2. Contents (Syllabus, 8 Hrs)
Introduction
Basic Transmission Theory
System Noise Temperature and G/T Ratio
Design of Downlinks
Satellite Systems using small Earth Stations (ES)
Uplink Design
Design of Specified C/N: Combining C/N and C/I
values in Satellite Links
System Design Examples
3. Text Book:
Satellite Communications- T Pratt, Charles Bostian,
Jeremy Allnutt, John Wiley & Sons.
Reference Book:
Satellite Communications- Dennis Roody, McGraw
Hill
4. Introduction
Design of a SCS is a complex process and requiring
compromises between many factors to achieve best
performance at an acceptable cost.
Three factors influence system design:
i. Frequency band
ii. Atmospheric propagation effects
iii. Multiple access technique
5. Performance objectives: (in baseband channel)
Demodulator
C/N
BER (digital link)
SNR (analog link)
C/N > 6dB
C/N < 10 dB (digital link)-must use error correction to
improve BER calculated at the i/p of receiver ( or o/p port
of receiving antenna)
For Noise less receiver :- It is constant at all points (RF
and IF chain)
Overall C/N: UL and DL
IF
Amplifier
C/N
8. Antenna Look Angles
For ES antenna alignment, Two Angles need to be
adjusted and fixed:
Azimuth Angle
Elevation Angle
Jointly referred as Antenna Look Angles.
Elevation Angle (Θ:- 0 to π) Azimuth Angle(Φ:- 0 to 2π)
10. Satellite Functions
(RF to RF conversion)
1. Signal reception: Uplink frequency
2. Processing of signal:
Amplification, Filtration, and Down conversion, etc
3. Signal retransmission: Downlink frequency
19. TV Signal link (FTA)
TV Rebroadcasting
Station- DD-I/II
(Sinhagad , Pune )
DD National, New Delhi
DBS-TV
20. TV Signal link (Pay)
Up-link
Down-link
DD Kendra, Worli, Mumbai
(C-Band)
DBS-TV
DBS-TV
Down-link
Ku Band (Thodapur, New Delhi)
21. Basic Transmission Theory
Satellite and Microwave link: Line-of-Sight (LoS)
Link analysis relates the Pt and Pr.
The flux density and link equation can be used to
calculate the Pr.
22. The flux density in the direction of the antenna bore sight at
a distance R meters is given by:
Pt = Output Power
Gt = Transmitting antenna gain
Pt Gt = Effective Isotropic Radiated Power or EIRP
R= Distance between source and receiving antenna.
A = Receiving antenna aperture area (m2)
Aperture efficiency:
Accounts for losses: blockage, phase errors,
polarization, and mismatches)
Cassegrain antennas 50 to 75%
Horn : 90 %
23.
24. Pr = EIRP + Gr – Lp – La – Lta – Lra (dBW)
La = attenuation in atmosphere
Lta = losses associated with transmitting antenna
Lra = losses associated with receiving antenna
25. Noise Temperature
Noise Temperature:
Pn = KTpBn
where:
k = Boltzmann’s constant (-228.6 dBW/K/Hz)
Tp = Physical temperature of source in (kelvin
degrees or dBK)
Bn = Noise bandwidth (in Hz or dBHz)
27. Pno=kTsBnGrx
Pn=KTsBn
C/N=PrGrx/KTsBnGrx=Pr/KTsBn
Pno= Noise power at demodulator i/p
Grx= Overall ene-to-end gain of the receiver
Ts=System noise temperature
Pn= Noise power at receiver i/p
C/N at demodulator
Pr=signal power at
receiver i/p
C= Pr for constant envelope signal (FM or PSK)
30. Noise Figure (NF)
It is frequently used to specify the noise generated
within a device.
NF = (SNR)in/(SNR)out
NF = 1 or 0 dB (Ideal receiver)
Td = To (NF-1)
Td=Noise temperature
To= Reference temp (290 K)
31. G/T Ratio for ESs
• C/N= [PtGtGr/kTsBn][λ/4πR]2
= [PtGt/kBn][Gr/Ts] [λ/4πR]2
C/N α G/T Gr/Ts=G/T
Increasing
Increases
32. Design of Downlinks
The design of any satellite communication is based on two
objectives:
i. Meeting a minimum C/N ratio
ii. Carrying the maximum revenue earning traffic
at minimum cost.
All satellite links are affected by rain attenuation
C-band:- Effect of rain is small
Ku/Ka-band:- Effect of rain is large
Rain attenuation is a variable phenomenon, both in time and
place
Satellite links are designed to achieve reliabilities of 99.5 to
99.99%, averaged over a long period of time.
33. Link Budgets
It is a tabular method for estimating the Pr and N in a radio
link. Also to calculate C/N ratio.
It quantifies link performance
It uses dB units for all quantities.
The link budget must be calculated for an individual
transponder, and must be repeated for each of the individual
links.
In a 2-way satellite link:- C/N for 4 separate links.
34. These are usually calculated for a worst case, the one
in which the link will have the lowest C/N ratio.
Factors of worst case scenario:
Location of ES at the edge of the satellite coverage
zone
Maximum path length (S to ES)
Elevation angle at ES
Worst
case
35. ES antennas are assumed to be pointed directly at the
satellite, and therefore operate at their on-axis gain.
If the antenna is mispointed, a loss factor is included
for reduction in antenna gain.
36.
37. Link margin:
Clear air: 16.0 - 9.5 = 6.5 dB
In Rain: 12.7 – 9.5 = 3.2 dB
Solution:
Uplink Power Control (UPC)
38. Satellite Systems Using small ESs
Small, low-cost ESs:
Satellites carry only one or two telephone or data
channels or a DBS -TV signal.
Two parameters in Pr equation:
i. Satellite transmitted power
ii. Satellite antenna beamwidth (or G)
39. Ku-Band Receiving Antennas
DTH
(D < 1m)
Transponders are more
powerful
VSAT:
(D:1 to 2 m)
Transponders are less
powerful
40.
41. • A=Aca + Arain dB
• Tsky=270×(1-10-A/10) K
• TA=ɳc ×Tsky K
• Ts rain= TLNA+TA K
• ΔNrain=10 log10[Ts rain/Tsca] dB
A= Total path attenuation
Aca = Clear sky path attenuation
Arain = Rain attenuation
Tsky= Sky noise temperature
TA=Antenna noise temperature
ɳc= Coupling coefficient (90 to 95%)
ΔNrain=Increase in noise
power due increase in Ts
Tsca= System noise
temperature in clear sky
conditions
42. • Crain=Cca-Arain dB
• (C/N)dn rain = (C/N)dn ca - Arain - ΔNrain dB
For Linear (bent pipe) transponder:
(C/N)o = (C/N)up + (C/N)dn rain
Crain= Carrier power in rain attenuation
Cca= Carrier power in clear sky conditions
43. Uplink Design
Easier than the downlink
Accurate specified carrier power can be presented at
the satellite transponder
High power transmitter at ES can be used
Transmitters are costlier than the receivers.
Major growth in satellite communications: Point to
multipoint transmission (Cable TV and DBS-
TV/Radio)
44. • Nxp=k + Txp + Bn dBW
• Prxp= Pt + Gt + Gr – Lp - Lup dBW
• (C/N)up= 10 log10 (Pr/N) = Prxp - Nxp dB
Nxp= Noise power at transponder i/p
Txp = System noise temperature of the
transponder
Prxp = Received power at transponder i/p
Lp = path loss
Lup = all uplink losses
45. Design of Specified C/N: Combining C/N and C/I
values in Satellite Links
Sources of Noise
Thermal noise
For complete satellite link
Receiver it self
Receiving antenna
Sky noise
Satellite transponder
Adjacent satellites
Terrestrial transmitter
Atmospheric gases
Rain
Demodulator
C/N
BER (digital link)
SNR (analog link)
IF
Amplifier
C/N
46. Reciprocal C/N formula (measured in ES@ o/p of IF
amplifier)
(C/N)o =1/[1/(C/N)1 + 1/(C/N)2 + 1/(C/N) 3 + …]
(C/N)o = C/(N1+N2+N3+….) Carrier power is same
(C/N)o = C dBW- 10 log10(N1+N2+N3+…. W) dB
(C/N)o = (C/N)dn => due to transponder and ES
Demodulator
C/N
BER (digital link)
SNR (analog link)
IF
Amplifier
C/N
47. Interference:
• Intermodulation products (IM) generated by the
transponder’s nonlinear i/o characteristic.
• IM power level = (C/I) must be include in (C/N)o
• Interference from adjacent satellites when small
receiving antennas are used (e.g., VSAT and DTH)
• Interference cancellation techniques can be used to
reduce the level of interference
48. Overall (C/N)o with uplink and downlink attenuation
Effect of change in (C/N)up on (C/N)o depending on
the operating modes (or types) and gain of the
transponder
• Linear Pout = Pin+ Gxp dBW
• Nonlinear Pout = Pin+ Gxp – ΔG dBW
• Regenerative Pout = constant dBW
Pout = Power delivered by transponder HPA
to transmitting antenna
Pin = Power delivered by receiving antenna
to transponder
Gxp = gain of transponder
ΔG = loss of gain due nonlinear saturation
characteristics of transponder
49. Output backoff
Saturated output power is the maximum output power and is nominal
transponder power rating that is usually quoted.
ISI and IM product (FDMA) results- when the transponder operating (non-
linear characteristic) close to its saturated output power level.
Transponders are usually operated with output backoff, to make the
characteristic more nearly linear.
Typical values of backoff:
1 dB- single FM or PSK carrier (Input backoff: 3dB)
3 dB- FDMA with several carrier (Input backoff: 5dB)
50. Uplink and Downlink Attenuation in Rain
Rain attenuation affects both uplink and downlink
Rain attenuation is occurring on either uplink or
downlink, but not on both at the same time.
Assumption: True for ESs are well separated
geographically
Example: PCCOE, Ravet to Balewadi (< 20 km)-
Rain attenuation occurs on both links at the same
time.
51. Uplink Attenuation and (C/N)up
Linear
(C/N) o uplink rain = (C/N) o clear air – Aup
Nonlinear
(C/N) o uplink rain = (C/N) o clear air – Aup + ΔG
Regenerative or AGC
(C/N) o uplink rain = (C/N) o clear air
52. Downlink Attenuation and (C/N)dn
Linear
(C/N)dn rain = (C/N)dn clear air – Arain –ΔNrain
(C/N) o = 1/[1/(C/N)dn rain +1/(C/N)up]
(C/N)up is clear air and remains constant regardless
of the attenuation on the downlink
53. Design Procedure
(One-way satellite link)
1. Determine the frequency band
2. Determine the communications parameters of the satellite.
Estimate any values that are not known.
3. Determine the parameters of the transmitting and receiving
ESs.
4. Start at the transmitting ES. Establish an uplink budget and a
transponder noise power budget to find (C/N)up.
5. Find the output power of the transponder based on
transponder gain or output backoff.
54. 6. Establish a downlink power and noise budget for the
receiving ES. Calculate (C/N)dn and (C/N)o for a station at
the edge of the coverage zone (worst case)
7. Calculate SNR or BER in the baseband channel. Find the link margins.
8. Evaluate the result and compare with the specification requirements.
Change the parameters of the systems as required to obtain acceptable
(C/N)o or SNR or BER values. This may require several trial designs.
9. Determine the propagation conditions under which the link must operate.
Calculate the outage times for uplink and downlinks.
10. Redesign the system by changing some parameters if the link margin are
inadequate. Design can be implemented within the expected budget.
57. Satellite link design using Ku-band GEO with bent
pipe transponders to distribute digital TV signals to
many receiving stations(US).
Minimum permitted overall C/N of 9.5dB
58. Ku-Band Uplink Design:
Noise power Budget
k=Boltzmann’s constant -228.6 dBW/K/Hz
Ts= 500 K 27.0 dBK
B= 43.2MHz 76.4 dBHz
N= Transponder noise power -125.2 dBW
Pr= -125.2+30 dB -95.2 dBW
Required C/N at the i/p of transponder
59. Gt=10 log 10[ɳe×(πD/λ)2]=55.7 dB ɳe = 68% D=5m
λ=0.0212m@14.15GHz
Lp =10 log 10[(4πR/λ)2]=207.2 dB
Power Budget
Pt= ES transmit power ? dBW
Gt= ES antenna gain 55.7 dB
Gr= Satellite antenna gain 31.0 dB
Lp = Free space path loss -207.2 dB
Lant= ES on 2 dB contour -2.0 dB
Lm= other losses -1.0 dB
Pr= Received power at transponder -123.5 dB
The required power at the transponder i/p is 30 dB-123.5 dB = - 95.2 dBW
Pt-123.5 dB= -95.2 dB= 28.3 dBW or 675 W
Required C/N at the i/p of transponder
60. Ku-Band Downlink Design:
1/ (C/N)dn = 1/(C/N)o - 1/(C/N)up (not in dB)
(C/N)dn = 17.2 dB (C/N)o=17 dB (C/N)up= 30 dB
Noise power budget
k=Boltzmann’s constant -228.6 dBW/K/Hz
Ts= 30+110 K 21.5 dBK
B= 43.2MHz 76.4 dBHz
N= Transponder noise power -130.7 dBW
Pr = -130.7 dBW+17.2 dB = -113.5 dBW
61. Lp =10 log 10[(4πR/λ)2] λ=0.0262m@11.45GHz
Lp =207.2-20 log 10[(14.15/11.45]=205.4 dB
Pt=19 dBW-1 dB= 18 dBW (1 dB below 80 W)
Power budget
Pt= Satellite o/p power 18.0 dBW
Gt= Satellite antenna gain 31.0 dB
Gr= ES antenna gain ? dB
Lp = Free space path loss -205.4 dB
Lant= ES on -3 dB contour of satellite antenna -3.0 dB
Lm= other losses -0.8 dB
Pr= Received power at transponder -160.2 dB
Gr-160.2 dB= -95.2 dB Gr= 46774 or 46.7 dB
D= 2.14 m Gr=ɳe×(πD/λ)2] = 46774 ɳe = 68%
