CSS3 provides new features for layout, typography, visual effects and graphics. Some key features include multiple column layout, rounded corners, box shadows, opacity, gradients, reflections, transforms and animations. Browser support for CSS3 is evolving with many properties requiring vendor prefixes. CSS3 brings more powerful and flexible options for designing user interfaces beyond what is possible with CSS2.

1. CSS
& CSS3
Robyn Overstreet

2. More CSS Layout

3. CSS Layout
• Positioning
• Display
• Floats

4. Inline vs. Block
Block
Start and end with new lines. Can have a
width.
<p>, <table>, <div>, ...
Inline
Does not force new lines. Cannot have
width.
<b>, <span>, <img>, ...
4

5. Display property
Switch elements between block and
inline display or hide elements
Possible properties
Text
• block
• inline
• none
#search-results{
display:none;
}

6. The Box Model
Four parts:
Content
Padding
Border
Margin
6

7. Box Model Measurements‫‏‬
In most browsers, a box with a 70px width take up
100px with margin and padding …
7

8. Box Model Measurements‫‏‬
In IE browsers, the padding is subtracted instead of
added, so the box will take up only 90px.
8

9. Window & Document

10. Relative Position
Positioned in relation to the other elements
around it

11. Absolute Position
Positioned in relation to its parent
without regard to the normal flow of
elements

12. Fixed Position
Absolutely positioned, but relative to
the viewport, instead of its parent
element. The element's position is
specified with the "left", "top",
"right", and "bottom" properties

13. Positioning Properties
 Positioning properties specify the left, right,
top, and bottom positions of an absolutely
positioned element
 They set the shape of an element, place
one element behind another, and indicate
directions for fitting an element's content
in a specified area
img.logo {
position: absolute;
top: 0;
left:0;
width: 150px;
height: 150px;
13
}

14. Floating for Layout
Floating allows elements to align to the left or the right of the page.
Inline elements will wrap around floated elements.
Left Float

15. Clear
The clear property sets the sides of an element
where other elements are not allowed.
Possible values:
• left
• right
• both
• none
15

16. 2-column Layout
• Experiment with floating both divs
right, both divs left, or one left and
one right

17. 3-column Layout

18. Lab: Layout
• Sketch a design layout on paper
• Build the wireframe in CSS and HTML
• Try positioning a sidebar on the left or
the right by just changing the CSS
(not the HTML)
• Extra: Position a logo over the columns
using absolute positioning

19. CSS 3

20. Modular
CSS3 is a collection of modules
• Allows updates on a module-by-
module basis (instead of waiting
for an update of the full spec)
• Browsers can add support for
features one module at a time
• Browsers are able to implement
some modules and not others

21. New Features in CSS 3
New Selectors

Rounded Corners

Text-Overflow

Border Image

Multi-Column Layout

Color and Opacity: RGBA

Web Fonts

Gradients

Transitions

Box and Text Shadows

Transformations

Multiple Backgrounds

Animation

Masks

Reflection


22. Browser Compatibility
• Many of the CSS3 features only work on specific browsers.
• Need to use browser-specific property names in those cases.
• Prefix with -webkit or -moz
Webkit-specific properties
http://qooxdoo.org/documentation/general/webkit_css_styles
Mozilla-specific properties
https://developer.mozilla.org/en/CSS_Reference/Mozilla_Extensions

23. Browser
compatibility charts
References for finding browser
support of CSS3 properties
• CanIUse.com
• FindMeByIP.com charts

24. Web Fonts

25. Web Fonts
@font-face allows use of fonts from URLs
The Basics: Call a font from a URL and give it a name
@font-face {
font-family: Gentium;
src: url(http://site/fonts/Gentium.ttf);
}
p { font-family: Gentium, serif; }

26. Web Fonts
The Thorough: Best bet for cross-browser support
@font-face {
font-family: "Your typeface";
src: url("type/filename.eot");
src: local("Your Typeface"),
url("type/filename.woff") format("woff"),
url("type/filename.otf") format("opentype"),
url("type/filename.svg#filename") format("svg");
}
• Start with the IE compatible font (.eot)‫‏‬
• Check for a local version of the font
(this also prevents IE from trying to load formats it can't understand)
• Offer other formats

27. Font Services
! Copyright. Fonts are copyrighted material.
Downloadable Fonts
• Font Squirrel fontsquirrel.com
Freeware fonts to download and host yourself, with helpers to
write CSS code
Font Hosting
Fonts delivered from server, with Javascript helpers
• Google Font API code.google.com/webfonts
Open-source font library with limited number of fonts
• TypeKit typekit.com
Subscription-based font service with a large library

28. Lab: Fonts
• Add fonts to your page using the Google
web fonts API
• Check display across browsers

29. Text Features

30. Text Overflow
A new option for content that overflows its containing box
Two roads diverged in
a yellow wood, and
sorry I could not ...
#poem_box{
text-overflow: ellipsis;
}

31. Multi-Column Layout
Add -moz- and/
or -webkit- to
each of these
column-count:2;
column-width:250px;
column-gap:20px;
column-rule:1px
dotted;

32. Multi-Column Layout
column-count
column-gap
column-rule
column-break-after
column-break-before
column-span
column-fill
These require -webkit- or -moz- prefixes

33. New Visual Effects
in CSS3

34. RGBA
background: rgba(255,70,280,.6);
red green blue alpha
60% opacity

35. Rounded Corners
W3C Official Spec:
border-radius:
55pt / 25pt;
Text
Browser Implementation:
New in FF 3.5 !
-webkit-border-radius: 55pt 25pt; Previous versions
did not support
-moz-border-radius: 55pt / 25pt;
elliptical borders

36. Quick-fire Lab
Round the corners of a div

37. Shadows
Applies to text and boxes with text-shadow and box-shadow.
box-shadow: 10px 10px 20px #000;
-webkit-box-shadow: 10px 10px 20px #000;
<horizontal distance> <vertical distance> <blur> <color>

38. Quick-fire Lab
Apply a shadow to a box or to text

39. Gradients
background: -webkit-gradient(linear,0 0, 0 100%,
from(#333),to(#fff));
0, 0
type: linear or radial.
points: space separated
from() and to(): value
color stop (optional)‫‏‬
color-stop(80%, #e4c700)‫‏‬
0, 100%

40. Quick-fire Lab
Create a gradient background for a
div

41. Multiple Backgrounds
Add multiple background images by separating urls with a comma
#box{
background: url(top.gif) top left no-repeat,
url(bottom.gif) bottom left no-repeat,
url(middle.gif) left repeat-y;
}

42. Reflection
-webkit-box-reflect: <direction> <offset> <mask-box-image>
<direction> can be one of above, below, left or right.
<offset> is a length or percentage that specifies the distance of the reflection
from the edge of the original border box (using the direction specified). It can
be omitted, in which case it defaults to 0.
<mask-box-image> is a mask-box-image that can be used to overlay the
reflection. If omitted, the reflection has no mask.
img.simple_reflect{
-webkit-box-reflect:below 5px;
}
img.deluxe_reflect{
-webkit-box-reflect:below 5px -webkit-
gradient(linear, left top, left bottom,
from(transparent), color-stop(.7,
transparent), to(rgba(255, 255, 255, 0.5)));
}

43. Reflection
img.deluxe_reflect{
-webkit-box-reflect:below 5px -webkit-
gradient(linear, left top, left bottom,
from(transparent), color-stop(.7,
transparent), to(rgba(255, 255, 255, 0.5)));
}

44. Quick-fire Lab
Try multiple background images
and/or reflection

45. Masks
img.photo {
-webkit-mask-box-image: url(mask.png);
}
+ =

46. Border Image
#box{
border-width: 8px;
-webkit-border-image: url("border2.png") 8 round;
}
<div id=”box”>

47. Graphic
Transformations

48. 2D Transformations
The transformation functions:
scale, scaleX, scaleY
translate, translateX, translateY
skew, skewX, skewY
rotate
matrix
-webkit-transform: skew(0deg, 30deg);
-webkit-transform: rotate(30deg);

49. Transformations: scale
-moz-transform: scale(3); 1 = 100%
or transform: scale(1,4); .2 = 20%
-webkit-transform: scaleY(1.5); 1.5 = 150%
transform: scaleX(.2); 3 = 300%

50. Transformations: skew
transform: skew(0deg, 30deg);
skewX skewY
-webkit-transform: skew(-25deg); -moz-transform: skew(0deg,-25deg);

51. Faking 3D: a 2D Cube
.cube {
position: relative;
top: 200px;
}
.rightFace,.leftFace,.topFace{
position: absolute;
padding: 10px;
width: 180px;
height: 180px;
}
.leftFace {
-webkit-transform: skew(0deg, 30deg);
}
.rightFace {
-webkit-transform: skew(0deg, -30deg);
left: 200px;
}
.topFace {
-webkit-transform: rotate(60deg) skew(0deg, -30deg) scale(1,
1.16);
top: -158px;
left: 100px;
}

52. Lab
Create a skewed box

53. Animation!

54. Transitions
#box {
transition-property: width,height;
transition-duration: 2s;
height: 150px;
width: 150px;
}
#box:hover{
height: 500px;
width: 500px;
}

55. Lab
Create a transition on hover.
Use scale, skew, translate, or change
width or height

56. Triggering Animation
:hover as used in previous versions of CSS
:target trigger animation with a anchor link, e.g. page.html#start
<div id="b" class="brick">foo</div>
<div id="c" class="brick">foo</div>
<p><a href="#c">drop c</a></p>
div.brick:target{
-webkit-transform: rotate(30deg);
}
onclick using javascript
<div onclick=
"this.style.webkitTransform='rotate(360deg)'">

57. Animation: keyframes
Illustration: Yurike Cynthia Go
Creative Commons License

58. Animation: keyframes
@-webkit-keyframes moveitaround{ {
@-webkit-keyframes moveitaround
from { {
from
-webkit-transform: translate(50px,50px) rotate(30deg);
-webkit-transform: translate(50px,50px) rotate(30deg);
} }
50% { {
50%
-webkit-transform: translate(100px,100px) rotate(140deg);
-webkit-transform: translate(100px,100px) rotate(140deg);
} }
to {
to -webkit-transform: translate(500px,200px) rotate(360deg) ;
{
-webkit-transform: translate(500px,200px) rotate(360deg) ;
}
}
}
}
div.mydiv {
-webkit-animation-name: moveitaround;
-webkit-animation-duration: 1s;
-webkit-animation-iteration-count: 3;
}

59. Animation Examples

60. Lab
Make an object move across the
screen using keyframes
