Intel® Xeon® Processor E5-2600 v3 Product Family Application Showcase - Data Center Optimization & Security

Intel® Xeon® Processor E5-2600 v3 Product Family
September 2014
Intel Confidential — Do Not Forward
The Fast Lane to Better Performance†
Application Showcase:
Data Center Optimization & Security
How fast do you want to go?
† Better Performance is demonstrated through proof points in this presentation.

The New
Foundation for
Software-Defined
Infrastructure
Efficient, High Performance
Building Blocks
System Visibility for
Monitoring and Control
2
Common Architecture for
Compute, Storage and Network
The Intel® Xeon® processor E5-2600 v3 product family is at
the heart of your agile, efficient data center, meeting your
needs for compute, storage, and network.
These energy-efficient marvels are designed to deliver the
best combination of performance, built-in capabilities, and
cost-effectiveness and are designed with technical
computing, cloud deployments, intelligent storage, design
automation and data analytics in mind.
Safeguard your data and infrastructure with foundational
technology for greater security. Break challenging data
management performance bottlenecks with 40 gigabit Intel®
Ethernet, DDR4 support and innovative storage features that
make Intel-powered platforms the smart choice for a
software defined world.
You only have to remember one thing: It’s what’s inside that
counts.
Copyright © 2014 Intel Corporation. All rights reserved. *Other names and brands may be claimed as the property of others.

 Up to Up to 6X increase in
performance with Intel® AVX25
 Up to 3X increase in virtual
machine density6,7
 Up to 3X increase in memory
bandwidth with DDR48
3
Delivering Leadership Performance
27 New World Records1!
 Up to 3X performance
improvement for efficient, high
performance building blocks3
 Up to 6X throughput
with the latest Intel® DC SSD4
 Up to 40GbE to improve
network virtualization
The World’s Most Energy Efficient Server2
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using specific computer systems, components, software, operations and functions. Any change to any of those factors may cause the results to
vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when combined with other products. For more information go to http://www.intel.com/performance Intel does not control or audit third-party benchmark data or the
web sites referenced in this document. You should visit the referenced web site and confirm whether referenced data are accurate.
*Other names and brands may be claimed as the property of others.
1. Twenty-seven performance world records based on two-socket configurations. Source as of September 8, 2014. Full details available at: http://www.intel.com/content/www/us/en/benchmarks/server/xeon-e5-2600-v3/xeon-e5-2600-v3-summary.html
2. Comparison based on SPECpower_ssj2008 results published as of August 26, 2014. New configuration: Sugon I620-G20 platform with two Intel Xeon Processor E5-2699 v3, 8x16GB DDR4-2133 DR-RDIMM, Microsoft Windows Server 2008 R2, IBM J9 VM, 10,599 overall ssj_ops/watt. Source
Other names and brands may be claimed as the property of others.
3. Source as of September 8, 2014. New configuration: Hewlett-Packard Company HP ProLiant ML350 Gen9 platform with two Intel® Xeon® Processor E5-2699 v3, Oracle Java Standard Edition 8 update 11, 190,674 SPECjbb2013-MultiJVM max-jOPS, 47,139 SPECjbb2013-MultiJVM critical-jOPS. Source. Baseline: Cisco Systems Cisco UCS
C240 M3 platform with two Intel® Xeon® Processor E5-2697 v2, Oracle Java Standard Edition 7 update 45, 63,079 SPECjbb2013-MultiJVM max-jOPS , 23,797 SPECjbb2013-MultiJVM critical-jOPS. Source.
4. Comparisons based by Intel on publicly available specification sheet data &/or white papers
5. Source as of August 2014 on Linpack*. Supermicro* X8DTN+ with two Intel® Xeon® processor X5690, RHEL* 6.1, 12x4GB DDR3-1333, Intel® HT Technology disabled, Intel® Turbo Boost Technology enabled, SMP Linpack 10.3.5. Intel internal measurements TR#1236. Score: 159.36 GFlops. New configuration: Intel® Server System
R2208WTTYS with two Intel® Xeon® Processor E5-2699 v3, Intel® HT Technology disabled, Intel® Turbo Boost Technology enabled, 8x16GB DDR4-2133, RHEL* 6.4, Intel® MKL 11.1.1. Intel internal measurements TR#3034. Score: 1,012 GFlops.
6. Intel does not control or audit the design or implementation of third party benchmark data or Web sites referenced in this document. Intel encourages all of its customers to visit the referenced Web sites or others where similar performance benchmark data are reported and confirm whether the referenced benchmark data are accurate
and reflect performance of systems available for purchase.
7. Source as of September 8, 2014. Baseline: Fujitsu PRIMENERGY RX300 S6 with two Intel® Xeon® Processor X5690, VMware ESXi 4.1 U1, VMmark* v2.1.1 score: 7.59 @ 7 tiles, source. New Configuration: Fujitsu PRIMERGY RX2540 M1 platform with two Intel® Xeon® Processor E5-2699 v3, VMware ESXi 5.5.0 U2, VMmark v2.5.2 score:
26.48 @ 22 tiles, source. VMware® VMmark® is a product of VMware, Inc.
8. Source as of August 2014 TR#3044 on STREAM (triad): Supermicro X8DTN+ platform with two Intel® Xeon® Processor X5680, 18x8GB DDR3-800 score: 26.5 GB/sec. New Configuration: Intel® Server System R2208WTTYSwith two Intel® Xeon® Processor E5-2699 v3, 24x16GB DDR4-2133 @ 1600MHz DR-RDIMM, score: 85.2 GB/sec.

Common Architecture Enhancements
Compute Storage Network
1st DDR4 Memory
Implementation
Intel® Advanced
Vector Extensions 2.0
Intel® Data Direct I/O
Intel® Intelligent
Storage Acceleration
Library
Intel® QuickAssist
Technology
Intel® Data Plane
Development Kit v1.7
4

Go to http://transformingbusiness.intel.com/software-solutions to see each
Application Showcase!
THE RIGHT FOUNDATION FOR A SOFTWARE-DEFINED INFRASTRUCTURE
The Intel® Xeon® processor E5-2600 v3 product family is delivering powerful new
capability and value for scaling, automating, and securing data center
infrastructure. For example, Innovatrics is taking advantage of the increased cores
and cache – and Intel® Advanced Vector Extensions 2.0 – to deliver next-generation
Up to
Faster1
6 Application Showcases!
Over 60 proof points
and solutions!
1. Demonstrated through the Security Code* proof point in this presentation.
Intel Confidential – NDA Only *Other names and brands may be claimed as the property of others.
performance for its fingerprint recognition and matching software.
With this support, data center security teams can provide strong, biometric-based
access controls with higher scalability per server. See the following slides to learn
more and to see more impressive results.
5
78%
with Intel® Xeon® Processor E5-2600 v3
product family and Intel® SSD DC P3700
Maximize software investments
with the latest Intel hardware

Proof Points in this Application Showcase:
• Some show how software and Intel products work better together, such
as the Intel® Xeon® processor E5-2600 v3 product family, utilizing Intel®
Advanced Vector Extensions 2 (Intel® AVX2), with the Intel® Solid-State
Drive Data Center P3700 Series and with Intel® Software Development
Tools.1
• Some show impressive out-of-the-box processor improvement
compared to the previous processor generation.2
Look Inside to see how leading software companies generated improved performances and
how other software companies can benefit from Intel products.
1,2: Demonstrated through proof points in this presentation.
Intel Confidential – NDA Only *Other names and brands may be claimed as the property of others.
6

7

1.8
1.3
0.8
0.3
-0.2
Intel® Xeon® processor E5-2697 v2
Intel® Xeon® processor E5-2697 v3, Intel® AVX2
8
Security Code*
GOST cipher* - GOST 28147-89 cipher; measure data encryption speed
workload
“Running our experimental optimized GOST 28147-89* code, we saw a
significant performance gain with the new Intel® Xeon® processor E5-2697
v3, especially with Intel® AVX2 that allows us to use 2X wider registers vs.
SSE. Intel® Xeon® processor E5-2697 v3 with Intel® AVX2 out-performs the
previous processor generation by 1.78X”1
Konstantin Pichugov - Director of Product Development
Optimized code increases standard data
encryption speed!
 Intel® Advanced Vector Extensions 2 (Intel® AVX2) enables Russian
government data encryption standard algorithm GOST 28147-89
cipher* to perform up to 1.43X better than the Intel® Xeon® processor
E5-2697 v3 performance improvement (1.35X) compared to the
previous processor generation.
 Higher data encryption speed for bandwidth-demanding VPN
networks.
www.securitycode.ru
Security Code* increased performance (2,962 to
5,260MB/second) with Intel® Xeon® processor E5-
2697 v3 and Intel® AVX2
Up to
78%
faster
Performance increase
1 - Testing conducted on Security Code GOST 28147-89 cipher* comparing Intel® Xeon® Processor E5-2697 v2 with Intel® Xeon® Processor E5-2697 v3. Testing done by Intel. For complete configuration details, go here.
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using specific computer systems,
components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated
purchases, including the performance of that product when combined with other products.

1.2
1
0.8
0.6
0.4
0.2
0
9
Innovatrics*
ExpressID AFIS* - Number of comparisons of fingerprint templates per
second workload
“The latest version of Innovatrics ExpressID AFIS*, a complete fingerprint
matching solution, continuously confirmed first-class performance.
Innovatrics identification algorithm achieves speed of 382,948,037
fingerprint matches per second on Intel® Xeon® processor E5-2697 v3,
compared to 335,555,780 fingerprint matches per second on the previous
processor generation.”1
Jan Lunter - CTO, Innovatrics
Tens of millions more fingerprints compared in
a second!
 The Intel® Xeon® processor E5-2697 v3 increased memory bandwidth,
allows better utilization of computational resources, improved
Innovatrics* algorithm by 1.14X.
www.innovatrics.com
Innovatrics* increased performance with
Up to
14%
faster
Performance increase
1 - Testing conducted on Innovatrics ExpressID AFIS* comparing Intel® Xeon® Processor E5-2697 v2 with Intel® Xeon® Processor E5-2697 v3. Testing done by Intel. For complete configuration details, go here.
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using specific computer systems,
components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated
purchases, including the performance of that product when combined with other products.

10
Economic
Headwinds Have
Put Pressure on
IT Budgets
Infrastructure is aging and
holding companies back.
IT must enable business
innovation while also cutting
costs.
This creates a key challenge
for business competitiveness
and growth.

32% of Servers are
>4 Years Old1 32%
> 4 YEARS OLD
Make up only 4% of
Total Performance
Capabilities of Servers1 4%
> 4 YEARS OLD
Use 65% of Total
Energy Consumption1 65
> 4 YEARS OLD
%
26%
CAPEX
74%
OPEX
Business innovation throttled to 26%2
 Time to revenue
 Cost of lost time, effort, opportunity
 Unpredictable business cycles
74% captive in operations and maintenance2
 Rigid & aging infrastructure
 Application & information complexity
 Inflexible business processes
Aging Infrastructure is Inefficient and Costly
1* Source: Intel analysis, 2012
2* Source: Gartner, IT Metrics: Align IT Investment Levels With Strategy Using Run, Grow, Transform and Beyond
(March 2012)
Software and workloads used in performance tests may have been optimized for performance only on Intel
microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using specific computer
systems, components, software, operations and functions. Any change to any of those factors may cause the
results to vary. You should consult other information and performance tests to assist you in fully evaluating your
contemplated purchases, including the performance of that product when combined with other products.
For more information go to http://www.intel.com/performance

An Approach to Infrastructure Modernization
EXECUTE
• Configure new hardware and install
new operating system and
applications
• Test functionality and acceptance
with select users
• Establish backup and disaster
recovery functionality
• Release to users
• Plan for new upgrade cycle
PLAN
• Determine site requirements for
hosting hardware
• Assign applications and development
environments to hardware
• Define network architecture and
storage requirements
• Assess ability of new architecture to
meet compute requirements
• Develop project plan with timeline
and costs
EXPLORE
• Determine business requirements
• Identify utilization and growth in
servers, network, and storage
• Identify software (custom or COTS)
• Diagram infrastructure architecture
• Determine costs and cost trends
MODEL
• Compare business requirements to
vendor offerings
• Identify application interoperability
issues across the solution stack
• Determine where applications will
be hosted (virtual, physical, cloud)
• Define the hardware components
to retain, upgrade, and acquire

The Journey Starts with a Strong Foundation
• Take advantage of new capabilities in hardware and software to support business growth
• Minimize operating expenses, maximize efficiency
• Ensure security and compliance
13

Effective IT
Empowers
Business Success
14
Companies that have invested
in IT to achieve operational
excellence and innovation are
seeing tremendous benefits.
Companies that integrate IT
into the business to deliver
differentiated services and
value for their customers are
thriving.

The Path to
Transformational IT
Data Center Optimization
Increase Operational
Efficiency
 Minimize operating expenses
and maximize efficiency
 Take advantage of new capabilities in
hardware and software
 Ensure security and compliance
 Ensure reliability to enhance service
quality (nonstop services, VoIP, XoIP, etc.)
Open
Standards
Based
Modernize
Service Delivery
 Deliver new services on demand
 Use private, public, or hybrid
cloud
 Develop APIs and service-oriented
architecture
Create New
Business Opportunities
 Use big data to identify
opportunities and respond to
competitive threats
 Optimize operations that improve
time to market and predictive
analytics
 Enhance customer value with new
products and services




15

16
Solutions that Work Better Together
Red Hat Enterprise
Linux* 7
Intel® Xeon®
Processor E5-2600
v3 Product Family
Virtualization
2014
2012
SPECvirt is a trademark of the Standard Performance Evaluation Corporation (SPEC).
For more information, visit intel.com/performance
*1,2,3 + Configuration details and additional information on the following page.
2014
Baseline
• Red Hat Enterprise Linux*
6.4 with KVM
Virtualization**
• Intel® Xeon® Processor
E5-2690
Software Upgrade
+ Red Hat Enterprise Linux* 7 with KVM**
• KVM supports optimized Interrupt
Handling in virtual environments (APIC)
• Up to 160 logical CPUs and 2TB of
memory per VM
• Enhanced cryptography capabilities
Better Together
Up to 2.5x higher VM
density3
Support for:
• More Users
• Larger VMs while
maintaining SLAs
• Secure Virtualization
Framework
• Reduced VMM Overhead
Benchmark: SPECvirt*_sc2013
Hardware Upgrade
+ Intel® Xeon® Processor E5-2699 v3
• Increased parallelism with up to 18 cores
• Up to 2.7x higher memory capacity1
• Up to 2x more R/W bandwidth with
integrated PCIe 3.0 reducing network &
storage bottlenecks2

17
Configuration Details for Red Hat Enterprise Linux with KVM* Virtualization and Intel®
Xeon® Processor E5-2600 Product Family
Processor
Intel® Xeon® Processor E5-2690
(8C, 2.9GHz, 135 W)
Intel® Xeon® Processor E5-2699 v3
(18C, 2.3 GHz, 145 W)
Sockets 2 2
Memory 256 GB (16x16 GB)
16 x 32 GB, 4R x4 PC4-17000 DDR4
2133MHz LRDIMM
KVM RHEL* 6.4 RHEL* 7
Virtualization
Performance
624.9 @ 37 VMs 1614 @ 95 VMs
1* Up to 2.7X memory capacity based on a 2-socket platform: Intel® Xeon® processor X5600 series supports 18 DIMMS, max memory per DIMM of 32 GB RDIMM; Intel® Xeon® processor
2600 v3 family supports 24 DIMMs, max memory per DIMM of 64GB RDIMM. This enables 2.7x the memory.
2* Intel estimates of maximum achievable I/O R/W bandwidth (512B transactions, 50% reads, 50% writes) comparing Intel® Xeon® processor E5-2680 based platform with 64 lanes of PCIe*
3.0 (66 GB/s) vs. Intel® Xeon® processor X5670 based platform with 32 lanes of PCIe* 2.0 (18 GB/s).
3* Up to 2.5x higher VM density based on SPECvirt_sc2013 workload comparing baseline IBM Flex System* x240 using two two Intel® Xeon® Processor E5-2690 scoring 624.9 @ 37 VMs
(www.spec.org) to the Hewlett-Packard Company ProLiant DL360 Gen9 with two Intel Xeon Processor E5-2699 v3, SPECvirt_sc2013 1614 @ 95 VMs. (Source)
**See source for configuration details.

18
Red Hat Enterprise
Linux* 7
Intel® Xeon®
Processor E5-2600
v3 Product Family
HPC
2014
2010
SPECfp*rate is a trademark of the Standard Performance Evaluation Corporation (SPEC).
2014
Baseline
• Red Hat Enterprise Linux* 6
X5690
Software Upgrade
+ Red Hat Enterprise Linux 7 with KVM*
• Delivers high capacity 64-bit XFS file
system
• Provides Performance Management suite
to tune and optimize performance to
selected system profile
• Automatic NUMA balancing
Better Together
Up to 3.7xhigher
performance3
Outstanding performance
across a range of real-world
HPC applications
Benchmark: SPECfp*_rate_base2006
Hardware Upgrade
• Intel® AVX2 delivers up to 4x DP
FLOPS/core and supports 2x wider vector
integer instructions1
• The DDR4 difference: Up to 3x more
memory bandwidth2

Configuration Details for Red Hat Enterprise Linux* Virtualization and Intel® Xeon®
Processor E5-2600 Product Family
Intel does not control or audit the design or implementation of third party benchmark data or Web sites referenced in this document. Intel encourages all of its customers to visit the referenced Web
sites or others where similar performance benchmark data are reported and confirm whether the referenced benchmark data are accurate and reflect performance of systems available for purchase.
19
Processor
Intel® Xeon® Processor X5690
(6C, 3.46 GHz, 130W)
(18C, 2.3 GHz, 145W)
Sockets 2 2
Memory
48 GB
(16x4 GB DDR3-1600)
128GB
(16 x 8GB DDR4-2133)
OS Distribution RHEL* 6.1 RHEL* 7
Compiler Intel® Compiler 12.1.0.255 Intel® Compiler 14.0
Idle Power (watts) 115.73 (Intel Est.4) 92 (Intel Est.4)
Performance
226 (Intel Est.3) 845 (Intel Est.3)
(SPECfp*_rate_base2006)
1* The Intel® Xeon® processor E5 product family supports Intel® Advanced Vector Extensions (Intel® AVX), which increases maximum vector size from 128 to 256 bits. Compared to the Intel® Xeon®
processor 5600 series, Intel™ AVX™ enables up to twice the work to be accomplished per clock cycle during floating point and vector operations
2* Up to 3x memory bandwidth based on STREAM(triad) benchmark comparing baseline Supermicro X8DTN+ platform with two Intel® Xeon® Processor X5680, 18x8GB DDR3-800 scoring 26.5 GB/sec
to the new Intel® Server System R2208WTTYS with two Intel® Xeon® Processor E5-2699 v3, 24x16GB DDR4-2133 @ 1600MHz DR-RDIMM scoring 85.2 GB/sec. Source: Intel internal testing.
3* Up to 3.7x performance gain based on SPECfp*_rate_base2006 workload on different Intel Compiler comparing Supermicro X8DTN+ with two Intel® Xeon® Processor X5690 scoring 226 to the new
Intel ® Server Board S2600WTT with two Intel® Xeon® Processor E5-2699 v3 scoring 845.
4* Idle power represents the average power of the server while not under any workload.
Intel's compilers may or may not optimize to the same degree for non-Intel microprocessors for optimizations that are not unique to Intel microprocessors. These optimizations include SSE2, SSE3,
and SSE3 instruction sets and other optimizations. Intel™ does not guarantee the availability, functionality, or effectiveness of any optimization on microprocessors not manufactured by Intel.
Microprocessor-dependent optimizations in this product are intended for use with Intel microprocessors. Certain optimizations not specific to Intel™ microarchitecture are reserved for Intel™
microprocessors. Please refer to the applicable product User and Reference Guides for more information regarding the specific instruction sets covered by this notice. Notice revision #20110804

20
Red Hat Enterprise
Linux* 7
Intel® Xeon®
Processor E5-2600
v3 Product Family
Enterprise
2014
2010
SPECint*rate is a trademark of the Standard Performance Evaluation Corporation (SPEC).
2014
Baseline
• Red Hat Enterprise Linux* 6
X5690
Software Upgrade
+ Red Hat Enterprise Linux* 7 with KVM*
• Delivers high capacity 64-bit XFS file
system for improved performance
• Performance Management suite to tune
and optimize performance to selected
system profile
• Automatic NUMA balancing
Better Together
Up to 3.1xhigher
performance3
Outstanding performance
across a range of real-world
general purpose applications
Benchmark: SPECint*_rate_base2006
Hardware Upgrade
• Intel® AVX2 delivers up to 4x DP
FLOPS/core and supports 2x wider vector
integer instructions1
The DDR4 difference
• Up to 3x more memory bandwidth2

21
Configuration Details for Red Hat Enterprise Linux* virtualization and Intel® Xeon®
Processor E5-2600 v3 Family
Processor
(6C, 3.46 GHz, 130W)
(18C, 2.3 GHz, 145W)
Sockets 2 2
Memory 48 GB (16x4 GB DDR3-1600) 128GB (16 x 8GB DDR4-2133)
OS Distribution RHEL* 6.1 RHEL* 7
Compiler Intel® Compiler 12.1.0.255 Intel® Compiler 14.0
Idle Power (watts) 115.73 (Intel Est.3) 92 (Intel Est.3)
Performance
414 (Intel Est.3) 1290 (Intel Est.3)
(SPECint_rate_base2006)
1* The Intel® Xeon® processor E5 product family supports Intel® Advanced Vector Extensions (Intel® AVX), which increases maximum vector size from 128 to 256 bits. Compared to the Intel®
Xeon® processor 5600 series, Intel AVX enables up to twice the work to be accomplished per clock cycle during floating point and vector operations
2* Up to 3x memory bandwidth based on STREAM(triad) benchmark comparing baseline Supermicro X8DTN+ platform with two Intel® Xeon® Processor X5680, 18x8GB DDR3-800 scoring
26.5 GB/sec to the new Intel® Server System R2208WTTYS with two Intel® Xeon® Processor E5-2699 v3, 24x16GB DDR4-2133 @ 1600MHz DR-RDIMM scoring 85.2 GB/sec. Source: Intel
internal testing.
3* Up to 3.1x performance improvement based on SPECint*_rate workload comparing baseline Supermicro X8DTN+ with two Intel® Xeon® Processor X5690 using Intel® Compiler 12.1.0.255
scoring 226 to the Intel® Server Platform with two Intel® Xeon® Processor E5-2699 v3 using Intel® Compiler 14.0 scoring 789
4 Idle power represents the average power of the server while not under any workload.
Intel's compilers may or may not optimize to the same degree for non-Intel microprocessors for optimizations that are not unique to Intel microprocessors. These optimizations include
SSE2, SSE3, and SSE3 instruction sets and other optimizations. Intel does not guarantee the availability, functionality, or effectiveness of any optimization on microprocessors not
manufactured by Intel.
Microprocessor-dependent optimizations in this product are intended for use with Intel microprocessors. Certain optimizations not specific to Intel microarchitecture are reserved for Intel
microprocessors. Please refer to the applicable product User and Reference Guides for more information regarding the specific instruction sets covered by this notice. Notice revision
#20110804
Copyright © 2014 Intel Corporation. All rights reserved.

22
VMware
vSphere*
Intel® Xeon®
Processor E5 v3
Family
2014
2010
2014
Baseline
• VMware vSphere* 4.1
X5690
Software Upgrade
+ VMware vSphere* 5.5
• 2x Increase in physical CPU (160 to 320
pCPU)
• 4x increase in VRAM (256 GB to 1 TB)
• 8x increase in virtual CPU per VM (8 to 64)
Better Together
Up to 3.3x improvement
in virtualization
performance3
Reduced overhead for near
native I/O performance with
SR-IOV
Benchmark: VMmark* 2.x
Hardware Upgrade
• Up to 2.7x memory capacity1
• Up to 2x more Read/Write bandwidth
with integrated PCIe 3.0 reducing network
& storage bottlenecks2

23
Get the Most Out of Modern Software & Hardware
Intel® Xeon® E5-2600 v3 product family and VMware vSphere*
Performance Benefits
100 Up to
Business Benefits
VMware vSphere*
100
Six-Core Intel® Xeon®
Processor X5690
Based Servers
&
Eighteen-Core
Intel® Xeon®
Processor
E5-2600 v3
Product Family-based
Servers
3.3x
more performance1
2x Increase in
Increase in
physical
CPU (160 to
320 pCPU)
4x Increase in
VRAM (256
GB to 1 TB)
virtual CPU
per VM (8
to 64)
8x
Software and workloads used in performance tests may have been optimized for performance only
on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured
using specific computer systems, components, software, operations and functions. Any change to
any of those factors may cause the results to vary. You should consult other information and
performance tests to assist you in fully evaluating your contemplated purchases, including the
performance of that product when combined with other products.
Configuration details on the following page
Performance
Business Value
Deploying virtualized workloads at near native
performance increases operational efficiency

24
Configuration Details for VMware vSphere* and Intel® Xeon® Processor E5 v3 Family
Processor
(6C, 3.46 GHz, 130 W)
(18C, 2.3 GHz, 145 W)
Sockets 2 2
Memory 12 x 8GB DDR3-1333 16 x 32GB DDR4-2133
VMWare* Software Distribution
ESXi* 4.1 on vCenter* 4.1
(Distributed with vSphere* 4.1)
ESXi 5.5 on vCenter 5.5
(Distributed with vSphere* 5.5)
Virtualization Performance 7.9 @ 7 tiles 3 26.48 @ 22 tiles3
1* Up to 2.7X memory capacity based on a 2-socket platform: Intel® Xeon® processor X5600 series supports 18 DIMMS, max memory per DIMM of 32 GB RDIMM; Intel® Xeon® processor
2600v3 family supports 24 DIMMs, max memory per DIMM of 64GB RDIMM. This enables 2.7x the memory.
2* Intel estimates of maximum achievable I/O R/W bandwidth (512B transactions, 50% reads, 50% writes) comparing Intel® Xeon® processor E5-2680 based platform with 64 lanes of PCIe*
3.0 (66 GB/s) vs. Intel® Xeon® processor X5670 based platform with 32 lanes of PCIe* 2.0 (18 GB/s). Baseline Configuration: Platform with two Intel® Xeon® processor X5670 (2.93 GHz, 6C),
24GB memory @ 1333, 4 x8 Intel internal PCIe* 2.0 test cards. New Configuration: Platform with two Intel® Xeon processor E5-2680 (2.7GHz, 8C), 64GB memory @1600 MHz, 2 x16 Intel
internal PCIe* 3.0 test cards on each node (all traffic sent to local nodes).
3* Up to 3.3x improvement in VM performance based on VMmark 2.x workload comparing baseline Fujitsu PRIMENERGY RX300 S6 with two Intel® Xeon® Processor X5690 , VMmark* v2.1.1
score: 7.59 @ 7 tiles to the new Fujitsu PRIMERGY RX2540 M1 platform with two Intel Xeon Processor E5-2699 v3, VMware ESXi 5.5.0 U2, VMmark v2.5.2 score: 26.48 @ 22 tiles. Source as
of September 8, 2014. VMware® VMmark® is a product of VMware, Inc.

25
See more Data Center Optimization & Security and Intel® Xeon® processor E5-
2600 v3 stories at http://transformingbusiness.intel.com/software-solutions
 Cloudera* Infographic
Big Data Storage and Analytics & Security
 HyTrust* Solution Brief
DataControl encryption and key management solution
 Vormetric & MongoDB* Solution Brief
Data & Data Base Security

26
Intel® Xeon® Processor. Intel® Solid-State Drives. Intel® Ethernet Solutions. Intel®
Software Development Tools
Accelerating Business Transformation
Up to 3.0X performance improvement1 for
efficient, high performance solutions
Common architecture for
compute, storage and networks
Monitoring and control for
improved system visibility
The Foundation for the
Software-Defined Infrastructure
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using specific computer systems, components, software, operations and functions. Any change to any of
those factors may cause the results to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when combined with other products. For more information go to
http://www.intel.com/performance Intel does not control or audit third-party benchmark data or the web sites referenced in this document. You should visit the referenced web site and confirm whether referenced data are accurate.
1. Source as of September 8, 2014. New configuration: Hewlett-Packard Company HP ProLiant ML350 Gen9 platform with two Intel® Xeon® Processor E5-2699 v3, Oracle Java Standard Edition 8 update 11, 190,674 SPECjbb2013-MultiJVM max-jOPS, 47,139 SPECjbb2013-MultiJVM critical-jOPS.
Source. Baseline: Cisco Systems Cisco UCS C240 M3 platform with two Intel® Xeon® Processor E5-2697 v2, Oracle Java Standard Edition 7 update 45, 63,079 SPECjbb2013-MultiJVM max-jOPS , 23,797 SPECjbb2013-MultiJVM critical-jOPS. Source.

Product and Support Pages
 Intel® Xeon® processor E5 v3 product family:
• Product page: http://www.intel.com/content/www/us/en/processors/xeon/xeon-processor-
e5-family.html
• Support page: http://www.intel.com/p/en_US/support/highlights/processors/xp-e5-2600
 Intel® Solid-State Drive Data Center P3700:
• Product Page: http://www.intel.com/content/www/us/en/solid-state-drives/intel-ssd-dc-family-
for-pcie.html
• Support Page: http://www.intel.com/p/en_US/support/highlights/ssdc/ssd-dc-p3700
 Intel® Ethernet Solutions:
• Product Page: http://www.intel.com/content/www/us/en/network-adapters/converged-network-
adapters.html
• Support Page: http://www.intel.com/p/en_US/support/highlights/network/xl710
 Intel® Server Software for Code Vectorization, Parallelism and Optimization:
• Product Page: https://software.intel.com/en-us/intel-mkl
• Product Page: https://software.intel.com/en-us/intel-parallel-studio-xe
23

28
All products, computer systems, dates, and figures specified are
preliminary based on current expectations, and are subject to
change without notice.
Intel processor numbers are not a measure of
performance. Processor numbers differentiate features within each
processor family, not across different processor families. Go to:
http://www.intel.com/products/processor_number
Intel, processors, chipsets, and desktop boards may contain design
defects or errors known as errata, which may cause the product to
deviate from published specifications. Current characterized errata
are available on request.
SPEC, SPECpower, and SPECjbb are trademarks of the Standard
Performance Evaluation
Corporation. See http://www.spec.org (http://www.spec.org/) for
more information.
TPC Benchmark is a trademark of the Transaction Processing
Council. See http://www.tpc.org for more information.
Requires a system with Intel® Turbo Boost Technology. Intel Turbo
Boost Technology and Intel Turbo Boost Technology 2.0 are only
available on select Intel® processors. Consult your PC manufacturer.
Performance varies depending on hardware, software, and system
configuration. For more information, visit
http://www.intel.com/go/turbo
Intel, Intel Xeon, the Intel Xeon logo, Intel Atom and the Intel logo
are trademarks or registered trademarks of Intel Corporation or its
subsidiaries in the United States and other countries. Other names
and brands may be claimed as the property of others.
Copyright © 2014, Intel Corporation. All rights reserved.
Legal Disclaimer

29
Legal Disclaimers: Performance
Performance tests and ratings are measured using specific
computer systems and/or components and reflect the
approximate performance of Intel products as measured by
those tests. Any difference in system hardware or software
design or configuration may affect actual performance. Buyers
should consult other sources of information to evaluate the
performance of systems or components they are considering
purchasing. For more information on performance tests and on
the performance of Intel products, Go to:
http://www.intel.com/performance/resources/benchmark_limit
ations.htm. and www.intel.com/software/products
Intel does not control or audit the design or implementation of
third party benchmarks or Web sites referenced in this
document. Intel encourages all of its customers to visit the
referenced Web sites or others where similar performance
benchmarks are reported and confirm whether the referenced
benchmarks are accurate and reflect performance of systems
available for purchase.
Relative performance is calculated by assigning a baseline
value of 1.0 to one benchmark result, and then dividing the
actual benchmark result for the baseline platform into each of
the specific benchmark results of each of the other platforms,
and assigning them a relative performance number that
correlates with the performance improvements reported.
INFORMATION IN THIS DOCUMENT IS PROVIDED “AS IS”. NO
LICENSE, EXPRESS OR IMPLIED, BY ESTOPPEL OR OTHERWISE, TO
ANY INTELLECTUAL PROPERTY RIGHTS IS GRANTED BY THIS
DOCUMENT. INTEL ASSUMES NO LIABILITY WHATSOEVER AND
INTEL DISCLAIMS ANY EXPRESS OR IMPLIED WARRANTY, RELATING
TO THIS INFORMATION INCLUDING LIABILITY OR WARRANTIES
RELATING TO FITNESS FOR A PARTICULAR PURPOSE,
MERCHANTABILITY, OR INFRINGEMENT OF ANY PATENT,
COPYRIGHT OR OTHER INTELLECTUAL PROPERTY RIGHT.

30
Legal Disclaimers: Performance
Intel® Advanced Vector Extensions 2 (Intel® AVX2): Intel® Advanced
Vector Extensions 2 (Intel® AVX2) provides higher throughput to
certain processor operations. Due to varying processor power
characteristics, utilizing AVX instructions may cause a) some parts
to operate at less than the rated frequency and b) some parts with
Intel® Turbo Boost Technology 2.0 to not achieve any or maximum
turbo frequencies. Performance varies depending on hardware,
software, and system configuration and you can learn more at
http://www.intel.com/go/turbo.
Intel® Hyper-Threading Technology (Intel® HT Technology): Available
on select Intel® processors. Requires an Intel® HT Technology-enabled
system. Your performance varies depending on the specific
hardware and software you use. Learn more by visiting
http://www.intel.com/info/hyperthreading.

31
Optimization Notice
Intel's compilers may or may not optimize to the same degree for non-Intel microprocessors for optimizations that are
not unique to Intel microprocessors. These optimizations include SSE2, SSE3, and SSSE3 instruction sets and other
optimizations. Intel does not guarantee the availability, functionality, or effectiveness of any optimization on
microprocessors not manufactured by Intel. Microprocessor-dependent optimizations in this product are intended for
use with Intel microprocessors. Certain optimizations not specific to Intel microarchitecture are reserved for Intel
microprocessors. Please refer to the applicable product User and Reference Guides for more information regarding the
specific instruction sets covered by this notice.
Notice revision #20110804

Configuration Details:
SECURITY CODE*: The benchmark app encrypts a test data using GOST 28147-89 cipher and measures data encryption speed
Baseline configuration: GOST 28147-89 cipher on Ubuntu* 14.04 x64, 2 Intel® Xeon® processor E5-2697 v2, 2.7GHz, 12 cores,
64GB/1866 DDR3, 2 SATA/7200RPM, 1Gb network, Source is Intel internal as of August 14, 2014.
New configuration: GOST 28147-89 cipher on Ubuntu* 14.04 x64, 2 Intel® Xeon® processor E5-2697 v3, 2.6GHz, 14 cores,
64GB/2133 DDR4, 2 SATA/7200RPM, 1Gb network, Source is Intel internal as of August 14, 2014.
INNOVATRICS*: Workload matched performance of identification request (1:n comparison). During identification phase,
fingerprint record from the input compared to all fingerprint records stored in ExpressID AFIS* and best matching candidate
together with similarity score returned as a result. Fingerprint records are stored in the data structure called fingerprint template -
digitized representation of fingerprint image. Reference fingerprint templates loaded into matching server RAM memory before
the test started (as for normal deployment), the benchmark evaluates matching performance - number of comparisons of
fingerprint templates per second. ExpressID AFIS contains multiple matching algorithms with different speed/accuracy ratio, all of
them were evaluated in this benchmark.
Baseline configuration: Innovatrics* Finger Print Matching Software on Windows Server 2008 R2 Enterprise* SP1, 2 Intel® Xeon®
processor E5-2697 v2, 2.7GHz, 12 cores, 64GB/1333 DDR3, 1 SATA/7200RPM, 1Gb network, Source is Intel internal as of May 8,
2014.
New configuration: Innovatrics* Finger Print Matching Software on Windows Server 2008 R2 Enterprise* SP1, 2 Intel® Xeon®
processor E5-2697 v3, 2.6GHz, 14 cores, 64GB/2133 DDR4, 1 SATA/7200RPM, 1Gb network, Source is Intel internal as of May 8,
2014.
32

REVISION 1.0 GOLD
Copyright © 2014 Intel Corporation. All rights reserved. *Other names and brands may be claimed Copyright © 2014 Intel Corporation. All rights reserved. *Other names and brands may be claim aesd t haes tphroep perrotpye ortfy o othf eortsh. ers.

Intel® Xeon® Processor E5-2600 v3 Product Family Application Showcase - Data Center Optimization & Security

More Related Content

What's hot

Similar to Intel® Xeon® Processor E5-2600 v3 Product Family Application Showcase - Data Center Optimization & Security

More from Intel IT Center

Recently uploaded

Intel® Xeon® Processor E5-2600 v3 Product Family Application Showcase - Data Center Optimization & Security

Editor's Notes
