Azure SQL DB V12 at your service by Pieter Vanhove

•Download as PPTX, PDF•

0 likes•640 views

Microsoft Azure SQL Database came in the picture when nobody was talking about cloud computing. Since that time, Azure SQL Database has known many versions but was rather limited in functionality. Backing up your database was not possible, the size of your database was limited, heap tables were not allowed… Last November, Microsoft reached another milestone by introducing near-complete SQL Server engine compatibility and more premium performance. So, let’s get ready for this new release! I will to take you on a tour around the new Microsoft Azure SQL Database world. You will get an overview of the fundamentals of Microsoft Azure SQL Database administration – What’s new in the latest Update V12 – Azure SQL Database Auditing – Dynamic Data Masking – Row Level Security and many more. After attending this session you will have a good idea which features can be helpful to move your production database to Microsoft Azure SQL Database.

Technology

Azure SQL Database v12
at your (database-as-a) service
Pieter Vanhove
Tweet and win an Ignite 2016 ticket #itproceed

Agenda V12 Overview
• Service Tiers and Performance Levels
• Scale up or down
• Expanded Database Management
Security
• Dynamic Data Masking
• Row-level Security
• Auditing
Monitor and Troubleshoot
• Better Customer Insights
• Alerts and Events
• Backup and Restore

Service Tiers
Basic
• Best suited for a small size database, supporting typically one single active
operation at a given time.
Standard
• The go-to option for most cloud applications, supporting multiple
concurrent queries.
Premium
• Designed for high transactional volume, supporting a large number of
concurrent users and requiring the highest level of business continuity
capabilities.

Overview of the Performance Model
Basic
• DTU = 5
• Max DB Size = 2GB
• 16 600 Trans/hour
Standard
• S0/S1/S2/S3
• DTU = 10 – 100
• Max DB Size = 250 GB
• 5100 Trans/min
Premium
• P1/P2/P3
• DTU = 125 – 1000
• Max DB Size = 500 GB
• 735 Trans/sec
http://azure.microsoft.com/en-in/documentation/articles/sql-database-service-tiers/

Upgrade to a
Higher Service Tier
Downgrade to a
Lower Service Tier
Changing
Performance Level
Scale up or down

Impact of Database Changes
3 x (5 minutes + database size / 150 MB/minute)

Expanded Database Management
Users in contained
databases
Table partitioning
Larger
transactions
Online index build
and rebuild
CHECKPOINT
support
ALTER TABLE
enhancement
TRUNCATE TABLE
enhancement
More options on
ALTER DATABASE
More DBCC
commands
Window functions
in Transact-SQL
queries
Change tracking
for data
Table as a heap

Dynamic data
masking policy
Privileged
logins
Masking rules
Masking by
Masking
functions

RLS – How it works
Data selected
from a table
Security
predicate
filter
Inline table
valued
function
Enforced by a
security
policy
Restrict the
rows that
may be
viewed

Auditing
• Maintain regulatory compliance
• Understand database activity
• Gain insight into discrepancies and anomalies

Retain an audit trail
of selected events.
Report on
database activity
Analyze reports

Better Customer Insights
DMVs
•Several DMVs are added in V12
Change
tracking
•V12 fully supports change tracking.
Columnstore
indexes
•A columnstore index improves system performance
for data warehouses

Alerts and events
Define
rule
Specify
threshold
Threshold
violated
Alert rule
active
Registers
an alert
Send E-
mail
(optional)

SQL Database Alert Rules
Blocked by
Firewall
Failed
Connections
Successful
Connections
CPU
Percentage
Deadlocks
DTU
Percentage
Log IO
Percentage
Data IO
Percentage
Total
Database Size

Backup & Restore
Service Tier Geo-Restore
Self-Service
Point in Time
Restore
Backup
Retention Period
Restore a
Deleted
Database
Basic Supported Supported 7 days Supported
Standard Supported Supported 14 days Supported
Premium Supported Supported 35 days Supported
Web Not supported Not supported n/a n/a
Business Not supported Not supported n/a n/a

Automatic Backup
Creates backups of every active
database
Every hour a backup is taken
Geo-replicated
Every 5 minutes a transaction Log
backup is taken
200% of your maximum provisioned
database storage of backup storage at
no additional cost

Point-in-Time Restore
Designed to recover a database to a
specific point in time
Creates a new database with the same
service tier
The time taken to complete a restore
depends on the size of the database and
the length of the log chain
Restoring a deleted database
Geo-Restore as disaster recovery option

And win a Lumia 635
Feedback form will be sent to you by email
Give me feedback

Follow Technet Belgium
@technetbelux
Subscribe to the TechNet newsletter
aka.ms/benews
Be the first to know
