GitFlow is a branching model for Git, created by Vincent Driessen. It has attracted a lot of attention because it is very well suited to collaboration and scaling the development team

1. Presented By: Mansi Babbar
Introduction to
Git Flow

2. Lack of etiquette and manners is a huge turn off.
KnolX Etiquettes
Punctuality
Respect Knolx session timings, you
are requested not to join sessions
after a 5 minutes threshold post
the session start time.
Feedback
Make sure to submit a constructive
feedback for all sessions as it is
very helpful for the presenter.
Mute
Please keep your window on mute
Avoid Disturbance
Avoid leaving your window
unmuted after asking a question

3. Agenda
01 Introduction
02 How Git Flow Works?
04 Release Branch
05 Hotfix Branch
06 Summary
05 Demo
07
7
Feature Branch
03

4. Introduction

5. Introduction
● Git Flow is Git workflow design
● Defines a strict branching model designed around the project release
● This provides a robust framework for managing larger projects
● Suited for projects having scheduled release cycle and continuous delivery
● Assigns specific roles to different branches
● Defines how and when the branches should inteact

6. Introduction
● Command line tool with an installation process
● Git Flow is a wrapper around Git
● After installing git-flow you can use it in your project by executing git flow init
● git flow init is extension of default command git init

7. How it Works?

8. Develop & Master
Branches

9. Develop and Master Branches
Based on two main branches with infinite lifetime:
○ master — this branch contains production code. Stores official release
history
○ develop — this branch contains pre-production code. Serves as an
integration branch for features
○ It is also convenient to tag all commits in the master branch with a
version number

10. Develop and Master Branches

11. Develop and Master Branches

12. Develop and Master Branches

13. Feature Branch

14. Feature Branch
● Each new feature should reside in its own branch
● Feature branches use develop as their parent branch
● When a feature is complete, it gets merged back into develop
● Features should never interact directly with master

15. Feature Branch

16. Creating a Feature Branch
● Without git-flow extensions:
○ git checkout develop
○ git checkout -b feature_branch
● With git-flow extension:
○ git flow feature start feature_branch

17. Finishing a Feature Branch
● Without git-flow extensions:
○ git checkout develop
○ git merge feature_branch
● With git-flow extensions:
○ git flow feature finish feature_branch

18. Release Branch

19. Release Branch
● Once develop has acquired enough features for a release, fork a
release branch off of develop
● Creating this branch starts the next release cycle, so no new
features can be added after this point
● Allow many minor bug to be fixed and preparation of meta-data
for a release
● Must merge into master and develop

20. Release Branch

21. Creating a Release Branch
● Without the git-flow extensions:
○ git checkout develop
○ git checkout -b release/0.1.0
● When using the git-flow extensions:
○ $ git flow release start 0.1.0
○ Switched to a new branch 'release/0.1.0'

22. Finishing a Release Branch
● Without git-flow extensions:
○ git checkout master
○ git merge release/0.1.0
● With git-flow extension:
○ git flow release finish 0.1.0

23. Hotfix Branch

24. Hotfix Branch
● Used to quickly patch production releases
● Created to act immediately upon an undesired status of master
● Based on master instead of develop
● Only branch that should fork directly off of master
● As soon as the fix is complete, it should be merged into both
master and develop

25. Hotfix Branch

26. Creating a Hotfix Branch
● Without git-flow extensions:
○ git checkout master
○ git checkout -b hotfix_branch
● With git-flow extensions:
○ $ git flow hotfix start hotfix_branch

27. Finishing a Hotfix Branch
● Without git-flow extensions:
○ git checkout master
○ git merge hotfix_branch
○ git checkout develop
○ git merge hotfix_branch
● With git-flow extension:
○ git branch -D hotfix_branch
○ $ git flow hotfix finish hotfix_branch

28. Demo

29. Summary

30. Summary
Gitflow is one of many styles of Git workflows you and your team
can utilize.
Some key takeaways to know about Gitflow are:
● The workflow is great for a release-based software workflow.
● Gitflow offers a dedicated channel for hotfixes to production.

31. Advantages
● Ensures a clean state of branches at any given moment in the life cycle of
project
● The branches naming follows a systematic pattern making it easier to
comprehend
● It has extensions and support on most used git tools
● It is ideal when there it needs to be multiple version in production

32. Disadvantages
● The Git history becomes unreadable
● The master/develop split is considered redundant
● It isn’t recommended when it need to maintain single version in production

33. Overall Flow of Git Flow
● A develop branch is created from master
● Feature branches are created from develop
● When a feature is complete it is merged into the develop branch
● A release branch is created from develop
● When the release branch is done it is merged into develop and master
● If an issue in master is detected a hotfix branch is created from master
● Once the hotfix is complete it is merged to both develop and master
