The Intel Xeon processor E5-2600 v4 product family delivers the high performance, increased memory, and I/O bandwidth required for all forms of enterprise databases, is ideal for next-generation application workloads, and is the powerhouse for software-defined infrastructure (SDI) environments where automation and orchestration capabilities are foundational. See how database solutions deployed on the Intel® Xeon® processor E5 v4 product family can deliver increased performance and throughput, as demonstrated by key software partners.
4. * Other Names and Brands May Be Claimed as the Property of Others 4
+
Intel®Xeon®
processorE5-2600v4
productfamily
Intel®SSDDCFamily
D3700/3600&P3320
+
Intel®Ethernet
OR
Intel®omni-path
architecture
TheNew2016PlatformOptimizedfortheCloud
5. * Other Names and Brands May Be Claimed as the Property of Others 5
Intel® Xeon® ProcessorE5-2600v4ProductFamily
NewProcessorTechnologies
• New Features and Enhancements
• Intel® Transactional Synchronization Extensions (TSX)
• Optimized Intel® AVX 2.0
• Gather Improvements
• Posted Interrupts
• Page Modification Logging
• VM Enter/Exit latency Reduction
Performance
• New Capabilities
• Cache Monitoring Technology (introduced on Xeon® E5-2600 v3)
• Cache Allocation Technology
• Code and Data Prioritization
• Memory Bandwidth Monitoring
Orchestration
• New Features
• Crypto Speedup
• New Random Seed Generator (RDSEED)
• #VE (Processor Virtualization exception)
• Supervisor Mode Access Protection (SMAP)
Security
Performance info
Orchestration info
Security info
Intel®Resource
DirectorTechnology
6. * Other Names and Brands May Be Claimed as the Property of Others
Softwareplatformvalueproposition
Intel®Xeon®ProcessorE5-2600v4productFamily
6
With software solutions running on the Intel® Xeon® processor E5-2600 v4
product family, you can:
Accelerate cloud deployments through a robust portfolio of capabilities in the
software defined infrastructure space, to better manage shared platform resources.
New features such as Intel® RDT can offer higher throughput for higher priority
workloads for better utilization overall.
Catalyze business innovation with cloud-based service and application delivery
models that increase efficiency and lower TCO. Software optimizations for this latest
generation processor can deliver improved user experiences.
Break through the “performance wall” with the Intel Xeon processor E5-2600 v4
product family for many High Performance Computing applications.
Stay competitive by enabling the IT organization to be more agile, flexible and
responsive to evolving business needs and to scale on demand.
7. * Other Names and Brands May Be Claimed as the Property of Others 7
Enterprisedatabase
8. * Other Names and Brands May Be Claimed as the Property of Others
EnterpriseDatabase
8
Up to
Faster1
54%
FASTER DATA FLOWS
TO POWER YOUR BUSINESS
From high-volume transactions to real-time
analytics, today’s data platforms have to do
more and do it faster. The Intel® Xeon®
processor E5-2600 v4 product family is helping
database vendors meet the challenge by
processing more simultaneous transactions and
queries while delivering faster response times.
Hardware and software work together to deliver
a smarter foundation for high-speed business.
See the following slides for more information
and a look at the compelling performance
gains.
1 – Demonstrated with Oracle MySQL* proof point, slide 9.
Telecom.
& Cloud
Financial
Services &
Security
Big Data
Analytics
Core Business
Technical
Computing
9. * Other Names and Brands May Be Claimed as the Property of Others
0
1
2S Intel® Xeon® processor E5-2697 v3
2S Intel® Xeon® processor E5-2699 v4
MySQL* 5.7 increased transactions/second by up to
1.54X with the 2S Intel® Xeon® processor E5-2699 v4
Oracle*
Oracle MySQL*
“The new Intel® Xeon® processor E5-2699 v4 gives a visible extra performance
gain for MySQL 5.7 running OLTP workloads. We see more than 50K TPS and up
to 1.54X performance gain for read-only scenario compared to the previous
processor generation.1
Tomas Ulin - VP MySQL Engineering, Oracle
9
The Intel® Xeon® processor E5-2699 v4 improved MySQL transactions per
second from 32,350 to 50,000, up to 1.54X more
Intel® Xeon® processor E5-2699 v4 with enhanced microarchitecture, additional
enhanced cores and larger cache gives the performance boost, delivers a
significant performance gain for database applications like MySQL, the world's
most popular open source database
The Intel® Xeon® processor E5-2697 v4 delivers about 34%2 improvement in
performance compared to the E5-2697 v3
.
Enterprise Database
Up to 54% more
1 - Testing conducted on ISV* software comparing 2S Intel® Xeon® Processor E5-2699 v4 to 2S Intel® Xeon® Processor E5-2699 v3. Testing done by Intel. For complete testing configuration details, SEE SLIDE 32. 2 - Estimated increase for 2S Intel® Xeon®
Processor E5-2697 v4 to 2S Intel® Xeon® Processor E5-2697 v3. Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured
using specific computer systems, components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated
purchases, including the performance of that product when combined with other products. For more complete information visit http://www.intel.com/performance.
Intel® Xeon® Processor E5-2600 v4 Family
Visible Performance Gains for the World's Most Popular
Open Source Database Workload: Sysbench OLTP, transactions per second
NormalizedPerformance
www.mysql.com
10. * Other Names and Brands May Be Claimed as the Property of Others
0
1
2S Intel® Xeon® processor E5-2697 v3
2S Intel® Xeon® processor E5-2699 v4
MariaDB increased performance by up to 1.51X with
the 2S Intel® Xeon® processor E5-2699 v4
MariaDB Corporation*
MariaDB 10.1*
“The new Intel® Xeon® processor E5-2699 v4 continues the dual-socket
performance evolution. Powered by additional enhanced cores it improves
performance for traditional databases by up to 1.51x vs. previous Xeon’s
generation for multi-table OLTP workloads. Our users and customers will get
faster responses to their complex queries, and can reduce TCO at the same
time—so they can realize even higher value with MariaDB.”
Michael Widenius, CTO for MariaDB Corporation
10
Robust, scalable, and reliable SQL server. Drop-in replacement for MySQL.
Intel® Xeon® processor E5-2600 v4 with enhanced microarchitecture, additional
enhanced cores and larger cache gives the performance boost, delivers a
significant performance gain for traditional database applications like MariaDB
Proved scalability for 2S, 88 H/W threads
The Intel® Xeon® processor E5-2697 v4 delivers about 33%2 improvement in
performance compared to the E5-2697 v3
Enterprise Database
Up to 51%
faster
1 - Testing conducted on ISV* software comparing 2S Intel® Xeon® Processor E5-2600 v4 to 2S Intel® Xeon® Processor E5-2600 v3. Testing done by ISV. For complete testing configuration details, SEE SLIDE 32. 2 - Estimated increase for 2S Intel® Xeon®
Processor E5-2697 v4 to 2S Intel® Xeon® Processor E5-2697 v3. Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured
using specific computer systems, components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated
purchases, including the performance of that product when combined with other products. For more complete information visit http://www.intel.com/performance.
Intel® Xeon® Processor E5-2600 v4 Family
Faster response times and lower TCO
on a popular, open-source database Workload: Sysbench OLTP
Normalizedperformance
https://mariadb.org/
11. * Other Names and Brands May Be Claimed as the Property of Others
0
1
2S Intel® Xeon® processor E5-2699 v3
2S Intel® Xeon® processor E5-2699 v4
NRI BOS performance increased by up to 1.39X with
the 2S Intel® Xeon® processor E5-2699 v4, Intel®
AVX2, and cluster-on-die technology
Nomura Research Institute, Ltd.*
Business Oriented Solution (BOS)
“NRI is excited that the Intel® Xeon® processor E5-2699 v4 improved BOS
performance with more CPU cores and higher cache hit rate. BOS’s NUMA
optimized deployment strategy perfectly matches the Cluster-on-Die technology
in relaxing the memory bandwidth bottleneck, which directly boosted
performance to amazing levels”1
Yuzo Ishida – Senior Application Engineer, NRI (BOS Architect)
11
www.nri.com
The Intel® Xeon® processor E5-2699 v4 with Intel® AVX2 reduced processing time
from 53 to 38 seconds, up to 1.39X faster.
BOS handles both OLTP and OLAP workloads, sharing “single source of truth” over
the extremely normalized single database schema.
End-Users can benefit from this application in turning operational data into real-time
business insight without the delays of traditional data warehouses and data marts.
The increased number of CPU cores per NUMA node directly contributed for quick
response time with more concurrent queries in building software-defined logical
views on Java* Virtual Machine on the fly.
Enterprise Database
Up to 39%
faster
1 - Testing conducted on ISV* software comparing 2S Intel® Xeon® Processor E5-2699 v4 to 2S Intel® Xeon® Processor E5-2699 v3. Testing done by NRI. For complete testing configuration details, SEE SLIDE 32.
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using specific computer systems, components, software, operations
and functions. Any change to any of those factors may cause the results to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when
combined with other products. For more complete information visit http://www.intel.com/performance.
Operational cost can be significantly reduced
by managing data as Single Source of Truth Workload: Real-time stock calculation; Benchmark schema derived
from TPC-H* queries.
NormalizedPerformance
Intel® Xeon® Processor E5-2600 v4 Product Family
Intel® Xeon® + AVX2 + 10GbE adapter + CoD
12. * Other Names and Brands May Be Claimed as the Property of Others
0
1
2S Intel® Xeon® processor E5-2699 v3
2S Intel® Xeon® processor E5-2699 v4
Workload: HDB in-memory DBMS
Altibase HDB* improved performance by up to 1.23X
with the 2S Intel® Xeon® processor E5-2699 v41
Altibase*
In-memory DBMS for the Enterprise
“HDB* is aiming for real-time access to time critical hot data. The Intel® Xeon®
processor E5-2699 v4 enables HDB to achieve more analytics results and faster
transactions storing and manipulating data.”
Kim, Gang-Seok – Head of Research and Development Dept., Altibase
12
http://altibase.com
HDB provides fast data processing speeds for online transactional processing
and online analytical processing
In-memory DBMS is required to deal with low latency and high throughput.
Intel® Xeon® Processor E5 2699 v4 can achieve this mission-critical transactions
with more stabilities
Enterprise Database
1 - Testing conducted on ISV* software comparing 2S Intel® Xeon® Processor E5-2699 v4 to 2S Intel® Xeon® Processor E5-2699 v3. Testing done by ISV. For complete testing configuration details, SEE SLIDE 32.
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using specific computer systems, components, software, operations
and functions. Any change to any of those factors may cause the results to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when
combined with other products. For more complete information visit http://www.intel.com/performance.
Intel® Xeon® Processor E5-2600 v4 Family
Optimized performance for maximizing in-memory DBMS
workloads
NormalizedPerformance
ISV logo
Up to 23%
Faster
13. * Other Names and Brands May Be Claimed as the Property of Others
0
1
2S Intel® Xeon® processor E5-2699 v3
2S Intel® Xeon® processor E5-2699 v4
IBM DB2 increased performance with the 2S Intel®
Xeon® processor E5-2699 v4
IBM*
DB2 10.5 (BLU*)
DB2 is IBM's flagship database product offers industry leading performance,
scale and reliability, in the cloud and on premise. DB2 v10.5 adds support for in-
memory column store tables (BLU) for analytics workloads that vastly accelerates
performance while lowering costs. IBM DB2 10.5 (BLU) produced up to a 18%
improvement with the Intel® Xeon® processor E-2699 v4 compared to the
previous generation processor.
13
Boosted by Intel® C++ Compiler for faster execution.
BLU* acceleration optimized for Intel® SIMD instructions.
BLU optimization for highly-parallel processing on Intel® Xeon® processors.
Enterprise Database
Up to 18%
faster
1 - Testing conducted on ISV* software comparing 2S Intel® Xeon® Processor E5-2699 v4 to 2S Intel® Xeon® Processor E5-2699 v3. Testing done by ISV. For complete testing configuration details, SEE SLIDE 32.
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using specific computer systems, components, software, operations
and functions. Any change to any of those factors may cause the results to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when
combined with other products. For more complete information visit http://www.intel.com/performance.
Intel® Xeon® Processor E5-2600 v4 Product Family
DB2: Accelerated for scalability and performance today Workload: IBM Proof of Performance and Scalability (POPS) 2TB
database.
NormalizedPerformance
www.ibm.com
14. * Other Names and Brands May Be Claimed as the Property of Others
0
1
2S Intel® Xeon® processor E5-2699 v3
2S Intel® Xeon® processor E5-2699 v4
IBM IWA increased performance with the 2S Intel®
Xeon® processor E5-2699 v4
IBM*
Informix Warehouse Accelerator* (IWA)
The IBM Informix Warehouse Accelerator is an in-memory database accelerator for
the IBM Informix database server, which includes deep columnar and compression
technology to improve query performance and reduce typical query tuning and
database tuning. Multi-core and vector optimized algorithms paired with massive
parallelism exploit the increased cores of the Intel® Xeon® processor E5-2600 v4
product family with SIMD technology. Frequency partitioning in combination with
predicate evaluation on compressed data allow optimal access of the data
residing in memory. IBM IWA produced up to a 16% improvement with the Intel®
Xeon® processor E-2699 v4 compared to the previous generation processor.
14
www.ibm.com
IWA optimized for Intel® SIMD instructions.
IWA optimization for highly-parallel processing on Intel® Xeon® processors.
Enterprise Database
Up to 16%
faster
1 - Testing conducted on ISV* software comparing 2S Intel® Xeon® Processor E5-2699 v4 to 2S Intel® Xeon® Processor E5-2699 v3. Testing done by ISV. For complete testing configuration details, SEE SLIDE 32.
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using specific computer systems, components, software, operations
and functions. Any change to any of those factors may cause the results to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when
combined with other products. For more complete information visit http://www.intel.com/performance.
Intel® Xeon® Processor E5-2600 v4 Product Family
Brilliant marriage of the Intel® Xeon® processor
E5-2699 v4 hardware and database software Workload: Analytical queries on noSQL sensor Time Series data (2.5
billion records)
Normalizedperformance
15. * Other Names and Brands May Be Claimed as the Property of Others
2x2andBettertogetherstories
15
16. * Other Names and Brands May Be Claimed as the Property of Others 16
MoreTransactionsperSecondwithMicrosoftSQLServer*
andIntel®Xeon®ProcessorE5-2699v4
Handling More Peak Database Transactions Together
2012 2016
Software Upgrade
Microsoft SQL Server* 2016
Performance and Scalability Enhancements
In-Memory Online Transaction Processing
Faster query response times
Hardware Upgrade
Intel® Xeon® processor E5-2699 v4
Increased parallelism - up to 22 cores, up to 2-sockets per server
natively
Up to 1.5TB of DDR4 memory supported per socket1
Reduce transaction bottlenecks with newer
Intel® SSD DC S3700 Series
Software
Baseline
Microsoft
SQL Server2012*
Enterprise Edition
Better Together
Up to 2.6x More On-Line Transaction Processing
requests per second for peak times2
Delivers in-memory analytics and business insight
through a modern, fully-integrated enterprise-
class data platform
Software and workloads used in performance tests may have been optimized for performance only
on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using
specific computer systems, components, software, operations and functions. Any change to any of
those factors may cause the results to vary. You should consult other information and performance
tests to assist you in fully evaluating your contemplated purchases, including the performance of that
product when combined with other products.
1 Up to 3TB of memory supported per 2-socket server. Each socket supports 4 memory channels @
3 DIMMs per channel = 12 DIMM slots per socket. Using 128GB memory DIMMS = 1.5TB per socket =
3 TB of memory per 2P server.
2 Up to 2.6x more transactions per second comparing HPE* Proliant DL380p Gen8 Server with two
Intel® Xeon® processor E5-2690, 256GB Memory (source: http://www.tpc.org/4060) to a Lenovo*
x3650 M5 Server with two Intel® Xeon® processor E5-2699 v4, 512GB Memory (source: to be updated
on 31 March 2016).
For more information, visit intel.com/performance
Hardware
Baseline
Intel® Xeon®
processor
E5-2690
Benchmark : TPC-E*
17. * Other Names and Brands May Be Claimed as the Property of Others
1,881
4,938
0
1,000
2,000
3,000
4,000
5,000
6,000
Intel® Xeon® processor E5-2690 + Microsoft SQL Server* 2012 EE Intel® Xeon® processor E5-2699 v4 + Microsoft SQL Server* 2016 EE
TransactionsperSecond
17
MoreTransactionsperSecondwithMicrosoftSQLServer*
andIntel®Xeon®ProcessorsE5-2699v4
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured
using specific computer systems, components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and
performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when combined with other products.
Configuration details on next slide.
For more complete information visit http://www.intel.com/performance.
Higher is better
Up to 2.6x more
Transactions/Second
18. * Other Names and Brands May Be Claimed as the Property of Others 18
ConfigurationDetails
Refresh Microsoft SQL Server* OLTP with Intel® Xeon® Processor E5-2699 v4
Processor
Intel® Xeon® processor E5-2690
(8 cores, 16 threads)
Intel® Xeon® processor E5-2699 v4
(22 Cores, 44 Threads)
Memory 256 GB (16x16 GB DDR3-1600) 512 GB (16 x 32 GB DDR4-2400)
Disk
32 x 400GB SAS SSD (Database)
2 x 500GB SAS 7.2K RPM HDD
2 x 900GB SAS HDD (Tempdb)
4 x 800GB SAS SSD (DB Log)
53 x 800GB SAS SSD (Database)
OS Distribution Microsoft Windows Server* 2012 SE Microsoft Windows Server* 2012 SE
Software Microsoft SQL Server* 2012 EE Microsoft SQL Server* 2016 EE
OLTP Throughput 1,881 K transactions per second 4,938 K transactions per second
Source http://www.tpc.org/4060 To be update 31 March 2016
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and
MobileMark, are measured using specific computer systems, components, software, operations and functions. Any change to any of those factors may cause the results
to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that
product when combined with other products.
For more complete information visit http://www.intel.com/performance.
19. * Other Names and Brands May Be Claimed as the Property of Others 19
DeliverFasterInsightswithRealValuewithMicrosoftSQLServer*andIntel®Xeon®
ProcessorE5-2699v4
Microsoft SQL Server* and Intel® architecture deliver a fully-integrated data platform for in-
memory computing and real-time business intelligence.
2013 2016
Software Upgrade
Microsoft SQL Server* 2016 EE
Performance and Scalability Enhancements
In-Memory Online Transaction Processing
Faster query response times
Software
Baseline
Microsoft Windows
Server* 2012 R2 SE
Microsoft SQL
Server* 2014 EE
Better Together
Up to 2.2X improvement in virtualized
performance2
Delivers deeper analytics and business insight
through a modern, fully-integrated enterprise-
class data platform
Hardware
Baseline
Intel® Xeon®
processor E5-
2690 v2
Hardware Upgrade
Intel® Xeon® processor E5-2699 v4
Built on Intel’s industry-leading 14nm second-
generation Tri-Gate transistor technology
Increased parallelism—up to 22 cores/44 threads per
socket
Up to 1.5TB of DDR4 memory supported per socket1
Software and workloads used in performance tests may have been optimized for performance only on
Intel microprocessors.
Performance tests, such as SYSmark and MobileMark, are measured using specific computer systems,
components, software, operations and functions. Any change to any of those factors may cause the
results to vary. You should consult other information and performance tests to assist you in fully
evaluating your contemplated purchases, including the performance of that product when combined
with other products. For more complete information visit http://www.intel.com/performance.
1. Up to 3TB of memory supported per 2-socket server. Each socket supports 4 memory channels @
3 DIMMs per channel = 12 DIMM slots per socket. Using 128GB memory DIMMS = 1.5TB per socket =
3 TB of memory per 2P server
2 Up to 2.2x performance improvement based on TPC-H workload comparing baseline Cisco UCS
C240 M3 Model Enterprise Server with two Intel® Xeon® processor E5-2590 v2 3GHz, 768GB memory
scoring 304,361.7 QphH, costing $221,937, $0.73/QphH (source: http://tpc.org/3301 ) to HPE*
Proliant DL380 Gen9 Server with two Intel® Xeon® processor E5-2699 v4 2.2GHz, 768GB memory
scoring 678,492.3 QphH costing $428,737, $0.64/QphH (Source: to be updated on 31 March 2016)
Benchmark : TPC-H*
20. * Other Names and Brands May Be Claimed as the Property of Others
304,361
678,492
0
100,000
200,000
300,000
400,000
500,000
600,000
700,000
800,000
Intel® Xeon® processor E5-2690 + Microsoft SQL
Server* 2014 EE
Intel® Xeon® processor E5-2699 v4 + Microsoft SQL
Server* 2016 EE
QphH@1000GB
20
DeliverFasterInsightswithRealValuewithMicrosoftSQLServer*andIntel®Xeon®
ProcessorE5-2699v4
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using specific computer systems,
components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated
purchases, including the performance of that product when combined with other products.
Configuration details on next slide.
For more complete information visit http://www.intel.com/performance.
Higher is Better
Up to 2.2X more
composite queries/hour
Microsoft SQL Server* and Intel® architecture deliver a fully-integrated data platform for in-
memory computing and real-time business intelligence.
21. * Other Names and Brands May Be Claimed as the Property of Others 21
ConfigurationDetails
Deliver Faster Insights with Real Value with Microsoft SQL Server* and Intel® Xeon® Processor
E5-2699 v4
Processor Intel® Xeon® processor E5-2690 v2 Intel® Xeon® processor E5-2699 v4
Cores/Threads 10/20 22/44
Memory 768GB (24 x 32GB DDR3-1866) 768GB (16 x 32GB PC4-2400T)
Operating System Microsoft Windows Server* 2012 R2 SE
Microsoft Windows Server* 2012 R2
SE
Software Microsoft SQL Server* 2014 EE Microsoft SQL Server* 2016 EE
QphH@1000GB 304,361.7 678,492.3
$/QphH@1000GB $0.73 USD $0.64 USD
Source http://www.tpc.org/3301 To be updated on 31 March 2016
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are
measured using specific computer systems, components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other
information and performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when combined with other products.
For more information, visit intel.com/performance
22. * Other Names and Brands May Be Claimed as the Property of Others
MaximizeThroughputwithIntel®Xeon®ProcessorE5-2699v4andSAP*ERP
2012 2016
Software Baseline
SAP* EHP5 for SAP ERP 6.0
Sybase* ASE 16.0
Fast queries with automatic optimizations
Efficient Indexing
Hardware Upgrade
Intel® Xeon® processor E5-2699 v4
Increased parallelism - up to 22 cores, up to 2-sockets
per server natively
Up to 1.5TB of DDR4 memory supported per socket1
Software
Baseline
• SAP* EHP5 for
SAP ERP 6.0
• Sybase ASE 15.7
Better Together
Up to 3.2xmore benchmark users2
Improve querying speed
Support more users3
Hardware
Baseline
• Intel® Xeon®
processor E5-
2690
SAP and SAP NetWeaver are the registered trademarks of SAP AG in Germany and in
several other countries. See www.sap.com/benchmark for more information.
Software and workloads used in performance tests may have been optimized for
performance only on Intel microprocessors. Performance tests, such as SYSmark and
MobileMark, are measured using specific computer systems, components, software,
operations and functions. Any change to any of those factors may cause the results to
vary. You should consult other information and performance tests to assist you in fully
evaluating your contemplated purchases, including the performance of that product
when combined with other products.
For more information, visit intel.com/performance
*1,2,3 - Additional information on the following page.
Benchmark : SAP SD 2-Tier
Process more Orders per Hour
85
23. * Other Names and Brands May Be Claimed as the Property of Others
MaximizeThroughputwithIntel®Xeon®ProcessorE5-2699v4andSAP*ERP
SAP and SAP NetWeaver are the registered trademarks of SAP AG in Germany and in several other countries. See www.sap.com/benchmark for more information.
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using specific computer systems, components, software,
operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product
when combined with other products.
For more information, visit intel.com/performance
1. Up to 3TB of memory supported per 2-socket server. Each socket supports 4 memory channels @ 3 DIMMs per channel = 12 DIMM slots per socket. Using 128GB memory DIMMS = 1.5TB per socket = 3 TB of memory per 2P server
2,3 Up to 3.2x more SAP SD 2-tier benchmark users running SAP SD 2-tier workload comparing Cisco* UCS B200 M3 server with two Intel® Xeon® processor E5-2690, 256GB memory running SAP* EHP 5 for ERP 6.0 + Sybase* ASE 15.7 scoring 6,530 benchmark
users (Source) to a Dell* PowerEdge R730 server with two Intel Xeon processor E5-2699 v4, 512GB memory running SAP* enhancement package 5 for SAP ERP 6.0 + Sybase* ASE 16.0, scoring 21,050 benchmark users (Source)
Configuration Details on next slide
Higher is Better
6,530
21,050
0
5,000
10,000
15,000
20,000
25,000
Intel® Xeon® processor E5-2690 Intel® Xeon® processor E5-2699 v4
NumberofSAP*SDBenchmarkUsers
Up to 3.2X more SAP SD
Benchmark Users
86
24. * Other Names and Brands May Be Claimed as the Property of Others
ConfigurationDetails:MaximizeThroughputwith
Intel®Xeon®ProcessorE5-2699v4andSAP*ERP
Processor
Intel® Xeon® processor E5-2690
(8 cores, 16 threads)
Intel® Xeon® processor E5-2699 v4
(22 cores, 44 threads)
Memory 256GB 512GB
SAP enhancement package SAP* enhancement package 5 for SAP ERP 6.0 SAP* enhancement package 5 for SAP ERP 6.0
OS Distribution Red Hat* Enterprise Linux 6.3 Red Hat* Enterprise Linux 7.2
Database Sybase* ASE 15.7 Sybase* ASE 16.0
Number of SAP SD benchmark users 6,530 21,050
Source Source To be updated on 31 March 2016
SAP and SAP NetWeaver are the registered trademarks of SAP AG in Germany and in several other countries. See www.sap.com/benchmark for more information.
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using specific
computer systems, components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and performance tests to assist you in
fully evaluating your contemplated purchases, including the performance of that product when combined with other products.
For more information, visit intel.com/performance
Process more Orders per Hour
87
25. * Other Names and Brands May Be Claimed as the Property of Others
MoreQueriesperSecondwithMariaDB*
andIntel®Xeon®ProcessorE5-2697v4^
25
Handling More Peak Database Queries Together
2012 2016
Software Upgrade
Ubuntu* 15.10
MariaDB* 10.1
Robust, scalable, and reliable SQL server
Faster query response times
In-Memory Online Transaction Processing
Hardware Upgrade^
Intel® Xeon® processor E5-2697 v4
Increased parallelism - up to 22 cores, up to 2-sockets per server
natively
Up to 1.5TB of DDR4 memory supported per socket1
Reduce transaction bottlenecks with newer
Intel® SSD Data Center Series
Software
Baseline
Ubuntu* 12.04
MariaDB* 10.0.4
Better Together
Up to 2.8X (estimated)^ more queries per second
for peak times2
Intel® and MariaDB delivers faster response times
to customer’s complex queries
Software and workloads used in performance tests may have been optimized for performance only on
Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using
specific computer systems, components, software, operations and functions. Any change to any of
those factors may cause the results to vary. You should consult other information and performance
tests to assist you in fully evaluating your contemplated purchases, including the performance of that
product when combined with other products.
Results have been estimated or simulated using internal Intel analysis or architecture simulation or
modeling, and provided to you for informational purposes. Any differences in your system hardware,
software or configuration may affect your actual performance.
1 Up to 3TB of memory supported per 2-socket server. Each socket supports 4 memory channels @ 3
DIMMs per channel = 12 DIMM slots per socket. Using 128GB memory DIMMS = 1.5TB per socket = 3
TB of memory per 2P server.
2 Up to 2.8x estimated more queries per second comparing baseline Intel® Server platform with two
Intel® Xeon® processor E5-2680, 64GB Memory (source: Intel® technical report #1942) to an Intel®
Server platform with two Intel® Xeon® processor E5-2697 v4, 64GB Memory (source: Intel® technical
report #1942).
For more information, visit intel.com/performance
Hardware
Baseline
Intel® Xeon®
processor
E5-2680
Benchmark : Sysbench OLTP
+
^ The results shown for the Intel® Xeon® processor E5-2697 v4 have been estimated based on
measured data obtained using the Intel® Xeon® processor E5-2699 v4
26. * Other Names and Brands May Be Claimed as the Property of Others
14,393
41,412
0
5,000
10,000
15,000
20,000
25,000
30,000
35,000
40,000
45,000
Intel® Xeon® processor E5-2680 Intel® Xeon® processor E5-2697 v4
QueriesperSecond
MoreQueriesperSecondwithMariaDB*
andIntel®Xeon®ProcessorsE5-2697v4^
26
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured
using specific computer systems, components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and
performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when combined with other products.
Results have been estimated or simulated using internal Intel analysis or architecture simulation or modeling, and provided to you for informational purposes. Any differences in your system
hardware, software or configuration may affect your actual performance.
Configuration details on next slide.
For more complete information visit http://www.intel.com/performance.
Higher is better Up to 2.8X^ more
Queries/Second
+
^ The results shown for the Intel® Xeon® processor E5-2697 v4 have been estimated based on measured data obtained using the Intel® Xeon® processor E5-2699 v4
27. * Other Names and Brands May Be Claimed as the Property of Others
ConfigurationDetails
27
More Queries per Second with MariaDB* and Intel® Xeon® Processor E5-2697 v4^
Processor
Intel® Xeon® processor E5-2680
(16 cores, 32 threads)
Intel® Xeon® processor E5-2697 v4
(18 Cores, 36 Threads)
Memory 64 GB (8x 8GB DDR3-1600) 64 GB (8x 8GB DDR4-2133)
OS Distribution Ubuntu* 12.04 Ubuntu* 15.10
Database Version MariaDB* 10.0.4 MariaDB* 10.1
OLTP Throughput 14,393 queries per second 41,412^ queries per second
Source Intel Internal Testing Intel Technical Report #1942
+
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured
using specific computer systems, components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and
performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when combined with other products.
Results have been estimated or simulated using internal Intel analysis or architecture simulation or modeling, and provided to you for informational purposes. Any differences in your system
hardware, software or configuration may affect your actual performance.
For more complete information visit http://www.intel.com/performance.
^ The results shown for the Intel® Xeon® processor E5-2697 v4 have been estimated based on measured data obtained using the Intel® Xeon® processor E5-2699 v4
28. * Other Names and Brands May Be Claimed as the Property of Others
MoreQueriesperSecondwithMySQL*
andIntel®Xeon®ProcessorE5-2697v4^
28
Handling More Peak Database Queries Together
2012 2016
Software Upgrade
Ubuntu* 15.10
MySQL* 5.7
Faster query response times
New Optimizer
Native JSON Support
Hardware Upgrade^
Intel® Xeon® processor E5-2697 v4
Increased parallelism - up to 22 cores, up to 2-sockets per server
natively
Up to 1.5TB of DDR4 memory supported per socket1
Reduce transaction bottlenecks with newer
Intel® SSD Data Center Series
Software
Baseline
Ubuntu* 12.04
MySQL* 5.6.12
Better Together
Up to 2.8X^ (estimated) more queries per second
for peak times2
Intel® Xeon® processors and MySQL provides
customers with more queries per second and
faster response times.
Software and workloads used in performance tests may have been optimized for performance only on
Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured using
specific computer systems, components, software, operations and functions. Any change to any of
those factors may cause the results to vary. You should consult other information and performance
tests to assist you in fully evaluating your contemplated purchases, including the performance of that
product when combined with other products.
Results have been estimated or simulated using internal Intel analysis or architecture simulation or
modeling, and provided to you for informational purposes. Any differences in your system hardware,
software or configuration may affect your actual performance.
1 Up to 3TB of memory supported per 2-socket server. Each socket supports 4 memory channels @ 3
DIMMs per channel = 12 DIMM slots per socket. Using 128GB memory DIMMS = 1.5TB per socket = 3
TB of memory per 2P server.
2 Up to 2.8x^ more estimated queries per second comparing baseline Intel® Server platform with two
Intel® Xeon® processor E5-2680, 64GB Memory (source: Intel® technical report #1942) to an Intel®
Server platform with two Intel® Xeon® processor E5-2697 v4, 64GB Memory (source: Intel® technical
report #1952).
For more information, visit intel.com/performance
Hardware
Baseline
Intel® Xeon®
processor
E5-2680
Benchmark : Sysbench OLTP
+
^ The results shown for the Intel® Xeon® processor E5-2697 v4 have been estimated based on
measured data obtained using the Intel® Xeon® processor E5-2699 v4
29. * Other Names and Brands May Be Claimed as the Property of Others
15,247
43,786
0
5,000
10,000
15,000
20,000
25,000
30,000
35,000
40,000
45,000
50,000
Intel® Xeon® processor E5-2680 Intel® Xeon® processor E5-2697 v4
QueriesperSecond
MoreQueriesperSecondwithMySQL*
andIntel®Xeon®ProcessorE5-2697v4^
29
Higher is better
Up to 2.8X^ more
Queries/Second
+
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured
using specific computer systems, components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and
performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when combined with other products.
Results have been estimated or simulated using internal Intel analysis or architecture simulation or modeling, and provided to you for informational purposes. Any differences in your system
hardware, software or configuration may affect your actual performance.
Configuration details on next slide.
For more complete information visit http://www.intel.com/performance.
^ The results shown for the Intel® Xeon® processor E5-2697 v4 have been estimated based on measured data obtained using the Intel® Xeon® processor E5-2699 v4
30. * Other Names and Brands May Be Claimed as the Property of Others
ConfigurationDetails
30
More Queries per Second with MySQL* and Intel® Xeon® Processor E5-2697 v4
Processor
Intel® Xeon® processor E5-2680
(16 cores, 32 threads)
Intel® Xeon® processor E5-2697 v4
(18 Cores, 36 Threads)
Memory 64 GB (8x 8GB DDR3-1600) 64 GB (8x 8GB DDR4-2133)
OS Distribution Ubuntu* 12.04 Ubuntu* 15.10
Database Version MySQL* 5.6.12 MySQL* 5.7
OLTP Throughput 15,247 queries per second 43,786 queries per second^
Source Intel Internal Testing Intel Technical Report #1952
+
Software and workloads used in performance tests may have been optimized for performance only on Intel microprocessors. Performance tests, such as SYSmark and MobileMark, are measured
using specific computer systems, components, software, operations and functions. Any change to any of those factors may cause the results to vary. You should consult other information and
performance tests to assist you in fully evaluating your contemplated purchases, including the performance of that product when combined with other products.
Results have been estimated or simulated using internal Intel analysis or architecture simulation or modeling, and provided to you for informational purposes. Any differences in your system
hardware, software or configuration may affect your actual performance.
For more complete information visit http://www.intel.com/performance.
^ The results shown for the Intel® Xeon® processor E5-2697 v4 have been estimated based on measured data obtained using the Intel® Xeon® processor E5-2699 v4
32. * Other Names and Brands May Be Claimed as the Property of Others
ProofpointConfigurationDetails:
Oracle MySQL: Sysbench OLTP, transactions per second (TPS) workload. Testing by Intel, 3/3/2016
BASELINE: 1-Node, 2 x Intel® Xeon® Processor E5-2697 v3 on Grantley-EP (Wellsburg) with 64 GB Total Memory, 8 slots / 8 GB / 2133 MT/s / DDR4 RDIMM, In-memory storage (RAM disk), disk I/O is not a
bottleneck, CPU bound, default BIOS settings, HT and turbo on, on Ubuntu 15.10 using Oracle's MySQL 5.7, Sysbench OLTP 0.4.12. Data Source: Request Number: 1952
NEW: 1-Node, 2 x Intel® Xeon® Processor E5-2699 v4 on Grantley-EP (Wellsburg) with 64 GB Total Memory, 8 slots / 8 GB / 2133 MT/s / DDR4 RDIMM, In-memory storage (RAM disk), disk I/O is not a
bottleneck, CPU bound, default BIOS settings, HT and turbo on, on Ubuntu 15.10 using Oracle's MySQL 5.7, Sysbench OLTP 0.4.12. Data Source: Request Number: 1952
MariaDB: Sysbench OLTP 0.4.12, transactions per second (TPS) workload. Testing by Intel, 3/3/2016
BASELINE: 1-Node, 2 x Intel® Xeon® Processor E5-2697 v3 on Grantley-EP (Wellsburg) with 64 GB Total Memory, 8 slots / 8 GB / 2133 MT/s / DDR4 RDIMM, In-memory storage (RAM disk), disk I/O is not a
bottleneck, CPU bound, default BIOS settings, HT and turbo on, on Ubuntu 15.10 using MariaDB 10.1, Sysbench OLTP 0.4.12. Data Source: Request Number: 1942
NEW: 1-Node, 2 x Intel® Xeon® Processor E5-2699 v4 on Grantley-EP (Wellsburg) with 64 GB Total Memory, 8 slots / 8 GB / 2133 MT/s / DDR4 RDIMM, In-memory storage (RAM disk), disk I/O is not a
bottleneck, CPU bound, default BIOS settings, HT and turbo on, on Ubuntu 15.10 using MariaDB 10.1,. Data Source: Request Number: 1942
Nomura Research Institute, Ltd.* BOS: Real-time stock calculation workload; Benchmark schema derived from TPC-H* queries. Testing done by NRI and Intel, 1/28/2016
BASELINE: 1-Node, 2 x Intel® Xeon® Processor E5-2699 v3 on Grantley-EP (Wellsburg) with 64 GB Total Memory, 8 slots / 8 GB / 2133 MT/s / DDR4 RDIMM, SSD SATA P3700 400G, on Red Hat Enterprise
Linux* 7.0 kernel 3.10.0-123 using Java 8u25, PostgreSQL 9.4. Data Source: Request Number: 1951
NEW: 1-Node, 2 x Intel® Xeon® Processor E5-2699 v4 on Grantley-EP (Wellsburg) with 128 GB Total Memory, 8 slots / 16 GB / 2400 MT/s / DDR4 RDIMM, SSD SATA P3700 400G, on Red Hat Enterprise Linux*
7.0 kernel 3.10.0-123 using Java 8u25, PostgreSQL 9.4. Data Source: Request Number: 1951
Altibase HDB*: In-memory DBMS queries per second workload. Testing by Intel, 2/16/2016
BASELINE: 1-Node, 2 x Intel® Xeon® Processor E5-2699 v3 on Grantley-EP (Wellsburg) with 128 GB Total Memory, 8 slots / 16 GB / 2133 MT/s / DDR4 RDIMM, 1TB HDD (SATA 7200rpm), HT and turbo on, on
Red Hat Enterprise Linux* 6.4 kernel 2.6.32-358 using Intel Compiler 16 . Data Source: Request Number: 1904
NEW: 1-Node, 2 x Intel® Xeon® Processor E5-2699 v4 on Grantley-EP (Wellsburg) with 128 GB Total Memory, 8 slots / 16 GB / 2400 MT/s / DDR4 RDIMM, 1TB HDD (SATA 7200rpm), HT and turbo on, on Red
Hat Enterprise Linux* 7.1 kernel 3.10.0-229 using Intel Compiler 16 . Data Source: Request Number: 1904
IBM DB2: POPS queries workload. Testing by Intel, 2/11/2016
BASELINE: 1-Node, 2 x Intel® Xeon® Processor E5-2699 v3 on Grantley-EP (Wellsburg) with 192 GB Total Memory, 24 slots / 8 GB / 2133 MT/s / DDR4 RDIMM / running at 1600MT/s, 2x 800GHz Intel S3700
SSD, 30R3 C-states off, turbo on, on SUSE Linux Enterprise Server* 11 SP3 using IBM DB2 10.5 FP7 running 36 queries. Data Source: Request Number: 1932
NEW: 1-Node, 2 x Intel® Xeon® Processor E5-2699 v4 on Grantley-EP (Wellsburg) with 192 GB Total Memory, 24 slots / 8 GB / 2133 MT/s / DDR4 RDIMM / BIOS reports 1600MHz due to full memory population,
2x 800GHz Intel S3700 SSD, 271.RR00 C-States off, turbo on, on SUSE Linux Enterprise Server* 11 SP3 using IBM DB2 v10.5 FP7 running 36 queries. Data Source: Request Number: 1932
IBM* Informix Warehouse Accelerator (IWA): In-memory accelerator total time workload. Testing by Intel, 2/11/2016
BASELINE: 1-Node, 2 x Intel® Xeon® Processor E5-2699 v3 on Grantley-EP (Wellsburg) with 192 GB Total Memory, 24 slots / 8 GB / 2133 MT/s / DDR4 RDIMM / BIOS reports 1600MHz due to full memory
population, BIOS reports 1600MHz due to full memory population, 1x 800GB Intel S3700 SSD, HT and turbo on, on Red Hat Enterprise Linux* 6.5 kernel 2.6.32-431 using Informix 12.10. Data Source: Request
Number: 1933
NEW: 1-Node, 2 x Intel® Xeon® Processor E5-2699 v4 on Grantley-EP (Wellsburg) with 192 GB Total Memory, 24 slots / 8 GB / 2133 MT/s / DDR4 RDIMM / BIOS reports 1600MHz due to full memory
population, BIOS reports 1600MHz due to full memory population, 1x 800GB Intel S3700 SSD, HT and turbo on, on Red Hat Enterprise Linux* 6.5 kernel 2.6.32-431 using Informix 12.10. Data Source: Request
Number: 1933
32
