3 stage CMOS Amplifier
•Download as DOCX, PDF•
0 likes•103 views
This document summarizes the design of a three stage CMOS operational amplifier including a bias network in a 0.35um CMOS process. The op-amp has specifications including a DC gain greater than 60dB, gain bandwidth greater than 1MHz, phase margin greater than 45 degrees, and a load capacitance of 30pF. The input stage uses a source-coupled pair and folded mirror transistors, the second stage is a common source PMOS gain stage, and the third stage is a class AB push-pull output stage to provide rail-to-rail output swing.
