Fracking technology involves injecting fluid into shale rock formations at high pressure to create fractures through which oil and gas can flow out. The process involves drilling wells deep underground and injecting a mixture of water, sand and chemicals to fracture the shale and release the hydrocarbons. While fracking has increased access to energy resources and lowered natural gas prices, it uses large amounts of water and raises environmental concerns about potential water and air contamination. Fracking has enabled countries like the US and Canada to boost oil and gas production from shale reserves. Pakistan also has significant shale gas reserves that could be extracted through fracking.
2. Table of Contents
Definition
History
Procedure
Advantage
Operations
Applications
2
3. What is Fracking ?
Is a technique designed to recover gas and oil from shale
rock(shale gas is trapped inside tiny pockets of rock)
Fracking is the process of drilling down into the earth before a
high-pressure water mixture is directed at the rock to release
the gas inside
Water, sand and chemicals are injected into the rock at high
pressure which allows the gas to flow out to the head of the well
3
4. History
1860’s: Fracturing, using nitroglyce, hard rock oil wells
1947: Floyd Farris of performs basic experiments of hydraulic fracturing
1970’s: The United States government initiated Projects
1997 – present: Development of "slick water fracturing
4
5. 5
• The problem is conventional hydrocarbon resources,
those that flow freely, are quickly diminishing,
while non conventional resources,
those that are locked in shale bed formations, are only
accessible though hydro-fracking.
6. Procedure
The hydraulic fracturing of shale rock formations by injecting fluid
into cracks to force them further open
The larger fissures allow more oil and gas to flow out of the formation and
into the wellbore. The gas released is methane, also referred to as natural
gas
6
8. Cont.
Drilling upto thousands of feet's below surface of earth to drill well
Cased and cemented, small perforations are made in the horizontal
portions of the pipe
a typical mixture of:
water(90%)
sand (9.5%)
chemicals(0.5%)
Pumped at high pressure to create micro-fractures
8
10. Advantages
As fracking grows, natural gas prices are dropping
Energy consumers are seeing economic gains
Despite economic gains , environmental concerns remain
Fracking allows drilling firms to access difficult to reach resources of oil
and gas.
10
11. Disadvantages
Uses huge amounts of water, which must be transported to the fracking
site
Air contamination
May cause small earth quakes
Applications:
Because of shale and fracking, the International Energy Agency projects
that the U.S. could become the world’s leading oil producer by 2015
2015: Canada produce half of CO2 as usually
11
12. Pakistan
Pakistan currently produces about 4.2 billion cubic feet of gas and about
70,000 barrels of oil per day
the Energy Information Administration (EIA), the American federal
authority on energy statistics and analysis, has estimated fresh
recoverable shale gas reserves of 105 trillion cubic feet (TCF) and
more than nine billion barrels of oil in Pakistan
Shale gas locations in Pakistan along border with India and Afghanistan
12
Modern day fracking didn't begin until the 1990s. This originated when George P. Mitchell created a new technique, which took hydraulic fracturing, and combined it with horizontal drilling. The technology known as hydraulic fracturing isn't new, and has been around for 100 plus years.
Stevens, Paul (August 2012). "The 'Shale Gas Revolution': Developments and Changes". Chatham House. Retrieved 2012-08-15.
Proppant: is a solid material, typically sand, treated sand or man-made ceramic materials, designed to keep an induced hydraulic fracture open, during or following a fracturing treatment.
Blender: a person or thing that mixes things together, in particular an electric mixing machine used in food preparation for liquidizing, chopping, or pureeing
Shale rock:
Barnett shale: is a geological formation located in the Bend Arch-Fort Worth Basin. It consists of sedimentary rocks dating from the Mississippian period (354–323 million years ago) in Texas.
In the rock.
Over 60% us oil and gas are drill through fracking .
Chemical : 700 d/f chemical agent such as benzene formic acid
3% of gas release in air during extraction process.
Alc to 2013 survey eia Pakistan currently produce.
