1. Design of I.C. Engine
Components
Prepared by:
Bhosale K.C.
Assistant Professor,
Department of Mechanical Engineering,
Sanjivani College of Engineering, Kopargaon
Savitribai Phule Pune University, Pune

4. I.C. Engine Classification
 Petrol Engine – Spark Ignition Engine
 Diesel Engine-Compression Ignition Engine
 Two Stroke Engine
 Four Stroke Engine

5. Diesel Engine
 High thermal efficiency
 More uniform torque
 Run at low speed, low maintenance cost
 Reliable And safe due to robust construction

6.  4 Stroke engine
- lower fuel consumption
- Higher efficiency
 2 Stroke Engine
- Light in weight
- Compact construction

7. I.C. Engine Components
 Cylinder & Cylinder liner
 Piston, Piston Pins & Piston Rings
 Connecting Rod
 Crank Shaft & Crank –Pin
 Valve gear system

8. I.C. Engine Components

9. Cylinder & Cylinder Liner
 Basic functions of Cylinder
-To retain working fluid
- to guide piston
 Cooling
- Air Cooled
- Water Cooled

10. Cylinder Liners

11. Materials
 Made of Gray C.I. with homogeneous and
closed structure.
 Centrifugally cast
 For heavy duty cylinder-Ni C.I. & Ni-Cr C.I.
 Cast steel & Al. Alloys

12. Bore & Length Of Cylinder
 Bore means I.D. of Cylinder
 Where,
 IP=Indicate power, W
 BP=Brake power, W,
 = mechanical efficiency ( in fraction) if not
specified assume 0.8

13.  Where,
 Pm= Indicated mean effective pressure (N/mm2)
 l = Length of Stroke (m)
 A= Cross Sectional Area of Cylinder (mm2),
 N= Engine speed (rpm)
 D= Dia. Of cylinder ( mm),
 n= No. of working strokes / min.
 For 2 Stroke engine n=N
 For 4 Stroke engine n=N/2
IP= PM LAN/60, Watts

14.  l/D ratio is assumed from 1.25 to 2. ( if not
specified assume 5)
 Length of cylinder is more than the length of
stroke. There is clearance on both the sides of
the stroke. Total clearance is taken as 15% of
the stroke.
 L= 1.15 l
 L= length of the cylinder.

15. Thickness of the cylinder Wall
 The engine cylinder is treated as Thin cylinder.
 t= Thickness of cylinder wall (mm)
 Pmax=Maximum gas pressure inside the cylinder (N/mm2)
 D= I.D. of Cylinder (mm)
 c=Permissible circumferential stress (N/mm2)
 C= Reboring allowance (mm)

16. Thickness of the cylinder Wall
 Max. Pressure is assumed 10
times mean effective pressure
 Permissible c=35 to 100N/mm2)
 Reboring allowance is taken from
table

17. Empirical Relations
 Thickness varies from 5-10 mm , Thickness=
 Thickness of dry liner =
 Thickness of water jacket wall = 1/3 t-3/4 t
 Thickness of water jacket wall =0.032D+ 1.6 ( mm)
 Water space = 9 mm for 75 mm to 75 for 750 mm of D
 Water space = 0.08 D + 6.5 mm
 Thickness of cylinder flange= 1.2 t -1.4 t
 Radial distance between O.D. of flange & PCD of studs=
(d+6) to 1.5 d
 d= nominal dia. Of bolt or stud

18. Cylinder Head
 A cylinder cover is provided for:
 Inlet & exhaust valves
 Air & gas ports
 Spark plug or atomiser
 In preliminary design, cylinder head is assumed
as flat circular head
 Where,
 th=thickness of cylinder head (mm),
 K=0.162
 Permissible c=35 to 50 N/mm2)

19.  Studs are used to connect cylinder, cylinder head
& gasket for leak proof joint.
 Initially studs are tightened by spanner to induce
preload, and
 In working condition they are subjected to
tensile stresses due to internal gas pressure
acting on cylinder head.

20. Design of Studs
 No. of Studs:
 Min. no. of studs =0.01 D+4,
 Max. no. of studs =0.02 D+4
 Dia. Of studs
 Gas force acting on cylinder head=
 Resisting force offered by all studs=

21. =
 Where,
 dc= core dia. Of studs (mm),
 z= no. of studs
 t=Permissible tensile stress for stud (N/mm2)=
 t=35-70 (N/mm2)
 Nominal dia=

22.  Pitch of Studs:
 PCD of Studs=
 Pitch of Studs=
 Min. Pitch= 19d max. pitch = 28.5d

23. Piston
 Piston is a reciprocating part of I.C. engine.
 Transmit force due to gas pressure to crankshaft
through connecting rod.
 Compresses the gas in compression stroke.
 Seals inside portion of cylinder from crankcase
by means of piston rings
 Takes side thrust resulting from obliquity of
connecting rod.
 Dissipates large amount of heat from
combustion chamber to cylinder wall.

25. Design requirements of Piston
 Should have sufficient strength
 Should have sufficient rigidity
 Adequate capacity to dissipate heat
 Should have minimum weight
 Form an efficient seal to prevent leakage
 Noiseless operation

26. Piston Materials
 Cast Iron,
 Cast Steel,
 Forged Steel,
 Cast Aluminum Alloy,
 Forged Aluminum Alloy

27. Thickness of Piston Head
 There are two types of piston heads:
 Flat head
 Cup type

28. Criteria for calculating piston head
thickness
 Strength
 Heat dissipation

29. Strength criteria
 Piston head is treated as flat circular plate of
uniform thickness.
 Where,
 th= thickness of Piston head (mm),
 D= Cylinder bore (mm),
 Pmax = Max. gas pressure (N/mm2)
 t=Permissible bending stress (N/mm2)

30.  Bending stress
 Bending stress- for C.I. (30-40 N/mm2) & for
Al. Alloy (50-90 N/mm2).
 Max. gas pressure may rise to 8 N/mm2. but
average value is taken as 4-5 N/mm2.
 Empirical formula to find out piston head
thickness

31. Heat dissipation criteria
 Thickness of piston head
 Where,
 Th= thickness of piston head (mm),
 H= amount of heat conducted through head (W)
 K= thermal conductivity factor (W/m/0C)
 Tc= temp. at center of piston head (0C)
 Te= temp. at edge of piston head (0C)

32.  K values
 C.I.=46.6 (W/m/0C)
 Al. alloy = 175 (W/m/0C)
 Permissible temp. difference( Tc-Te)
 C.I.=2200 C
 Al. alloy = 75 0C

33. Amount of heat conducted
 HCV= Higher Calorific Value (kJ/Kg)
 M= mass of fuel per power per second (kg/kW/s)
 BP=brake power of engine per cylinder (kW)
 C= ratio of heat absorbed by piston to heat
developed in cylinder=0.05

34.  HCV values
 For diesel = 44*103 kJ/kg
 For Petrol = 47*103 kJ/kg
 The Avg. consumption of fuel in diesel engine is
0.24 – 0.30 kg/kW/h

35. Piston ribs and cups
 Piston head is provided with a no. of ribs for:
 Strengthening piston head against gas pressure
 Ribs transmit large portion of heat from piston
head to piston rings.
 Side thrust created by obliquity of connecting
rod is transmitted to piston at piston pin.

36. Guidelines for ribs
 th < 6 mm – no ribs
 th > 6 mm – ribs required.
 No. of ribs = 4 – 6
 Thickness of rib is
 Where,
 tR=thickness of rib
 th= thickness of piston head

37. Piston Cup
 A cup provides additional space for combustion
of fuel.
 Depends upon volume of combustion chamber.
 And arrangement of valves.

38. Guidelines for cup
 l/D < 1.5 – cup required
 l/D > 1.5 – cup not required
 Radius of cup= 0.7 D

39. Piston Rings
 Compression ring
 Oil scrapper ring

40. Guidelines for design of rings
 Material– Gray C.I. & Alloy C.I.
 No. of piston rings—
 Compression rings for aircraft engine= 3 – 4
 For stationary engine= 5-7
 Oil scrapper rings= 1 – 3

41. Dimensions of c/s
 Rectangular c/s
 Where,
 b = radial width of ring
 Pw = allowable radial pressure on cylinder wall (N/mm2)
 t=Permissible tensile stress for ring material (N/mm2)
 Pw =0.025 – 0.042 (N/mm2)
 t = 85 – 110 (N/mm2)
 Axial thickness of ring h = (0.7 b ) to b

42.  Gap between free ends
 3.5 b – 4 b
 Width of top land and
ring lands
 h1 = th – 1.2 th
 h2 = 0.75 h -h

43. Piston barrel
 t3 = (0.03 D + b + 4.9
 t3 = thickness of piston barrel at
top end ( mm)
 b= radial width of ring ( mm)
 t4 = thickness of piston barrel at
open end ( mm)
 t4 = 0.25 t3 – 0.35 t3

44. Piston skirt
 Acts as bearing
surface for side thrust

45.  Max. gas pressure on piston head=
 Side thrust =
 Where, µ= coefficient of friction = 0.1
 Side thrust=
 Where, Pb= allowable bearing pressure (Mpa)
 ls =length of skirt (mm)
 Equating above eqns.
 From this length of skirt is obtained

46. Piston pin
 To connect piston and
connecting rod.
 It is hollow circular.
 End movement is
restricted by circlips.
 Two criteria's
 Bearing
 bending

47. Bearing considerations
 Length of pin in small end of connecting rod l1=0.45 D
 O.D. of pin
 Force on piston=
 Resisting fore =
 (Pb)1 = brg. Pr. At bushing of small end of
connecting rod (Mpa)
 do = O.D.of piston pin

48. Bending considerations
 B.M. at section XX
 Also,
 Bending stress
 b = 84 (N/mm2) for case hardened steel
 b = 140 (N/mm2) for heat treated alloy steel

49. Connecting Rod
 Consists of an eye at small end to accommodate
the piston pin, a long shank and big end opening
split into two parts to accommodate crank pin.
 Basic function is to transmit push and pull forces
from piston pin to crank pin.
 Connecting rod transmits the reciprocating
motion of the piston to the rotary motion of the
crankshaft.
 Splash oil lubrication.

50. Connecting rod

51.  Subjected to gas pressure and inertia force due to
reciprocating parts
 Material medium carbon steel or alloy steel.
 Lubrication – splash & pressure feed
 Length
 When length is small compared to crank radius, it
has greater angular swing resulting in greater side
thrust on the piston.
 Normally

52. Buckling of connecting rod
 Subjected to compressive stress
 Designed as column or strut

53.  Buckling about XX axis, ends are hinged in
crank pin and piston pin. So, end fixity
coefficient is one.
 Buckling about YY axis, ends are fixed due to
constraining effect of bearings at crank pin and
piston pin. So, end fixity coefficient is four.
 Therefore, connecting rod is 4 times stronger
for buckling about YY axis as compared to XX
axis.

54.  If a connecting rod is designed in such a way
that it is equally resistant to buckling in either
plane then,
 Where, I = moment of inertia ( mm4)
 Substitute I = Ak2,
 k= radius of gyration (mm)

55. C/S for connecting rod
 P= force acting on piston due to
gas pressure (N)
 Ps = side thrust on side wall (N)
 Pc=force acting on connecting
rod (N),
 =angle of inclination of
connecting rod with line of
stroke
 =angle of inclination from TDC

56.  P = Pc cos 
 Max gas load occurs at = 3.30
 Max. force acing on the piston due to gas pressure =
 Dimensions are calculated by Rankin’s formula
 Pcr= critical buckling load
 c=compressive yield stress = 330 (N/mm2)
 A= c/s area of connecting rod mm2
 a = constant = 1/7500
 L= length of connecting rod (mm)
 Pcr = Pc (fs)

57. Procedure
 Calculate force acing on connecting rod
 Calculate critical buckling load Pcr = Pc (fs), fs=5 – 6
 By Rankine's formula
 Substitute,
 A=11t2
 Kxx= 1.78 t
 a= 1/7500
 c=330 (N/mm2)

58. Big and small end bearing
 Force acting on piston pin
bearing
 Also,
 dp= dia. Of piston pin
 lp= length of piston pin.
 (Pb)p= allowable bearing
pressure = 10 – 12.5 MPa
 l/d ratio for piston pin bush
= 1.5 – 2.

59. Big end cap & bolts
 Inertia acting on bolts
 Where,
 Pi= inertia force on cap or bolts (N)
 mr= mass of reciprocating parts (kg)
 r = crank radius (mm)
 n1= ratio of length of connecting rod to crank radius
 L= length of connecting rod

60.  Mass of reciprocating parts
 mr = mass of piston assembly+ 1/3 mass of
connecting rod
 The inertia is max at TDC when =0, cos =1
