1. 1© 2004, Cisco Systems, Inc. All rights reserved.
Module 10
Routing Fundamentals and
Subnets

2. 222© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Objectives

3. 333© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
IP Address

4. 444© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
IP Address Grouping

5. 555© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routed and Routing Protocols
• Consider that a packet needs to be sent from node A
to node F. How would it decide which path to take?

6. 666© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routing Protocol vs Routed Protocol
• A routed protocol
1. defines the end to end addressing and the
packet format of a packet that is forwarded
between nodes on different networks.
Internet Protocol (IP) is a routed protocol
• A routing protocol
1. exchanges topology information with adjacent
routers to update and maintain their routing tables.
2. selects the best path through a network
RIP is a routing protocol

7. 777© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routed Protocol
• A protocol is a set of rules
• A routed protocol is a set of rules that determines how
computers at the source and destination communicate
with each other across networks
– packet format
– end to end addressing
• In order for a protocol to be routable, it must provide the
ability to assign both a network number and a host
number for each individual device.

8. 888© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Internet Protocol IP
• IP is a connectionless, unreliable, best-effort delivery protocol
• As information flows down the layers of the OSI model, the data is
processed at each layer.
• IP accepts whatever data is passed down to it from the upper layers.

9. 999© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
IP Packet Header

10. 101010© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Network Layer Devices in Data Flow
• As a frame is received at a
router interface.
• The MAC address is checked
to see if the frame is directly
addressed to the router
interface, or a broadcast.
• The frame header and trailer
are removed and the packet is
passed up to Layer 3.
• The destination IP address is
compared to the routing table
to find a match.
• The packet (datagram) is
placed in a new frame with the
MAC address of the next hop
interface.
• The frame is then transmitted.
If a match is found or there is a default
route, the packet will be sent to the
interface specified in the matched routing
table statement otherwise packet is
discarded

11. 111111© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Packets Travel Across Links in a Frame
• Packets NEVER travel through the network – they are carried within frames
• A new frame MUST be created to carry the packet over each individual link
• Routers provide the IP address of the next hop interface (router or host)
• The ARP table provides the MAC address of this IP address for the frame destination

12. 121212© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Connectionless vs. Connection-Oriented
• In a connection oriented system is established
between the sender and the recipient before any
data is transferred.
– example: Telephone
• In a connectionless system, the destination is not
contacted before a packet is sent.
– example: Postal system
• TCP is connection oriented
• IP is connectionless

13. 131313© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Connectionless Network Services
• The Internet is a huge network where packets are routed according to their
IP addresses.
• IP is unreliable and best-effort as IP does not verify that the data reached its
destination and therefore does not resend missing packets.
• Reliability and resending of packets is handled by the upper layer protocols.
• IP may be used in conjunction with TCP to add a Layer 4, connection-
oriented service that checks for missing segments and resends them to
provide reliability.

14. 141414© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
The IPv4 Packet Header
Time-to-live (TTL)
Count Decreases with every hop
This prevents packets from
looping endlessly.

15. 151515© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routing

16. 161616© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
The Network Layer

17. 171717© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routing
• Routing is an OSI Layer 3 function.
• Routers connect networks (or subnetworks)
• Routing is the process of finding the most efficient
path from one device to another (router)
• Routers must maintain routing tables and make sure
other routers know of changes in the network
topology. This function is performed using a routing
protocol to communicate network information with
other routers

18. 181818© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routing Through a Network
• A router is a network layer device that uses one or more
routing metrics to determine the optimal path through the
network

19. 191919© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routing Metrics

20. 202020© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Data Encapsulation

21. 212121© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Layer 3 Routing and Layer 2 Switching

22. 222222© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routers Reduce the Size of Broadcast Domains
• Routers block LAN broadcasts, so a broadcast
storm only affects the broadcast domain from which
it originated
• Switched networks do not block broadcasts

23. 232323© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routing and Switching in a Network

24. 242424© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
ARP Tables and Routing Tables

25. 252525© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
The difference between a routed and routing
protocol – revisited

26. 262626© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routed Protocol

27. 272727© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routing Protocol

28. 282828© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routed Vs Routing protocols
• A Routed Protocol:
– A network protocol suite that provides enough information in its network
layer address to allow a router to forward it to the next device and ultimately
to its destination.
– Defines the format and use of the fields within a packet.
– The Internet Protocol (IP) and Novell's Internetwork Packet Exchange (IPX),
DECnet, AppleTalk, Banyan VINES, and Xerox Network Systems (XNS)
• A Routing Protocol:
– Provides processes for sharing route information. Exchange topology info.
To determining the best routing paths and transporting packets through an
internetwork
– Also allows routers to communicate with other routers to update and
maintain the routing tables.
– Routing Information Protocol (RIP), Interior Gateway Routing Protocol
(IGRP), Open Shortest Path First (OSPF), Border Gateway Protocol (BGP),
and Enhanced IGRP (EIGRP).

29. 292929© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Back to Routing

30. 303030© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Path Determination

31. 313131© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Path Determination

32. 323232© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routing Tables
• Routing tables contain the best routes to all known
networks.
• These routes can be either
– Static routes, which are entered manually by the system
administrator
– Or dynamic routes, which are constructed from
information passed between adjacent routers.
• A routing table entry contains:
– Each Destination
– The next hop IP address to reach that destination
– The metric for the route via that next hop
– Outbound router interface for the next hop

33. 333333© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routing Tables

34. 343434© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routing Algorithms and Metrics
• Routing protocols have one or more of the following
design goals:
Optimization
Simplicity and low overhead
Robustness and stability
Flexibility
Rapid convergence

35. 353535© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Routing Algorithms and Metrics

36. 363636© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Interior and Exterior Gateway Protocols

37. 373737© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Interior and Exterior Gateway Protocols
• IGPs route data within an autonomous system.
RIP, RIPv2, IGRP, EIGRP, OSPF, IS-IS
• EGPs route data between autonomous systems
Border Gateway Protocol (BGP)

38. 383838© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Interior Gateway Routing Protocols
• Link State and Distance Vector Routing Protocols
• Examples of distance-vector protocols:
Routing Information Protocol (RIP)
Interior Gateway Routing Protocol (IGRP)
Enhanced IGRP (EIGRP)
• Examples of link-state protocols:
Open Shortest Path First (OSPF)
Intermediate System-to-Intermediate System (IS-IS)

39. 393939© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Mechanics of Subnetting

40. 404040© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Subnetting
• Reasons for subnetting
– Provides addressing flexibility for the network
administrator.
• Each LAN must have its own network or subnetwork
address.
– Provides broadcast containment and low-level security on
the LAN.
– Provides some security since access to other subnets is
only available through the services of a router.

41. 414141© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
IP Address Bit Patterns

42. 424242© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Introduction to Subnetting
• Host bits must are
reassigned (or
“borrowed”) as
network bits.
• The starting point is
always the leftmost
host bit.
3 bits borrowed allows 23
-2 or 6 subnets
5 bits borrowed allows 25
-2 or 30 subnets
12 bits borrowed allows 212
-2 or 4094 subnets

43. 434343© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Subnetting Chart (Bit Position and Value)

44. 444444© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Subnetting Chart (Subnet Mask Identifier)

45. 454545© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Subnetting

46. 464646© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Subnetting Chart

47. 474747© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Subnetting Example
• This is an example of subnetting the 192.168.10.0 class C
network into 8 subnets with 32 host addresses per subnet
• Note that the first and last subnets are not used (the first can be)
• Also the first and last host address in each subnet are not used

48. 484848© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Example Host IP Address from Subnet 2
Packet Address 192.168.10.65 11000000.10101000.00001010.010 00001
Subnet Mask 255.255.255.224 11111111.11111111.11111111.111 00000
Subnet Address 192.168.10.64 11000000.10101000.00001010.010 00000
• The subnet mask is ANDed with the packet address to
determine the subnet address - as shown in the next slides

49. 494949© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
The Logical ANDing Process

50. 505050© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Calculating the Subnet ID

51. 515151© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Subnet Mask Defines the Number of Subnets

52. 525252© 2004, Cisco Systems, Inc. All rights reserved.
www.pnj.ac.id
Summary
