State Estimation of Power System with Interline Power Flow ControllerIDES Editor
Now-a-days Flexible A.C. Transmission
System (FACTS) controllers are incorporated into the
power system network to control the power flow and
enhance system stability. Traditional state estimation
methods without integrating FACTS devices will not be
suitable for power systems embedded with FACTS
controller. Based on the conventional power system state
estimation model, a new method is proposed wherein an
IPFC based power injection model is incorporated in the
state estimation algorithm. Interline power flow controller
(IPFC) is one of the versatile FACTS device. The
proposed method is tested on Anderson and Fouad 9-bus
test system and the results are presented.
Power System State Estimation - A ReviewIDES Editor
The aim of this article is to provide a comprehensive
survey on power system state estimation techniques. The
algorithms used for finding the system states under both static
and dynamic state estimations are discussed in brief. The
authors are opinion that the scope of pursuing research in the
area of state estimation with PMU and SCADA measurements
is the state of the art and timely.
