The document discusses symbolic execution, which is a program analysis technique that executes programs with symbolic inputs instead of concrete inputs. It describes symbolic execution as an approach for solving satisfiability modulo theories (SMT) problems, by viewing symbolic execution as an SMT solver. It presents an implementation of symbolic execution based on a Boolean executor that performs a depth-first search, combined with an SMT solver to check satisfiability of path conditions.

1. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Execution as DPLL Modulo Theories
Q. Sang Phan
Queen Mary, University of London
September 25, 2014
1 / 25

2. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Outline
1 Introduction
2 Background
3 Symbolic Execution as DPLL(T )
4 A lightweight approach for Symbolic Execution
5 Conclusion
2 / 25

3. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Outline
1 Introduction
2 Background
3 Symbolic Execution as DPLL(T )
4 A lightweight approach for Symbolic Execution
5 Conclusion
3 / 25

4. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Execution
A program analysis technique that has several applications, in particular
automated test generation.
Executing programs with symbols instead of concrete inputs.
4 / 25

5. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Execution
Academic:
Imperial: KLEE
EPFL: S2E
UC Berkeley: CREST and BitBlaze
UIUC: Cute, jCute
. . .
Industry:
NASA: Symbolic PathFinder
Microsoft: Pex, Sage, Yogi
IBM: Apollo
. . .
5 / 25

6. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Satis

7. ability Modulo Theories
Decision problem for logical formulas over one or more

8. rst-order theories
' (:(x0 5) _ T1) ^ ((x0 5) _ T2) ^ (:(x0 5) _ (x1 = x0 + 1)) ^
(:(x1 3) _ T3) ^ (:(x1 3) _ (x2 = x1 1)) ^
((x1 3) _ T4) ^ ((x1 3) _ (y1 = x1 + 1))
6 / 25

9. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Satis

10. ability Modulo Theories
Decision problem for logical formulas over one or more

11. rst-order theories
' (:(x0 5) _ T1) ^ ((x0 5) _ T2) ^ (:(x0 5) _ (x1 = x0 + 1)) ^
(:(x1 3) _ T3) ^ (:(x1 3) _ (x2 = x1 1)) ^
((x1 3) _ T4) ^ ((x1 3) _ (y1 = x1 + 1))
Tools:
Microsoft: Z3
NYU: CVC3
SRI: Yices
. . .
SMT competition: http://www.smtcomp.org/
6 / 25

12. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Execution as an SMT solver
Symbolic Execution can be viewed as an SMT solver
7 / 25

13. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Outline
1 Introduction
2 Background
3 Symbolic Execution as DPLL(T )
4 A lightweight approach for Symbolic Execution
5 Conclusion
8 / 25

14. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
DPLL Modulo Theories
The lazy approach for SMT
SMT solver = SAT solver + T -solver
SAT solver: implement DPLL algorithm
T -solver: check satis

15. ability of conjunctions of literals
9 / 25

16. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
DPLL Modulo Theories
The lazy approach for SMT
SMT solver = SAT solver + T -solver
SAT solver: implement DPLL algorithm
T -solver: check satis

17. ability of conjunctions of literals
DPLL-based SAT solver: a depth-

18. rst search procedure, using three main operations:
decide: choose a literal l from the formula.
propagate: remove all the clauses containing l , and deletes all occurrences of :l
in the formula.
backtrack: if encounter a con
ict.
9 / 25

19. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Boolean Abstraction
' (:(x0 5) _ T1) ^ ((x0 5) _ T2) ^ (:(x0 5) _ (x1 = x0 + 1)) ^
(:(x1 3) _ T3) ^ (:(x1 3) _ (x2 = x1 1)) ^
((x1 3) _ T4) ^ ((x1 3) _ (y1 = x1 + 1))
(x0 5), (x1 = x0 + 1), . . . : T -atoms
T1;T2; : : : : Boolean atoms
10 / 25

20. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Boolean Abstraction
' (:(x0 5) _ T1) ^ ((x0 5) _ T2) ^ (:(x0 5) _ (x1 = x0 + 1)) ^
(:(x1 3) _ T3) ^ (:(x1 3) _ (x2 = x1 1)) ^
((x1 3) _ T4) ^ ((x1 3) _ (y1 = x1 + 1))
(x0 5), (x1 = x0 + 1), . . . : T -atoms
T1;T2; : : : : Boolean atoms
Boolean abstraction of ':
'P (:G1 _ T1) ^ (G1 _ T2) ^ (:G1 _ A1) ^
(:G2 _ T3) ^ (:G2 _ A2) ^
(G2 _ T4) ^ (G2 _ A3)
10 / 25

21. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
DPLL-based SAT solver
'P (:G1 _ T1) ^ (G1 _ T2) ^ (:G1 _ A1) ^
(:G2 _ T3) ^ (:G2 _ A2) ^
(G2 _ T4) ^ (G2 _ A3)
0. P = True 'P
1. P = G1 'P = (:G2 _ T3) ^ (:G2 _ A2) ^ (G2 _ T4) ^ (G2 _ A3)
2. P = G1 ^ G2 'P = True ; T -solver() = Inconsistent
3. P = G1 'P = (:G2 _ T3) ^ (:G2 _ A2) ^ (G2 _ T4) ^ (G2 _ A3)
4. P = G1 ^ :G2 'P = True ; T -solver() = Consistent
11 / 25

22. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Execution
pc ` c : execute the then path
pc ` :c : execute the else path
(pc 0 c) ^ (pc 0 :c): execute both paths
then path: update pc1 = pc ^ c
else path: update pc2 = pc ^ :c
Use SMT solver to check satis

23. ability of path
conditions
12 / 25

24. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Execution
pc ` c : execute the then path
pc ` :c : execute the else path
(pc 0 c) ^ (pc 0 :c): execute both paths
then path: update pc1 = pc ^ c
else path: update pc2 = pc ^ :c
Use SMT solver to check satis

25. ability of path
conditions
Observation
SMT solver is used to solve conjunctions of literals ) the SAT solver is not used
12 / 25

26. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Implementation of Symbolic Execution
Symbolic Executor = Boolean Executor + T -solver
Boolean Executor: A depth-

27. rst search procedure, using three main operations:
decide: choose a literal from the condition.
update: execute block of code on that path.
backtrack: if reach the leaf of the symbolic execution tree.
13 / 25

28. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Outline
1 Introduction
2 Background
3 Symbolic Execution as DPLL(T )
4 A lightweight approach for Symbolic Execution
5 Conclusion
14 / 25

29. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Transition System
A bounded Static Single Assignment program:
P (S; I ; G;A;T)
S: the set of symbolic states
I S : the set of initial symbolic states
G : the set of guards
A : the set of action
Actions do not update computer memory: presented by Boolean atoms.
Actions update computer memory: presented by T -atoms.
T S G A S: the transition function
15 / 25

30. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Program to formula
tij = hsi ; gij ; aij ; sj i 2 T: si ! sj by action aij under guard gij
16 / 25

31. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Program to formula
tij = hsi ; gij ; aij ; sj i 2 T: si ! sj by action aij under guard gij
Encode the transition into a formula:
tij gij ! aij or equally tij :gij _ aij
16 / 25

32. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Program to formula
tij = hsi ; gij ; aij ; sj i 2 T: si ! sj by action aij under guard gij
Encode the transition into a formula:
tij gij ! aij or equally tij :gij _ aij
A program trace:
t01 ^ t12 ^ ^ t(k1)k = (:g01 _ a01) ^ (:g12 _ a12) ^ (:g(k1)k _ a(k1)k )
16 / 25

33. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Program to formula
tij = hsi ; gij ; aij ; sj i 2 T: si ! sj by action aij under guard gij
Encode the transition into a formula:
tij gij ! aij or equally tij :gij _ aij
A program trace:
t01 ^ t12 ^ ^ t(k1)k = (:g01 _ a01) ^ (:g12 _ a12) ^ (:g(k1)k _ a(k1)k )
Program semantics: all possible traces
' =
^
tij2T
tij =
^
tij2T
(:gij _ aij )
16 / 25

34. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Transition System: Example
void test ( int x, int y){
if(x 5){
x ++;
if (x 3)
x --;
else
y = x + 1;
}
}
s0
x0 5
T1
s1 s2
s3
s4 s5
s6 s7
¬(x0 5)
T2
x0 5
x1 = x0 + 1
x1 3
T3
¬(x1 3)
T4
x1 3 ¬(x1 3)
x2 = x1 − 1 y1 = x1 + 1
17 / 25

35. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Transition System: Example
void test ( int x, int y){
if(x 5){
x ++;
if (x 3)
x --;
else
y = x + 1;
}
}
s0
x0 5
T1
s1 s2
s3
s4 s5
s6 s7
¬(x0 5)
T2
x0 5
x1 = x0 + 1
x1 3
T3
¬(x1 3)
T4
x1 3 ¬(x1 3)
x2 = x1 − 1 y1 = x1 + 1
' (:(x0 5) _ T1) ^ ((x0 5) _ T2) ^ (:(x0 5) _ (x1 = x0 + 1)) ^
(:(x1 3) _ T3) ^ (:(x1 3) _ (x2 = x1 1)) ^
((x1 3) _ T4) ^ ((x1 3) _ (y1 = x1 + 1))
17 / 25

36. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Execution vs SMT solver
Symbolic Execution
Symbolic Executor = Boolean Executor + T -solver
Boolean Executor: a depth-

37. rst search procedure, using three main operations:
decide, update, backtrack
SMT solver
SMT solver = SAT solver + T -solver
DPLL-based SAT solver: a depth-

38. rst search procedure, using three main operations:
decide, propagate, backtrack
18 / 25

39. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Outline
1 Introduction
2 Background
3 Symbolic Execution as DPLL(T )
4 A lightweight approach for Symbolic Execution
5 Conclusion
19 / 25

40. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Execution vs SMT solver
Symbolic Execution returns all symbolic path.
SMT solvers return only one model.
! Use an SMT solver that can return all models for Symbolic Execution
! The only SMT solver known to generate all models: MathSAT
20 / 25

41. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Execution via All-SMT
'P := (:G1 _ T1) ^ (G1 _ T2) ^ (:G1 _ A1) ^
(:G2 _ T3) ^ (:G2 _ A2) ^
(G2 _ T4) ^ (G2 _ A3)
1 (assert (= ( x0 5) G1)) 8 (assert (or (not G1) A1))
2 (assert (= ( x1 3) G2)) 9 (assert (or (not G2) T3))
3 (assert (= (= x1 (+ x0 1)) A1)) 10 (assert (or (not G2) A2))
4 (assert (= (= x2 ( x1 1)) A2)) 11 (assert (or G2 T4))
5 (assert (= (= y1 (+ x1 1)) A2)) 12 (assert (or G2 A3))
6 (assert (or (not G1) T1)) 13 (check-allsat (G1 G2))
7 (assert (or G1 T2))
21 / 25

42. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Symbolic Execution via All-SMT
(G1 G2): (True,False), (False,True) and (False,False)
s0
x0 5
T1
s1 s2
s3
s4 s5
s6 s7
¬(x0 5)
T2
x0 5
x1 = x0 + 1
x1 3
T3
¬(x1 3)
T4
x1 3 ¬(x1 3)
x2 = x1 − 1 y1 = x1 + 1
22 / 25

43. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Outline
1 Introduction
2 Background
3 Symbolic Execution as DPLL(T )
4 A lightweight approach for Symbolic Execution
5 Conclusion
23 / 25

44. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
Conclusion
Symbolic Execution can be viewed as an SMT solver
Exploit techniques developed for Symbolic Execution to SMT.
Exploit techniques developed for SMT for Symbolic Execution.
A lightweight approach for Symbolic Execution based on All-SMT solver
24 / 25

45. Introduction
Background
Symbolic Execution as DPLL(T )
A lightweight approach for Symbolic Execution
Conclusion
THANK YOU FOR YOUR ATTENTION!
25 / 25
