Power Quality - Dips and Interrutions
•
0 likes•180 views
This document discusses power quality issues related to voltage dips and interruptions. It defines voltage dips as sudden reductions in voltage for short periods of time, followed by recovery to the original voltage. Short interruptions are defined as the disappearance of AC voltage for less than a minute, followed by recovery. Causes of dips include lightning strikes, short circuits, and starting large motors. The document also discusses dip profiles, immunity testing standards IEC 61000-4-11, and classifications of test results.
