Programmable logic controllers (PLCs) are solid-state industrial computer control systems that can store instructions to control machines and processes. PLCs are capable of controlling binary inputs and outputs, performing arithmetic and data manipulation, sequencing, timing, counting, and communication. Modern PLCs are modular, scalable, and programmable via simple programming methods to control industrial automation applications. PLCs use logic gates and binary concepts to read inputs, execute program instructions, and control outputs.

1. 1

2. DEFINITION
•Programmable logic controllers, also called
programmable controllers or PLCs, are solid-
state members of the computer family, using
integrated circuits instead of electromechanical
devices to implement control functions.
•They are capable of storing instructions, such
as sequencing, timing, counting, arithmetic,
data manipulation, and communication, to
control industrial machines and processes.
2

3. 3

4. Small modular PLC
courtesy ABB
courtesy Backmann
mounted on DIN-rail, 24V supply
cheaper (€5000)
not water-proof,
no ventilator
extensible by a parallel bus (flat cable or rail)
4

5. Simple PLC
network binary inputs
analog inputs / outputs
binary outputs
5

6. PLC in a cabinet
CPU1 CPU2
serial connections
redundant
field bus
connection inputs/outputs
6

7. Global players
7

8. • The control system had to be price competitive.
• It had to be capable of sustaining an industrial
environment.
• The I/O interfaces had to be easily replaceable.
• The controller had to be designed in modular form, so
that subassemblies could be removed easily for
replacement or repair.
• It needed the capability to pass data to a central system.
• The system had to be reusable.
• The method used to program it had to be simple. 8

9. TODAY’S PROGRAMMABLE CONTROLLERS
• Faster scan times.
• Small, low-cost.
• High-density input/output (I/O) systems.
• Intelligent, microprocessor-based.
• Mechanical design improvements.
• Special interfaces.
•Peripheral equipment has improved operator interface
techniques. 9

10. 10

11. Programmable controller block diagram
11

12. Block diagram of major CPU components
12

13. Graphic Representation of a Scan
13

14. Input/Output Interface
14

15. 15

16. Personal Computer Used as a
Programming Devices
16

17. Typical programmable controller applications
17

18. 18

19. PLC PRODUCT APPLICATION RANGES
19

20. LADDER DIAGRAMS AND THE PLC
20

21. 21

22. 22

23. Typical programmable controller
features and benefits.
23

24. 24

25. Programmable controller I/O connection diagram showing
no physical connections between the inputs and outputs.
25

26. Remote I/O station installation
26

27. EASE OF MAINTENANCE AND
TROUBLESHOOTING
27

28. Failures in a PLC-based system
28

29. A programming device being used to monitor
inputs and outputs, with highlighted contacts
indicating an ON condition.
29

30. 30

31. DECIMAL NUMBER SYSTEM
31

32. BINARY NUMBER SYSTEM
32

33. 33

34. ASCII Code
representation of the character Z
34

35. Binary Coded Decimal (BCD)
(Thumbwheel switch)
35

36. Gray code
It is one of a series of cyclic codes known as reflected codes and
is suited primarily for position transducers
36

37. 37

38. Binary Concept Using Positive Logic
Binary Concept Using Negative Logic
38

39. AND Gate
39

40. OR Gate
40

41. NOT Function
41

42. 42

43. 43

44. 44

45. 45

46. 46

47. Hardwired relay logic circuit
47

48. ADDRESSES USED IN PLCS
48

49. CONTACT SYMBOLS USED IN PLCS
49

50. 50

51. Multiple contacts
from a PLC output coil
51
