The document provides information about database normalization and different types of joins. It discusses the problems that can occur without normalization such as insertion, update, and deletion anomalies. It then covers the different normal forms including 1NF, 2NF, and 3NF and how to determine if a table meets each normal form. The document also defines different types of joins including inner joins, outer joins, theta joins, and natural joins and provides examples of each.

1. WEL COME
TO
OUR PRESENTATION
18/8/2017

2. PRESENTED
BY: Presented to:
Normalization & JOIN
28/8/2017
Md . Sohag
Em@il : sohag.0315@gmail.com
Daffodil international University

3. NORMALIZATION OF DATABASE
Database Normalization is a technique of organizing the data in the
database. Normalization is a systematic approach of decomposing
tables to eliminate data redundancy and undesirable characteristics like
Insertion, Update and Deletion Anomalies .
 Normalization is used for mainly two purpose
 Eliminating redundant(useless) data.
 The problem usually happens when an existing system uses unstructured file, e.g. in M
8/8/2017 3

4. PROBLEM WITHOUT NORMALIZATION
 Without Normalization, it becomes difficult to handle and update
the database, without facing data loss. Insertion, Updation and
Deletion Anomalies are very frequent if Database is not Normalized.
S_id S_Name S_Address Subject_opted
401 Adam Noida Bio
402 Alex Panipat Maths
403 Stuart Jammu Maths
404 Adam Noida Physics
8/8/2017 4

5. PROBLEM WITHOUT NORMALIZATION
 Updation Anomaly
 Insertion Anomaly
 Deletion Anomaly
S_id S_Name S_Address Subject_opted
401 Adam Noida Bio
402 Alex Panipat Maths
403 Stuart Jammu Maths
404 Adam Noida Physics
8/8/2017 5

6. NORMALIZATION RULE
 Normalization rule are divided into following normal
form :
 First Normal Form
 Second Normal Form
 Third Normal Form
8/8/2017 6

7. FIRST NORMAL FORM(1NF)
THE OFFICIAL QUALIFICATIONS FOR 1NF ARE:
1. Each Attribute Name Must Be Unique.
2. Each Attribute Value Must Be Single.
3. Each Row Must Be Unique.
4. There Is No Repeating Groups.
78/8/2017

8. FIRST NORMAL FORM(1NF)
8
Example of a table not in 1NF :
 It violates the 1NF.
Student Age Subject
Adam 15 Biology, Maths
Alex 14 Maths
Stuart 17 Maths
8/8/2017

9. FIRST NORMAL FORM (1NF)
9
 Now it is in 1NF.
 However, it might still violate 2NF and so on.
Student Age Subject
Adam 15 Biology
Adam 15 Maths
Alex 14 Maths
Stuart 17 Maths
8/8/2017

10. FUNCTIONAL DEPENDENCIES
10
We say an attribute, B, has a functional dependency on another attribute, A, if for any two
records, which have
the same value for A, then the values for B in these two records must be the same. We
illustrate this as:
A  B (read as: A determines B or B depends on A)
employee name  email address
employee name project email address
Sok San POS Mart Sys soksan@yahoo.com
Sao Ry Univ Mgt Sys sao@yahoo.com
Sok San Web Redesign soksan@yahoo.com
Chan Sokna POS Mart Sys chan@gmail.com
Sao Ry DB Design sao@yahoo.com
8/8/2017

11. FUNCTIONAL DEPENDENCIES
11
EmpNum EmpEmail EmpFname EmpLname
123 jdoe@abc.com John Doe
456 psmith@abc.com Peter Smith
555 alee1@abc.com Alan Lee
633 pdoe@abc.com Peter Doe
787 alee2@abc.com Alan Lee
If EmpNum is the PK then the FDs:
EmpNum  EmpEmail, EmpFname, EmpLname
must exist.
8/8/2017

12. FUNCTIONAL DEPENDENCIES
12
EmpNum  EmpEmail, EmpFname, EmpLname
EmpNum
EmpEmail
EmpFname
EmpLname
EmpNum EmpEmail EmpFname EmpLname
8/8/2017

13. DETERMINANT
13
Functional Dependency
EmpNum  EmpEmail
Attribute on the left hand side is known as the
determinant
• EmpNum is a determinant of EmpEmail
8/8/2017

14. SECOND NORMAL FORM(2NF)
THE OFFICIAL QUALIFICATIONS FOR 2NF
ARE:
1. A TABLE IS ALREADY IN 1NF.
2. ALL NONKEY ATTRIBUTES ARE FULLY DEPENDENT ON THE PRIMARY KEY.
ALL PARTIAL DEPENDENCIES ARE REMOVED TO PLACE IN ANOTHER TABLE.
128/8/2017

15. CourseID SemesterID Num Student Course Name
IT101 201301 25 Database
IT101 201302 25 Database
IT102 201301 30 Web Prog
IT102 201302 35 Web Prog
IT103 201401 20 Networking
Example of a table not in 2NF:
Primary Key
The Course Name depends on only CourseID, a part of the primary key
not the whole primary {CourseID, SemesterID}.It’s called partial
dependency.
15
SECOND NORMAL FORM(2NF)
8/8/2017

16. CourseID Course Name
IT101 Database
IT101 Database
IT102 Web Prog
IT102 Web Prog
IT103 Networking
SemesterDone? Oh no, it is still
not in 1NF yet.
Remove the repeating
groups too.
Finally, connect the
relationship.
CourseID Course Name
IT101 Database
IT102 Web Prog
IT103 Networking
CourseID SemesterID Num Student
IT101 201301 25
IT101 201302 25
IT102 201301 30
IT102 201302 35
IT103 201401 20
16
SECOND NORMAL FORM(2NF)
8/8/2017

17. THIRD NORMAL FORM (3NF)
THE OFFICIAL QUALIFICATIONS FOR 3NF ARE:
1. A TABLE IS ALREADY IN 2NF.
2. NONPRIMARY KEY ATTRIBUTES DO NOT DEPEND ON OTHER NONPRIMARY
KEY ATTRIBUTES
178/8/2017

18. StudyID Course Name Teacher Name Teacher Tel
1 Database Sok Piseth 012 123 456
2 Database Sao Kanha 0977 322 111
3 Web Prog Chan Veasna 012 412 333
4 Web Prog Chan Veasna 012 412 333
5 Networking Pou Sambath 077 545 221
Example of a Table not in 3NF:
Primary Key
18
THIRD NORMAL FORM (3NF)
8/8/2017

19. Teacher Name Teacher Tel
Sok Piseth 012 123 456
Sao Kanha 0977 322 111
Chan Veasna 012 412 333
Chan Veasna 012 412 333
Pou Sambath 077 545 221
Done?
Oh no, it is still not in 1NF yet.
Remove Repeating row.
Teacher Name Teacher Tel
Sok Piseth 012 123 456
Sao Kanha 0977 322 111
Chan Veasna 012 412 333
Pou Sambath 077 545 221
Note about primary key:
- In theory, you can choose
Teacher Name to be a primary key.
- But in practice, you should add
Teacher ID as the primary key.
ID Teacher Name Teacher Tel
T1 Sok Piseth 012 123 456
T2 Sao Kanha 0977 322
111
T3 Chan Veasna 012 412 333
T4 Pou Sambath 077 545 221
StudyID Course Name T.ID
1 Database T1
2 Database T2
3 Web Prog T3
4 Web Prog T3
5 Networking T4
198/8/2017

20. JOIN
 Join Is A Special Form Of Cross Product
Of Two Tables.
 In Cartesian Product We Join A Tuple Of
One Table With The Tuples Of The
Second Table. But In Join There Is A
Special Requirement Of Relationship
Between Tuples.
8/8/2017 20

21. JOIN TYPES
SQL JOIN
Inner
Join
Outer
Join
Self Join
Cross
Join
Theta Join
Equi Join
Natural
Join
Left Outer JOIN
Right Outer
JOIN
Full Outer JOIN 8/8/2017 21

22. INNER JOIN
AN INNER JOIN IS THE MOST COMMON JOIN OPERATION USED IN
APPLICATIONS AND CAN BE REGARDED AS THE DEFAULT JOIN-
TYPE.
 INNER JOIN CREATES A NEW RESULT TABLE BY COMBINING
COLUMN VALUES OF TWO TABLES (A AND B) BASED UPON THE
JOIN-PREDICATE.
8/8/2017 22

23. Θ-JOIN
CONSIDER TABLES CAR AND BOAT WHICH LIST MODELS OF CARS
AND BOATS AND THEIR RESPECTIVE PRICES.
 SUPPOSE A CUSTOMER WANTS TO BUY A CAR AND A BOAT, BUT
SHE DOES NOT WANT TO SPEND MORE MONEY FOR THE BOAT
THAN FOR THE CAR.
8/8/2017 23

24. EQUI JOIN
AN EQUI-JOIN, ALSO KNOWN AS AN EQUIJOIN, IS A SPECIFIC TYPE
OF COMPARATOR-BASED JOIN, OR THETA JOIN, THAT USES
ONLY EQUALITY COMPARISONS IN THE JOIN-PREDICATE. USING
OTHER COMPARISON OPERATORS (SUCH AS <) DISQUALIFIES A
JOIN AS AN EQUI-JOIN.
8/8/2017 24

25. EQUI JOIN EXAMPLE
8/8/2017 25

26. NATURAL JOIN
NATURAL JOIN ( ) IS A BINARY OPERATOR THAT IS WRITTEN AS
(R S) WHERE R AND S ARE RELATIONS.
 IN PARTICULAR, NATURAL JOIN ALLOWS THE COMBINATION OF
RELATIONS THAT ARE ASSOCIATED BY A FOREIGN KEY.
8/8/2017 26

27. OUTER JOIN
 An Outer Join Does Not Require Each Record In The Two Joined
Tables To Have A Matching Record. The Joined Table Retains Each
Record—even If No Other Matching Record Exists.
8/8/2017 27

28. LEFT OUTER JOIN
The Result Of A Left Outer Join (Or Simply Left Join) For Table A And B Always
Contains All Records Of The "Left" Table (A), Even If The Join-condition Does
Not Find Any Matching Record In The "Right" Table (B).
Employee
Dept
Employee =X Dept
8/8/2017 28

29. LEFT OUTER JOIN EXAMPLE
8/8/2017 29

30. RIGHT OUTER JOIN
A RIGHT OUTER JOIN (OR RIGHT JOIN) CLOSELY RESEMBLES A LEFT OUTER JOIN,
EXCEPT WITH THE TREATMENT OF THE TABLES REVERSED
Employee X= Dept
Employee
Dept
8/8/2017 30

31. RIGHT OUTER JOIN EXAMPLE
8/8/2017 31

32. FULL OUTER JOIN
Conceptually, A Full Outer Join Combines The Effect Of Applying Both Left And
Right Outer Joins.
Employee =X= Dept
Employee
Dept
8/8/2017 32

33. FULL OUTER JOIN (EXAMPLE)
8/8/2017 33

34. 8/8/2017 34
