1. Security –
Enterprise Mobile
Applications
Venkat Alagarsamy
venkat.alagarsamy@gmail.com
www.linkedin.com/in/VenkatAlagarsamy
www.scribd.com/VenkatAlagarsamy
www.facebook.com/Venkatachalapathi.Alagarsamy
www.slideshare.net/VenkatAlagarsamy
www.twitter.com/TwitsOfVenkat
VenkatAlagarsamy.blogspot.in
Last Updated: 18th Jan 2013

2. Corporate Data Users
• It is a business fact that nearly 60% of all corporate
employees access content through public network
using phones, tablets and other hand-held devices.
• Other than employees, the customers and vendors
too access the corporate database anywhere,
anytime on any device.
• Public

3. Statistics
• 80% of corporate users using the device without
knowing security threats.
• 80% of corporate users using the jail Broken
device
• 70% of users do not have Anti-virus on their device
• 70% is the possibility that the application getting
misused.
• 55% user losing sensitive credentials and
corporate data to a hacker.

4. The Challenge
The rapid adoption of mobile application by the
corporate has created a significant security
challenge because the corporate data is accessed
outside of the firewall/DMZ. So the challenges to
corporate mobile application developers are:
How do I secure mobile application with/without limited
users?
How to secure the application itself?
What is to be developed as mobile application?
How should I provision this application to users?

5. Attacks – Device Based
• Device based attacks
– Misplaced or lost the device
• Unencrypted credentials
• Insecure Storage
• Cached Data
– Malware installation due to down loading unknown
application
• Malicious certificates
• Reconfigure proxy settings or
• Allow man-in-the-middle (MiTM) visibility into every user
transaction.

6. Attacks – Network and
Server Based
• Identity Spoofing (IP address Spoofing)
– Using a special programs attacker would construct IP
packets that appear to originate from valid addresses
inside the corporate intranet.
– After gaining access to the network with a valid IP
address, the attacker can modify, reroute, or delete
data.
• Password Attacks
– Obtain lists of valid user and computer names and
network information.
– Modify server and network configurations, including

7. Attacks – Network and
Server Based
• Denial-of-Service Attack
– Randomize the attention of corporate internal
Information Systems staff so that they do not see the
intrusion immediately, which allows the attacker to make
more attacks during the diversion.
– Send invalid data to applications or network services,
which causes abnormal termination or behavior of the
applications or services.
– Flood a computer or the entire network with traffic until a
shutdown occurs because of the overload.
– Block traffic, which results in a loss of access to network
resources by authorized users.

8. Attacks – Network and
Server Based
• Man-in-the-Middle Attack
– actively monitoring, capturing, and controlling all
communication and re-route a data exchange
• Compromised-key-attack
– By getting the compromised key, the attacker can
decode any secured encrypted data and the use the
data as required.
• Sniffer Attack
– Analyze network and gain information to eventually
cause network to crash or to become corrupted.
– Read transaction/data communications.

9. Attacks – Network and
Server Based
• Application-Layer Attack
An application-layer attack targets application servers by
deliberately causing a fault in a server's operating system
or applications. This results in the attacker gaining the
ability to bypass normal access controls. The attacker takes
advantage of this situation, gaining control of application,
system, or network, and can do any of the following:
– Read, add, delete, or modify data or operating system.
– Introduce a virus program that uses corporate computers
and software applications to copy viruses throughout
corporate network.
– Introduce a sniffer program to analyze network and gain
information that can eventually be used to crash or to
corrupt legacy systems and network.

10. Device Security - Reverse
Engineering
• Understand the logic and application security
weakness
• Look for key words like password, key, SQL and
security logic (AES/DES)
• Modify the code to bi-pass client side checks and
rebuild app
• Send request with altered data pack from modified
apps
• Steps:
 Get Executable
 Understand the technology

11. Device Security -Reverse
Engineering – Tools Used
OS De-
compress
or
Object -> Class ->
Functions
Editor
Windows Winzip ILSpy Visual
Studio
Notepad
Obfuscator preemptive.com/products/dotfuscato
r/overview
confuser.codeplex.com/
Android Winzip Dex2Jar and JD-GUI Notepad
Obfuscator http://proguard.sourceforge.net/
iOS iExplorer OTool and Class-dump-
z

12. Device Security – Malwares
 Malwares (Worms and Trojans) are installed in the
device either by SMS/MMS or by untrusted
application download.
 Destroy Operating system
 Provide misleading information
 Steal data/cookies
 Deactivate other trusted applications
 Plant spyware to spy calendars, email accounts,
notes etc.

13. Device Security – Malware
Samples
Virus Name OS Symptom, Propagation and Damages
Cabir Symbi
an
Display „Caribe‟ whenever phone is turned on.
Spread to other phone using Bluetooth
Duts Wind
ows
Affect EXE file more than 4KB
Skulls - Trojan Wind
ows
Replace all icons with image of skull.
Commwarrior Symbi
an
Spread by MMS and Bluetooth. Hunt devices
running Bluetooth and send infected files
Gingermaster
- Trojan
Andro
id
Hidden malware. Steal device details and send to
remote server.
DroidKunFu –
Trojan
Andro
id
Gets privileges of root and install com.google and
ssearch.apk, which remove files, open and auto
download of some applications. It also sends
device data to remote server.

14. Device Security – Antivirus
Protection Software
Operating
System
BullGu
ard
Lookou
t
McAfee
ESET
Kasper
sky
Trend
Micro
F-
Secure
Webroo
t
NetQin
Android
Ye
s
Ye
s
Ye
s
Ye
s
Ye
s
Ye
s
Ye
s
Ye
s
Ye
s
Symbian
Ye
s
Ye
s
Ye
s
Ye
s
Ye
s
BlackBerry
Ye
s
Ye
s
Ye
s
Windows
Ye
s
Ye
s

15. Device Security – Some Best
Practices (User)
 Download applications from the official application
store only. Otherwise you expose yourself and your
mobile phone software provider does not protect you.
 Don‟t jailbreak or root device. If cracked software is
installed you are inheriting a risk.
 Install an antivirus. Antivirus protects device against
apps that try to steal data.
 Before installing the application, from application store
understand and agree to the application device/data
usage.‟
 Disable Bluetooth and other wireless components
when not in use.

16. Device Security – Enterprise
Application Design Practices
 Should adhere to corporate password policy
 Transfer the data only through SSL or VPN (Use VPN if possible)
 Auto disable all unwanted components like Bluetooth when not
required
 Make sure there is no memory leakage
 Do not store any critical data offline. If required, encrypt data and
store using encrypted database like SQLCipher
 Ensure the device is registered for using the application
 Ensure the user logged-in is the right user to use the device and
application
 Provide Single sign-on
 Provide remote-wipe if device lost
 Use dynamic key for encryption of in/out data where the key is
controlled by server
 Do not use any special characters or SQL, in posting data

17. Network Security
 It is an activities designed to protect network for its
 Usability
 Reliability
 Integrity
 Safety
 From the threats like
 Viruses, worms, and Trojan horses
 Spyware and adware
 Zero-day attacks, also called zero-hour attacks
 Denial of service attacks
 Data interception and theft
 Identity theft

18. Network Security Components
• Multiple layers of security. If one fails, others still
stand.
• Network security is accomplished through
hardware and software. The software must be
constantly updated and managed to protect from
emerging threats.
• Network security components often include:
– Anti-virus and anti-spyware
– Firewall, to block unauthorized access to your network
(DMZ)
– Intrusion prevention systems (IPS), to identify fast-
spreading threats, such as zero-day or zero-hour attacks

19. Attackers – How they do?
• Most popular attacks using
– Reverse Engineering
– Cross site scripting (XSS)
– SQL Injection

20. Cross-site Scripting (XSS
Attack)
• As documented by Symantec 2007, 84%
vulnerability are caused by XSS attacks.
• Cross-Site Scripting (XSS) attacks occur when:
– Data enters a Web application through an untrusted
source, most frequently a web request.
– The data is included in dynamic content that is sent to a
web user without being validated for malicious code
• It is a process of injecting a malicious content in
web page and have the content (usually ActiveX,
JavaScript, VBScript, Applet, Flash, HTML etc)
executed in client browser
– To steal client data.

21. Cross-site Scripting - XSS
Types
• Stored XSS Attacks – Permanently stores injected
code in targeted components like database,
message forum, visitor log, comment field, etc.
• Reflected XSS Attacks – Injected code is reflected
off the web server
– As a response such as error message, search result etc.
– eMail message
When a user is tricked into clicking on a malicious link or
submitting a specially crafted form, the injected code travels to
the vulnerable web server, which reflects the attack back to the
user‟s browser. The browser then executes the code because it
came from a "trusted" server.

22. XSS – Prevention Summary
Data
Type
Conte
xt
Code Sample Defense
Strin
g
HTML
Body
<span>UNTRUSTE
D DATA </span>
•HTML Entity Encoding
Strin
g
Safe
HTML
Attribut
es
<input type=“text”
name=“fname”
value=“UNTRUSTE
D DATA”>
•Aggressive HTML Entity Encoding
•Only place untrusted data into white list of
safe attributes
•Strictly validate unsafe attributes such as
background, id and name
Strin
g
GET
Param
eter
<a
href=“/site/search?v
alue=UNTRUSTED
DATA”> clickme
</a>
URL Encoding String
Strin
Untrus
ted
URL in
a SRC
<a
href="UNTRUSTED
URL">clickme</a>
•Cannonicalize input
•URL Validation
•Safe URL verification
•Whitelist http and https URL's only (Avoid
Source:
https://www.owasp.org/index.php/XSS_(Cross_Site_Scripting)_Prevention_Cheat_Sheet#XSS_Pre
vention_Rules_Summary

23. XSS – Prevention Summary
(Contd…) Source:
https://www.owasp.org/index.php/XSS_(Cross_Site_Scripting)_Prevention_Cheat_Sheet#XSS_Pre
vention_Rules_Summary
Data
Type
Conte
xt
Code Sample Defense
Strin
g
CSS
Value
<div
style="width: UNTRU
STED
DATA;">Selection</di
v>
•Strict structural validation
•CSS Hex encoding
•Good design of CSS Features
Strin
g
JavaS
cript
Variab
le
<script>var
currentValue='UNTR
USTED
DATA';</script>
<script>someFunctio
n('UNTRUSTED
DATA');</script>
•Ensure JavaScript variables are quoted
•JavaScript Hex Encoding
•JavaScript Unicode Encoding
•Avoid backslash encoding (" or ' or )
HTM
L
HTML
Body
<div>UNTRUSTED
HTML</div>
•HTML Validation (JSoup, AntiSamy, HTML
Sanitizer)
Strin DOM
<script>document.wri
te("UNTRUSTED

24. XSS Prevention – Output
Encoding
Source:
https://www.owasp.org/index.php/XSS_(Cross_Site_Scripting)_Prevention_Cheat_Sheet#XSS_Pre
vention_Rules_SummaryEncoding
Type
Encoding Mechanism
HTML Entity
Encoding
Convert & to &amp;
Convert < to &lt;
Convert > to &gt;
Convert " to &quot;
Convert ' to &#x27;
Convert / to &#x2F;
HTML
Attribute
Encoding
Except for alphanumeric characters, escape all characters with
the HTML Entity &#xHH; format, including spaces. (HH = Hex
Value)
URL
Encoding
Standard percent encoding, see:
http://www.w3schools.com/tags/ref_urlencode.asp
JavaScript
Encoding
Except for alphanumeric characters, escape all characters with
the uXXXX unicode escaping format (X = Integer).
CSS escaping supports XX and XXXXXX. Using a two
character escape can cause problems if the next character

25. XSS Prevention – Testing
Tools
• Commercial License:
o Veracode Dynamic Scanner
o Whitehat
o HP WebInspect
o Cenzic Hailstorm
o IBM AppScan
o NTOSpider
o Qualys
o Burp Professional
• Free/Open Source:
o W3af
o XSS-Me and Access-Me
o OWASP ZAP
o Skipfish
o Wfuzz
o Reference for more tools :

26. SQL Injection
• SQL Injection Attack (SQLIA) is the one of the top
10 vulnerability, identified by OWASP.
• It is a insertion of a SQL in posted request from
client application to server.
• By injecting SQL, the attacker can
– Read sensitive database
– Modify (insert/update/delete) database
– Execute admin operations
– Alter DB structure
– Bi-pass user authentication

27. Sub Classes of SQLIA
• Classic SQLIA
• Inference SQL injection
• Interacting with SQL
injection
• Database management
system-specific SQLIA
• Compounded SQLIA
• SQL injection +
insufficient authentication
• SQL injection + DDoS
attacks
Source: http://en.wikipedia.org/wiki/SQL_injection

28. Prevention of SQL Injection –
Primary Defense
 Prepare Statements (Parameterized Queries) –
Attacker can not change the intent of a query.
Recommendations
 Java EE – use PreparedStatement() with bind variables
 .NET – use parameterized queries like SqlCommand() or OleDbCommand() with
bind variables
 PHP – use PDO with strongly typed parameterized queries (using bindParam())
 Hibernate - use createQuery() with bind variables (called named parameters in
Hibernate)
 SQLite - use sqlite3_prepare() to create a statement object
 Stored Procedures – Same like Prepare Statement
 Escaping All User Supplied Input
Reference
OWASP: https://www.owasp.org/index.php/ESAPI
Google: http://owasp-esapi-

29. Prevention of SQL Injection –
Additional Defense
Least Privilege
White list Input Validation
Reference:
http://ferruh.mavituna.com/sql-injection-
cheatsheet-oku/
https://www.owasp.org/index.php/Input_Validation
_Cheat_Sheet

30. Prevention of SQL Injection –
Testing Tools
 SQL Inject-Me
 SQLMAP
 SQLler
 SQLbftools
 SQL Injection brute-
force
 SQLBrute
 BobCat
 Absinthe
Source: http://rochakchauhan.com/blog/2008/01/10/top-15-free-sql-injection-
scanners/
 SQL Injection Pen-
testing tools
 SQID
 Blind SQL Injection
Perl tool
 SQL Power Injector
 FJ-Injector framework
 SQLNinja
 Automatic SQL Injector
 NGGSS SQL Injector

31. Architectural and
Development consideration
 Validate the Device Registration from Server
 Always use VPN (at least SSL) network for communication
 Encrypt the critical data in both ends
 Use Dynamic Encryption keys. A Encryption key should be used for only
one communication and it should have automatic expiry.
 The key should have some complex generation logic.
 Do not store entire initial complete encryption key in device. i.e., a complete
key should be generated based on partial key.
 Do no cache, store data. Do not create any cookies
 Disable all network components that are not used by the application
 Enforce password policy
 Enable single sign-on using servers like LDAP
 Disable client-scripting
 Do not keep any SQL in client side
 If necessary, to store offline data, use encrypted DB like SQLCipher
 Always validate the both input and output data for its format and canonical

32. Conclusion
 The security of mobile application should be ensured at all
levels and by all players
 Application/service providers
 Organization
 Device providers
 Registries
 Data Centers/Cloud Services
 Government
 CERTs
 Users
 All players in this ecosystem must apply the basic rules for
effective security
 Coordination
 Communication and
