UI Testing - Selenium? Rich-Clients? Containers? (SwanseaCon 2018)

UI TestingUI Testing
Selenium? Rich-Clients? Containers?Selenium? Rich-Clients? Containers?
, /Tobias Schneck Loodse GmbH ConSol Software GmbH

During the UI development phase ...During the UI development phase ...

Yeah - release 1.0 is out!Yeah - release 1.0 is out!

Writing first web UI tests!Writing first web UI tests!
Sahi OS Selenium TestCafe

First Selenium TestFirst Selenium Test
public class CitrusHtmSeleniumTest {
private static final String CITRUS_URL = "http://www.citrusframework.org/";
private WebDriver driver;
private CustomSeleniumDsl dsl;
@BeforeMethod
public void setUp() {
driver = new ChromeDriver();
dsl = new CustomSeleniumDsl((JavascriptExecutor) driver);
}
@Test
public void testCitrusHtmlContent() throws Exception {
driver.get(CITRUS_URL);
//find Heading
WebElement heading1 = driver.findElement(By.cssSelector("p.first"));
dsl.highlightElement(heading1);
assertEquals(heading1.getText(), "Citrus IntegrationnTesting");
assertTrue(heading1.isDisplayed());
//validate HTML content
WebElement heading2 = driver.findElement(By.tagName("h1"));
dsl.highlightElement(heading2);
assertEquals(heading2.getText(), "Integration challenge");
}
@AfterMethod
public void tearDown() { driver.close();}
}

Next stepNext step ??
Make this things perfect!Make this things perfect!

Rewrite all of our tests?Rewrite all of our tests?
Validate the documentation PDF?Validate the documentation PDF?
Test the rich-client implementation as well?Test the rich-client implementation as well?
Where to run the test?Where to run the test?

Keep current tests
Use same codebase
Keep it simple

Add Maven DependenciesAdd Maven Dependencies
<dependencies>

<dependency>
<groupid>org.sakuli</groupid>
<artifactid>sakuli-selenium-setup</artifactid>
<version>1.3.0-247-sakuli-se-SNAPSHOT</version>
<scope>test</scope>
</dependency>
</dependencies>

<repository>
<id>labs-consol</id>
<name>ConSol Labs Repository</name>
<url>http://labs.consol.de/maven/repository</url>
<snapshots>
<enabled>false</enabled>
</snapshots>
<releases>
<enabled>true</enabled>
</releases>
</repository>
<repository>
<id>labs-consol-snapshots</id>
<name>ConSol Labs Snapshot-Repository</name>
<url>http://labs.consol.de/maven/snapshots-repository</url>
<snapshots>
</snapshots>
<releases>
</releases>
</repository>

Use the Sakuli AnnotationsUse the Sakuli Annotations
@Listeners(SakuliSeTest.class)
public class BasicSakuliSeTest {
private static final String PDF_EDITOR_NAME = "masterpdfeditor4";
protected WebDriver driver;
protected Region screen;
protected Environment env;
protected SeTestCaseAction tcAction;
private Application pdfEditor;
@BeforeMethod
public void setUp() throws Exception {
driver = getSeleniumDriver();
screen = new Region();
env = new Environment();
tcAction = new SeTestCaseAction();
}
@AfterMethod(alwaysRun = true)
public void tearDown() throws Exception {
if (driver != null)
driver.close();
}
private Application openPDF(String pdfFilePath) {
return pdfEditor = new Application(PDF_EDITOR_NAME + " "" + pdfFilePath + """).open();
}
//....
}

Use the Sakuli AnnotationsUse the Sakuli Annotations
public class GitHubSakuliSeExampleTest extends AbstractSakuliSeTest {
private String SAKULI_URL = "https://github.com/ConSol/sakuli/blob/master/README.adoc";
@Test
@SakuliTestCase(additionalImagePaths = "/common_pics")
public void test1() throws Exception {
//your test code
driver.get(SAKULI_URL);
screen.highlight(5);
screen.find("sakuli_logo.png").highlight();
}
@Test
@SakuliTestCase(
testCaseName = "mysecondtest",
warningTime = 15, criticalTime = 25,
additionalImagePaths = "/common_pics")
public void test2() throws Exception {
//your test code
driver.get(SAKULI_URL);
screen.highlight(5);
screen.type(Key.END).find("github_logo.png").highlight();
}
}

Generate PDF file
Open it in a native PDF viewer
Validate the content

Test DefinitionTest Definition (Selenium only)(Selenium only)
@Test
@SakuliTestCase
public void testCitrusHtmlContent() throws Exception {
testCitrusContent("HTML");
//VALIDATE HTML content
WebElement heading = driver.findElement(
By.cssSelector("#citrus-framework--reference-documentation-"));
dsl.highlightElement(heading);
assertEquals(heading.getText(), "Citrus Framework - Reference Documentation");
assertTrue(heading.isDisplayed());
//VALIDATE PDF ???
}
public void testCitrusContent(String dest) throws Exception {
searchHeading();
WebElement docuLink = driver.findElement(By.partialLinkText("Documentation"));
dsl.highlightElement(docuLink);
assertTrue(docuLink.isDisplayed());
docuLink.click();
WebElement userGuideLink = driver.findElement(By.partialLinkText("User Guide"));
dsl.highlightElement(userGuideLink);
assertTrue(userGuideLink.isDisplayed());
userGuideLink.click();
WebElement htmlUserGuideLink = driver.findElement(By.partialLinkText(dest));
dsl.highlightElement(htmlUserGuideLink);
assertTrue(htmlUserGuideLink.isDisplayed());
htmlUserGuideLink.click();
}

Test DefinitionTest Definition (Selenium + Sakuli SE)(Selenium + Sakuli SE)
@Test
@SakuliTestCase(additionalImagePaths = "citrus_pics")
public void testCitrusPdfContent() throws Exception {
//opens PDF download page and click download
testCitrusContent("PDF");
screen.find("reload_button.png").highlight();
scroll( //search citrus logo on PDF
() -> screen.exists("pdf_citrus_title.png", 1),
//scroll action
() -> env.type(Key.DOWN).type(Key.DOWN).type(Key.DOWN).type(Key.DOWN),
//times to try
10
);
//navigate over bookmark menu of PDF viewer
screen.find("reload_button.png")
.below(40).highlight()
.mouseMove();
screen.find("bookmark_button.png").highlight().click();
screen.find("bookmark_entry.png").highlight().click();
screen.find("test_case_pdf_heading.png").highlight().click();
//scroll until the expected diagram is visible
scroll(() -> screen.exists("test_case_diagram.png", 1),
10
);
}

Using Java power for UI testing!Using Java power for UI testing!
//...
scroll( //search for logo
() -> screen.exists("citrus_fruit.png", 1),
//scroll action
//times to try
10
);
//...
public void scroll(Supplier<Region> check, Supplier doScroll, int times) throws SakuliException {
for (int i = 1; !Optional.ofNullable(check.get()).isPresent() && i <= times; i++) {
Logger.logInfo("Scroll page (" + i + ")");
doScroll.get();
}
Optional.ofNullable(check.get()).orElseThrow(() ->
new SakuliException("Cannot find region by scrooling!")).highlight();
}

Make an order at the web client
Trigger the reporting function in the rich client
Validate the reported count of produces orders

Control Web and Rich ClientsControl Web and Rich Clients
@Test
@SakuliTestCase
public void testWebOrderToReportClient() throws Exception {
driver.get(TEST_URL);
WebElement heading1 = driver.findElement(By.name("Cookie Bakery Application"));
WebElement order = driver.findElement(By.cssSelector("button blueberry-order"));
assertTrue(order.isDisplayed());
for (int i = 0; i < 20; i++) {
LOGGER.info("place blueberry order " + i);
order.click();
}
//open native client application over $PATH
reportClient = new Application("baker-report-client").open();
Region reportClientRegion = reportClient.getRegion();
//generate the report
reportClientRegion.type("r", Key.ALT); //type ALT + r to open the report view
reportClientRegion.find("get-daily-report-button").click();
reportClientRegion.waitForImage("report-header", 10);
try {
reportClientRegion.find("blueberry_muffin_logo");
reportClientRegion.find("report_blueberry")
.below(100)
.find("report_value_20");
} catch (Exception e) {
//useful for custom error messaten
throw new SakuliException("Validation of the report client failed"
+ " - no muffins produced?");
}
}

Rich Client Gnome EditorRich Client Gnome Editor
@Test
@SakuliTestCase(warningTime = 50, criticalTime = 60)
public void testEditorOpensReadMe() throws Exception {
checkEnvironment();
gedit.open();
// shows fluent API and how sub regions can be used
final Region geditAnchor = screen.waitForImage("gedit", 5)
.highlight()
.click();
// move focus mouse pointer
geditAnchor.below(100).highlight().mouseMove();
// use already known region
final Region otherDocument = geditAnchor
// great larger search region
.below(200).setW(300).highlight()
.waitForImage("search", 20).highlight()
.click()
.type("Hello Guys!")
// base region of "search" button grows 400px
.grow(400, 400).highlight(2)
.find("other_documents").highlight();
//...
}

Run all UI tests in the container
Make it scalable for parallel execution
Keep the possibility to "watch" the test
Should be triggered by the CI server
Use our internal private cloud infrastructure

We need a containerized UI!We need a containerized UI!
Based on: ConSol/docker-headless-vnc-container

Containers - the new VMs?Containers - the new VMs?

Let's try the Sakuli ContainerLet's try the Sakuli Container
# start the docker container
docker run -it -p 5911:5901 -p 6911:6901 consol/sakuli-ubuntu-xfce
docker run -it -p 5912:5901 -p 6912:6901 consol/sakuli-centos-xfce
docker run -it -p 5913:5901 -p 6913:6901 consol/sakuli-ubuntu-xfce-java
docker run -it -p 5914:5901 -p 6914:6901 consol/sakuli-centos-xfce-java
# start in parallel via docker-compose
# use docker-compos.yml from https://github.com/ConSol/sakuli/tree/master/docker
docker-compose up

Setup Selenium in DockerSetup Selenium in Docker
(Dockerfile)
FROM consol/sakuli-ubuntu-xfce-java:1.3.0-247-sakuli-se-SNAPSHOT
MAINTAINER Tobias Schneck "tobias.schneck@consol.de"
ENV REFRESHED_AT 2018-07-23
### Install gedit as test app
USER 0
RUN apt-get update
&& apt-get install -y gedit
&& apt-get clean -y
USER 1000
### Install webdriver
ENV WEB_DRIVER /headless/webdriver
#chrome
RUN mkdir $WEB_DRIVER && cd $WEB_DRIVER
&& wget https://chromedriver.storage.googleapis.com/2.25/chromedriver_linux64.zip
&& unzip *.zip && rm *.zip && ls -la
Build and start the container:
docker build -t local/sakuli-se .
&& docker run -it -v $(pwd):/opt/maven --user $(id -u) -p 6911:6901
local/sakuli-se mvn -P docker test

Define a repeatable Test SetupDefine a repeatable Test Setup
(e.g. Docker Compose)
version: '2'
services:
sakuli_se_test:
build: .
environment:
- TZ=Europe/Berlin
user: "1000"
volumes:
- .:/opt/maven
- data:/headless/.m2
network_mode: "bridge"
ports:
- 5911:5901
- 6911:6901
# to keep container running and login via `docker exec -it javaexample_sakuli_java_test_1 bash
# command: "'--tail-log'"
command: mvn clean test -P docker -f /opt/maven/pom.xml
volumes:
data:
driver: local
Build and start the container:
docker-compose up --build --force-recreate

Add tests to Kubernetes clusterAdd tests to Kubernetes cluster
(e.g. Skaffold)
apiVersion: skaffold/v1alpha2
kind: Config
build:
tagPolicy:
gitCommit: {}
artifacts:
- imageName: toschneck/sakuli-se-example
docker:
dockerfilePath: Dockerfile.skaffold
deploy:
kubectl:
manifests:
- ./kubernetes-manifests/**.yaml
Build and create Kubernetes Job:
# local (dev stage)
skaffold dev
# remote (deployment stage)
skaffold run

WhyWhy
Support different web testing providers:
Sahi OS
Selenium
... more should follow
Combines DOM access and native screen recognition
OpenSource
no vendor lock in and easy to extend
Ready-to-use Docker images
Cloud-ready: Kubernetes & OpenShift

Monitoring IntegrationMonitoring Integration
Nagios OMD Incinga Check_MK

CI Pipeline with JenkinsCI Pipeline with Jenkins

Test Management UITest Management UI
Comfortable writing and management of test suites
Direct test execution with integrated live view and logs
Extended reports for easy error detection
Video

What's next?What's next?
Implement Junit 5 test runner
Web UI to handle Sakuli test suites
JavaScript
Java
Headless execution
Linux: VNC & Docker
Windows: only Terminalserver
Video recording of the test execution (error documentation)

LinksLinks
ConSol/sakuli
ConSol/sakuli-examples
ConSol/sakuli-examples/java-selenium-example
Sakuli Showroom
sakuli@consol.de @sakuli_e2e

Thank you!Thank you!
Tobias Schneck
Loodse GmbH
Fuhlsbüttler Straße 405
D-22307 Hamburg
tobi@loodse.com
@toschneck toschneck
info@loodse.com
www.loodse.com
@Loodse Loodse

UI Testing - Selenium? Rich-Clients? Containers? (SwanseaCon 2018)

Recommended

Recommended

More Related Content

What's hot

What's hot (19)

Similar to UI Testing - Selenium? Rich-Clients? Containers? (SwanseaCon 2018)

Similar to UI Testing - Selenium? Rich-Clients? Containers? (SwanseaCon 2018) (20)

More from Tobias Schneck

More from Tobias Schneck (20)

Recently uploaded

Recently uploaded (20)

UI Testing - Selenium? Rich-Clients? Containers? (SwanseaCon 2018)
