Mastering selenium for automated acceptance tests

Nick Belhomme January 26th, PHPBenelux Conference 2013, Belgium

Nick Belhomme
International Conference Speaker

Contributor to various Open Source
Projects

Building Constructor

Software Architect / Project Lead

Loving Husband

Freelance PHP Consultant

PHP QA trainer

Your host for the upcoming hour

Selenium
34
Claims, Benefits:

Prevents cancer

Aging

Selenium – the web browser
automation tool set

Acceptance Tests
● System tests
● Black box
● Functional testing

Browser Compatibility Tests
● Different Browsers
● Different Operating Systems

Regression Tests

● Internal Changes
● Partner Changes

Tools
● Humans
● Capture and replay
● Scripts and bots
● Selenium

Manual Testing
● Time-intensive
● Nerve-stretching
● Human error / understanding of the flow
● Costly

Capture and Replay
● Captures mouse movements and inputs
● Replays later
● Screenresolution, operating systems, window
sizes, makes this very unmaintainable

Scripts and Bots
● Bot makes screen-shots, analyzes them for
visual blocks
● Calculates visual blocks x-y positions and
generates mouse clicks on that location and
user input.
● Generating a test is time-intensive
● Error prone on design changes.

Selenium
● Records and playback browser tests
● Asserts on DOM
● Javascript is being executed and testable
● Css selectors or xpath position sensitive
● Hard to detect layout errors

Learning Curve

● Jump in quickly
● Steep – If you want to do it right
● Mastering it – creating readable,
understandable, maintainable and robust tests -
takes time and effort.

Worth it

Ask a Salary
Increase
and
own a second
modest
vacation property

And as an added bonus
● Better code architecture
● More functional code
● High browser compatibility
● No more regressions
● Neat cool stuff to brag about at your local pub!!!

Selenium IDE
Firefox Plugin:
http://release.seleniumhq.org/selenium-ide/1.10.0/selenium-ide-1.10.0.xpi

●
Easy record and playback
● Intelligent field selection will use IDs, names, or XPath as needed
●
Autocomplete for all common Selenium commands
● Walk through tests
●
Debug and set breakpoints
● Save tests as HTML, PHPUnit, or any other format
●
Support for Selenium user-extensions.js file
●
Option to automatically assert the title of every page
●
Easy customization through plugins

X-forwarding
run software on remote machine and display the GUI locally

● Linux and Mac OS X support X Forwarding with no extra
software
ssh -X
● Windows needs extra software
Xming

Xming
(X-forwarding for windows)

http://sourceforge.net/projects/xming/files/latest/download

Configure Xming
Windows Start => Xming => XLaunch
Display settings dialog box:
Multiple windows
Display number as 0
Keep clicking next then Finish.

Putty (windows)

● Connection => SSH => X11
● Enable X11 forwarding
● Set X display location as :0.0

Setting it up server side
(headless)

Firefox

● [64 bit] wget
http://download-origin.cdn.mozilla.net/pub/mozilla.org/firefox/relea
● [32 bit] wget
http://download-origin.cdn.mozilla.net/pub/mozilla.org/firefox/relea

● tar -jxvf firefox-18.0.tar.bz2 -C /opt
● ln -s /opt/firefox/firefox /usr/bin/firefox
●
Firefox (No X-Display needed thanks to forwarding)

Completely headless
(no X-forwarding)
● Install Xvfb
aptitude install Xvfb
● Update to latest java version
aptitude install sun-java6-jre
● Download the latest Selenium Server Jar
package
wget http://selenium.googlecode.com/files/selenium-
server-standalone-2.28.0.jar

Test driving Selenium RC
(X-forwarding)

To test-drive it is always easier to first use X-forwarding:

java -jar selenium-server-standalone-2.28.0.jar -htmlSuite
*firefox "http://www.domaintocheck.com"
“/path/to/selenium/testSuite.html”
“/path/where/selenium/should/store/results.html”

testSuite.html and related files are the files saved by Selenium IDE

Test driving Selenium RC
(X Virtual Frame Buffer)
● Open a connection and run Xvfb
Xvfb :99

● Open another connection and run selenium

export DISPLAY=:99 & java -jar selenium-server-
standalone-2.28.0.jar -htmlSuite *firefox
"http://www.domaintocheck.com"
“/path/to/selenium/testSuite.html”
“/path/where/selenium/should/store/results.html”

Integrate into

Make certain your Jenkins server is started with Xvfb run on :99
● Check with:
ps -ef | grep Xvfb
● If not running then issue a
Xvfb :99
CTRL + Z
● Log into Jenkins: manage Jenkins -> Manage Plugins
install “Hudson Seleniumhq plugin”

Setup a Job
● Create a new freestyle job

Problem
● remote control is slow at driving the browser.

● limited number of concurrent tests on the same
remote control before seriously impacting its
stability.

● Multiple Selenium Remote Controls In Jenkins
to work around the limitation on the number of
parallel tests.

The Grid

● Run tests against multiple browsers

● multiple versions of browser

● browsers running on different operating systems

● To reduce the time it takes for the test suite to
complete a test pass.

The Hub
● 1 instance

● Allocating a Selenium Remote Control to a specific
test (transparently)

● Limiting the number of concurrent test runs on each
Remote Control

● Shielding the tests from the actual grid
infrastructure

A Node
● Remote Control

● Multiple instances (across machines preferably)

● Multiple Browsers

● Can be configured using a json file

● Start the hub
java -jar selenium-server-standalone-2.28.0.jar -role hub

● Start nodes on separate machines
java -jar selenium-server-standalone-2.28.0.jar -role
node -hub http://hub-address:4444/grid/register

http://hub-address:4444/grid/console

Optimizing a Node with js
● java -jar selenium-server-standalone-2.28.0.jar -role node -nodeConfig nodeConfig.js

//nodeConfig.js
{
"class":"org.openqa.grid.common.RegistrationRequest",
"capabilities":[
{
"platform":"VISTA",
"seleniumProtocol":"Selenium",
"browserName":"*firefox",
"maxInstances":5
},
{
"platform":"VISTA",
"seleniumProtocol":"Selenium",
"browserName":"*iexplore",
"maxInstances":1
}
],

"configuration":{
"port":5555,
"register":true,
"host":"node-address",
"proxy":"org.openqa.grid.selenium.proxy.DefaultRemoteProxy",
"maxSession":5,
"role":"node",
"hubHost":"hub-address",
"registerCycle":5000,
"hub":"http://hub-address:4444/grid/register",
"hubPort":4444,
"url":"http://node-address:5555",
"remoteHost":"http://node-address:5555"
}
}

Run the suite
● No Native HTML Selenese tests support

● Web driver needed

● PHPUnit

+ Selenium Web Driver

wget http://pear.phpunit.de/get/phpunit.phar
chmod +x phpunit.phar

Selenium-ide-php-formatters

Convert Html Selenese tests to PHPUnit test
cases

Firefox Addon:
https://addons.mozilla.org/en-US/firefox/addon/selenium-ide-
php-formatters/

The test case

<?php
class Example extends PHPUnit_Extensions_SeleniumTestCase
{
protected function setUp()
{
$this->setBrowser("*iexplore");
$this->setBrowserUrl("http://www.nickbelhomme.com/");
}

public function testMyTestCase()
{
$this->open("/");
$this->assertTrue($this->isElementPresent("link=About"));
$this->assertTrue($this->isElementPresent("link=Consulting & Training"));
$this->assertTrue($this->isElementPresent("link=Blog"));
$this->assertTrue($this->isElementPresent("link=Contact"));
$name = $this->getEval(""nick"==="nick"");
}
}
?>

Run the test case
php phpunit.phar testcases/testMenu.php

Run the test suite
php phpunit.phar testcases

Use multiple browsers
public static $browsers = array(
array(
'name' => 'Firefox',
'browser' => '*firefox',
'host' => 'hub-address',
'port' => 4444,
'timeout' => 30000,
),
array(
'name' => 'Internet Explorer',
'browser' => '*iexplore',
'host' => 'hub-address',
'port' => 4444,
'timeout' => 30000,
)
);

protected function setUp()
{
$this->setBrowserUrl('http://www.example.com/');
}

Use raw Html Selenese test

public function testMenu()
{
$this->runSelenese('testMenu.html')
}

Use raw Html Selenese testsuite

public static $seleneseDirectory = '/path/to/files';

With Paratest
Parallel PHPUnit – running tests concurrently

● Support for annotated tests
● Inheritance
● Tests suites
● Test methods
● Reflection driven

composer install
// composer.json
{
"require": {
"brianium/paratest": "dev-master",
"phpunit/dbunit": ">=1.2",
"phpunit/php-invoker": "*",
"phpunit/phpunit-selenium": ">=1.2",
"phpunit/phpunit-story": "*"
}
}

PHPUnit

Paratest + PHPUnit

References
● X-Forwarding:
http://en.gentoo-wiki.com/wiki/X-Forwarding
http://www.straightrunning.com/XmingNotes/
● Xvfb
http://www.x.org/releases/X11R7.6/doc/man/man1/Xvfb.1.xhtml
● Driving Selenium with PHPUnit
http://www.phpunit.de/manual/3.8/en/selenium.html
● Selenium Hq
http://seleniumhq.org/docs/index.jsp
● Composer
http://getcomposer.org
● Paratest
http://brianscaturro.com/2012/11/02/parallel-phpunit.html

Troubleshooting
● Firefox install dependencies
http://www.thinkplexx.com/learn/howto/linux/system/installing-
and-running-firefox-on-debian-linux-getting-missing-
dependencies-shared-libs
● Specify different ports in Jenkins for each RC when not using
the grid
● Proxy settings in Browser – use X-Forwarding to run Browser
and change settings, use profile as a RC param when needed.

Link to slides and other updates is
available at
http://www.facebook.com/NickBelhommeFanPage

The End!

THANK YOU
Please rate my talk
https://joind.in/7796
contact@nickbelhomme.com

Slideshare, Twitter, IRC: NickBelhomme

http://blog.nickbelhomme.com
