The document describes pneumatic breakers made by Chicago Pneumatic for demolition and construction work. The new generation of CP breakers deliver power and durability for tough jobs while being easier for operators to use with streamlined designs. Models include the CP 1260 and CP 1290 which provide more power yet are lighter weight than previous models. The breakers are designed to be comfortable and efficient for operators.
