2. UNIT-3
• Agreement Protocols
• Distributed Resource Management: Issues in
distributed File Systems, Mechanism for
building distributed file systems, Design issues
in Distributed Shared Memory, Algorithm for
Implementation of Distributed Shared
Memory.
3. Agreement Protocols
• A kind of co-operation or unity or accordance among processes.
• As we know that all the nodes in a distributed system are working
together in a cooperation to achieve a common goals. Hence
cooperation among the process is very necessary .
• Agreement protocol is used to ensure that DS is able to achieve the
common goal even after occurrence of various failures in Distributed
system.
• There are some standard agreement problem in DC. We will see
each problem and try to find some protocol or algorithm to solve the
agreement problem.
4.
5. Why Agreement Protocol
• Agreement is always required to achieve a common goal in
distributed system.
• When there are some types of faulty processes present in the
distributed system at that time we need to make sure that
performance of distributed system should not be affected at that
time we implement some agreement protocol (algorithms) ,so that
output of distributed should not be incorrect or should not be
affected.
• To achieve reliability of Distributed system. So, mainly
agreement protocols are used for fault (failure) tolerance in DS
6. Problem which require Agreement
• Leader Election
• Distributed Transaction
• Mutual exclusion
• Any many more ….
7. System Model
Agreement Problems have been studied under
following System Model:
1. ‘n’ processors and at most ‘m’ of the processors
can be faulty.
2. Processors can directly communicate with other
processors by message passing.
3. Receiver knows the identity of the sender.
4. Communication medium is reliable.
8. Model of processor Failures
Processor Can Fail in three modes:
1. Crash Failure : Processor stops and never resumes operation.
2. Send/ Receive Omission : Processor Omits to send/receive
message to some processors
3. Malicious Failure : most dangerous one
(i) Also known as Byzantine Failure.
(ii) Processor may send fictitious values/message to other processes to
confuse them.
(iii) Tough to detect/correct.
9. Classification of Messages in DS
1. Authenticated Messages: Also known as signed
Message. Processor can not forge/change a received
message. Processor can verify the authenticity of the
message. It is easier to reach on an agreement in this
case because faulty processors are capable of doing less
damage.
2. Non-Authenticated Messages: Also known as
Oral Message. Processor can forge/change a received
message and claims to have received it from others.
Processor can not verify the authenticity of the message
in this case.
10. We will find agreement solution in two mode
of communication under various failure
11. Classification of Computation:
1. Synchronous mode:
• Finite message delay.
• This model specify that the process in the system
execute step by step i.e. lockup step manner.
• One step is known as round.
• A process receives messages (1 round), performs a
computation (2 round), and send messages to other
processes (3 round).
• If there is any delay between messages then
computation work will slow down and decrease the
performance of the system.
12. 2. Asynchronous mode:
• Infinite message delay.
• Non lockup step manner.
• The computation at processes does not proceed in
steps.
• A process can send and receive messages and perform
computation at any time without any sequence of
steps.
13. Agreement Problem Types
1. Byzantine Agreement problem.
The Byzantine Agreement problem is a primitive to
the other two problems. So, The other two
Agreement Problems are:
2. The Consensus Problem.
3. The Interactive Consistency Problem.
15. Byzantine General Problem
(Inspired from Byzantine Empire)
There was byzantine empire in middle ages ….there
were some army generals who were protecting the
city. Now all general have to make an agreement or
some negotiation to protect the city . If any general is
found to be traitors they will not be able to protect
the city .hence they have to agree on some common
terms and then only they can protect the byzantine
empire.
Present part of Byzantine Empire is knowns
Turkey (Istanbul).
16.
17. 1. Byzantine Problem in DS
An arbitrarily chosen processor, called the source
processor, broadcasts its initial value to all other
processors.
Agreement: All non-faulty processors should
agree on the same value.
Validity: If the source processor is non-faulty,
then the common agreed upon value by all non-
faulty processors must be same as the initial value
of the source.
18. Termination: Each non-faulty processor must
eventually decide on a value.
• Two Important Points to be remember:
1. If source is faulty then all non- faulty
processes can agree on any common value.
2. Value agreed upon by faulty processors is
irrelevant.
19. Agreement algorithm for No-failure
• Agreement can easily achieved in constant no of
message exchange.
• Both synchronous and asynchronous mode will
always achieve agreement .Because when all
process are working fine then they are eventually
satisfying the property of Distributed system and
with constant no of message exchange we can
achieve i.e. all nodes in a distributed system are
working in a cooperation to achieve some
common goal.
21. Solution for Byzantine Agreement
Problem
Lamport et. al proposed an algorithm for
byzantine agreement problem which is known
as Lamport-Shostak-Pease Algorithm.
• Source Broadcasts its initial value to all other processors.
• Processors send their values to other processors and also
received values from others.
• During Execution faulty processors may confuse by sending
conflicting values.
• However if faulty processors dominate in number, they can
prevent non-faulty processors from reaching an agreement.
• So, the no of faulty processors should not exceed certain
limit.
22. Lamport-Shostak-Pease Algorithm
This algorithm is also known as Oral Message
Algorithm (OM).
• Considering there are ‘n’ processors and ‘m’ faulty
processors.
• Pease showed that in a fully connected network, it is
impossible to reach an agreement if number faulty
processors ‘m’ exceeds (n-1)/3
• i.e. n >= (3m+1)
23. Algorithm is Recursively defined as follows:
• Algorithm OM(0), i.e. (m=0)
Step 1: Source processor sends its values to every
processor.
Step 2: Each processor uses the value it receives from
source (If no value is received default value 0 is used).
24. • Algorithm OM(m), i.e. (m>0)
Step 1: The source processor sends its value to
every processor.
Step 2: If a processor does not receive value it uses
a default value of zero.
Step 3: For each processor Pi, let vi be the value
processor receives from source, then it behaves like
source processor.
Step 4: If for a processor Pi, Vj (j!=i) is the value
received from Pj, the Pi uses the majority value as
agreement value.
25. Byzantine Agreement can not have solution when
among three processors if one processor is faulty.
26. 2. The Consensus Problem
Here all process have some initial value they
broadcast their initial values to all others process
and satisfy the following condition:
Agreement: All non-faulty processes must agree on
same single values.
Validity: if all non faulty processes have the same
initial value , then the agreed value by all the non-
faulty processes must be that same value.
27. Termination: Each non-faulty process must
eventually decide on a value.
• Two Important Points to be remember:
1. If initial value of non-faulty processors are
different then all non-faulty then processors
can agree on any common value.
2. Value agreed upon by faulty processors is
irrelevant.
28. 3. The Interactive Consistency Problem
Every processor broadcasts its initial value to all other processors.
The initial values of the processors may be different . A protocol for
the interactive consistency problem should meet the following
conditions:
Agreement: All non-faulty processes must agree on the same array of
values A[v1 : : : vn].
Validity: If processor Pi is non-faulty and its initial value is vi , then all
non-faulty processes agree on vi as the ith element of the array A. If
process j is faulty, then the non-faulty processes can agree on any
value for A[j].
Termination: Each non-faulty process must eventually decide on the
array A.
29.
30. Metrics to measure performance of
Agreement Protocol
• Time: Time taken to reach an agreement under a
protocol. The time is usually expressed as the
number of rounds needed to reach an agreement.
• Message Traffic: Number of messages exchanged
to reach an agreement.
• Storage Overhead: Amount of information that
need to be stored at processors during execution
of the protocol.
31. • There are some solution that solve agreement problems by
satisfying all condition of agreement problem in case of
synchronous system.
• But in case of asynchronous models , agreement problem are
not solvable. However we can solve agreement problem in
asynchronous System after converting agreement problem in its
weaker version. That means agreement problem are reduce to
some weaker version :
Weaker version of agreement problem are:
1.k-set consensus
2.Approximate consensus
3.Renaming problem
4.Terminating reliable broadcast ( it is a kind of problem which
require consensus.)
32. Applications of Agreement Protocol
1. Clock Synchronization in Distributed Systems:
• Distributed Systems require physical clocks to synchronized
but physical clocks have drift problem. So, they must
periodically resynchronized.
• Such periodically synchronization becomes extremely difficult
if the Byzantine failures are allowed.
• This is due to the fact that faulty processors can report different
clock value to different processors.
• Agreement Protocols may help to reach a common clock value.
33. 2. Atomic Commit in Distributed Database:
• DDBS sites must agree whether to commit or abort the
transaction.
• In first Phase, sites execute their part of a distributed
transaction and broadcast their decisions to all other
sites.
• In Second Phase, each site based on what is received
from other sites in the first phase, decides whether to
commit or abort.
46. Distributed Resource
Management
Issues in distributed File Systems,
Mechanism for building distributed file
systems, Design issues in Distributed Shared
Memory, Algorithm for Implementation of
Distributed Shared Memory.
47. • File System work as the resource management component,
which manages the availability of files in distributed
system.
• A common file system that can be shared by all the
autonomous computers in the system. i.e. files can be stored
at any machine and the computation can be performed at any
machine.
Two important goals :
1. Network transparency – to access files distributed over a network.
Ideally, users do not have to be aware of the location of files to access
them.
2. High Availability - to provide high availability. Users should have the
same easy access to files, irrespective of their physical location.
Distributed File Systems
50. Architecture
• File servers and File clients interconnected by
a communication network.
• Two most important components:
1. Name Server: map logical names to stored
object’s (files, directories) physical location.
2. Cache Manager: perform file caching. Can
present on both servers and clients.
1. Cache on the client deals with network latency
2. Cache on the server deals with disk latency
51. • Typical steps to access data:
1. check client cache, if present, return data.
2. Check local disk, if present, load into local cache,
return data.
3. Send request to file server
4. ...
5. server checks cache, if present, load into client
cache, return data
6. disk read
7. load into server cache
8. load into client cache
9. return data
52. 1. Naming and Transparency
2. Remote file access and Caching
3. Replication and Concurrent file updates
4. Availability
5. Scalability
6. Semantics
Issues in distributed File Systems
56. 3. Concurrent file updates
• Server data is replicated across multiple
machines.
• Need to ensure consistency of files when a file
is updated by multiple clients.
• Changes to a file by one client should not
interfere with the operations of other clients.
57. 4. Availability
• how to keep replicas consistent.
• how to detect inconsistencies among replicas.
• consistency problem may decrease the
availability.
• Replica Management: voting mechanism to
read and write to replica.
58. 5. Scalability
• How to meet the demand of a growing
system?
• The biggest hurdle: consistency issue
59. 6. Semantics
• What a user wants? strict consistency.
• Users can usually tolerate a certain degree of
errors in file handling -- no need to enforce
strict consistency.
60. Mechanism for building Distributed
File Systems
1. Mounting:
A mount mechanism allows the binding
together of different filename spaces to form
a single hierarchically structured name
space.
61.
62. 2. Caching
• Caching is commonly employed in distributed files
systems to reduce delays in the accessing of data.
• In file caching, a copy of data stored at a remote file
server is brought to the client when referenced by
the client.
• Subsequent access to the data is performed locally
at the client, thereby reducing access delays due to
network latency.
• Caching exploits the temporal locality of reference
exhibited by programs.
• The temporal locality of reference refers to the fact
that a file recently accessed is likely to be accessed
again in the near future.
63. 3. Hint
• An alternative approach is used when cached data are not
expected to be completely accurate.
• However, valid cache entries improve performance
substantially without incurring the cost of maintaining cost
consistency.
• The class of applications that can utilize hints are those which
can recover after discovering that the cached data are invalid.
• For example, after the name of a file or directory is mapped to
the physical object, the address of the object can be stored as
a hint in the cache.
• If the address fails to map to the object in the following
attempt, the cached address is purged from the cache.
• The file server consults the name server to determine the
actual location of the file or directory and updates the cache.
64. 4. Bulk Data Transfer
• Transferring data in bulk reduces the protocol
processing overhead at both servers and clients.
• In bulk data transfer, multiple consecutive data
blocks are transferred from servers to clients instead
of just the block referenced by clients.
• Bulk transfers reduce file access overhead through
obtaining a multiple number of blocks with a single
seek; by formatting and transmitting a multiple
number of large packets in a single context switch;
and by reducing the number of acknowledgements
that need to be sent.
65. 5. Encryption
• Encryption is used for enforcing security in
distributed systems.
• In this scheme, two entities wishing to
communicate with each other establish a key for
conversation with the help of an authentication
server.
• It is important to note that the conversation key
is determined by the authentication server, but is
never spent in plain (unencrypted) text to either
of the entities.
66. Distributed Shared Memory
• Idea of distributed shared memory is to provide an environment
where computers support a shared address space that is made by
physically dispersed memories.
• It refers to shared memory paradigm applied to loosely coupled
distributed memory systems. It gives the systems illusion of
physically shared memory.
• Memory mapping manager is responsible for mapping between
local memories and the shared memory address space.
• Any processor can access any memory location in the address
space directly.
• Chief responsibility is to keep the address space coherent at the
times.
67.
68. Architecture
• Each node of the system consist of one or more CPUs
and memory unit.
• Nodes are connected by high speed communication
network.
• Simple message passing system for nodes to exchange
information.
• Main memory of individual nodes is used to cache pieces
of shared memory space.
• Shared memory exist only virtually.
• Memory mapping manager routine maps local memory
to shared virtual memory.
69.
70. • The shared memory model provides a virtual
address space which is shared by all nodes in a
distributed system.
• The basic unit of caching is a memory block.
• Shared memory space is partitioned into blocks.
• Data caching is used to reduce network latency.
• The missing block is migrate from the remote
node to the client process’s node and operating
system maps into the application’s address space.
• Data block keep migrating from one node to
another on demand but no communication is
visible to the user processes.
71. Advantages of DSM(or DSVM)
1. Simpler Abstraction: shields the application
programmers from low level concern.
2. Better portability of distributed application
programs: The access protocol used in case
of DSM is consistent with the way sequential
application access data this allows for a more
natural transition from sequential to
distributed application.
72. 3. Better performance: due to Locality of data,
On demand data moment, Large memory
space as total memory size is the sum of the
memory size of all the nodes in the system.
4. Flexible communication environment
5. On demand migration of data between
processors.
73. Design issues in Distributed Shared
Memory
1. Granularity
2. Structure of Shared memory
3. Memory coherence and access
synchronization
4. Data location and access
5. Replacement strategy
6. Thrashing
7. Heterogeneity
74. 1. Granularity:
• Computation granularity refers to the size of the
sharing unit. It can be a byte, a word, a page or
other type of unit.
• Choosing the right granularity is a major issue in
distributed shared memory because it deals
with the amount of computation done between
synchronization or communication points.
• Other issue is, moving around code and data in
the networks involves latency and overhead from
network protocols.
75. 2. Structure of Shared memory
• Structure refers to the layout of the shared
data in memory.
• Dependent on the type of applications that
the distributed shared memory system is
intended to support.
76. 3. Memory coherence and access
synchronization
• In a DSM system that allows replication of shared data
item, copies of shared data item may simultaneously
be available in the main memories of a number of
nodes.
• To solve the memory coherence problem that deal with
the consistency of a piece of shared data lying in the
main memories of two or more nodes.
• There might be some potential consistency problems
when different processors access, cache and update
the shared single memory space.
77. 4. Data location and access
• To share data in a DSM, should be possible to
locate and retrieve the data accessed by a
user process.
78. 5. Replacement strategy
• If the local memory of a node is full, a cache
miss at that node implies not only a fetch of
accessed data block from a remote node but
also a replacement.
• Data block must be replaced by the new data
block.
79. 6. Thrashing
• Thrashing occurs when a computer's virtual memory
resources are overused, this causes the performance of
the computer to degrade or collapse.
• The problem of thrashing may occur when data item in
the same data block are being updated by multiple
node at the same time.
• Problem may occur with any block size, it is more likely
with larger block size.
80. 7. Heterogeneity
• The DSM system built for homogeneous
system need not address the heterogeneity
issue.
81. • So most the important issues are:
- How to keep track of the location of remote
data
- How to minimize communication overhead
when accessing remote data
- How to access concurrently remote data at
several nodes
82. Algorithm for Implementation of
Distributed Shared Memory
1. The Central Server Algorithm
2. The Migration Algorithm
3. The Read-Replication Algorithm
4. The Full–Replication Algorithm
83. 1. The Central Server Algorithm
• Central server maintains all shared data:
– Read request: returns data item.
– Write request: updates data and returns acknowledgement
message.
84. • Implementation:
– A timeout is used to resend a request if acknowledgment
fails.
– Associated sequence numbers can be used to detect
duplicate write requests
– If an application’s request to access shared data fails
repeatedly, a failure condition is sent to the application
– It is simpler to implement but the central server can become
bottleneck and to overcome this shared data can be
distributed among several servers.
• Issues: performance and reliability.
• Possible solutions:
– Partition shared data between several servers
– Use a mapping function to distribute/locate data
85. 2. The Migration Algorithm
• Every data access request is forwarded to location of data
while in this data is shipped to location of data access request
which allows subsequent access to be performed locally.
• It allows only one node to access a shared data at a time.
• The whole block containing data item migrates instead of
individual item requested.
• This algorithm provides an opportunity to integrate DSM with
virtual memory provided by operating system at individual
nodes.
86. • Advantages: Takes advantage of the locality of
reference.
• To locate a remote data object:
– Use a location server
– Maintain hints at each node
– Broadcast query
• Issues
– Only one node can access a data object at a time
– Thrashing can occur: to minimize it, set minimum
time data object resides at a node
87. • This extends the migration algorithm by replicating data
blocks to multiple nodes and allowing multiple nodes to
have read access or one node to have both read write
access.
• After a write, all copies are invalidated or updated.
• DSM has to keep track of locations of all copies of data
objects.
• Advantage:
The read-replication can lead to substantial
performance improvements if the ratio of reads to
writes is large.
It improves system performance by allowing
multiple nodes to access data concurrently.
3. The Read-Replication Algorithm
88. The write operation in this is expensive as all copies of a shared
block at various nodes will either have to invalidated or updated
with the current value to maintain consistency of shared data
block.
89. • It is an extension of read replication algorithm which
allows multiple nodes to have both read and write
access to shared data blocks.
• Issue: Since many nodes can write shared data
concurrently, the access to shared data must be
controlled to maintain it’s consistency.
4. The Full–Replication Algorithm
90. • Solution: use of gap-free sequencer
All writes sent to sequencer.
all nodes wishing to modify shared data will send
the modification to sequencer which will then
assign a sequence number and multicast the
modification with sequence number to all nodes
that have a copy of shared data item.
Each node performs writes according to
sequence numbers.
A gap in sequence numbers indicates a missing
write request: node asks for retransmission of
missing write requests.
