04 - Risk analysis - ESTIEM Lean Six Sigma Green Belt Course
1. European Students of Industrial Engineering and Management
www.estiem.org
Risk analysis
for publication
1
2. European Students of Industrial Engineering and Management
www.estiem.org
It’s Feedback time!
2
Persons giving feedback
Link to the feedback form
(can be found on Schoology and
WhatsApp)
Instructor to give feedback toPersons giving feedback
INSTRUCTOR 1
INSTRUCTOR 2
3. European Students of Industrial Engineering and Management
www.estiem.org
What is the Y
measure?
The training today will comprise three phases
Fishbone
Potential
Problem
Analysis (PPA)
1
2
3
3
4. European Students of Industrial Engineering and Management
www.estiem.org
What do you remember about DMAIC?
Project
Charter
SIPOC
EDA
VA vs.
NVA
DEFINE
Deployment
Diagram
Identifying the
Bottleneck
MEASURE
4
5. European Students of Industrial Engineering and Management
www.estiem.org
Fishbone Diagram and PPA as part of the
Measure phase
Fishbone
Diagram
Deployment
Diagram
MEASURE
PPA
Measure, Analyze
& Improve
5
Identifying the
Bottleneck
6. European Students of Industrial Engineering and Management
www.estiem.org
What methods will we use today?
Defining the
Y measure
Fishbone diagram
Potential Problem
Analysis
6
7. European Students of Industrial Engineering and Management
www.estiem.org
What is the definition of
the Y measure ?
7
8. European Students of Industrial Engineering and Management
www.estiem.org
Y = f(x)
8
9. European Students of Industrial Engineering and Management
www.estiem.org
Characteristics of a good catapult
Shoots fast
Low
Variation
Hits the
target
9
10. European Students of Industrial Engineering and Management
www.estiem.org
Why is it important to understand what
is the Y measure of the process?
Why is it important to understand what
the x measures of the process are?
10
11. European Students of Industrial Engineering and Management
www.estiem.org
Next method Fishbone diagram!
Defining the
Y measure
Fishbone diagram
Potential Problem
Analysis
11
12. European Students of Industrial Engineering and Management
www.estiem.org
What is the purpose of doing a
Fishbone diagram?
It serves as a long list of
possible factors
(x’s of the process)
affecting the Y
13. European Students of Industrial Engineering and Management
www.estiem.org
Fishbone Diagram
13
Desired
output
14. European Students of Industrial Engineering and Management
www.estiem.org
Have you heard of the
7M categories?
Can you remember them all?
14
15. European Students of Industrial Engineering and Management
www.estiem.org
7M categories
▪ Measurements
▪ Material
▪ Methods
▪ Manpower
▪ Machinery
▪ Mother Nature
▪ Money
15
16. European Students of Industrial Engineering and Management
www.estiem.org
Fishbone Diagram
16
Materials Methods
Machinery
Mother
Nature
Measurement
Manpower
Money
Desired
output
17. European Students of Industrial Engineering and Management
www.estiem.org
Can you think of other methods
to list the factors that could
possibly affect the Y?
17
18. European Students of Industrial Engineering and Management
www.estiem.org
Time to work…
18
19. European Students of Industrial Engineering and Management
www.estiem.org
SPONSOR MESSAGE
19
20. European Students of Industrial Engineering and Management
www.estiem.org
Sometimes the items are labelled as
controllable (C) or noise (N)
What do these terms mean?
20
21. European Students of Industrial Engineering and Management
www.estiem.org
Sometimes the items are labelled as
controllable (C) or noise (N)
Why do we distinguish between the two?
21
22. European Students of Industrial Engineering and Management
www.estiem.org
SPONSOR MESSAGE
22
23. European Students of Industrial Engineering and Management
www.estiem.org
In which phase of the DMAIC process
should you use the Fishbone diagram?
23
24. European Students of Industrial Engineering and Management
www.estiem.org
Fishbone is often created in the Measure phase
but used throughout the DMAIC.
1) When suck – Helps to find a new approach.
2) New things can come up later in the DMAIC
- Add them
24
25. European Students of Industrial Engineering and Management
www.estiem.org
Ask why 5 or as many times as needed, to
identify the possible root
Are you familiar with 5 why’s technique?
25
26. European Students of Industrial Engineering and Management
www.estiem.org
Let’s think about the Method 5 Why’s
26
It is to warm when distributed
Thermostat is broken
Cooling is varying
Not enough maintenance
Ice cream melts too fast
Cooling has to be adjusted manually
No maintenance planned
Why?
Why?
Why?
Why?
Why?
Why?
This causes ?
This causes ?
This causes ?
This causes ?
This causes ?
This causes ?
27. European Students of Industrial Engineering and Management
www.estiem.org
Next we’ll jump to PPA
Defining the
Y measure
Fishbone diagram
Potential Problem
Analysis
27
28. European Students of Industrial Engineering and Management
www.estiem.org
Which tools you know can be helpful to
understand the potential risks?
Deployment Diagram
Fishbone
Potential Problem Analysis
(PPA)
EDA
28
29. European Students of Industrial Engineering and Management
www.estiem.org
Often the different risks are linked – there is
often one risk that causes several others
29
Risk / Problem
Likely causes Effects
30. European Students of Industrial Engineering and Management
www.estiem.org
Have you heard about FMEA
(Failure Mode Effective Analysis)?
FMEA is a widely used methodology for
risk analysis that was developed in the
1950s
30
31. European Students of Industrial Engineering and Management
www.estiem.org
In FMEA Risk Priority Number can be calculated
Failure Mode Severity Occurrence Detection RPN
A 4 5 10 200
B 4 8 2 64
C 9 2 1 18
0 1 2 3 4 5 6 7 8 9 10
10
9
8
7
6
5
4
3
2
1
0
SEVERITY
O
C
C
U
R
R
A
N
C
E
B
C
Risk Priority Number (RPN) = S * O * D
Which failure mode has
the biggest impact?
A
31
32. European Students of Industrial Engineering and Management
www.estiem.org
In the ESTIEM Lean Six Sigma Green Belt
course we teach the Potential Problem
Analysis which is a developed version of the
FMEA
32
33. European Students of Industrial Engineering and Management
www.estiem.org
PLAN/
ACTIONS/TA
SKS
PROBLEMS EFFECTS
LIKELY
CAUSES
SEV OCC
PREVENTIVE
ACTIONS
CONTINGENT
ACTIONS
TRIGGERS FOR
CONTINGENT
33
Potential Problem Analysis (PPA)
34. European Students of Industrial Engineering and Management
www.estiem.org
PLAN/
ACTIONS/T
ASKS
PROBLEMS EFFECTS
LIKELY
CAUSES
SEV OCC
PREVENTIVE
ACTIONS
CONTINGENT
ACTIONS
TRIGGERS FOR
CONTINGENT
34
Potential Problem Analysis (PPA)
We are going to focus on this part now
35. European Students of Industrial Engineering and Management
www.estiem.org
An example of filling PPA
35
Plan / Action
/ Task
Problem Effects likely causes
Pulling the
catapult arm
Finger slips
Ball does not
fly as long as
it could
Wet finger
Shaking
hands
36. European Students of Industrial Engineering and Management
www.estiem.org
Time to work…
36
37. European Students of Industrial Engineering and Management
www.estiem.org
SPONSOR MESSAGE
37
38. European Students of Industrial Engineering and Management
www.estiem.org
Did you find problems linked
to each other?
38
39. European Students of Industrial Engineering and Management
www.estiem.org
PLAN/
ACTIONS/T
ASKS
POTENTIAL
PROBLEMS
EFFECTS
LIKELY
CAUSES
SEV OCC
Potential Problem Analysis (PPA)
39
40. European Students of Industrial Engineering and Management
www.estiem.org
Risks are often categorized from 1-10
(10 highest)
How would categorize (1-10) the risk:
The catapult is instable
40
41. European Students of Industrial Engineering and Management
www.estiem.org
Don’t start by voting on the number values…
41
Define the scale
Fill in the
risk values
Prioritize the
risks
42. European Students of Industrial Engineering and Management
www.estiem.org
If possible, use data!
42
43. European Students of Industrial Engineering and Management
www.estiem.org
Example of the severity table
43
44. European Students of Industrial Engineering and Management
www.estiem.org
Example of an occurrence table
44
45. European Students of Industrial Engineering and Management
www.estiem.org
Matrix can be helpful to visualize the prioritizing
process for risk
Severity
Occurrence
45
46. European Students of Industrial Engineering and Management
www.estiem.org
Excel is a good tool to create a PPA
Potential problem Effect Likely causes Severity Occurance
46
47. European Students of Industrial Engineering and Management
www.estiem.org
Time to work…
47
48. European Students of Industrial Engineering and Management
www.estiem.org
SPONSOR MESSAGE
48
49. European Students of Industrial Engineering and Management
www.estiem.org
PLAN/
ACTIONS/T
ASKS
POTENTIAL
PROBLEMS
EFFECTS
LIKELY
CAUSES
SEV OCC
PREVENTIVE
ACTIONS
CONTINGENT
ACTIONS
TRIGGERS FOR
CONTINGENT
ACTIONS
Potential Problem Analysis (PPA)
49
50. European Students of Industrial Engineering and Management
www.estiem.org
What is the difference between?
1) Preventive action
2) Contingent action
3) Trigger for contingent action
50
51. European Students of Industrial Engineering and Management
www.estiem.org
An example of the items in the case of a
burning house
51
Preventive Trigger Contingent
No open fire in
house
Hear fire
alarm
Fire
extinguisher
52. European Students of Industrial Engineering and Management
www.estiem.org
Time to work…
52
53. European Students of Industrial Engineering and Management
www.estiem.org
SPONSOR MESSAGE
53
54. European Students of Industrial Engineering and Management
www.estiem.org
Question 1/2:
Which other tools can link to the
creation of a PPA?
54
55. European Students of Industrial Engineering and Management
www.estiem.org
Question 2/2:
How should the risks be prioritised, and
why is it important to follow that process?
55
56. European Students of Industrial Engineering and Management
www.estiem.org
PPA can be started in Measure but continues
throughout Analyse, Improve & Control
Measure Analyze Improve
Potential Problem
Likely Causes
Effects
SEVERITY
OCCURANCEAction
Trigger for
contingent action
Contingent Action
Preventive Action
Need for
data!
56
57. European Students of Industrial Engineering and Management
www.estiem.org
Time for reflection and
questions
57
58. European Students of Industrial Engineering and Management
www.estiem.org
It’s Feedback time!
58
Persons giving feedback
Link to the feedback form
(can be found on Schoology and
WhatsApp)
Instructor to give feedback toPersons giving feedback
INSTRUCTOR 1
INSTRUCTOR 2
59. European Students of Industrial Engineering and Management
www.estiem.org
Usage license of the
materials
https://creativecommons.org/licenses/by-nc/4.0/legalcode
Contact leansixsigma@estiem.org
for commercial usage of the materials
Materials of the trainings have been created based on the materials provided by
ESTIEM Summer Academy Professor Gregory H. Watson
