Short presentation made for OpenStack London "Tokyo Aftermath" meetup, on current upstream activity in the OpenStack HA developers community around high availability for compute nodes.

1. Compute node HA
a.k.a. “can pets survive in OpenStack?”
Adam Spiers
Senior Software Engineer, Cloud & High Availability
aspiers@suse.com
OpenStack London Meetup, Wednesday 18th
November
– short update on upstream development

2. High Availability in
a typical OpenStack cloud today

3. 3
Typical HA control plane in OpenStack
Pacemaker Cluster
Control Node 1 Node
DRBD
PostgreSQL
RabbitMQ
Keystone
Glance
Nova
Dashboard
Cinder
Neutron
Database Cluster
Node 1 Node 2
DRBD or shared storage
Database
Message Queue
Services Cluster
Node 1 Node 2 Node 3
Orchestration
Keystone
Glance
Nova
Dashboard
Cinder
Telemetry
Neutron
• Maximises cloud uptime
• Automatic restart of
OpenStack controller
services
• Active/Active API services
with load balancing
• DB + MQ either
Active/Active or
Active/Passive

4. 4
Under the covers
Services Cluster
Node 1 Node 2 Node 3
• Recommended by
official HA guide
• HAProxy distributes service
requests
• Pacemaker
‒ monitoring and control of nodes
and services
• Corosync
‒ cluster membership /
messaging / quorum /
leadership election
Corosync
Pacemaker
HAProxy
But what I really want to do is keep my workloads up!

5. 6
HA Cluster
Control node
OS
Message queue
Database
Identity
Images
Block storage
Networking
Dashboard
Compute
OS
Compute node
nova-compute
libvirt
HA only on control plane
OS
Compute node
nova-compute
libvirt
OS
Compute node
nova-compute
libvirt

6. 7
HA Cluster
Control node
OS
Message queue
Database
Identity
Images
Block storage
Networking
Dashboard
Compute
OS
Compute node
nova-compute
libvirt
Can we simply extend the cluster?
OS
Compute node
nova-compute
libvirt
OS
Compute node
nova-compute
libvirt

7. 8

8. 9
Scaling up
• Corosync requires <= 32 nodes
• But we want lots of compute nodes!
• The obvious workarounds are ugly
‒ Multiple compute clusters
‒ introduces unwanted artificial boundaries
‒ Clusters inside / between guest VM instances
‒ requires cloud users to modify guest images (installing & configuring cluster
software)
‒ cluster stacks are not OS-agnostic
‒ cloud is supposed to make things easier not harder!

9. 10
pacemaker_remote to the rescue!
• New(-ish) Pacemaker feature
• Allows arbitrary scalability of an existing
Pacemaker cluster

10. 11
Extending the cluster to compute nodes
Services Cluster
Node 1 Node 2 Node 3
Corosync
Pacemaker
HAProxy Compute node
pacemaker_remote
Compute node
pacemaker_remote
Compute node
pacemaker_remote
Compute node
pacemaker_remote

11. 12
Capabilities
• Increases availability of compute nodes
‒ Detects failed compute services
‒ Automatic recovery of compute services where possible
• “Quarantines” failing compute nodes
‒ STONITH (fencing) extends to remote nodes
• Coordinates with control plane
‒ VMs on dead compute nodes are resurrected elsewhere
‒ In nova, this is described as “evacuation”

12. 13
Public Health Warning
nova evacuate does not really mean evacuation!

13. 14
Think about earthquakes
Not too late
to evacuate
Too late to
evacuate

14. 15
nova terminology
nova live-migration
nova evacuate

15. 16
Public Health Warning
• nova evacuate does not do evacuation
• nova evacuate does resurrection
• In Vancouver, nova developers considered a rename
‒ Hasn't happened yet
‒ Due to impact, seems unlikely to happen any time soon
‒ Whenever you see “evacuate” in a nova-related context,
pretend you saw “resurrect”

16. 17
Existing solutions
• NovaCompute / NovaEvacuate custom OCF RAs
‒ used by Red Hat / SUSE / Intel
‒ works with known limitations
• EvacuationD
‒ PoC to address above limitations
‒ decouples resurrection workflow from Pacemaker
• Masakari (NTT)
‒ similar architecture, different code
‒ monitoring at 3 layers (node, process, hypervisor)
• Approach of AWcloud / ChinaMobile
‒ very different; uses consul / raft / gossip

17. 18
Proposed solutions
• Use Mistral to orchestrate resurrection workflow
• Intel currently working on prototype
• Possibly the most promising approach
‒ Mistral considered pretty solid
‒ This is exactly the kind of thing it was designed for
• However, Mistral currently a SPoF … oops
‒ Don't worry, should be fixed in mitaka cycle
• Feasibility of convergence with Masakari will probably
be analysed within next week or two

18. 19
Community developments
• openstack-resource-agents project now on
stackforge
‒ maintained by me
• New #openstack-ha IRC channel on FreeNode
‒ automatic notifications for activity on HA repositories
• New topic category on openstack-dev@ mailing list
Subject: [HA] i can haz pets in my cloud?
• Weekly IRC meetings at Monday 9am UTC
• HA guide currently undergoing a revamp
• Everyone welcome to get involved!

19. 21
