1) The document discusses integrating digital terrain elevation data (DTED) into GPS navigation to improve height accuracy when fewer than 4 satellites are available.
2) It outlines an algorithm that uses a 4th order polynomial surface fit to DTED data points within the error ellipse of an initial 3-satellite position fix to generate a 4th equation.
3) The GPS measurements and 4th equation are then solved together using least squares to provide an improved position and height estimate, which is checked against the original DTED points for validity.
