This document discusses algorithm analysis and complexity. It introduces algorithm analysis as a way to predict and compare algorithm performance. Different algorithms for computing factorials and finding the maximum subsequence sum are presented, along with their time complexities. The importance of efficient algorithms for problems involving large datasets is discussed.

1. Algorithm Analysis & Data Structures Jaideep Srivastava

4. Lecture 1 – Algorithm Analysis & Complexity

33. Complexity and Tractability Assume the computer does 1 billion ops per sec.

34. 2 n n 2 n log n n log n log n n n log n n 2 n 3 n 3 2 n

40. Example

41. Examples

56. Lecture 2 - Recursion

77. A Tree Diagram for Fibonacci’s Puzzle

82. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5)

83. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns Fib(3) + Fib(4)

84. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns Fib(3) + Fib(4) Fib(3): Fib returns Fib(1) + Fib(2)

85. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns Fib(3) + Fib(4) Fib(3): Fib returns Fib(1) + Fib(2) Fib(1): Fib returns 1

86. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns Fib(3) + Fib(4) Fib(3): Fib returns 1 + Fib(2)

87. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns Fib(3) + Fib(4) Fib(3): Fib returns 1 + Fib(2) Fib(2): Fib returns 1

88. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns Fib(3) + Fib(4) Fib(3): Fib returns 1 + 1

89. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns 2 + Fib(4)

90. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns 2 + Fib(4) Fib(4): Fib returns Fib(2) + Fib(3)

91. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns 2 + Fib(4) Fib(4): Fib returns Fib(2) + Fib(3) Fib(2): Fib returns 1

92. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns 2 + Fib(4) Fib(4): Fib returns 1 + Fib(3)

93. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns 2 + Fib(4) Fib(4): Fib returns 1 + Fib(3) Fib(3): Fib returns Fib(1) + Fib(2)

94. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns 2 + Fib(4) Fib(4): Fib returns 1 + Fib(3) Fib(3): Fib returns Fib(1) + Fib(2) Fib(1): Fib returns 1

95. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns 2 + Fib(4) Fib(4): Fib returns 1 + Fib(3) Fib(3): Fib returns 1 + Fib(2)

96. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns 2 + Fib(4) Fib(4): Fib returns 1 + Fib(3) Fib(3): Fib returns 1 + Fib(2) Fib(2): Fib returns 1

97. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns 2 + Fib(4) Fib(4): Fib returns 1 + Fib(3) Fib(3): Fib returns 1 + 1

98. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns 2 + Fib(4) Fib(4): Fib returns 1 + 2

99. Tracing with Multiple Recursive Calls Main Algorithm: answer <- Fib(5) Fib(5): Fib returns 2 + 3

100. Tracing with Multiple Recursive Calls Main Algorithm: answer <- 5

101. Fib(5) 15 calls to Fib to find the 5th Fibonacci number!!! Fib(3) Fib(4) Fib(3) Fib(2) Fib(2) Fib(1) Fib(1) Fib(0) Fib(1) Fib(0) Fib(2) Fib(1) Fib(1) Fib(0)

109. Towers of Hanoi B C A

110. Towers of Hanoi B C A

111. Towers of Hanoi B C A

112. Towers of Hanoi B C A

113. Towers of Hanoi B C A

114. Towers of Hanoi B C A

115. Towers of Hanoi B C A

116. Towers of Hanoi B C A

117. Towers of Hanoi A pseudocode description of the solution is: Towers(Count, Source, Dest, Spare) if (Count is 1) Move the disk directly from Source to Dest else { Solve Towers(Count-1, Source, Spare, Dest) Solve Towers(1, Source, Dest, Spare) Solve Towers(Count-1, Spare, Dest, Source) }

118. Towers of Hanoi void solveTowers( int count, char source, char dest, char spare){ if (count == 1) cout<<“Move disk from pole “ << source << &quot; to pole &quot; << destination <<endl; else { towers(count-1, source, spare, destination); towers(1, source, destination, spare); towers(count-1, spare, destination, source); }//end if }//end solveTowers

120. Pascal Triangle (Is this recursive?)

133. “ Why use recursion?” Many solutions could have been written without recursion, by using iteration instead. The iterative solution uses a loop, and the recursive solution uses an if statement. However, for certain problems the recursive solution is the most natural solution. This often occurs when pointer variables are used.

136. Lecture 3 – Binary Trees

139. Trees: Recursive Definition (cont.) ROOT OF TREE T T1 T2 T3 T4 T5 SUBTREES

140. Trees: An Example A B C D E F G H I

145. Binary Trees: Recursive Definition ROOT OF TREE T T1 T2 SUBTREES *left_child *right_child

167. struct TreeNode { Object element; TreeNode *child1; TreeNode *sibling; }; Each node contain a link to its first child and a link to its next sibling. This is a better idea. Trees: Linked representation Implementation 2

168. Implementation 2: Example / The downward links are to the first child; the horizontal links are to the next sibling. / / / / A / B F / C D E / G H / I /

170. Linked Representation Example a c b d f e g h leftChild element rightChild root

172. CS122 Algorithms and Data Structures Week 7: Binary Search Trees Binary Expression Trees

175. A Property of Binary Search Tree ROOT OF TREE T T1 T2 SUBTREES *left_child *right_child X All nodes in T1 have keys < X. All nodes in T2 have keys > X.

177. Search Operation BinaryNode *search (const int &x, BinaryNode *t) { if ( t == NULL ) return NULL; if (x == t->key) return t; // Match if ( x < t->key ) return search( x, t->left ); else // t ->key < x return search( x, t->right ); }

178. FindMin Operation BinaryNode* findMin (BinaryNode *t) { if ( t == NULL ) return NULL; if ( t -> left == NULL ) return t; return findMin (t -> left); } This method returns a pointer to the node containing the smallest element in the tree.

179. FindMax Operation BinaryNode* findMax (BinaryNode *t) { if ( t == NULL ) return NULL; if ( t -> right == NULL ) return t; return findMax (t -> right); } This function returns a pointer to the node containing the largest element in the tree.

181. Insert Operation (cont.) void BinarySearchTree insert (const int &x, BinaryNode *&t) const { if (t == NULL) t = new BinaryNode (x, NULL, NULL); else if (x < t->key) insert(x, t->left); else if( t->key < x) insert(x, t->right); else ; // Duplicate entry; do nothing } Note the pointer t is passed using call by reference.

184. Removal Operation (cont.) void remove (const int &x, BinaryNode* &t) const { if ( t == NULL ) return; // key is not found; do nothing if ( t->key == x) { if( t->left != NULL && t->right != NULL ) { // Two children t->key = findMin( t->right )->key; remove( t->key, t->right ); } else { // One child BinaryNode *oldNode = t; t = ( t->left != NULL ) ? t->left : t->right; delete oldNode; } } else { // Two recursive calls if ( x < t->key ) remove( x, t->left ); else if( t->key < x ) remove( x, t->right ); } }

185. Deleting by merging

186. Deleting by merging

187. Deleting by copying

189. Balancing a binary tree

191. Average Level of Nodes 10 5 20 1 8 13 34 Consider this very well-balanced binary search tree. What is the level of its leaf nodes? N=7 Data Order: 10, 5, 1, 8, 20, 13, 34

193. Effect of Data Order Obtained if data is 4, 3, 2 1 Obtained if data is 1, 2, 3, 4 Note in these cases the average depth of nodes is about N/2 , not log(N)!

201. A Binary Expression Tree What value does it have? ( 4 + 2 ) * 3 = 18 ‘ *’ ‘ +’ ‘ 4’ ‘ 3’ ‘ 2’

202. Inorder Traversal: (A + H) / (M - Y) ‘ +’ ‘ A’ ‘ H’ ‘ -’ ‘ M’ ‘ Y’ tree Print left subtree first Print right subtree last Print second ‘ /’

203. Inorder Traversal (cont.) a + * b c + * + g * d e f Inorder traversal yields: (a + (b * c)) + (((d * e) + f) * g)

204. Preorder Traversal: / + A H - M Y ‘ +’ ‘ A’ ‘ H’ ‘ -’ ‘ M’ ‘ Y’ tree Print left subtree second Print right subtree last Print first ‘ /’

205. Preorder Traversal (cont.) a + * b c + * + g * d e f Preorder traversal yields: (+ (+ a (* b c)) (* (+ (* d e) f) g))

206. ‘ +’ ‘ A’ ‘ H’ ‘ -’ ‘ M’ ‘ Y’ tree Print left subtree first Print right subtree second Print last Postorder Traversal: A H + M Y - / ‘ /’

207. Postorder Traversal (cont.) a + * b c + * + g * d e f Postorder traversal yields: a b c * + d e * f + g * +

211. Example a b + : Note: These stacks are depicted horizontally. a b + b a

212. Example a b + c d e + : + b a c d e + b a c d e +

213. Example a b + c d e + * : + b a c d e + *

214. Example a b + c d e + * * : + b a c d e + * *
