State of the Art
  Web Mapping
with Open Source
OSCON 2012 | Dane Springmeyer
@springmeyer
 github / twitter
see also:
           Justin Miller
Building a mobile, offline mapping stack
        using open tools & data

        5pm Wednesday, F150
Background

    Engineer @ MapBox
 Building TileMill and Mapnik
Web performance / rendering
github / twitter
http://mapbox.com
We provide services & open source tools
open source tools
    to cover
CartoDB
TileMill
•
maps are simple
   (a primer)
geodata as
  just another
data field / type
cartography as just a
 sexy form of data
    visualization
location: lat/lon, x/y

    attributes:
 name, type, value
styles separate from
data akin to css/html
CartoCSS
@motorway: #90BFE0;

.highway[TYPE='motorway'] {

  .line[zoom>=0]    {

      line-color: spin(darken(@motorway,36),-10);

      line-cap:round;

      line-join:round;

  }

  .fill[zoom>=10] {

      line-color:@motorway;

      line-cap:round;

      line-join:round;}}
spatial types
point:







 •
line:











 -----------
polygon:
                             _____
                            |_____|
Multi* types
  many to one
geometries   feature
tabular geo-csv
 latitude    longitude   name



45.5        -122.6       PDX
tabular geo-csv
        (multipoint)
        WKT                     Name
 MULTIPOINT ((10 40),
(40 30), (20 20), (30 10))
                             Group of Cities
geojson
 { "type": "FeatureCollection",
   "features": [
     { "type": "Feature",
         "properties": { "name": "PDX" },
         "geometry" : { "type": "Point",
            "coordinates": [ -122.6, 45.5 ]
          }
     }]}

Works everywhere: e.g QGIS, TileMill, Web clients
postgis
postgis=# select 'POINT(-122.6
45.5)'::geometry as geom,'PDX'::text as name;

                    geom                    | name
--------------------------------------------+------
 01010000006666666666A65EC00000000000C04640 | PDX
(1 row)



                                     WKB
                              (Well Known Binary)
postgis
postgis=# select ST_Distance('POINT(-122.6
45.5)'::geography,'POINT(-122.3
47.6)'::geography)/1609.344 as
dist_in_miles_from_pdx_to_sea;

 dist_in_miles_from_pdx_to_sea
-------------------------------
              145.755555956692
(1 row)
minimal code for
simple maps, both
 server and client
Mapnik

var mapnik = require('mapnik');
var map = new mapnik.Map(256, 256);
map.loadSync('map.xml');
map.zoomAll();
map.renderFileSync('map.png');
Leaflet
<html>
<head>
  <link rel="stylesheet" href="http://cdn.leafletjs.com/leaflet-0.3.1/leaflet.css" />
  <script src="http://cdn.leafletjs.com/leaflet-0.3.1/leaflet.js"></script>
</head>
<body>
! <div id="map" style="width: 100%; height: 100%"></div>
  <script>
   var map = new L.Map('map');
   var osm = new L.TileLayer('http://tile.osm.org/{z}/{x}/{y}.png');
   map.setView(new L.LatLng(45.5, -122.65), 12).addLayer(osm);
   var pdx = { "type": "FeatureCollection", "features": [ { "type": "Feature",
     "properties": { "name": "PDX" },
     "geometry" : { "type": "Point","coordinates": [ -122.65, 45.5 ]}}]
   };
   map.addLayer(new L.GeoJSON(pdx));
  </script>
</body>
</html>
•
but maps are
    hard
geodata can be
messy and multi-
  resolution
geodata can be
    huge
geodata can be
   dynamic
data    story
takes too long
maps as the single
lock-in point (google)
  or point of failure
 (Slow WMS, IE support, clashing
           design)
•
how modern
web maps work
or, how to tell stories
  with maps quickly,
 ensure they are fast
    under load and
      work in IE
open data
         osm.org
   naturalearthdata.com
us census (geo/www/tiger)
local governments portals
serverside
pre-processing
gradually work
   clientside
tile renderers
mapnik / mapserver
fast app servers
Node.js/Python/C++
pre-processed
pre-rendered
  cacheable
beautiful graphics
 Antigrain Geometry
   Cairo Graphics
standard formats
  geojson, wkt, csv,
  shapefile, postgis,
       geotiff
tiled data
bake big data   bitmaps
pre-render where
possible, but beware the
      world is big
coming...
optimized tiled formats
like msgpack, protobuf
    (not just bitmaps)
coming ...
optimized tiled storage
     and indexing
coming ...
  more robust and
configurable clientside
     renderers
UI: Browser JS client / Mobile Native client

   Render:                            Display:
Hardware Vector                       <img> tiles
   Renderer



 Data Tiles:                        Image Tiles:
Optimized vectors                   Software Vector
                                       Renderer


  Storage: Database / Flat file (Spatially Indexed)
     Data Processing: GIS Apps, Scripting
UI: Leaflet / ModestMaps / RouteMe

    Render:                         Display:
 Kothic.js / Vecnik                all browers
(Canvas/WebGL in                     support
 some browsers)


  Data Tiles:                    Image Tiles:
  TileStache /                  Mapnik via TileMill
   Kothic.js /                    or TileStache
   TileMill ?                 + UTFGrid interactivity

   Storage: Postgres-PostGIS / CSV / GeoJSON
   Data Processing: Qgis, R stats, Python, SQL
•
TileMill
http://mapbox.com/tilemill/
Installing TileMill
TileMill: Ubuntu
sudo apt-add-repository
ppa:developmentseed/mapbox
sudo apt-get -y update
sudo apt-get -y install tilemill
sudo start tilemill
TileMill: Mac
TileMill: Basics
 Cross platform - Linux, Win, OS X
  Same code both desktop & web
Outputs PNG, MBTiles, Mapnik XML
Written in Javascript (Node.js) and C
             ++ (Mapnik)
Art of the possible
http://project.wnyc.org/stop-frisk-guns/
http://gop.sites.devseed.com/
foursquare.com
http://www.npr.org/censusmap/
http://streeteasy.com/
Millions of points without sacrificing speed
TileMill: Live

       http://bit.ly/MFjLnG
       http://bit.ly/SFeBfJ
      Ec2 machines only available on July 17,2012
set one up yourself like: http://mapbox.com/tilemill/docs/
                guides/ubuntu-service/
Demos...

• TileMill: layer ordering, fonts, labeling,
  plugins, mbtiles export, mapnik xml export,
  svg/marker-transforms
• TileMill: reinforce basics through demos:
  arc.js geojson, cartodb csv, etherpad csv
• OSM-bright setup
Thanks!

 @springmeyer
  github / twitter
dane@mapbox.com
•
Do not miss Stamen
   and Vizzuality
    (Cartodb)
TileMill Extra Details
