LINEAR QUEUE with Diagram and C implementation. Operations of LINEAR QUEUE Drawback of LINEAR QUEUE CIRCULAR QUEUE with Diagram and C implementation Operations of CIRCULAR QUEUE PRIORITY QUEUE with Diagram and C implementation Operations of PRIORITY QUEUE CASE STUDIES EXAMPLES

1. Queues
SOUMEN SANTRA
MCA, M.Tech, SCJP, MCP

2. DEFINITION OF QUEUE
• A Queue is an ordered collection ADT(Abstract Data Type) of items
from which items may be deleted at one end (FRONT) and into
which items may be inserted at the other end (REAR).
• The first element inserted into the queue is the first element to be
removed. The queue is sometimes called a FIFO (first-in first-out) list
as opposed to the stack, which is a LIFO (last-in first-out).

3. Queue
• Stores a set of elements in a particular order
• Stack principle: FIRST IN FIRST OUT
• = FIFO
• It means: the first element inserted is the first one to be
removed.
• The first one in line is the first one to be served
• Example

4. Queue Applications
• Real life examples
• Waiting in line for reservation
• Waiting on hold for tech support
• Applications related to Computer Science
• Threads scheduling & synchronization
• Job scheduling (e.g. Round-Robin algorithm for CPU allocation)

5. A
B
A
C
B
A
D
C
B
A
D
C
Brear
front
rear
front
rear
front
rear
front
rear
front
First In First Out

6. front rear Q[0] Q[1] Q[2] Q[3] Comments
-1
-1
-1
-1
0
1
-1
0
1
2
2
2
J1
J1 J2
J1 J2 J3
J2 J3
J3
queue is empty
Job 1 is added
Job 2 is added
Job 3 is added
Job 1 is deleted
Job 2 is deleted
Applications: Job Scheduling

7. Queue
items[MAX-1]
. .
. .
. .
items[2] C
items[1] B
items[0] A Front=0
Rear=2

8. Declaration of a Queue
# define MAX 500 /* size of the queue items*/
typedef struct {
int front;
int rear;
int items[MAX];
}QUEUE;

9. QUEUE OPERATIONS
• Initialize the queue
• Insert to the rear of the queue
• Remove (Delete) from the front of the queue
• Is the Queue Empty
• Is the Queue Full
• What is the size of the Queue

10. Queue Example: Class Diagram Concept
+Queue()
+insert() : void
+remove() : long
+peekFront() : long
+isEmpty() : bool
+isFull() : bool
+size() : int
-maxSize : int
-queueArray [] : long
-front : int
-rear : int
-nItems : int
Queue
QueueApp
Interface1

11. INITIALIZE THE QUEUE
items[MAX-1]
. .
. .
.
items[1]
items[0] front=0
rear=-1
•The queue is initialized by having the rear set to -1, and front set to 0. Let us
assume that maximum number of the element we have in a queue is MAX size
elements as shown below.

12. insert(&Queue, ‘A’) Method
• an item (A) is inserted at the Rear of the queue
items[MAX-1]
. .
. .
items[3]
items[2]
items[1]
items[0] A Front=0,
Rear=0

13. insert(&Queue, ‘B’) Method
• A new item (B) is inserted at the Rear of the queue
items[MAX-1]
. .
. .
items[3]
items[2]
items[1] B Rear=1
items[0] A Front=0

14. insert(&Queue, ‘C’) Method
• A new item (C) is inserted at the Rear of the queue
items[MAX-1]
. .
. .
items[3]
items[2] C Rear=2
items[1] B
items[0] A Front=0

15. insert(&Queue, ‘D’) Method
• A new item (D) is inserted at the Rear of the queue
items[MAX-1]
. .
. .
items[3] D Rear=3
items[2] C
items[1] B
items[0] A Front=0

16. Array-based Queue Implementation
• As with the array-based stack implementation, the array is
of fixed size
• A queue of maximum N elements
• Slightly more complicated
• Need to maintain CONTROL of both front and rear
Implementation 1
Implementation 2

17. Insert Operation of Queue using pointer
void insert(QUEUE *qptr, char x)
{
if(qptr->rear == MAX-1)
{
printf("Queue is full!");
exit(1);
}
else
{
qptr->rear++;
qptr->items[qptr->rear]=x;
}
}

18. char remove(&Queue) Method
• an item (A) is removed (deleted) from the Front of
the queue & return it as per datatype.
items[MAX-1]
. .
. .
items[3] D Rear=3
items[2] C
items[1] B Front=1
items[0] A

19. char remove(&Queue) Method
• Remove two items from the front of the queue.
items[MAX-1]
. .
. .
items[3] D Rear=3
items[2] C Front=2
items[1] B
items[0] A

20. char remove(&Queue) Method
• Remove two items from the front of the queue.
items[MAX-1]
. .
. .
items[3] D Front=Rear=3
items[2] C
items[1] B
items[0] A

21. char remove(&Queue) Method
• Remove one more item from the front of the queue.
items[MAX-1]
. .
items[4] Front=4
items[3] D Rear=3
items[2] C
items[1] B
items[0] A

22. Remove Operation implementation in c
char remove(struct queue *qptr)
{
char p;
if(qptr->front > qptr->rear){
printf("Queue is empty");
exit(1);
}
else
{p=qptr->items[qptr->front];
qptr->front++;
return p;
}
}

23. INSERT / REMOVE ITEMS : Drawback of Linear Queue
• Assume that the rear= MAX-1
•What happens if we want to insert a new
item into the queue?
items[MAX-1] X rear=MAX-1
. .
. .
items[3] D front=3
items[2] C
items[1] B
items[0] A

24. INSERT / REMOVE ITEMS
• What happens if we want to insert a new item F into the
queue?
• Although there is some empty space, the queue is full.
• One of the methods to overcome this problem is to shift all
the items to occupy the location of deleted item.

25. REMOVE ITEM
items[MAX-1]
. .
. .
items[3] D Rear=3
items[2] C
items[1] B Front=1
items[0] A

26. REMOVE ITEM : Example
items[MAX-1]
. .
. .
items[3] D Rear=3
items[2] C
items[1] B Front=1
items[0] B

27. REMOVE ITEM : Example
items[MAX-1]
. .
. .
items[3] D Rear=3
items[2] C
items[1] C
items[0] B

28. REMOVE ITEM : Example
items[MAX-1]
. .
. .
items[3] D Rear=3
items[2] D
items[1] C
items[0] B

29. REMOVE ITEM : Example
items[MAX-1]
. .
. .
items[3] D
items[2] D Rear=2
items[1] C
items[0] B

30. Modified Remove Operation implementation
in C
char remove(struct queue *qptr)
{
char p;
int i;
if(qptr->front > qptr->rear){
printf("Queue is empty");
exit(1);
}
else
{p=qptr->items[qptr->front];
for(i=1;i<=qptr->rear;i++)
qptr->items[i-1]=qptr->items[i];
qptr->rear--
return p;
}
}

31. INSERT / REMOVE ITEMS
• Since all the items in the queue are required to shift when an
item is deleted, this method is not preferred.
• The other method is circular queue.
• When rear = MAX-1, the next element is entered at items[0] in
case that spot is free.

32. How to Initialize the queue
items[6] front=rear=6
items[5]
items[4]
items[3]
items[2]
items[1]
items[0]

33. Insert operation in Circular Queue
items[6] front=6
items[5]
items[4]
items[3]
items[2]
items[1]
items[0] 1 rear=0
 Insert 1,2,3 to the rear of the queue.

34. Insert operation in Circular Queue
items[6] front=6
items[5]
items[4]
items[3]
items[2]
items[1] 2 rear=1
items[0] 1
 Insert 1,2,3 to the rear of the queue.

35. Insert operation in Circular Queue
• Insert 1,2,3 to the rear of the queue.
items[6] front=6
items[5]
items[4]
items[3]
items[2] 3 rear=2
items[1] 2
items[0] 1

36. Remove items from circular queue
• Remove two items from the queue.
items[6]
items[5]
items[4]
items[3]
items[2] 3 rear=2
items[1] 2
items[0] 1 front=0

37. Remove items from circular queue
• Remove two items from the queue.
items[6]
items[5]
items[4]
items[3]
items[2] 3 rear=2
items[1] 2 front=1
items[0] 1

38. Remove items from circular queue
• Remove one more item from the queue.
items[6]
items[5]
items[4]
items[3]
items[2] 3 rear=front=2
items[1] 2
items[0] 1

39. Insert operation in Circular Queue:
Overcome Drawback of Linear Queue
• Insert 4,5,6,7 to the queue.
items[6] 7 rear=6
items[5] 6
items[4] 5
items[3] 4
items[2] 3 front=2
items[1] 2
items[0] 1

40. Insert operation in Circular Queue:
Overcome Drawback of Linear Queue
• Insert 8 and 9 to the queue.
items[6] 7
items[5] 6
items[4] 5
items[3] 4
items[2] 3 front=2
items[1] 2
items[0] 8 rear=0

41. Insert operation in Circular Queue:
Overcome Drawback of Linear Queue
• Insert 8 and 9 to the queue.
items[6] 7
items[5] 6
items[4] 5
items[3] 4
items[2] 3 front=2
items[1] 9
items[0] 8 rear=0

42. Insert operation in Circular Queue:
Overcome Drawback of Linear Queue
• Insert 10 to the queue.
items[6] 7
items[5] 6
items[4] 5
items[3] 4
items[2] ?? front=rear=2
items[1] 9
items[0] 8

43. Implementation of a Circular Queue in C
#define MAX 10 /* size of the queue items*/
typedef struct {
int front;
int rear;
int items[MAX];
}QUEUE;
QUEUE Q;
Q.front = MAX-1;
Q.rear= MAX-1;

44. EMPTY QUEUE
[2] [3] [2] [3]
[1] [4] [1] [4]
[0] [5] [0] [5]
front = 0 front = 0
rear = 0 rear = 3
B
A
C
Implementation 2:Cyclic View
Can be seen as a circular queue

45. FULL QUEUE FULL QUEUE
[2] [3] [2] [3]
[1] [4][1] [4]
[0] [5] [0] [5]
front =0
rear = 5
front =4
rear =3
B C
A D
E F E
G
H I
Advantage of Circular Queue:
How to test when queue is UNDERFLOW?
How to test when queue is OVERFLOW?

46. Implementation of Insert Operation for
Circular Queue in C
void insert(QUEUE *qptr, char x)
{
if(qptr->rear == MAX-1)
qptr->rear=0;
else
qptr->rear++;
/* or qptr->rear=(qptr->rear+1)%MAX) */
if(qptr->rear == qptr->front){
printf("Queue overflow");
exit(1);
}
qptr->items[qptr->rear]=x;
}

47. Implementation of Remove Operation
for Circular Queue in C
char remove(struct queue *qptr)
{
if(qptr->front == qptr->rear){
printf("Queue underflow");
exit(1);
}
if(qptr->front == MAX-1)
qptr->front=0;
else
qptr->front++;
return qptr->items[qptr->front];
}

48. #include <stdlib.h>
#include <stdio.h>
#define MAX 50
#define TRUE 1
#define FALSE 0
typedef struct
{
int items[MAX];
int front , rear ;
} Q;
void queinsert( Q * , int);
int quedelete(Q *);
int isempty(Q *);
EXAMPLE in C

49. int main()
{
char operation;
int x;
Q q;
q.front = q.rear = MAX - 1;
do
{
printf("%sn",“Queue Operation type I(Insert) D(Delete) or E(Exit) ");
scanf("n%c",&choice);
switch (choice) {
case 'I’: printf("%sn","Insert an element");
scanf("n%d",&x);
qinsert(&q , x);
break;
case 'D’: x=qdelete(&q);
printf("n %d is deleted n",x);
break;
default: printf(“Incorrect Operation typen”);
break;
}
}
while (choice != 'E’&&choice!='e');
return 0;
}

50. int isempty(Q *qptr)
{
return((qptr->front == qptr->rear) ? TRUE : FALSE);
}
int qdelete(Q *qptr)
{
if (empty(qptr)) {
printf("Queue underflow ");
exit(1);
}
qptr->front=(qptr->front+1)%(MAX)
return(qptr->items[qptr->front]);
}
void qinsert(Q *qptr , int x)
{
/* make room for new element */
printf("n %d is inserted n",x);
qptr->rear=(qptr->rear+1)%(MAX)
if (qptr->rear == qptr->front) {
printf("Queue overflow");
exit(1);
}
qptr->items[qptr->rear] = x;
return;
}

51. #include<stdio.h>
#include<stdlib.h>
#define MAX 5 /* size of the queue items*/
typedef struct{
int front;
int rear;
float items[MAX];
}Q;
void qinsert(Q *, float);
float qdelete(Q *);
void display( Q *);
void clear( Q *);
void menu();

52. int main()
{
int choice;
float x;
Q q;
q.front = M-1;
q.rear= MAX-1;
do{
menu();
scanf("%d",&choice);
switch(choice){
case 1: printf("Enter the item to be inserted:");
scanf("%f",&x);
insert(&q,x);
break;
case 2: x=remove(&q); printf("nRemoved item:%f",x);
break;
case 3: display(&q);
break;
case 4: clear(&q);
break;
default: printf("nWrong entry, Try again!!");
break;
}
}while(choice != 5);
return 0;
}

53. void menu()
{
printf("Press 1 to insert n");
printf("Press 2 to remove n");
printf("Press 3 to display n");
printf("Press 4 to clear n");
printf("Press 5 to quitn");
printf("nnEnter your choice:n");
}
void insert(q *qptr, float x)
{
if(qptr->rear == MAXQ-1)
qptr->rear=0;
else
qptr->rear++;
if(qptr->rear == qptr->front){
printf("Queue overflow");
exit(1);
}
qptr->items[qptr->rear]=x;
}

54. float remove(q *qptr)
{
if(qptr->front == qptr->rear){
printf("Queue underflow");
exit(1);
}
if(qptr->front == MAX-1)
qptr->front=0;
else
qptr->front++;
return qptr->items[qptr->front];
}
void clear(q *qptr)
{
qptr->front=MAX-1;
qptr->rear =MAX-1;
printf("Now the Queue is Emptyn");
}

55. void display(q *qptr)
{
int f,r;
f=qptr->front;
r=qptr->rear;
while(qptr->front !=qptr->rear){
if(qptr->front == MAX-1)
qptr->front =0;
else
qptr->front++;
printf("%5.2f",qptr->items[qptr->front]);
}
printf("n");
qptr->front=f;
qptr->rear=r;
}

56. typedef struct{
int front;
int rear;
int items[MAX]; /* Assume that MAX SIZE is
defined*/
}Q;
Case Study for Queue Search Element

57. int QSearch(Q *qptr, int search)
{
int pos = -1,f;
f=qptr->front;
while(qptr->front !=qptr->rear){
if(qptr->front == MAX-1)
qptr->front =0;
else
qptr->front++;
if(qptr->items[qptr->front] == search){
pos = qptr->front;
qptr->front = f;
return pos;
}
}
qptr->front=f;
return pos;
}
Implementation in C:

58. Case Study in Queue: Copy Reverse
typedef struct{
int front;
int rear;
int items[MAX]; /* Assume that MAX SIZE is
defined*/
}Q;

59. void QCopyReverse(Q *qptr1, Q *qptr2)
{
int r,item;
r=qptr1->rear;
do{
item = qptr1->items[qptr1->rear];
insert(qptr2,item);
if(qptr1->rear ==0)
qptr1->rear = MAX-1;
else
qptr1->rear --;
}while(qptr1->rear != qptr1->front);
qptr1->rear = r;
}
void insert(Q *qptr, int item)
{
if(qptr->rear == MAX-1)
qptr->rear=0;
else
qptr->rear++;
if(qptr->rear == qptr->front){
printf("Queue overflow");
exit(1);
}
qptr->items[qptr->rear]=item;
}

60. PRIORITY QUEUES
• The priority queue is a data structure in which internally
ordering of the elements determines the results of its basic
operations.
• An ascending priority queue is a combination of items with
priority into which items can be inserted arbitrarily and from
which only the smallest item can be removed. On the other
hand a descending priority queue allows only the largest item to
be removed.
• We use process.h for operation.

61. Priority QUEUE Operations
• Insertion
• The insertion in Priority queues is the same as in non-priority
queues.
• Deletion
• Deletion requires a search for the element of highest priority
and deletes the element with highest priority. The following
methods can be used for deletion/removal from a given
Priority Queue:
• An empty indicator replaces deleted elements.
• After each deletion elements can be moved up in the array
decrementing the rear.
• The array in the queue can be maintained as an ordered
circular array

62. Priority Queues Features
• Specialized data structure.
• Same as Queue, having front and rear.
• Items are deleted from the front.
• Items are ordered by priority value so that the item
with the lowest key (or highest) is always at the
front.
• Items are inserted in proper position to maintain
the order of ascending or descending.

63. Priority Queue : Class Diagram
+Queue()
+insert() : void
+remove() : long
+peekMin() : long
+isEmpty() : bool
+isFull() : bool
-maxSize : int
-queueArray [] : long
-nItems : int
PrioityQ
PriorityQApp
Interface1

64. Priority Queue Implementation in C
#define MAX 10 /* size of the queue items*/
typedef struct {
int front, rear;
int items[MAX];
}PQ;

65. int PQremove(Q *qptr)
{
int small, loc, f, i;
f=qptr->front;
if(qptr->front == qptr->rear){
printf("Queue underflow");
exit(1);
}
small = qptr->items[(qptr->front+1)%MAX];
loc = (qptr->front+1)%MAX;
(qptr->front++)%MAX; /* Circular increment*/
while(qptr->front != qptr->rear){
if(qptr->items[(qptr->front+1)%MAX] <small){
small = qptr->items[(qptr->front+1)%MAX];
loc = (qptr->front+1)%MAX;
}
qptr->front =(qptr->front+1)%MAX;
}

66. while(loc != qptr->rear){
qptr->items[loc] = qptr->items[(loc+1)%MAX];
(loc++)%MAX;
}
qptr->front=f;
if(qptr->rear == 0) /*Decrement rear after removing one
item*/
qptr->rear = MAX -1;
else
qptr->rear--;
return smallest;
}

67. Insert Operation of Priority Queue implemented in C
void insert(struct q *qptr, int item)
{
qptr->rear = (qptr->rear++)%MAX; /*Circular
increment*/
if(qptr->rear == qptr->front){
printf("Queue overflow");
exit(1);
}
qptr->items[qptr->rear]=item;
}

68. void enqueue(pqnode front, pqnode rear, element x)
{
pqnode temp =(pqnode) malloc(sizeof (queue));
if (IS_FULL(temp))
{
printf(“ The memory is fulln”);
exit(1);
}
temp->data = x;
temp->next= NULL;
if (front) { (rear) -> next= temp;}
else front = temp;
rear = temp;
Case Study: List-based Queue Implementation in C: insertion

69. int dequeue(pqnode front)
{
pqnode temp = front;
int x;
if (IS_EMPTY(front))
{
printf(“The queue is emptyn”);
exit(1);
}
x = temp->data;
front = temp->next;
free(temp);
return x;
}
Case Study: List-based Queue
Implementation in C: Deletion

70. Stack vs. Queue vs. Array
• Stack & Queue vs. Array
• Arrays are homogeneous data storage structures while
stacks and queues are derived ADT data storage
structures.
• Stack – ADT that allows push, peep and pop.
• Queue - ADT that allows enqueue and dequeue.
• In an array any item can be accessed through
index, while in these data structures access is
restricted.

71. Real world example of Queue
<?xml version = "1.0"?>
<!-- An author -->
<author>
<name gender = "male">
<first> Art </first>
<last> Gentleman </last>
</name>
</author>

72. THANK YOU
GIVE FEEDBACK
