These slides are part of the ESTIEM Lean Six Sigma Green Belt course which also includes 13hr of video by Gregory H. Watson. For more info about the ESTIEM Lean Six Sigma Green Belt course visit https://internal.estiem.org/leansixsigma

1. European Students of Industrial Engineering and Management
www.estiem.org
Exploratory Data Analysis (EDA)
for publication
1

2. European Students of Industrial Engineering and Management
www.estiem.org
It’s Feedback time!
2
Persons giving feedback
Link to the feedback form
(can be found on Schoology and
WhatsApp)
Instructor to give feedback toPersons giving feedback
INSTRUCTOR 1
INSTRUCTOR 2

3. European Students of Industrial Engineering and Management
www.estiem.org
3
What do you remember about DMAIC?
Project
Charter
SIPOC
EDA
VA vs.
NVA
DEFINE

4. European Students of Industrial Engineering and Management
www.estiem.org
4
Agenda
▪ What is Minitab?
▪ What is EDA?
▪ 4 tools used in EDA
▪ Practice of interpreting the charts
▪ Making an analysis with Minitab

5. European Students of Industrial Engineering and Management
www.estiem.org
5

6. European Students of Industrial Engineering and Management
www.estiem.org
6
What is Minitab?
Minitab is a lot like Excel…
▪ Statistical program for data
analysis
▪ Holds data in cells
… but also rather different!
▪ Not possible to use formulas in cells.
The cells in Minitab merely hold
values.
▪ Additional tools for statistical analysis
compared to excel e.g.
▪ I-chart
▪ ANOVA
▪ Control chart
▪ Capability analyses
● Certain things are easier to do in Excel and other things in Minitab
● Used together, they are powerful!

7. European Students of Industrial Engineering and Management
www.estiem.org
7
How to import data into Minitab
▪ As a rule of thumb, the data should be prepared in Excel
▪ Do all cell-based calculations in Excel
▪ Organize the data so that one column holds data related to one variable
▪ The first row of the data column should be the label/title of the column
▪ Simply copy - paste the data from Excel cells to Minitab cells
▪ The import data - function can also be used but copying is easier!

8. European Students of Industrial Engineering and Management
www.estiem.org
8
How to do simple analyses with Minitab?
Most of the statistical tools can
be found under Stat and Graph

9. European Students of Industrial Engineering and Management
www.estiem.org
9
What is EDA?

10. European Students of Industrial Engineering and Management
www.estiem.org
10
What is Exploratory Data Analysis?
“The purpose of Exploratory Data Analysis (is) to rapidly investigate the
performance of a process and determine quickly where the
improvement effort should be focused for further action.”

11. European Students of Industrial Engineering and Management
www.estiem.org
11
What is Exploratory Data Analysis?
Exploring the current
data about the process
by making many charts
Where should the drill
down focus on?
“The purpose of Exploratory Data Analysis (is) to rapidly investigate the
performance of a process and determine quickly where the
improvement effort should be focused for further action.”

12. European Students of Industrial Engineering and Management
www.estiem.org
12
EDA can be used in different phases of
DMAIC
Define
Focuses direction
Get first insights
of the data
Measure
Identify & quantify
rational subgroups
Analyze
Support Prioritization

13. European Students of Industrial Engineering and Management
www.estiem.org
13
Different types of Data Analysis
Exploratory
▪ Finding the right questions
▪ What can I try easily?
▪ How do I study what’s going
on in here?
▪ “An attitude AND a flexibility
AND some graphs” - Tukey
Confirmatory
▪ Answering well formulated
questions
▪ Confirming hypotheses
▪ Conducting well planned
experiments
▪ Statistical hypothesis testing
13

14. European Students of Industrial Engineering and Management
www.estiem.org
14
Today we talk about…

15. European Students of Industrial Engineering and Management
www.estiem.org
15
CATAPULT INC

16. European Students of Industrial Engineering and Management
www.estiem.org
16
First, let’s remember some basic definitions
• Average = Mean = Sum / N
• Median = The middle value
• Mode = The most common value
0
5
10
15
20
25
1 2 3 4 5
Grades
Mean = 3,29
Median = 3 Mode = 4

17. European Students of Industrial Engineering and Management
www.estiem.org
17
I-chart
Pareto
Process
Capability
Analysis
Boxplot

18. European Students of Industrial Engineering and Management
www.estiem.org
18
The four tools each have their own strengths
in understanding the process performance
I-chart
Capability
Analysis
Pareto chart
Boxplot
Show a time sequence – were there time based
differences?
Performance of the process against customer
requirement or target for the process
Prioritize e.g. the defects/focus areas
Differences between the rational subgroups

19. European Students of Industrial Engineering and Management
www.estiem.org
19
The four tools each have their own strengths
in understanding the process performance
I-chart
Capability
Analysis
Pareto chart
Boxplot
The Best of the Best and
The Worst of the Worst
Flaw of averages
I chart with stages

20. European Students of Industrial Engineering and Management
www.estiem.org
20
I-chart – How to read?
Mean Control
Limits
Special
Cause of
Variation
Time /
observation
number
Control
Limits

21. European Students of Industrial Engineering and Management
www.estiem.org
21
I-chart – How are control limits calculated?
Control
Limits
Control
Limits
+/- 3 std

22. European Students of Industrial Engineering and Management
www.estiem.org
22
Let’s now, try to understand why
the daily output differs in a
production line

23. European Students of Industrial Engineering and Management
www.estiem.org
23
0
20
40
60
80
100
120
Daily output per Machine
(average)
1 2 3 4 5 6 107 8 9 1112
The daily outputs per machine for a different
process, where would you focus your inquiry?

24. European Students of Industrial Engineering and Management
www.estiem.org
24
0
20
40
60
80
100
120
Daily output per Machine
(average)
1 2 3 4 5 6 107 8 9 1112
Looking at the variation reveals new aspects,
where would you focus now?

25. European Students of Industrial Engineering and Management
www.estiem.org
25
I-Chart with stages – How to read?
(Can be four different I-Charts)

26. European Students of Industrial Engineering and Management
www.estiem.org
26
BOB’s and WOW’s?
Where would you focus your inquiry?

27. European Students of Industrial Engineering and Management
www.estiem.org
27
We rely on averages, which hide the true
improvement levers

28. European Students of Industrial Engineering and Management
www.estiem.org
28
The four tools each have their own strengths
in understanding the process performance
I-chart
Capability
Analysis
Pareto chart
Boxplot
Settings of a machines
”Nuts and bolts”
Difference between machines
”Nuts and bolts”
Difference betweet control and
specification limits

29. European Students of Industrial Engineering and Management
www.estiem.org
29
Remember the bolts…
Bolt needs to be exact size in order to fit the nut
• Above 605 → doesn’t fit in
• Below 595 → doesn’t hold tight

30. European Students of Industrial Engineering and Management
www.estiem.org
30
Which settings is the best for the machine?

31. European Students of Industrial Engineering and Management
www.estiem.org
31
Which machine is the best one?
Some numbers would help on interpreting the differences, right?

32. European Students of Industrial Engineering and Management
www.estiem.org
32
So, which setting is better?
Cp Cpk
0.5 0.25
Cp Cpk
0.5 0.49

33. European Students of Industrial Engineering and Management
www.estiem.org
33
How is process capability calculated?
Variation of process respect to
specification limits
Variation of process respect to
the closest specification limit

34. European Students of Industrial Engineering and Management
www.estiem.org
34
How is process capability calculated?
Cp Cpk
1.14 0.78

35. European Students of Industrial Engineering and Management
www.estiem.org
35
What is the difference between
a control limit and a specification limit?

36. European Students of Industrial Engineering and Management
www.estiem.org
36
Now another of the bolt production lines
with the following specs:
The size must be between 650-680

37. European Students of Industrial Engineering and Management
www.estiem.org
37
What do you think about this process?
Capability analysis of bolt processLSL
650
USL
680
Mean
658,4
N
500
StDev
11.6
Cp
0,43
Cpk
0,24

38. European Students of Industrial Engineering and Management
www.estiem.org
38
Let’s think next of the call center of Catapult
Inc
Your task is to assess the process
The goal is 200 calls per day per person
Discuss, how the process is doing?

39. European Students of Industrial Engineering and Management
www.estiem.org
39
How is the person in our call center doing?
LSL
205
USL
-
Mean
213.7
N
193
StDev
34
Cp
Not calculated
USL is not set
Cpk
0.1

40. European Students of Industrial Engineering and Management
www.estiem.org
40
The four tools each have their own strengths
in understanding the process performance
I-chart
Capability
Analysis
Pareto chart
Boxplot
Production process A
Prioritizing defects
Support function A
Prioritizing improvement opportunities

41. European Students of Industrial Engineering and Management
www.estiem.org
41
What is the Pareto principle?

42. European Students of Industrial Engineering and Management
www.estiem.org
42
80%
of issues
are caused by
20%
of factors

43. European Students of Industrial Engineering and Management
www.estiem.org
43
First, a production center has
identified the reasons for customer
claims in one of the products
Let’s interpret the pareto chart

44. European Students of Industrial Engineering and Management
www.estiem.org
44
67% of defects are caused by two defects
Cumulative count
Possible defects

45. European Students of Industrial Engineering and Management
www.estiem.org
45
Next up: How the pareto chart can be
used to focus the project to most
important areas?

46. European Students of Industrial Engineering and Management
www.estiem.org
46
Which customer groups are the biggest?
To which ones would you focus your inquiry?

47. European Students of Industrial Engineering and Management
www.estiem.org
47
The four tools each have their own strengths
in understanding the process performance
I-chart
Capability
Analysis
Pareto chart
Boxplot
Reading a boxplot
Different process steps
Subgroups

48. European Students of Industrial Engineering and Management
www.estiem.org
48
What is a rational subgroup?

49. European Students of Industrial Engineering and Management
www.estiem.org
49
Some logical group, which might have an effect on
the conditions of the process

50. European Students of Industrial Engineering and Management
www.estiem.org
50
Items in a rational subgroup
are similar within the group
but differ between the groups
E.g. materials from Supplier A form a rational
subgroup, which might have different attributes as
the same materials produced by Supplier B.

51. European Students of Industrial Engineering and Management
www.estiem.org
51
Before we create a boxplot, let’s use this thinking
model on how to approach the data analysis tasks
Identify the
rational
subgroups
Choose the most
important
subgroups
Observe if
differences exist

52. European Students of Industrial Engineering and Management
www.estiem.org
52
Boxplot - how to read?
25% of data here
25% of data here
50% of data here
x
x
Outliers*
Outliers*
Median
* 1,5 times the size of the box above or
below the box

53. European Students of Industrial Engineering and Management
www.estiem.org
53
Different view to data with boxplot
25% of data
25% of data
50% of data
Median =
Mean =
Data set 1
Data set 1
Can be added to the
graph in Minitab
from options

54. European Students of Industrial Engineering and Management
www.estiem.org
54
First, a production process where you are
interested in comparing the output of 4
workers in the process
What is different between the workers?

55. European Students of Industrial Engineering and Management
www.estiem.org
55
Boxplots can describe the difference
between workers in the process

56. European Students of Industrial Engineering and Management
www.estiem.org
56
The four tools each have their own strengths
in understanding the process performance
I-chart
Capability
Analysis
Pareto chart
Boxplot
Show a time sequence – were there time based
differences?
Performance of the process against customer
requirement or target for the process
Prioritize e.g. the defects/focus areas
Differences between the rational subgroups

57. European Students of Industrial Engineering and Management
www.estiem.org
57
I-chart
Pareto
Process
Capability
Analysis
Boxplot

58. European Students of Industrial Engineering and Management
www.estiem.org
58
Time for a thinking exercise!
We’re investigating an invoicing process with 6
persons.
The process daily output should be 1200 per
day (200/person).

59. European Students of Industrial Engineering and Management
www.estiem.org
59
First task, you would like to
understand how well the target of
1200 daily invoices is reached.
Which graph would you use?

60. European Students of Industrial Engineering and Management
www.estiem.org
60
Next, you’re interested in seeing how the
invoicing has changed over time
Which graph would you use?

61. European Students of Industrial Engineering and Management
www.estiem.org
61
Third thing, you would like to understand
the differences between the 6 persons
doing invoicing
Which graph would you use?

62. European Students of Industrial Engineering and Management
www.estiem.org
62
Lastly, you would like to know which
invoices are the most common, i.e. where
you should focus your inquiry
Which graph would you use?

63. European Students of Industrial Engineering and Management
www.estiem.org
63

64. European Students of Industrial Engineering and Management
www.estiem.org
64
Time to work…

65. European Students of Industrial Engineering and Management
www.estiem.org
65
SPONSOR MESSAGE
65

66. European Students of Industrial Engineering and Management
www.estiem.org
It’s Feedback time!
66
Persons giving feedback
Link to the feedback form
(can be found on Schoology and
WhatsApp)
Instructor to give feedback toPersons giving feedback
INSTRUCTOR 1
INSTRUCTOR 2

67. European Students of Industrial Engineering and Management
www.estiem.org
67
It’s Feedback time!
Feedback box

68. European Students of Industrial Engineering and Management
www.estiem.org
68
Usage license of the
materials
https://creativecommons.org/licenses/by-nc/4.0/legalcode
Contact leansixsigma@estiem.org
for commercial usage of the materials
Materials of the trainings have been created based on the materials provided by
ESTIEM Summer Academy Professor Gregory H. Watson
