2011/11/12 福岡のAndroid Make Daysというイベントで使用した資料です。
Android端末と組み込みマイコンがUSB接続で連携するMicrobridge/PICという手段と、それを使用した例についてご紹介しています。
This slide is used for event that named Android Make Days at Fukuoka held on 12 Nov,2011.
About the method that to connect between Android-powered device and embedded microcontrollers by USB with Microbridge/PIC and introduce some examples with it.
These slides include many inappropriate graphs. If you want to tell the summary of the data correctly, you should avoid to use graphs in this presentation. They can mislead those who view them.
In English, the title of presentaion is "24 slides including graphs that should not be absolutely drawn".
Android-controlled robot,Original PCB to work as a bridge between Android-pho...Yasuhiro Ishii
This is a short presentation about me and Kobe branch,Android Japan Group.
For detailed information about the things in this document,please visit our website.
https://sites.google.com/site/androidjpkobe/
Android-controlled robot,Original PCB to work as a bridge between Android-pho...Yasuhiro Ishii
This is a short presentation about me and Kobe branch,Android Japan Group.
For detailed information about the things in this document,please visit our website.
https://sites.google.com/site/androidjpkobe/
These slides include many inappropriate graphs. If you want to tell the summary of the data correctly, you should avoid to use graphs in this presentation. They can mislead those who view them.
In English, the title of presentaion is "24 slides including graphs that should not be absolutely drawn".
Android-controlled robot,Original PCB to work as a bridge between Android-pho...Yasuhiro Ishii
This is a short presentation about me and Kobe branch,Android Japan Group.
For detailed information about the things in this document,please visit our website.
https://sites.google.com/site/androidjpkobe/
Android-controlled robot,Original PCB to work as a bridge between Android-pho...Yasuhiro Ishii
This is a short presentation about me and Kobe branch,Android Japan Group.
For detailed information about the things in this document,please visit our website.
https://sites.google.com/site/androidjpkobe/
This Arduino library provides functions for mapping memory addresses to variables to make it easier to access hardware registers. It defines a MemoryMap class that allows defining variables that correspond directly to memory locations, making it simpler to interface with peripherals. Accessing the mapped variables is equivalent to accessing the underlying memory addresses.
20. PCでのADB forwardとは?
アプリ
Android ソケット通信
アプリ
ADB ADB Server
Daemon
USB IF ADB
USB IF
(Android
Debug
Bridge)
Android端末 外部機器(PC)
Android端末内ソフトと外部とでソケット通信による
データのやりとりが可能
11年11月15日火曜日
21. MicrobridgeでのADB forwardとは?
制御ソフト
Android ソケット通信
アプリ
ADB Microbridge
Daemon
USB IF ADB
USB IF
(Android
Debug
Bridge)
Android端末 外部機器(Microbridge)
Android端末内ソフトと外部とでソケット通信による
データのやりとりが可能
11年11月15日火曜日
34. SL4A(Scripting Layer for Android)
Android端末上で直接スクリプトを
編集し実行できる環境
Python、PHP、Perl、Ruby等の言語が
対応している
11年11月15日火曜日
35. PC + Arduino IDE + Arduino
digitalWrite(0,HIGH);
while (1){
result = digitalRead(1);
for(i=0;i<NUMBER_OF
compress(array_recei
digitalWrite(0,HIGH);
while (1){
result = digitalRead(1);
for(i=0;i<NUMBER_OF
compress(array_recei
11年11月15日火曜日
