#ATAGTR2021 Presentation - "Selenium 4 Observability – a 90 Min Hands on Lab"

SELENIUM 4.0 GRID OBSERVABILITY
LAB
#ATAGTR2021 DAY 2 12TH DECEMBER 2021
Aditya Garg

MY SOCIAL MEDIA HANDLES
https://twitter.com/adigindia
https://www.linkedin.com/in/adigarg/

WHAT WILL BE
COVERED
1. Selenium Grid and importance of traceability in Distributed architecture
2. Understanding Observability components in Selenium 4.0 and installing
coursier
3. Setting up a GCP machine with docker
4. Opening up necessary ports
5. Running Jaeger on the GCP machine
6. Setting up traceability in SeleniumGrid 4.0
7. Executing the tests and observing the trace

Have you worked on Java and Selenium before (yes or no)
ⓘ Start presenting to display the poll results on this slide.

Have you worked in Selenium Grid before
ⓘ Start presenting to display the poll results on this slide.

MORE QUESTIONS
1. How many of you would be participating in this Lab with me ?
2. Do you have your laptops ready ?
3. Do you have the following installed
1. JDK 1.8
2. Maven
4. Do you have PowerShell installed ?
5. Do you have your account with GCP ?

CHECKS CONTINUED
1. Double check on few things
Follow along with me
1. Java check
2. Maven check
3. Selenium 4.0 latest Jar
4. Powershell check
5. GCP account
https://docs.microsoft.com/en-
us/powershell/scripting/install/installing-powershell-on-
windows?view=powershell-7.2#msi
https://www.selenium.dev/downloads/
https://ataevents.online/LabGuideATAGTR2021

SELENIUM GRID AND IMPORTANCE OF
TRACEABILITY/OBSERVABILITY IN
DISTRIBUTED ARCHITECTURE

Grid
3.X
1. Multiple nodes
Ref: https://www.lambdatest.com/blog/selenium-grid-4-tutorial-for-distributed-testing/

Grid
4.0
Ref: https://www.browserstack.com/guide/selenium-grid-4-tutorial

What
can
go
wrong
Any of the process Any of the nodes
• Imagine running your tests
on a fully distributed
architecture and things are
not going as planned.
• How do you trace or observe
your request going through
multiple processes and
running on a node (specially
if things are not working as
planned)
This is where observability comes in
We can trace every request in a time series manner

OpenTelemetry
Grid 4.0 is special in more than
many ways
1. It is designed to work with
modern infrastructures like
docker and Kubernetes
2. The code is by default
instrumented with
OpenTelemetry

OpenTelemetry 1. Telemetry Data such as
traces, metrics and logs
2. Popular Opensource
Backends (which help
us analyze or use this
data)
a. Jaeger
b. Prometheus

Grid
4.0
is
fully
observable Grid 4.0 is special in more than
many ways
1. It is designed to work with
modern infrastructures like
docker and Kubernetes
2. The code is by default
instrumented with
OpenTelemetry
This is where the entire request responses telemetry data ((metrics, logs, and traces) can be
instrumented, collected, and exported to help us analyze our Grid’s performance and behavior.
Selenium 4 Grid is thus fully observable – it helps us troubleshoot issues, optimize performance, and
provide visibility into the system

Selenium
Grid
4
Observability
components
1
Open Telemetry which is instrumented in the
Selenium 4.0 Jar files or code itself.
• This helps in tracing every requests lifecycle
• Trace contains details about the information called as spans
• Span records time logs – called as events
• All these are nothing but some form of logs – which we were
already used to see on a command prompt.
• This can be configured easily to send all the data to a backend
data consolidator – Jaeger

Selenium
Grid
4
Observability
components
• Since Console logs becomes too tedious to query and analyze
• We need a mechanism for visualizing and querying traces
• Jaeger seamlessly integrates with OpenTelemetry to provide a
rich experience of querying, visualizing and collecting request
traces
https://www.jaegertracing.io/
2
The second player in the Selenium 4.0
Observability is Jaeger

LET US GET INTO SOME ACTION
1
2
3
Using Selenium 4.0 Jar
Installing coursier – which is used for updating the classpath for tracer (open telemetery)
Running Jaeger
We can install using binaries or run docker through docker images

Selenium
Grid
4
Observability
Setup
java -jar selenium-server-4.1.0.jar info tracing
This example uses a tool called "coursier" to generate a full classpath, but
you can also write this manually. When started this way, the selenium
server will inform you that it has found a tracer on stdout.
1

Selenium
Grid
4
Observability
Setup
2
Installing coursier – which is used for updating the
classpath for tracer (open telemetery)
https://get-coursier.io/docs/overview#coursier
https://get-coursier.io/docs/cli-installation

Selenium
Grid
4
Observability
Setup

Selenium
Grid
4
Observability
Setup
3
Running Jaeger
docker run -d --name jaeger -p 16686:16686 -p 14250:14250
jaegertracing/all-in-one:latest

Selenium
Grid
4
Observability
Setup
Do you have docker installed on your machine ?

Selenium
Grid
4
Observability
Setup
https://console.cloud.google.com
1. We will create a VM with pre-
installed docker
2. Open required ports
3. Install and run Jaeger
4. If you already have docker installed,
you do not need these steps.

Docker Engine Community on Ubuntu 18.04 LTS

Selenium
Grid
4
Observability
Setup docker run -d --name jaeger -p 16686:16686 -p 14250:14250
We will run our docker VM in a GCP
Open ports 16686 and also 14250 for our telemetry needs
Run the Jaeger image

Selenium
Grid
4
Observability
Setup
2 Running Jaeger
docker run -d --name jaeger -p 16686:16686 -p 14250:14250

Selenium
Grid
4
Observability
Setup
3
Running Selenium Grid with OpenTelemetery Java extension classes
connected to the running instance of Jaeger
We will be running distributed grid

Selenium
Grid
4
Observability
Setup
3
java -D"otel.traces.exporter=jaeger" -
D"otel.exporter.jaeger.endpoint=http://164.52.192.223:14250" -
D"otel.resource.attributes=service.name=selenium-event-bus" -jar
selenium-server-4.0.0-rc-2.jar --ext $(cs fetch -p
io.opentelemetry:opentelemetry-exporter-jaeger:1.0.0 io.grpc:grpc-
netty:1.35.0) event-bus
a
Start Event Bus – connect to Jaeger and enable opentelemetry using –
ext option using coursier

Selenium
Grid
4
Observability
Setup
3
D"otel.resource.attributes=service.name=selenium-sessions" -jar
netty:1.35.0) sessions
b Start sessionMap – connect to Jaeger and enable opentelemetry
using –ext option using coursier

Selenium
Grid
4
Observability
Setup
3
D"otel.resource.attributes=service.name=selenium-session-queue" -jar
netty:1.35.0) sessionqueue
c Start sessionQueue – connect to Jaeger and enable
opentelemetry using –ext option using coursier

Selenium
Grid
4
Observability
Setup
3
D"otel.resource.attributes=service.name=selenium-distributor" -jar
netty:1.35.0) distributor --sessions http://localhost:5556 --sessionqueue
http://localhost:5559 --bind-bus false
d Start distributor – connect to Jaeger and enable opentelemetry
using –ext option using coursier

Selenium
Grid
4
Observability
Setup
3
D"otel.resource.attributes=service.name=selenium-router" -jar selenium-
server-4.0.0-rc-2.jar --ext $(cs fetch -p
netty:1.35.0) router --sessions http://localhost:5556 --sessionqueue
http://localhost:5559 --distributor http://localhost:5553
e Start router – connect to Jaeger and enable opentelemetry using –

Selenium
Grid
4
Observability
Setup
3
D"otel.resource.attributes=service.name=selenium-node" -jar selenium-
server-4.0.0-rc-2.jar --ext $(cs fetch -p
netty:1.35.0) node
f Start node – connect to Jaeger and enable opentelemetry using –

Selenium
Grid
4
Observability
Setup
4
Add the necessary telemetry dependencies in selenium client
and run the code
a Add telemetry related dependencies in POM file
https://gitlab.com/adigindia/atagtr2021selenium4observability

Selenium
Grid
4
Observability
Setup
<dependency>
<groupId>io.opentelemetry</groupId>
<artifactId>opentelemetry-exporter-jaeger</artifactId>
<version>1.0.0</version>
</dependency>
<dependency>
<groupId>io.grpc</groupId>
<artifactId>grpc-netty</artifactId>
<version>1.35.0</version>
</dependency>

<dependency>
<groupId>com.google.guava</groupId>
<artifactId>guava</artifactId>
<version>31.0.1-jre</version>
</dependency>

<dependency>
<groupId>io.netty</groupId>
<artifactId>netty-handler</artifactId>
<version>4.1.68.Final</version>
</dependency>
a
Add telemetry
related
dependencies in
POM file
4
Add the necessary
telemetry dependencies in
selenium client and run the
code

Selenium
Grid
4
Observability
Setup
4
Add the necessary telemetry dependencies in selenium client and run
the code
b Add system properties in selenium client code
System.setProperty("otel.traces.exporter", "jaeger");
System.setProperty("otel.exporter.jaeger.endpoint",
"http://164.52.192.223:14250");
System.setProperty("otel.resource.attributes", "service.name=selenium-java-client");
ImmutableCapabilities capabilities = new ImmutableCapabilities("browserName",
"chrome");
driver = new RemoteWebDriver(new URL(hubURL), capabilities);
String hubURL = "http://localhost:4444";

BRING NODE DOWN AND
OBSERVE ON JAEGER

Key
references
1. https://www.selenium.dev/blog/2021/selenium-4-observability/
2. https://www.selenium.dev/documentation/webdriver/remote_webdriver/
3. https://github.com/manoj9788/tracing-selenium-grid
4. https://get-coursier.io/docs/cli-installation
5. https://www.ibm.com/docs/en/sdk-java-technology/7.1?topic=jjc-specifying-java-
options-system-properties-2
6. https://github.com/SeleniumHQ/selenium/blob/selenium-4.0.0-beta-
1/java/server/src/org/openqa/selenium/grid/commands/tracing.txt
7. https://opentelemetry.io/docs/java/
8. https://www.lambdatest.com/blog/selenium-grid-4-tutorial-for-distributed-testing/
9. https://www.browserstack.com/guide/selenium-grid-4-tutorial
10.https://docs.docker.com/compose/environment-variables/
11.https://github.com/SeleniumHQ/docker-selenium

THANK YOU
https://twitter.com/adigindia
https://www.linkedin.com/in/adigarg/
