3. UNIT II ONE-DIMENSIONAL
PROBLEMS
One Dimensional Second Order Equations –
Discretization – Element types- Linear and Higher
order Elements – Derivation of Shape functions and
Stiffness matrices and force vectors- Assembly of
Matrices - Solution of problems from solid mechanics
and heat transfer. Longitudinal vibration frequencies
and mode shapes. Fourth Order Beam Equation –
Transverse deflections and Natural frequencies of
beams.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
3
4. ONE DIMENSIONAL FINITE
ELEMENT ANALYSIS
The geometry and other parameters of bar and beam element can be
defined in terms of only one spatial co-ordinate, the element is called as
one dimensional element.
A bar is a member which resist only axial loads.
Where u1 & u2 are the nodal variables.
u(x) is the nodal displacement.
A beam can resist transverse and twisting loads.
Where v1 & v2 are the transverse displacements
of nodal variables.
θ1 & θ2 are the slopes (rotations) of the nodes.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
4
5. SHAPE FUNCTION FOR ONE-
DIMENSIONAL ELEMENT
Consider a one-dimensional element (line segment) of length l
with two nodes, one at each end, as shown in Figure. Let the
nodes be denoted as i and j and the nodal values of the field
variable as Φi and Φj.ϕ
The variation of inside theϕ
element is assumed to be linear
as ϕ(x) = α1 + α2x …(1)
where α1 and α2 are the
unknown coefficients.
By using the nodal conditions
(x) = Φi at x = xiϕ
(x) = Φj at x = xjϕ
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
5
6. and Eq. (1), we obtain
Φi = α1 + α2xi
Φj = α1 + α2xj
The solution of these equations gives
α1 = Φixj −Φjxi
l …(2)
α2 = Φj −Φi
l
where xi and xjdenote the global coordinates of nodes i and j,
respectively. By substituting Eq. (2) into Eq. (1), we obtain
Φ(x) = Φixj −Φjxi + Φj −Φi x ……(3)
l l
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
6
7. This equation can be written, after rearrangement of terms, as
Φ(x) = Ni(x)Φi +Nj(x)Φj = [N(x)] Φ(e)
….(4)
[N(x)] = [Ni(x) Nj(x)] … (5)
Ni(x) = xj −x
l …(6)
Nj(x) = x −xi
l
and Φ(e) = Φi = vector of nodal unknowns of elements e …(7)
Φj
Note that the superscript e is not used for Φi and Φj for simplicity.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
7
8. The linear functions of x defined in Eq. (6) are called
interpolation or shape functions.
Note that each interpolation function has a subscript to denote
the node to which it is associated.
Furthermore, the value of Ni(x) can be seen to be 1 at node i (x =
xi) and 0 at node j (x = xj). Likewise, the value of Nj(x) will be 0
at node i and 1 at node j.
These represent the common characteristics of interpolation
functions.
They will be equal to 1 at one node and 0 at each of the other
nodes of the element.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
8
9. STIFFNESS MATRIX
The primary characteristics of a finite element are
embodied in the element stiffness matrix.
For a structural finite element, the stiffness matrix
contains the geometric and material behavior
information that indicates the resistance of the element
to deformation when subjected to loading.
Such deformation may include axial, bending, shear,
and torsional effects.
For finite elements used in nonstructural analyses, such
as fluid flow and heat transfer, the term stiffness matrix is
also used, since the matrix represents the resistance of the
element to change when subjected to external influences.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
9
10. STIFFNESS MATRIX …,
we know that,
Strain, {e} = [B] {u*}
{e}T
= [B]T
{u*}T
where,
{e} is a strain matrix
[B] is strain- displacement matrix
{u*} is a degree of freedom
we know that,
Stress, {δ} = [E] {e}
{δ} = [D] {e}
where [E] =[D] = Young’s modulus.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
10
11. Strain energy expression is given by,
U = ∫½ {e}T
{δ} dv
v
Substitute {e}T
and {δ} values,
U = ∫½ [B]T
{u*}T
[D] {e} dv
v
= ½ {u*}T
∫[B]T
[D] {e} dv
v
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
11
12. Substitute {e} values,
U = ½ {u*}T
∫[B]T
[D] [B] {u*} dv
v
U = ½ {u*}T
∫[B]T
[D] [B] dv {u*}
v
So, Stiffness matrix, [K] = ∫[B]T
[D] [B] dv
v
where,
[B] is strain- displacement relationship matrix
[D] Elasticity matrix or Stress-strain relationship matrix
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
12
13. In 1D problem,
Strain, e = du/dx
Where, u = Displacement function
[D] = [B] = E = Young’s modulus.
In Beam problem, Strain, e = Curvature = d2
u/dx2
[D] = [EI] = Flexural rigidity
Properties of stiffness Matrix:
1. It is symmetric.
2. The sum of elements in any column is equal to zero.
3. It is an unstable element. So, the determinants is equal to zero.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
13
14. STIFFNESS MATRIX FOR
1-D LINEAR BAR ELEMENT
Consider a 1-D bar element with nodes 1 and 2 as shown in figure. Let
u1 and u2 be the nodal displacement parameters or otherwise known as
degrees of freedom.
We know that,
Stiffness matrix, [K] = [B]T
[D] [B] dv
v
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
14
1 2
l
u1 u2
x
15. In 1-D Bar element,
Displacement function u = N1u1 + N2u2
Where , N1 = l-x/L and N2= x/L
We know that, Strain displacement matrix, [B] = dN1/dx dN2/dx
= -1/L 1/L
Substitute [B], [B]T
and [D] values in stiffness matrix equation[Limits is 0 to l]
L
[K] = -1/L x E x -1/L 1/L dv
1/L
0
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
15
16. l
1/L2
-1/L2
[K] = E dv
-1/L2
1/L2
0
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
16
l
1/L2
-1/L2
[K] = E A dx [ dv= A dx]
-1/L2
1/L2
0
l
1/L2
-1/L2
1/L2
-1/L2
L 1 -1
[K] = E A dx = AE [x] = AE/L
-1/L2
1/L2
-1/L2
1/L2
0 -1 1
0
17. The properties of stiffness matrix are satisfied.
1. It is symmetric.
2. The sum of elements in any column is equal to zero.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
17
18. FINITE ELEMENT EQUATION
FOR 1-D BAR ELEMENT
We know that, General force equation is,
[k] {u} = {F} ----------- (1)
where [k] is stiffness matrix
{u} is displacement vector and
{F} is force vector in the coordinate directions
The element kij of stiffness matrix maybe defined as the force at
coordinate i due to unit displacement in coordinate direction j.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
18
19. For 1-D bar element, stiffness matrix [k] is given by,
For two noded bar element,
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
19
1 -1
[K] = AE/L
-1 1
F1
{F} = &
F2
u1
{u} = , Substitute [K] {F} {u}
values
u2 in equ. (1)
1 -1 u1
{F}=AE/L This is a finite element equation for 1D 2-noded bar element
-1 1 u2
20. P1: A two noded bar element is shown in figure. The nodal displacement are
u1=5mm and u2= 8mm. Calculate the displacement at x= l/4, l/3 and l/2.
Solution:
Displacement function for 2-noded bar element is given by,
u = N1u1 + N2u2
Where, N1 = l-x/L and N2 = x/L => u =[ l-x/L] u1 + [x/L]u2
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
20
1 2
L
u1= 5mm u2=8mm
x
21. Substitute x= l/4, u1 = 5 and u2 = 8 in the above equation,
u = 5.75 mm at x=l/4
Substitute x= l/3, u1 = 5 and u2 = 8 in the above equation,
u = 6 mm at x=l/3
Substitute x= l/2, u1 = 5 and u2 = 8 in the above equation,
u = 6.5 mm at x=l/2
Result: u = 5.75 mm at x=l/4, u = 6 mm at x=l/3 & u = 6.5 mm at x=l/2
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
21
22. P2: A one dimensional bar is shown in figure. Calculate the following:
(i) Shape function N1 and N2 at point P.
(ii) If u1=3mm and u2=-5mm, calculate the displacement u at ponit P.
We know that,
Actual length of the bar, L=x2-x1=36-20=16mm
The distance between point 1 and point P is, x= 24-20=4mm
Displacement function for two noded bar element is given by,
u = N1u1+ N2u2
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
22
X1
2
L
X1= 20mm
u1= 5mm
X2=36mm
u2=-5mm
P
X=24mm
23. Where, N1 = l- x/L and N2 = x/L
N1 = 16- 4/16 = 0.75mm
N2 = 4/6 = 0.25mm
Substitute N1, N2, u1 and u2 values in the above equation,
u = N1u1+N2u2
= (0.75)(3)+0.25(-5)
u = 1mm
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
23
24. THE QUADRATIC BAR
ELEMENT
Determination of Shape Function:
The Three noded quadratic bar element is shown in figure.
The displacement at any point within the element is now interpolated
from the three nodal displacement using the shape functions as follows:
u(x) = N1(x)u1 + N2(x)u2+ N3(x)u3 ---------------- (1)
The shape functions Ni vary quadratically with in the element.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
24
X=0 X=lX=l/2
1
→u1
23
X
→u3
→u2
25. Let u(x) be given by the complete quadratic polynomial
u(x) = a0 + a1x + a2x2
-------------- (2)
We know that u(0) =u1, u(l) = u2 and u(l/2) = u3,. Hence, from the above
equation,
u1 = a0, u2 = a0 + a1l + a2l2
and u3 = a0 + a1(l/2) + a2(l/2)2
Solving for ai, we obtain
a0 = u1
a1 = (4u3 – u2 – 3u1)/l
a2 = (2u1 + 2u2 + 4u3)/l2
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
25
27. STIFFNESS MATRIX FOR
QUADRATIC BAR ELEMENT
Given the shape functions, we get the strain- displacement relation
matrix [B] as
e = du/dx = d/dx [N] {u}
Where [B] = [dN1/ dx dN2/dx dN3/dx]
= [2/l2
(2x – 3 l/2) 2/l2
(2x – l/2) -4/l2
(2x - l)]
We know that the stiffness matrix of the element
Stiffness matrix, [K] = [B]T
[B] EA dx
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
27
28. 1
2/l2
(2x - 3l/2)
=
2/l2
(2x - l/2) [2/l2
(2x - 3l/2) 2/l2
(2x - l/2) -4/l2
(2x - l)] EA dx
0
-4/l2
(2x - l)
On evaluating all the integrals, we obtain the element stiffness matrix as
7 1 -8
[k] = AE/3l 1 7 -8
-8 -8 16
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
28
29. A steel bar of length 800mm is subjected to an axial load of 3KN as
shown in figure. Find the elongation of the bar, neglecting
self weight. Take E = 2x 105
N/mm2
, A = 300mm2
.
Solution:
We can divide the bar into two elements as shown in
Figure.
Now the bar has 2elements with 3 nodes.
Displacement at
node 1 = u1
node 2 = u2
node 3 = u3
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
29
3 x 103
N
800mm
400mm
400mm1
3
1
2
1
2
3 x 103
N
800mm
400mm
400mm1
u3
u1
u2
1
2
30. For 1D two noded bar element, the finite element equation is,
For element 1: (node 1, 2)
Finite element equation is,
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
30
F1 1 -1 u1
=AE/L
F2
-1 1 u2
1 -1 u1 F1
A1E/L1 =
-1 1 u2 F2
400mm
u2
u1
1
31. ------------ (1)
For element 2 (Nodes 2,3)
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
31
1 -1 u1 F1
300x2x105
/400 =
-1 1 u2 F2
1 -1 u1 F1
150x103
=
-1 1 u2 F2
3 x 103
KN
400mm
u3
u2
2
1 -1 u2 F2
A2E/L2 =
-1 1 u3 F3
32. ---------------- (2)
Assemble the finite element equations (1) and (2).
-------- (3)
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
32
1 -1 u2 F2
150x103
=
-1 1 u3 F3
1 -1 0 u1 F1
150x103
-1 2 -1 u2 = F2
0 -1 1 u3 F3
33. Applying boundary conditions:
u1 = 0
F3 = 3x103
N
Substitute u1, F1,F2 and F3 values in equation (3)
Here u1=0. So, neglect first row and first column of [K] matrix. Hence
the final reduced equation is,
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
33
1 -1 0 0 0
150x103
-1 2 -1 u2 = 0
0 -1 1 u3 3x103
2 -1 u2 0
150x103
=
-1 1 u3 3x103
34. 150 x 103
(2u2 – u3) = 0 ----------- (4)
150 x 103
(-u2 + u3) 3 x 103
-----------(5)
Solving, 150 x 103
(u2) = 3 x 103
u2 = 0.02mm
Substitute u2 value in equation (4),
u3 = 0.04mm
Result:
1. Displacement at node 1 , u1 = 0
2. Displacement at node 2 , u2 = 0.02 mm
3. Displacement at node 3 , u3 = 0.04 mm
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
34
35. Consider a taper steel plate of uniform thickness, t = 25 mm as shown in
figure. The Young’s modulus of the plate, E = 2 X 105
N/mm2
and weight
density, ρ = 0.82 x 10-4
N/mm3. In addition to its self-weight, the plate is
subjected to a point load p = 100N at its mid point. Calculate the
following by modeling the plate with
two finite elements:
(i) Global force vector {F}.
(ii) Global stiffness matrix [K].
(iii) Displacement in each element.
(iv) Stresses in each element.
(v) Reaction force at the support.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
35
300 mm
600 mm
75 mm
p
150 mm
x
36. In this problem, the area of the element is varying at each c-s. If we
consider this area variation, the problem will be tedious. So the given
taper bar is considered as stepped bar as shown in figure.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
36
300 mm
600 mm
W3 = 75 mm
p
W1 = 150 mm
x
W2
3
2
1
W1 = 150 mm
300 mm
300 mm
p
75 mm
1
2
37. Solution:
Area at node 1, A1 = Width X Thickness = W1 X t1 = 150 X 25 = 3750 mm2
Area at node 2, A2 = Width X Thickness = W2 X t2 = [(W1 + W2)/2] X t2
A2 = 2812.5 mm2
Area at node 3, A3 = Width X Thickness = W3 X t3= 75 X 25 = 1875 mm2
Average area of element (1):
A1 = (Area of node 1 + Area of node 2) /2 = 3281.25 mm2
Average area of element (2):
A2 = (Area of node 2 + Area of node 3) /2 = 2343.75 mm2
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
37
38. The steel plate is subjected to self-weigth.So, we have to findout the
body force acting at nodal points 1,2 and 3.
1
We know that, Body force vector, {F} = (ρ A L) /2
1
F1 1
For element (1) : Force vector = (ρ1 A1 L1) /2
F2 1 1
= (0.82 X 10-4 X 3281.25 X 300)/2 X
F1 40.359 1
= --------- (1)
F2 40.359
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
38
39. F2 1
For element (2) : Force vector = (ρ2 A2 L2) /2
F3 1 1
= (0.82 X 10-4 X 2343.75 X 300)/2 X
F2 28.828 1
= --------- (2)
F3 28.828
Assembling the force vector i.e. assemble the equation (1) and (2)
F1 40.359
F2 = 69.187
F3 28.828
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
39
40. A point load of 100N is acting at node 2 as shown in figure. So, add
100N in F2 vector.
F1 40.359
Global Force Vector, F2 = 169.187
F3 28.828
Finite element equation for 1D- plate element is given by
F1 1 -1 u1
= A E /L
F2 -1 1 u2
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
40
41. For element 1: (node 1, 2)
Finite element equation is,
1 2
10.937 -10.937 1 u1 F1
2 X 105
= ------- (4)
-10.937 10.937 2 u2 F2
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
41
1 -1 u1 F1
A1E/L1 =
-1 1 u2 F2
300mm
u2
u1
1
43. Assemble the finite element equations (4) and (5)
Apply the B.Cs i.e., at node 1, Displacement u1 = 0. Substitute u1, F1, F2
and F3 value in equ. (6)
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
43
10.937 -10.937 0 u1 F1
2x105
-10.937 18.749 -7.8125 u2 = F2 ------- (6)
0 -7.8125 7.8125 u3 F3
10.937 -10.937 0 0 40.359
2x105
-10.937 18.749 -7.8125 u2 = 169.187
0 -7.8125 7.8125 u3 28.828
44. In the above equation, u1 = 0. So, neglect first row and first column of
[K] matrix. The reduced equation is,
2x105
(18.749u2 - 7.8125 u3) = 169.187 ------------- (7)
2x105
(-7.8125u2+7.8125u3) = 28.828 ------------- (8)
Solving, 2x105
x (10.936)u2 = 198.015
u2 = 9.053 x 10-5
mm
Substitute u2 value in equ. (7),
u3 = 10.898 x 10-5
mm
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
44
2x105
18.749 -7.8125 u2 = 169.187
-7.8125 7.8125 u3 28.828
45. Stresses :
Stress, σ1 = E ε12 = E (u2-u1)/ L1 = 0.060 N/mm2
Stress, σ2 = E ε23 = E (u3-u2)/ L1 = 0.0123 N/mm2
Reaction force:
We know that, {R} = [K]{u} – {F}
2x105
(-10.937 x 9.053 x 10-5
) = 40.359
R1 = -238.379 N04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
45
10.937 -10.937 0 0 40.359
{R} =2x105
-10.937 18.749 -7.8125 u2 - 169.187
0 -7.8125 7.8125 u3 28.828
46. In figure, a load P = 60 X 103
N is applied as shown. Determine the
displacement field, stress and support reactions in the body.
Take E = 20 X 103
N/mm2
.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
46
Wall
P
1.2mm
150mm
150mm
250mm2
47. Solution:
In this problem, we should first determine whether contact occurs
between the bar and the wall. To do this, assume that the wall does not
exit. The deformation at node is given by,
δ = PL/AE = (60 X 103
) x 150 /(250 x 20 X 103
) = 1.8 mm
The gap between the wall and node 3 is 1.2 mm. So, that contact occurs
between the bar and the wall.
Displacement at point 3 ,(u3) = 1.2 mm. From this result, we see that
contact does not occur.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
47
1.2mm
P
150mm
150mm
Wall
u3u2
u1
48. The problem has to be resolved, since the B.Cs are now different. The
displacement at u3 is specified to be 1.2 mm. Consider the 2 element
finite element model in figure. The B.Cs are u1= 0 and u3 = 1.2mm.
The structural stiffness matrix [K1
] and [K2
] are:
1 -1 1 -1
[k12
] = AE/L =(250 x 20 x 103
) /150
-1 1 -1 1
The global unreduced stiffness matrix is ,
1.667 -1.667 0
[K] = 20 x 103
-1.667 3.333 -1.667
0 -1.667 1.667
The finite element equation can be written,
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
48
3P
150mm
150mm
250mm2
1
2
1 2
49. 1.667 -1.667 0
[K] = 20 x 103
-1.667 3.333 -1.667
0 -1.667 1.667
Retaining 2 equation yields,
20x103
(3.33u2 -1.67 x 1.2) = 60 x 103
=> u2 =1.5 mm
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
49
1.667 -1.667 0 0 0
20x103
-1.667 3.333 -1.667 u2 = 60 x 103
0 -1.667 1.667 1.2 0
P
150mm
u2
u1 1
150mm
u3
u2 2
1.2
mm
50. Stresses:
For element 1:
Stress, σ1 = E ε12 = E (u2-u1)/ L1 = 2000 N/mm2
For element 2:
Stress, σ2 = E ε23 = E (u3-u2)/ L1 = -400 N/mm2
Reaction force:
We know that, {R} = [K]{u} – {F}
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
50
R1 1.667 -1.667 0 0 0
R2 =20x103
-1.667 3.333 -1.667 1.5 - 60 x 103
R3 0 -1.667 1.667 1.2 0
52. SPRING ELEMENT
Consider a system of springs connected in series as shown in Figure.
The analysis of the system (to find the nodal displacements under a
prescribed set of loads) can be conducted using the finite element
method.
For this, the equilibrium relations of a typical spring element are to be
derived first.
Let the stiffnesses of the springs be denoted k1, k2, …, kn. Let Fi and Fj be
the forces applied at nodes i and j, and ui and uj be the displacements of
nodes i and j, respectively.
The relations between the nodal forces and nodal displacements of a
typical spring element e can be derived using the relation:
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
52
53. Force = Spring stiffness × Net deformation of the spring
Thus, the forces at nodes i and j can be expressed as
Fi = ke ui −uj -------- (1)
(where ui is assumed to be larger than uj so that the compressive force Fi
leads to a decrease in the length of the spring), and
Fj = ke uj −ui -------- (2)
(where uj is assumed to be larger than ui so that the tensile force Fj leads
to an increase in the length of the spring). Equations (1) and (2) can be
expressed in matrix form as04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
53
54. 1 −1 ui Fi
ke = = -------- (3)
−1 1 uj Fj
From Eq. (3), the characteristic (stiffness) matrix of the element can be
identified as
i j
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
54
1 -1 i
[K] = k
-1 1 j l
K
Fi
i j
Fj
55. where the degree of freedom numbers corresponding to the rows and
columns of the stiffness matrix [K] are also indicated. Equation (3) can
be expressed as
[K] u= F ------------ (4)
where u and F denote the vectors of nodal displacements and nodal
forces, respectively.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
55
60. BEAM ELEMENT
Selection of Nodal D.O.F
A beam is a straight bar element that is primarily subjected to transverse
loads.
The deformed shape of a beam is described by the transverse
displacement(v) and slope (rotation-θ) of the beam is shown figure.
Typical Beam Section and
its deformation
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
60
M
X
Z
61. Hence, the transverse displacement and rotation at each end of the beam
element are treated as the unknown degrees of freedom.
For a beam element of length L lying in the xz plane, as shown in
Figure, the four degrees of freedom in the local (xz) coordinate system
are indicated as vi, θi, vj, and θj.
According to Euler- Bernoulli theory of beam bending, the entire c-s has
the same transverse deflection v as the neutral axis. The Euler- Bernoulli
beam element is shown in figure.
The Euler- Bernoulli beam element
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
61
x=Lx=0
vj
vi
θi θj
62. Hence the deflection are small and we assume that the rotation of each
section is the same as the slope of deflection curve at that point. i.e.,
(dv/dx)
Therefore, the axial deformation of any point P away from the neutral
axis (due to bending alone) is given by uP = -(z)(dv/dx).
Thus, if v(x) is determine, then the entire state of deformation of the
body is completely determined.
Abeam element is a simple line element, representing the neutral axis of
the beam.
To ensure the continuity of the deformation at any point ( i.e., on the
neutral axis), to ensure that v and dv/dx are continuous.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
62
63. Taking two nodal D.O.F viz., v and θ (= dv/dx).
These nodal D.O.F permits to readily assign prescribed essential B.Cs
i.e., v= 0= dv/dx at fixed end.
A prescribed value of moment load can readily taken into account with
the rotational D.O.F θ.
At all nodes, the following sign conversions are used:
(i) Moments are +ve in the CCW direction.
(ii) Rotations are positive in the CCW direction.
(iii) Forces are +ve in the +ve z direction.
(iv) Displacements are +ve in the +ve z direction
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
63
64. SHAPE FUNCTION OF BEAM
ELEMENT
The displacement field v(x) assumed for the beam element should be
such that it takes on the values of deflection and the slope at either end
as given by the nodal values vi, θi, vj, θj. Let v(x) be given by
v(x) = c0 + c1x + c2x2
+ c3x3
------- (1)
Differentiating w.r.t x, we have
dv/dx = c1 + 2c2x + 3c3x2
---------- (2)
At x= 0 and L , we have
vi = c0, θi = c1, vj = c0 + c1L + c2L2
+ c3L3
, θj = c1 + 2c2L + 3c3L2
----- (3)
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
64
65. We can solve for the coefficients c0, c1, c2, c3 in terms of the nodal D.O.F.
vi, θi, vj, θj and substitute in equation (1) we get,
v(x) = N1vi + N2 θi + N3vj + N4 θj ---------- (4)
Where the shape function N are given by,
N1 = 1 – 3x2
/L2
+ 2X3
/L3
, N2 = x – 2x2
/L + x3
/L2
N3 = 3x2
/L2
-2x3
/L3
, N4 = -x2
/L + x3
/L2
vi
θi
Rewrite equation , v(x) = [N] {δ} = [N1 N2 N3 N4] vj ------------ (5)
θj
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
65
66. STIFFNESS MATRIX FOR BEAM
ELEMENT
The strain at any point in the beam is given by
{ ε} = εx = du/dx = d/dx [-z (dv/dx)] = -z (d2
v/dx2
)
From equation (5) we have
εx = -z [d2
N1/dx2
d2
N2/dx2
d2
N3/dx2
d2
N4/dx2
]{δ}
= -z [((-6/L2
) + (12x/L3
)) ((-4/L) + (6x/L2
)) ((6/L2
)- (12x/L3
)) ((-2/L) + (6x/L2
))]{δ}
Thus the strain displacement relation matrix [B] is given by
[B] = -z [((12x/L3
) - (6/L2
)) ((6x/L) – (4/L2
)) ((6/L2
) - (12x/L3
)) ((6x/L2
) – (2/L))]
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
66
67. We can obtain the element stiffness matrix as
[k] = ∫[B]T
[B] E dv
v
L (12x/L3
) - (6/L2
)
= ∫ ∫(-z) (6x/L) – (4/L2
) x (E)(-z) [((12x/L3
) - (6/L2
)) ((6x/L) – (4/L2
))
A 0 (6/L2
) - (12x/L3
) ((6/L2
) - (12x/L3
)) ((6x/L2
) – (2/L))] (dA) dx
(6x/L2
) – (2/L)
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
67
68.
Noting that ∫z2
dA = I, the second moment of area of the C-S and
A
carrying out the integration w.r.t x, we get
12 6L -12 6L
6L 4L2
-6L 2L2
[k] = EI/L3
-12 -6L 12 -6L
6L 2L2
-6L 4L2
The element nodal force vectors are now obtained for specific cases of
loading
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
68
69. P1: A beam, fixed at one end and supported by a roller at the other end, has
a 20KN concentrated load applied at the centre of the span, as shown in
figure. Calculate the deflection under the load and construct the shear
force and bending moment diagrams for the beam.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
69
20KN
500 cm
E= 20 X 106
N/cm2
I = 2500 cm
500 cm
70. Solution:
Let the beam is divided into 2 elements having nodes 1,2,3.
Let v1, θ1, F1, M1- Vertical deflection, Slope, Shear force and Bending
moment at node 1.
v2, θ2, F2, M2- Vertical deflection, Slope, Shear force and Bending
moment at node 2.
v3, θ3, F3, M3- Vertical deflection, Slope, Shear force and Bending
moment at node 3.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
70
E= 20 X 106
N/cm2
I = 2500 cm
θ1 M1
v1, F1 v2, F2
θ2 M2
v3,F3
θ3 M3
1 2
321
71. (a) Determination of nodal deflections:
Element (1):
It has nodal displacements v1, θ1 ,v2, θ2 at nodes 1 and 2.
The element stiffness matrix for element (1) is given by
12 6L -12 6L
6L 4L2
-6L 2L2
[k1] =E1I1/L1
3
-12 -6L 12 -6L
6L 2L2
-6L 4L2
Now E1I1/L1
3
= (20 x 106
x 2500) / 5003
= 400 N/cm
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
71
76. Since v1 = 0, θ1 = 0, v3 = 0, neglect 1st
, 2nd
, 5th
rows and columns in the
global stiffness matrix. From the remaining terms, the F.E. equation can
be written as
24 0 3000 v2- 20000
400 0 2 x106
5x105
θ2 = 0
3000 5x105
106
θ3 0
θ2 = -0.003125 rad, θ3 = 0.0125 rad and v2 = -3.646 cm
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
76
77. (b) Determination of shear force and bending moment:
The shear force at node 1 is given by
F1 = 400 (-12v2 + 3000 θ2 ) = 13750 N
Bending moment at node 1 is
M1 = 400 (-3000 v2 + 5 x 105
θ2) = 3750200 N-cm
The shear force at node 3 is
F3 = 400 (-12v2 - 3000 θ2 - 3000 θ3) = 6250 N
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
77
79. For the beam and loading shown in figure, determine (1) the slopes at 2
and 3 and (2) the vertical deflection at the midpoint of the distributed
load.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
79
12KN/m
1 m
E= 200 GPa
I = 4 x 106
mm4
1 m
1 2
80. Solution:
Element (1):
Let v1, θ1, F1, M1- Vertical deflection, Slope, Shear force and Bending
moment at node 1.
v2, θ2, F2, M2- Vertical deflection, Slope, Shear force and Bending
moment at node 2.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
80
1 m
1
v1 F1
θ2 M2
v2 F2
θ1 M1
81. It has nodal displacements v1, θ1 ,v2, θ2 at nodes 1 and 2.
The element stiffness matrix for element (1) is given by
Now E1I1/L1
3
= (200 x 109
x 4 x 10-6
) / 13
= 800 x 103
N/m
v1 θ1 v2 θ2
12 6L -12 6L v1
[k1] =800 x 103
6L 4L2
-6L 2L2
θ1 --------- (1)
-12 -6L 12 -6L v2
6L 2L2
-6L 4L2
θ2
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
81
82. Element (2):
It has nodal displacements v1, θ1 ,v2, θ2 at nodes 1 and 2.
The element stiffness matrix for element (1) is given by
Now E2I2/L2
3
= (200 x 109
x 4 x 10-6
) / 13
= 800 x 103
N/m
v2 θ2 v3 θ3
12 6L -12 6L v2
[k2] =800 x 103
6L 4L2
-6L 2L2
θ2 --- (2)
-12 -6L 12 -6L v3
6L 2L2
-6L 4L2
θ3
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
82
12KN/m
1 m
2
θ2 M2 θ3 M3
v2, F2 v3,F3
32
87. 8 2 θ2 -1000
800 x103
=
2 4 θ3 1000
Slope or rotation at 2, θ2 = -2.679 x 10-4
rad
Slope or rotation at 3, θ3 = 4.464x 10-4
rad
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
87
88. The vertical deflection at the midpoint of the distributed load.
Consider the element (2) and its loading arrangements as shown in
figure.
For any beam element the vertical deflection can be obtained by using
the relation,
v(x) = N1v1 + N2 θ1 + N3v2 + N4 θ2
Where the shape function N are given by,
N1 = 1 – 3x2
/L2
+ 2X3
/L3
, N2 = x – 2x2
/L + x3
/L2
N3 = 3x2
/L2
-2x3
/L3
, N4 = -x2
/L + x3
/L2
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
88
12KN/m
1 m
2
θ2 M2 θ3 M3
v2, F2 v3,F3
21
89. Also in order to simplify the analysis, consider the element (2) as the
separate element and its nodes 1 and 2.
v1 = 0, θ1 = -2.679 x 10-4
rad, v2 = 0, θ2 = 4.464x 10-4
rad
Now at x= 0.5m (i.e., at mid point of element (2))
N1v1 = 0, N2 θ1 = [0.5 – (2(0.5)2
/1) + ((0.5)3
/12
)] (-2.67 x 10-4
)
= 3.338 x 10-5
N3v2 =0 , N4 θ2 = [(– (0.5)2
/1) + ((0.5)3
/12
)] (4.46x 10-4
)
= 5.575 x 10-5
v = 0-3.338 x 10-5
+ 0 – 5.575 x 10-5
= -8.913 x 10-5
m = -0.08913 mm
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
89
90. i.e., Displacement at the midpoint is directing downwards ass shown in
figure.
v = -0.08913 mm
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
90
2
91. FRAME ELEMENT
The bar element can permit only axial deformation and the beam
element can permit only transverse deflection.
By combining the bar and the beam elements, we obtain the “frame
element” which enables us to model typical problems of framed
structures which in general involve both types of deformation.
A typical planar frame element is shown in figure, and the
corresponding element equations are
[k] {δ} = {f}
Plane frame element
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
91
ujui
x=Lx=0
vj
vi
θi θj
93. and the element stiffness matrix for frame element (using equs. 1 &2) is
ui vi θi uj vj θj
AE/L 0 0 -AE/L 0 0 ui
0 12EI/L3
6EI/L2
0 -12EI/L3
6EI/L2
vi
[k] = 0 6EI/L2
4EI/L 0 -6EI/L2
2EI/L θi
-AE/L 0 0 AE/L 0 0 uj
0 -12EI/L3
-6EI/L2
0 12EI/L3
-6EI/L2
vj
0 6EI/L2
-2EI/L 0 -6EI/L2
4EI/L θj
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
93
94. The beam elements also have different orientations. Figure shows the
inclined frame element.
It have two displacement and a rotational deformation for each node.
The nodal displacement vector is given by
{δ} = {ui, vi, θi, uj, vj, θj}
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
94
ui
y
x i
j
uj
vj
θi
θj
ujy
ujx
uiy
uix
Fi sin θθi
Fi cos θ
Fi
Fj sin θθj
Fjcos θ
Fj
vi
vj
95. For beam element in its own local coordinate frame, we have the force
deflection relations, viz
The tranformation matrix would be
cos θ sin θ
[T] =
-sin θ cos θ
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
95
1 -1 u1 Fi
AE/L =
-1 1 u2 Fj
ui = uix cos θ + uiy sin θ
uj = ujx cos θ + ujy sin θ
96. P1: The framed structure made of steel shown in figure. To calculate the
deflection using the frame element.
Structure details
FE model
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
96
20 mm dia.
Steel rod
4 m
3 m
Steel I-beam
A=2000mm2
I=106
mm4
10KN
Steel I-beam
A=2000mm2
I=106
mm4
20 mm dia.
Steel rod
10KN
Y
y2
X
x2
θ
y1
x1
3
21 4
1
2
97. Element 1:
L = 3m =3000mm, A = 2000mm2, E = 200,000 N/mm2, I = 106
mm4. The
element stiffness matrix in its coordinate frame is given in the form
ui vi θi uj vj θj
AE/L 0 0 -AE/L 0 0 ui
0 12EI/L3
6EI/L2
0 -12EI/L3
6EI/L2
vi
[k] = 0 6EI/L2
4EI/L 0 -6EI/L2
2EI/L θi
-AE/L 0 0 AE/L 0 0 uj
0 -12EI/L3
-6EI/L2
0 12EI/L3
-6EI/L2
vj
0 6EI/L2
-2EI/L 0 -6EI/L2
4EI/L θj
-------- (1)
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
97
99. The local coordinate frame of element 1 is identical to the global frame
and hence no transformation is required
Element 2: L=5000 mm, A=314.16 mm2
, E = 200,000 N/mm2, I =
7,854mm4
. The element stiffness matrix in its coordinate frame is given
in the form
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
99
101. The local coordinate frame is inclined w.r.t global reference frame and
hence we need to transform the element stiffness matrix into global
frame. For any orientation θ, the transformation matrix related local and
global d.o.f. can be readily shown to be given by
cos θ sin θ 0 0 0 0
-sin θ cos θ 0 0 0 0
[T] = 0 0 1 0 0 0
0 0 0 cos θ sin θ 0
0 0 0 -sin θ cos θ 0
0 0 0 0 0 1
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
101
105. Result:
u2 = -0.12mm; v2= 2.564 mm
θ2 = 0.0013 rad θ3 = θ4 = 3.26 x 10-4
rad
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
105
106. ONE-DIMENSIONAL HEAT
TRANSFER
The GDE for the steady state one-dimensional conduction heat transfer
with convective heat loss from lateral surfaces is given by
k d2
T /dx2
+ q = [P/Ac] h (T - T∞) --------- (1)
Where
k = Co-efficient of thermal conductivity of the material,
T = temperature,
q = internal heat source /unit volume,
Ac= the C-S area,
h = convective heat transfer co-efficient, and
T∞ = ambient temperature.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
106
107. The weighted residual statement can be written as
L
∫ W [k (d2
T /dx2
) + q – (P/Ac) h (T - T∞) ] dx = 0 --------- (2)
0
By performing integration by parts, the weak form of the DE can be obtained
as
L L L
∫ W [k (d2
T /dx2
)+ ∫Wq dx –∫W(P/Ac) h (T - T∞) ] dx = 0
0 0 0
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
107
108. L
∫ W d[k (dT /dx)]
0 u d v
L L L L
W k(dT/dx) -∫[k (dW/dx dT/dx)dx + ∫ Wq dx - ∫W(P/Ac) h (T - T∞)] dx= 0
0 0 0
0
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
108
∫ u dv = uv - ∫ v du
109. The weak form, for a typical mesh of n finite elements, can be written as,
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
109
L L
∫k (dW/dx) (dT/dx)dx + ∫W(P/Ac) h (T) dx
0 L L 0 L
= ∫Wq dx +∫W(P/Ac) h (T∞) dx + W k (dT/dx)
0 0 0
n L L
Σ ∫[k (dW/dx) ( dT/dx) dx + ∫W(P/Ac)hT dx
k=1 0 n L 0 L
= Σ ∫W [q + (P/Ac ) hT∞ ] dx + Wk(dT/dx) --------- (3)
k=1 0 0
110. PROCEDURE FOR DEVELOPING THE
1-D HEAT TRANSFER BAR ELEMENT
Figure shows the typical heat transfer element, with its nodes and nodal
d.o.f.
Equation for 1D bar element heat transfer nodal temperature:
T(x) = 1- (x/L) T1 + x/L T2 -------- (4)
dT/ dx = (T2 – T1)/L -------- (5)
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
110
Node 2Node 1
x=Lx=0
T2T1
111. W1 = 1- (x/L), dW1/dx = -1/L
-------- (6)
W2 = (x/L), dW2/dx = 1/L
Now compute the elemental level contribution to Equ. (3)
LHS first term (Equ. (3)). Similar to 1D bar finite element, k replaces AE
and T replaces u. Thus we have
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
111
1 -1 T1
k/L
-1 1 T2
112. LHS Second term (Equ. (3)). With W1,
L
∫ 1- (x/L) (P/Ac) h (1- (x/L) ) T1 + (x/L)T2 dx
0
L L
= (Ph/Ac) ∫[ 1- (x/L) ]2
dx T1 + ∫(x/L) (1- (x/L) ) T2 dx
0 0
= ((PhL)/(6Ac)) [2T1 + T2]
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
112
113. With W2,
L
∫ (x/L) (P/Ac) h (1- (x/L) ) T1 + (x/L)T2 dx = ((PhL)/(6Ac)) [T1 + 2T2]
0
We can now write the second term on the LHS in matrix notation as
2 1 T1
(PhL)/(6Ac)
1 2 T2
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
113
114. RHS First term. Similar to the RHS first term of the bar element equation
replacing q0 by q0 + (PhT∞)/(Ac) , we can write
L/2
q0 + (PhT∞)/(Ac)
L/2
RHS Second term. Similar to RHS second term of the bar element
-Q0
QL
Where Q0, QL represent the heat flux at the ends of the element (nodes).
Thus the element level equations can be written as
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
114
115. LHS = Element conduction matrix
RHS First term = Nodal heat flux
RHS Second vector = Net heat flux at nodes
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
115
1 -1 2 1 T1 L/2 -Q0
k/L +(PhL)/(6Ac) = q0 + (PhT∞)/(Ac) +
-1 1 1 2 T2 L/2 QL
116. P1 : A 1 mm dia., 50mm long aluminium pin-fin as shown in figure,
used to enhance the heat transfer from a surface wall maintained at
3000
C. Use k = 200 W/m/0
C for ,aluminium, h = 20 W/m2
C , T∞ = 300
C.
Calculate the temperature distribution between in the fin.
A Pin- Fin.
04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
116
h T∞
Tw
Wall
L=50 mm
117. With two equal elements, L1 = L2 =0.025m. Assembling the two
elemental level equations , we get the
1 -1 0 2 1 0 T1
200/0.025 -1 2 -1 + ((π)(0.001)(20) (0.025))/((6)(π) (0.0005)2
) 1 4 1 T2
0 -1 1 0 1 2 T3
0.0125 QWall
= ((π)(0.001)(20))/((π) (0.0005)2
) (30) 0.025 + 0
0.0125 Qtip
From the B.Cs , T1 = 3000
C, Qtip = 0.
Substituting and solving the equations, we get
T1 = 226.1850
C, T3 = 203.5480
C04/03/19 Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
117
1
2
3
21
L1 L2
118. SOLUTION OF EIGENVALUE
PROBLEMS
The general form of G.E for un-damped free vibration of the structure is
given by
[k]nxn {ui}nx1 = ω2
i [m]nxn{ui}nx1, i= 1, 2, 3.., n ---(1)
Where, [k] = stiffness matrices
[m] = mass matrices
ωi = Natural frequencies
{ui} = Mode shape
Then equ (1) can be rewrite as
[m]-1
[k] {ui} = ω2
i {ui}
[A] {ui} = λi {ui}
Where [A] = [m] λ-1
[k] and λi = ω2
i
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
04/03/19 118
119. [A] {u} = λ {u} is known as Standard form of eigen value problem.
[k] {u} = λ [m]{u} is known as non-standard form of eigen value
problem.
The determinant | k – λm | = 0 is called as the characteristic equation.
{k – λm } {u} = 0 is called Eigen vector.
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
04/03/19 119
120. P1: Find the natural frequencies of longitudinal vibration of the
unconstrained stepped bar shown in figure.
Solution:
The dynamic equation of motion
for the un-damped free vibration
of whose system is given by
[ [K] – [M] ω2
] (u) = 0 ------(1)
Where
[K] = Global stiffness matrix
[M] = Global mass matrix
ω = Natural frequency
{u} = Displacement vector
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
u3
A(1) = 2A
A(1) = A
Element 1 Element 2
u1 u2
x
1
2
3
l(1) = L/2 l(2) = L/2
Stepped bar with axial degree of freedom
04/03/19 120
121. For two element stepped bar, the equation of motion(1) can be derived
as follows:
For element (1): (Between nodes 1&2)
1 -1
Element stiffness matrix [k1] = (A1E1)/l1
-1 1
1 -1 1 -1
= (2A E)/(L/2) = (4A E)/(L) ------(2)
-1 1 -1 1
2 1
Element stiffness matrix [m1] = (ρ1 A1 l1)/6
1 2
(Assumingconsistent mass matrix)Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
04/03/19 121
123. 2 1 2 1
= (ρ.A. L/2)/6 =(ρAL)/12 ------(5)
1 2 1 2
By combining the equas.(2) & (4), we get global stiffness matrix as
2 -2 0
[K] = (2AE)/L -2 3 -1
0 -1 1
Similarly by combining the equas.(3) & (5), we get global mass matrix as
4 2 0 u1
[M]= (ρAL)/12 2 6 1 and {u} = u2
0 1 2 u3
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
04/03/19 123
124. Now , by substituting the values of above matrices in equation (1) we get
2 -2 0 4 2 0 u1
(2AE)/L -2 3 -1 - (ρAL)/12 2 6 1 ω2
u2 = 0 --(6)
0 -1 1 0 1 2 u3
We know that, for getting the non-zero solution of circular frequency ω
for {u}, the determinant of the coefficient matrix [ [K] – [M] ω2
] should be
zero.
i.e., | [K] – [M] ω2
| = 0
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
04/03/19 124
126. Then, the equation (7) becomes,
(2-4λ) (-2-2λ) 0
(-2-2λ) (3 -6λ) (-1- λ ) = 0 ----(8)
0 (-1-λ) (1-2 λ)
i.e., (2-4λ) [(3 -6λ) (1-2 λ) - (-1-λ)(-1-λ)] - (-2-2λ) [(-2-2λ) (1-2 λ)-0] +0 = 0
i.e., -36 λ3
+ 90λ2
+ -36 λ = 0
i.e., 18λ(1-2λ) (λ-2) = 0
(or) λ(1-2λ) (λ-2) = 0
In the above equation either λ=0 or (1-2λ)=0 or (λ-2) = 0
When λ = 0 we get (ρL2
ω2
)/24E= 0 => ω2
= 0 (or) ω=0
i.e., the first natural frequency ω1 = 0
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
04/03/19 126
127. When (1-2λ)=0, we get 1- ( 2 (ρL2
ω2
)/24E)= 0
i.e., ω2
=12E/ ρL2
=> ω = 3.46( E/(ρL2
))1/2
The second natural frequency ω2 = 3.46( E/(ρL2
))1/2
When (λ-2)=0, we get (ρL2
ω2
)/24E) - 2= 0
i.e., ω2
=48E/ ρL2
=> ω = 6.93( E/(ρL2
))1/2
The third natural frequency ω3 = 6.93( E/(ρL2
))1/2
That is the natural frequencies of unconstrained stepped bar are,
ω1 = 0
ω2 = 3.46( E/(ρL2
))1/2
rad/sec
ω3= 6.93( E/(ρL2
))1/2
rad/sec
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
04/03/19 127
128. P2: Find the mode shapes (i.e., eigenvectors) for the natural
frequencies of longitudinal vibration of the unconstrained stepped
bar shown in figure.
Solution:
The natural frequencies of the
unconstrained stepped bar as
described in the above problem are :
ω1 = 0
ω2 = 3.46( E/(ρL2
))1/2
rad/sec
ω3= 6.93( E/(ρL2
))1/2
rad/sec
The natural frequencies follow some well defined deformation patterns
called mode shapes. It is observed that the first frequency ω1 = 0
corresponds to rigid body mode, whereas the second and third
frequencies (ω2 , ω3) correspond to elastic deformation modes.
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
u3
A(1) = 2A
A(1) = A
Element 1 Element 2
u1 u2
x
1
2
3
l(1) = L/2 l(2) = L/2
Stepped bar with axial degree of freedom
04/03/19 128
129. To find the mode shape corresponding to natural frequencies ωi, we
must solve the equation[ [K] – [M] ω2
] (u) = 0.
The equation (6) of the above problem is given by
2 -2 0 4 2 0 u1
(2AE)/L -2 3 -1 -(ρAL)/12 2 6 1 ω2
u2 = 0 ------ I
0 -1 1 0 1 2 u3
By selecting λ = (ρL2
ω2
)/24E the above equation can be simplified as
(2-4λ) (-2-2λ) 0 u1
(-2-2λ) (3 -6λ) (-1- λ ) u2 = 0 ---- II
0 (-1-λ) (1-2 λ) u3
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
04/03/19 129
130. By equating the determinant of coefficient matrix for {u} to zero, we get
λ(1-2λ) (λ-2) = 0 which implies λ = 0 (or) λ = 0.5 (or) λ = 2.
i.e., the eigen values are
λ1 0
λ2 = 0.5 writing in the increasing order.
λ3 2
To find 1st
mode shape:
Let λ = 0
Now the equation II implies
2u1 – 2u2 = 0 ---(i)
-2u1 + 3u2 – u3 = 0 ---(ii)
-u2 + u3 = 0 ---(iii)
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
04/03/19 130
131. Equa. (i) => u1 = u2 and Equa (iii) u2 = u3
Hence u1 = u2 = u3
For ω1 = 0 (or) λ = 0, corresponding to rigid body
u1 = u2 = u3 = 1
That is , 1st
mode shape is
u1 1
Um1 = u2 = 1 u1
u3 1
To find 2nd
mode shape:
Let λ = 0.5
Now the equation II implies
– 3u2 = 0 ---(iv)
-3u1–1.3u3 = 0 ---(v)
-1.5u2 = 0 ---(vi)Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
04/03/19 131
132. Equa(iv) => u2 = 0 and Equa(v) => 3u1 = -1.5u3 (or) 2u1 = -u3
That is , 2nd
mode shape is
u1 1 1
Um2 = u2 = 0 = 0 u1
u3 -2u1 -2
To find 3rd
mode shape:
Let λ = 2
The equation II implies
-6u1– 6u2 = 0 ---(vii)
-6u1-9u2–3u3 = 0 ---(viii)
- 3u2 -3u3= 0 ---(ix)
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
04/03/19 132
133. Equa(vii) => u1= -u2 and Equa(ix) => u2 = -u3
That is , 3rd
mode shape is
u1 u1 1
Um3 = u2 = -u1 = -1 u1
u3 u1 1
The three mode shapes corresponding to λ = 0, λ = 0.5 and λ = 2
(i.e.,corresponding to ω1 , ω2 and ω3) are shown in figure.
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
04/03/19 133
134. Types of mode-shapes
(Eigenvectors)
1st
mode shape
2nd
mode shape
Dr.G.PAULRAJ,
Professor&Head(Mech.),Avadi,
VTRS,Chennai.
u3u1
u21
2
3
L/2 L/2
x
1 1 1
u1 u2 u3
0 L/2 L
x
u1
u2
u3
0
L0
1
-2
x
u1
u2
u3
0 0
1 1
-1
3rd
mode shape
04/03/19 134
