1 touchscreen edited
1.
2. Introduction
Evolution Of Touch Screen
Types Of Touch Screen
IPOD Touch Screen
3. A Touchscreen is an electronic visual display that can
detect the presence and location of a touch within the
display area
It is an Input device that allows users to operate a PC by
simply touching the display screen
A touch screen is based on CRT (Cathode Ray Tube)
technology, SAW (Surface Acoustic Wave) technology,
that accepts direct onscreen input.
The ability for direct onscreen input is facilitated by an
external (light pen) or an internal device (touch overlay and
controller) .
4.
5. How Does a Touchscreen Work?
A basic touchscreen has three main components:
Touch Sensor,
Controller
Software Driver.
The touchscreen is an input device, so it needs to be
combined with a display and a PC or other device to
Make a complete touch input system.
6. A touch screen sensor is a clear glass panel
with a touch responsive surface.
The sensor generally has an electrical current
or signal going through it and touching the
screen causes a voltage or signal change.
This voltage change is used to determine the
location of the touch to the screen.
7. The controller is a small PC card that
connects between the touch sensor
and the PC. It takes information from
the touch sensor and translates it into
information that PC can understand.
The controller determines what type of
interface/connection you will need on
the PC.
Controllers are available that can
connect to a Serial/COM port (PC) or
to a USB port (PC or Macintosh).
Specialized controllers are also
available that work with DVD players
and other devices.
8. The driver is a software that allows the touch
screen and computer to work together. It tells
the operating system how to interpret the
touch event information that is sent from the
controller.
Most touch screen drivers today are a mouse-
emulation type driver. This makes touching the
screen the same as clicking your mouse at the
same location on the screen.
This allows the touchscreen to work with
existing software and screen driver.
10. Resistive touch screen monitors are usually
made up of a flexible top layer and a rigid
bottom layer.
The resistive touch screen monitors are very
durable and are not easily contaminated with
items that may interfere with the acoustic
waves. Bottom Resistive Layer .
Insulating Dots .
Glass Substrate
11. A capacitive touch
screen panel is coated
with a material, typically
indium tin oxide that
conducts a continuous
electrical current across
the sensor.
The sensor therefore
exhibits a precisely
controlled field of
stored electrons in both
the horizontal and
vertical axes - it
achieves capacitance.
12. Surface acoustic wave
(SAW) technology uses
ultrasonic waves that pass
over the touch screen
panel.
When the panel is touched,
a portion of the wave is
absorbed. This change in
the ultrasonic waves
registers the position of the
touch event and sends this
information to the controller
for processing.
13. An infrared (IR) touch screen panel employs one of two very
different methods.
One method uses thermal induced changes of the surface
resistance. This method is sometimes slow and requires warm
hands.
Another method is an array of vertical and horizontal IR
sensors that detect the interruption of a modulated light beam
near the surface of the screen.
IR touch screens have the most durable surfaces and are used
in many military applications that require a touch panel display.
14. iPod touch apart from other iPod models -- other than the latest nano -- is its touch-
screen interface. When you touch the screen, the iPod's circuitry detects the presence
of your finger. It keeps track of how many fingers you have on the screen and where
you move them.
15.
16. Top polyester coated with a transparent
metallic conductive coating on the bottom
Adhesive layer on the backside of the glass
for mounting.
Glass layer coated with a transparent
metallic conductive coating on the top
Adhesive spacer
19. A Kiosk ( Pronounced Key-osk) is a computer based terminal or
display that is used to provide information or services typically in
public place kiosk systems
