1. Deploying Hyper-scale SDN and NFV
in Next-generation Data Centers
Copyright © 2016 Radisys Corporation – All rights reserved. MT 08.22.16
Bryan Sadowski
VP, Product Management

2. Who is Radisys
Copyright © 2016 Radisys Corporation – All rights reserved. 2
25+ Years
Telecom Software
Experts
a new operator centric company
essential for the
Agile, DevOps world.
+ =Telecom Hardware
Experts
25+ Years
Carrier Scale
hardware design expertise
Telecom and Datacom software expertise Open source hardware - no “closed systems” hidden
agenda like some large incumbents
World class supply chain management End to end network protocol expertise Nimble, vendor agnostic systems integration
Deep and rich 3rd party hardware
ecosystem
Agile/DevOps centric mindset First mover advantage in open source telecom
OCP, ONOS, CORD, …
Operational excellence and nimbleness Open source tool chains and software
for system automation
telco datacenter transformation experts
With deep open source software competency
Trusted and Proven
Hardware Partner
Trusted and Proven
Software Partner
The Best Choice for Open Telecom
Solutions in the DevOps Era

3. SDN/NFV Market Trends
Copyright © 2016 Radisys Corporation – All rights reserved. 3
TODAY TOMORROW FUTURE
• Market lifts off
• Early deployments expand
• SDN/NFV Products Mature
• Market Expands
• SDN/NFV becomes mainstream
• Macro SDN/NFV deployment on a
few use cases.
• Individual operators move 1-3
use cases into field trials.
• SDN and NFV products
mature and multiply
• Revenue ramps markedly
• Operators and vendors search
for solutions for federating
multiple orchestration and control
systems
2016 2017/2018 2019 and Beyond
• Most network service functions
can be purchased as VNFs
• Most network hardware sold can
be directly controlled by SDN
controllers
• Operators focus on fuller policy-
driven automation
Source: IHS Carrier SDN hardware, software and services annual market report

4. Carriers shift to SDN and NFV
Copyright © 2016 Radisys Corporation – All rights reserved. 4
Service Agility
Quicker Time to Revenue
Operational
Efficiency
Global View Across Multi-domain,
Multi-vendor Networks
Primary Drivers
Physical and Virtual
Integration Complexities
within Existing Network
Software Not
Carrier Grade Yet
Primary Barriers

5. Radisys FlowEngine: Open, Compact and High Scale
Ultra compact with high performance (up to 1.2 Tbps per 3U)
Scalable to support millions of flows and subscribers
Wire speed switching and routing
High speed DDoS detection and application monitoring
L4 – L7 services on top of L2 & L3
Best power & space efficiency
Fully data and control plane programmable
Radisys
FlowEngine
L2 – L7
Intelligent Network
Service Platform
Copyright © 2016 Radisys Corporation – All rights reserved. 5

6. CORD: Central Office Re-architected as Datacenter
SDN Control Plane
- ONOS
NFV
Orchestration
w/XOS
Large number of COs
Evolved over 40-50 years
300+ Types of equipment
Huge source of
CAPEX/OPEX
White Box White Box White Box
White Box
White Box White Box
White Box White Box White Box White Box
White Box White Box White Box White Box
Leaf-Spine
Fabric
White Box
White Box
SDN enabled DC Fabric
Commodity servers, switches and network access
Access
Core
Cloud
NFV
SDN
Copyright © 2016 Radisys Corporation – All rights reserved. 6

7. Radisys DCEngine: DevOps Ready / Rapid Deployment Clusters
Copyright © 2016 Radisys Corporation – All rights reserved. 7
+ =Telecom
OCP Rack
Radisys
Software and
Services
Commercial &
Open Source
Software
Radisys
DCEngine+
Test
Automation
Deploy &
Upgrade
Rack
Management
Scripting
Tools
Inventory &
Lifecycle Mgmt
Radisys Software
Management &
Automation Tools
Patch
Automation
For example, …
And others available upon request.
R / M
Data
Center
Apps
CORD
Package

8. Bringing It Together:
Carrier Grade Integrated hardware and software SDN/NFV Solution
Copyright © 2016 Radisys Corporation – All rights reserved. 8
eNodeB
Carrier Data Center
SDN Controller
Data
Center Network
Service Function
Chaining
FlowEngine
L2-4 Traffic
Distribution
Service
Function
Chaining
Intelligent
Traffic Distribution
FlowEngine
Delivering SFC
Virtual Network Functions
(VNFs)
Flexible and
Scalable Evolved
Packet Core (EPC)
- M-CORD
Internet
DCEngine
FlowEngine
Leaf/Spine
DCEngine
Hyper Scale Telecom OCP RackDCEngine
FlowEngine
Leaf/Spine Intelligent L2-L4 Traffic Distribution Switch with Load Balancer
Radisys
Professtional
Service
Your Extended DevOps team

9. Radisys Professional Services:
Continuous collaboration to accelerate your telco data center rollout
Copyright © 2016 Radisys Corporation – All rights reserved. 9
PARTNERSHIP
Innovate Test
Continuous Optimization
Monitor
Speed and Collaboration Problem Solving with Extended Teams
BuildDesign Monetize
You
Trial &
Deploy

10. Summary
Copyright © 2016 Radisys Corporation – All rights reserved. 10
Service Agility
Quicker Time to Revenue
Embracing the Drivers
• Radisys FlowEngine delivers rapid network
configuration under OpenFlow Control.
• Radisys DCEngine delivers a DevOps environment
to accelerate SDN and NFV deployments.
Operational Efficiency
Global View Across Multi-domain, Multi-vendor Networks
• Radisys’ Collaboration with On.LAB and CORD
proving operational efficiencies.
Software Not Carrier Grade Yet
Overcoming the Barriers
• Radisys FlowEngine designed to manage millions
of flows.
• Radisys DCEngine pre-integrated with platform
and orchestration software.
Physical and Virtual Integration
Complexities within Existing Network
• Radisys Professional Services collaborates with
our customers to overcome integration
complexities.
We Are your Extended Dev Ops Team

11. Thank You
Copyright © 2016 Radisys Corporation – All rights reserved. 11
•Any questions?
• Please visit the Radisys booth in the Expo Hall
