Highlighted notes on Hybrid Multicore Computing
While doing research work under Prof. Dip Banerjee, Prof. Kishore Kothapalli.
In this comprehensive report, Prof. Dip Banerjee describes about the benefit of utilizing both multicore systems, CPUs with vector instructions, and manycore systems, GPUs with large no. of low speed ALUs. Such hybrid systems are beneficial to several algorithms as an accelerator cant optimize for all parts of an algorithms (some computations are very regular, while some very irregular).
