This document provides an overview of how to integrate Red Hat CloudForms 4 with OpenShift 3 to retrieve container metrics. It describes demonstrating the integration, installing and configuring CloudForms 4 to add OpenShift 3.1 as a container provider, configuring Hawkular on OpenShift to expose metrics via the Hawkular Metrics API, and modifying the Hawkular configuration to make it compatible with how CloudForms expects to retrieve metrics. The presentation contains steps for configuring CloudForms and OpenShift, creating service accounts, adding roles, and configuring routes to expose the Hawkular Metrics API on a port CloudForms can access.

1. INTEGRATE OPENSHIFT WITH
CLOUDFORMS 4
Technical presentation
Michael Lessard
Senior Solutions Architect
February 2016

2. Cloudforms 4 :: Openshift 3
Agenda
2
● Demonstration
● Install and configure Cloudforms 4
○ Add Openshift 3.1 as a container provider
● Getting the metrics in Cloudforms
○ Configure Hawkular (Openshift doc way)
○ Modify the Hawkular config

3. LET’S START WITH THE DEMO

4. Cloudforms 4 :: Openshift 3
My Openshift setup
4
● Openshift domain : os3.mlc.dom
● Openshift app domain : app.os3.mlc.dom

5. Cloudforms 4 :: Openshift 3
Requirements
5
● Virtual machine, 40Gig of space, 4 Gig of ram
● Openshift 3.1.1 installed
● Cloudforms 4 image downloaded (cfme-rhos-5.5.2.4-1.x86_64.
qcow2)

6. Cloudforms 4 :: Openshift 3

7. CONFIGURE CLOUDFORMS 4

8. Cloudforms 4 :: Openshift 3
Configure Cloudforms 4 - Part 1
8
1. Launch a new vm, use an existing image (4 gig of RAM is sufficient)
2. Login as root:smartvm
3. Configure the cloudforms appliance (# appliance_console)
a. assign an ip and hostname
b. Configure timezone
c. configure the database, do not need to use an external partition
4. Connect to the web interface. Username : admin, passwd : smartvm
5. Configure - Configuration, activate all roles except database synchro
and RHN mirror + configure the timezone (again)
6. Reboot the appliance

9. Cloudforms 4 :: Openshift 3
Configure Cloudforms 4 - Part 2
Add Openshift as a container provider
ON YOUR OPENSHIFT VM, RETRIEVE AN ADMIN KEY
# oc login -u system:admin -n default
# oc get -n management-infra sa/management-admin --template='{{range .
secrets}}{{printf "%sn" .name}}{{end}}'
management-admin-token-2g4iv
management-admin-dockercfg-02kl4
management-admin-token-5xqyo
# oc get -n management-infra secrets management-admin-token-2g4iv --
template='{{.data.token}}' | base64 -d > key.txt
9
Copy the key
https://access.redhat.com/documentation/en/red-hat-cloudforms/version-4.0
/managing-providers/#configuring_service_accounts

10. Cloudforms 4 :: Openshift 3
Configure Cloudforms 4 - Part 3
10
1. Login into the CF4 interface
2. Containers - Provider - Configuration - Add New containers provider
3. Put a name and select in type Openshift
4. Put the hostname and port 8443
5. Past the key then click validate
6. Et voilà :)
Add Openshift as a container provider

11. Cloudforms 4 :: Openshift 3

12. GETTING THE METRICS IN
CLOUDFORMS 4

13. CONFIGURE HAWKULAR PART 1
(Openshift doc way)

14. Cloudforms 4 :: Openshift 3
Configure Hawkular - Part 1
Create the service account
# oc project openshift-infra (should be there by default)
# oc create -f - <<API
apiVersion: v1
kind: ServiceAccount
metadata:
name: metrics-deployer
secrets:
- name: metrics-deployer
API
14

15. Cloudforms 4 :: Openshift 3
Configure Hawkular - Part 2
ADD ROLES TO SOME SERVICE ACCOUNT
# oadm policy add-role-to-user edit system:serviceaccount:openshift-infra:
metrics-deployer
# oadm policy add-cluster-role-to-user cluster-reader system:serviceaccount:
openshift-infra:heapster
CREATES A SUPER SECURE SECRET
# oc secrets new metrics-deployer nothing=/dev/null
COPY THE TEMPLATE
# cp /usr/share/ansible/openshift-
ansible/roles/openshift_examples/files/examples/v1.1/infrastructure-
templates/enterprise/metrics-deployer.yaml /root/metrics.yaml
15

16. Cloudforms 4 :: Openshift 3
Configure Hawkular - Part 3
# cd /root/
# oc process -f metrics.yaml -v
HAWKULAR_METRICS_HOSTNAME=metrics.app.os3.mlc.dom,USE_PERSISTENT_STORAGE=false,
IMAGE_PREFIX=openshift3/,IMAGE_VERSION=latest
| oc create -f -
*** a reboot might be required … and wait … oc get pods is your friend
# vi /etc/origin/master/master-config.yaml
assetConfig:
.....
metricsPublicURL: https://metrics.app.os3.mlc.dom/hawkular/metrics
# systemctl restart atomic-openshift-master
16
Using a webbrowser, validate that Hawkular is started

17. Cloudforms 4 :: Openshift 3

18. Cloudforms 4 :: Openshift 3

19. MODIFY HAWKULAR CONFIGURATION
TO MAKE IT WORKS WITH CF4

20. Cloudforms 4 :: Openshift 3
Router for CF - map port 5000
At the moment a limitation in CloudForms Management Engine is assuming that the provider
Hostname is used also to collect the metrics.
Create an openshift router to give access to the metric information for
Cloudforms
# oadm router management-metrics -n default --
credentials=/etc/origin/master/openshift-router.kubeconfig --service-
account=router --ports='443:5000' --selector='kubernetes.
io/hostname=os3.mlc.dom' --stats-port=1937 --host-network=false
20

21. Cloudforms 4 :: Openshift 3
Modify the route config + OS3 config
# oc project openshift-infra
# oc edit route
hosts: os3.mlc.dom
# vi /etc/origin/master/master-config.yaml
assetConfig:
.....
masterPublicURL: https://os3.mlc.dom:8443
metricsPublicURL: https://os3.mlc.dom:5000/hawkular/metrics
# systemctl restart atomic-openshift-master
21
