(Canvas canvas, Rect bounds) {
canvas.drawText("18:42", bounds.centerX(), bounds.centerY(), paint);
}
}

24. Style.STROKE
if (inAmbientMode) {
paint.setColor(WHITE);
paint.setStyle(STROKE);
paint.setStrokeWidth(1_DIP);
if (lowBitEnabled) {
paint.setAntiAlias(false);
}
}

25. Lifecycle

28. Enough theory

29. 10mn to create a watch face

30. #1: Draw the background

31. Paint backgroundPaint = new Paint();
@Override void onCreate(SurfaceHolder holder) {
super.onCreate(holder);
backgroundPaint.setStyle(FILL);
backgroundPaint.setColor(DKGRAY);
backgroundPaint.setAntiAlias(true);
}
@Override void onDraw(Canvas canvas, Rect bounds) {
canvas.drawRect(0, 0, bounds.width(), bounds.height(), backgroundPaint);
}

32. Background

33. Gradient: Linear / Sweep / Radial
LinearGradient(0, centerY, width, centerY, WHITE, BLACK, CLAMP));
SweepGradient(radius, radius, WHITE, BLACK));
RadialGradient(centerX, centerY, radius, WHITE, BLACK, CLAMP));
paint.setShader(shader);

34. Tile mode: Clamp / Mirror / Repeat
tileMode = Shader.TileMode.CLAMP;
tileMode = Shader.TileMode.MIRROR;
tileMode = Shader.TileMode.REPEAT;
new RadialGradient(radius, radius, radius / 10, WHITE, BLACK, tileMode));

35. Gradient posi-ons
int[] colors = new int[] { RED, GREEN, BLUE, MAGENTA, CYAN};
float[] positions = new float[] { 0f, 0.1f, 0.4f, 0.8f, 1.0f};
gradient = new LinearGradient(0, radius, width, radius, colors, positions, CLAMP);

36. Gradient posi-ons
Shader shader = new LinearGradient(
0, centerY, width, centerY,
new int[] {blue, blue, white, white, red, red},
new float[] {0f, 0.33f, 0.33f, 0.66f, 0.66f, 1f},
CLAMP);
bgPaint.setShader(shader);

37. Back to our background
int[] colors = new int[] {DKGRAY, DKGRAY, BLACK, BLACK};
float[] positions = new float[] {0, 0.25f, 0.25f, 1f};
bgPaint.setShader(new RadialGradient(centerX, centerY, 6_DIP, colors, positions, REPEAT));

38. #2 Place the minutes indicators

39. Path path;
@Override void onApplyWindowInsets(WindowInsets insets) {
[...]
path = createMinutesIndicators(centerX, centerY, radius - 10_DP);
}
@Override void onDraw(Canvas canvas, Rect bounds) {
[...]
canvas.drawPath(path, paint);
}

41. Minutes indicators

42. Add shadow
mnPaint.setShadowLayer(4f, 2f, 2f, Color.GRAY);

43. #3 Create the watch hands

44. Paint handHourPaint;
Path handHourPath;
@Override void onCreate(SurfaceHolder holder) { [...]
handHourPaint = new Paint();
handHourPaint.setStyle(Paint.Style.FILL);
handHourPaint.setColor(Color.WHITE);
handHourPaint.setAntiAlias(true);
handHourPaint.setPathEffect(new CornerPathEffect(2_DP));
}
@Override void onApplyWindowInsets(WindowInsets insets) { [...]
handHourPath = createHandHour(centerX, centerY, radius - 20_DP);
}
@Override void onDraw(Canvas canvas, Rect bounds) { [...]
canvas.drawPath(handHourPath, handHourPaint);
}

45. Hour hand
path.moveTo(
centerX - 16_DIP, centerY
);
path.lineTo(
centerX - 10_DIP, centerY
);

46. path.arcTo(
new RectF(
centerX - 10_DIP,
centerY - 10_DIP,
centerX + 10_DIP,
centerY + 10_DIP
),
180f, -180f
);

47. path.lineTo(
centerX + 16_DIP, centerY
);

48. path.quadTo(
centerX,
centerY - 20_DIP,
centerX + 1_DIP,
centerY - needleHeight
);

49. path.quadTo(
centerX,
centerY - 20_DIP,
centerX - 16_DIP,
centerY
);

50. int[] colors = new int[] {
0xff878191, 0xffaba6b3,
0xffb9b1c5, 0xffa9a2b3
};
float[] positions = new float[] {
0, 0.49f, 0.51f, 1f
},
Shader gradient = new LinearGradient(
radius - 10_DIP, 0,
radius + 10_DIP, 0,
colors, positions,
Shader.TileMode.CLAMP
);
handHourPaint.setShader(gradient);

51. canvas.save();
canvas.rotate(
10 * 360 / 12,
centerX, centerY
);
canvas.drawPath(path, paint);
canvas.restore();

52. Paint shadowPaint = new Paint();
shadowPaint.setAntiAlias(true);
shadowPaint.setColor(GRAY);
shadowPaint.setShadowLayer(4f, 4f, 2f, GRAY);
[...]
canvas.drawPath(handHourPath, shadowPaint);
canvas.drawPath(handHourPath, watchHandPaint);

53. Add the minute
hand

54. Add the second
hand

55. #4 Create the ambient mode

56. #5 No step 5

57. Source code
github.com/Nilhcem/the-10mn-watchface

58. Tips & Tricks

59. #1: Official documenta2on is !
developer.android.com/wear/index.html

60. #2: Share code with a common module

61. #3: Custom WatchFrame
Layout
h"ps://github.com/Nilhcem/hexawatch/
blob/master/companion/src/main/java/
com/nilhcem/hexawatch/ui/widget/
WearFrameLayout.java
<com.nilhcem.hexawatch.ui.widget.WearFrameLayout
android:layout_width="wrap_content"
android:layout_height="match_parent">
<com.nilhcem.hexawatch.ui.widget.HexawatchView
android:layout_width="match_parent"
android:layout_height="match_parent"/>
</com.nilhcem.hexawatch.ui.widget.WearFrameLayout>

62. #4: Consider using Protobuf over
Json

63. #5: Want to cut bitmaps? Use Xfermode

64. #6: Check out ustwo clockwise SDK
h"ps://github.com/ustwo/clockwise

65. #7: Stripes shader
aka "A burn-in friendly way to fill a large surface"
paint.setStyle(Paint.Style.FILL);
paint.setShader(new LinearGradient(
0f, 0f, TWO_DIP, TWO_DIP,
new int[] {
WHITE, WHITE, TRANSPARENT, TRANSPARENT
},
new float[] {
0, 0.25f, 0.25f, 1f
},
Shader.TileMode.REPEAT
)
);

66. #8: Bitmap shader
github.com/Nilhcem/shammane-
androidwear
Bitmap dotPattern = BitmapFactory.decodeResource(
context.getResources(),
R.drawable.dot_pattern
);
paint.setShader(
new BitmapShader(
dotPattern, TileMode.REPEAT, TileMode.REPEAT
)
);

67. #9: Experiment in an
Android (not wear) custom
View
<com.nilhcem.experiments.ui.widget.WearFrameLayout
android:layout_width="match_parent"
android:layout_height="match_parent">
<com.nilhcem.experiments.ui.ExperimentalView
android:layout_width="match_parent"
android:layout_height="match_parent"/>
</com.nilhcem.experiments.ui.widget.WearFrameLayout>

68. #10: Use ValueAnimator
for onDraw anima7ons
private ValueAnimator animator;
private final Handler handler = new Handler();
public void onTapCommand(int tapType, int x, int y, long e) {
if (tapType == TAP_TYPE_TAP) {
animator = ValueAnimator.ofInt(0, Math.round(MAX_RADIUS));
animator.setDuration(600L);
animator.setInterpolator(new AccelerateDecelerateInterpolator());
animator.start();
invalidate();
}
}
public void onDraw(Canvas canvas, Rect bounds) {
if (animator != null && animator.isRunning()) {
int value = (Integer) animator.getAnimatedValue();
canvas.drawCircle(centerX, centerY, value, paint);
// Invalidate at a 30fps ratio
handler.postDelayed(() -> invalidate()), 1000L / 30);
}
}

69. #11: Path Interpolator
Anima3on
Path path = new Path();
path.moveTo(0, 0);
path.lineTo(0.250f, 0.250f);
path.lineTo(0.500f, -0.500f);
path.lineTo(0.750f, 0.625f);
path.lineTo(0.875f, 0.500f);
path.lineTo(1f, 1f);
ObjectAnimator animator =
ObjectAnimator.ofFloat(bugdroid, View.TRANSLATION_X, 0, 100);
animator.setRepeatCount(ObjectAnimator.INFINITE);
animator.setRepeatMode(ObjectAnimator.REVERSE);
animator.setInterpolator(PathInterpolatorCompat.create(path));
animator.setDuration(2000);
animator.start();

70. #11: Path Interpolator
Anima3on

71. #12: Move a view along a
Path
h"p://stackoverflow.com/ques5ons/6154370/
android-move-object-along-a-path
Path path = new Path();
path.arcTo(new RectF(0, 0, 300, 300), 0, 180); // 1 -> 2
path.quadTo(200, 80, 400, 400); // 2 -> 3
path.lineTo(500f, 300f); // 3 -> 4
path.close(); // 4 -> 1
ObjectAnimator animator =
ObjectAnimator.ofFloat(bugdroid, "x", "y", path);
animator.setRepeatCount(ObjectAnimator.INFINITE);
animator.setInterpolator(new DecelerateInterpolator());
animator.setDuration(7000);
animator.start();

72. #13: Vector Drawables
• M (x,y): Absolute move to (x,y)
• m (x,y): Rela5ve move to (x,y)
• L or l (x,y): Line to (x,y)
• C or c (x1,y1,x2,y2): Curve from (x1,y1) to (x2,y2)
• Q or q (x1,y1,x,y): Quadra5c curve to (x,y) using (x1,y1) as the control point
• Z or z: Close path
h#ps://www.w3.org/TR/SVG/paths.html

73. #13: Vector Drawables

74. #14: Port your app to
Tizen
• HTML5 Canvas api
• Low-Bit Ambient mode
• Burn-in support
• onTimeTick() becomes
window.addEventListener("time
tick", drawWatchContent);

75. Hexawatch
github.com/Nilhcem/hexawatch
• Square / Circular shapes
• Se1ngs app
• Protobuf
• Gear s2 port
• Custom views
• Custom wear frame layout
• Common module

76. From a hoodie to a watch face
nilhcem.com/android-wear/watchfaces-
design
• Android Wear 1 + 2 support
• Square / Circular shapes
• Chin support
• Textures + Xfer modes

77. Conclusion
• Good to be curious
• Improve your skills
• Fun
• Rewarding

78. Android Wear Essen-als
• Twi%er: @Nilhcem
• Slides: slideshare.net/Nilhcem/android-wear-essen:als
• 10mn-watchface: github.com/Nilhcem/the-10mn-watchface
• Hexawatch: github.com/Nilhcem/hexawatch
• Hoodie watch face making-of: nilhcem.com/android-wear/
watchfaces-design
