This document summarizes a research paper that proposes a technique to improve performance in simultaneous multithreaded (SMT) processor cores. The technique partitions a shared write buffer and implements register capping to better manage two critical shared resources: the physical register file and write buffer. Register capping limits the number of physical registers each thread can use. This increases variety in the sources that can commit instructions to the write buffer. The paper proposes partitioning the write buffer to prioritize committing instructions from threads with cache hits. Simulations show the combined approach can improve SMT system performance and resource efficiency by up to 70.6% in a 4-threaded SMT system and 65.9% in an 8-threaded SMT system.
LATENCY-AWARE WRITE BUFFER RESOURCE CONTROL IN MULTITHREADED CORESijmvsc
In a simultaneous multithreaded system, a core’s pipeline resources are sometimes partitioned and
otherwise shared amongst numerous active threads. One mutual resource is the write buffer, which acts as
an intermediary between a store instruction’s retirement from the pipeline and the store value being written
to cache. The write buffer takes a completed store instruction from the load/store queue and eventually
writes the value to the level-one data cache. Once a store is buffered with a write-allocate cache policy, the
store must remain in the write buffer until its cache block is in level-one data cache. This latency may vary
from as little as a single clock cycle (in the case of a level-one cache hit) to several hundred clock cycles
(in the case of a cache miss). This paper shows that cache misses routinely dominate the write buffer’s
resources and deny cache hits from being written to memory, thereby degrading performance of
simultaneous multithreaded systems. This paper proposes a technique to reduce denial of resources to
cache hits by limiting the number of cache misses that may concurrently reside in the write buffer and
shows that system performance can be improved by using this technique.
LATENCY-AWARE WRITE BUFFER RESOURCE CONTROL IN MULTITHREADED CORESijdpsjournal
In a simultaneous multithreaded system, a core’s pipeline resources are sometimes partitioned and
otherwise shared amongst numerous active threads. One mutual resource is the write buffer, which acts as
an intermediary between a store instruction’s retirement from the pipeline and the store value being written
to cache. The write buffer takes a completed store instruction from the load/store queue and eventually
writes the value to the level-one data cache. Once a store is buffered with a write-allocate cache policy, the
store must remain in the write buffer until its cache block is in level-one data cache. This latency may vary
from as little as a single clock cycle (in the case of a level-one cache hit) to several hundred clock cycles
(in the case of a cache miss). This paper shows that cache misses routinely dominate the write buffer’s
resources and deny cache hits from being written to memory, thereby degrading performance of
simultaneous multithreaded systems. This paper proposes a technique to reduce denial of resources to
cache hits by limiting the number of cache misses that may concurrently reside in the write buffer and
shows that system performance can be improved by using this technique.
In a simultaneous multithreaded system, a core’s pipeline resources are sometimes partitioned and otherwise shared amongst numerous active threads. One mutual resource is the write buffer, which acts as an intermediary between a store instruction’s retirement from the pipeline and the store value being written to cache. The write buffer takes a completed store instruction from the load/store queue and eventually writes the value to the level-one data cache. Once a store is buffered with a write-allocate cache policy, the store must remain in the write buffer until its cache block is in level-one data cache. This latency may vary from as little as a single clock cycle (in the case of a level-one cache hit) to several hundred clock cycles (in the case of a cache miss). This paper shows that cache misses routinely dominate the write buffer’s resources and deny cache hits from being written to memory, thereby degrading performance of simultaneous multithreaded systems. This paper proposes a technique to reduce denial of resources to cache hits by limiting the number of cache misses that may concurrently reside in the write buffer and shows that system performance can be improved by using this technique.
Dominant block guided optimal cache size estimation to maximize ipc of embedd...ijesajournal
Embedded system software is highly constrained from performance, memory footprint, energy consumption and implementing cost view point. It is always desirable to obtain better Instructions per Cycle (IPC). Instruction cache has major contribution in improving IPC. Cache memories are realized on the same chip where the processor is running. This considerably increases the system cost as well. Hence, it is required to maintain a trade-off between cache sizes and performance improvement offered. Determining the number of cache lines and size of cache line are important parameters for cache designing. The design space for cache is quite large. It is time taking to execute the given application with different cache sizes on an instruction set simulator (ISS) to figure out the optimal cache size. In this paper, a technique is proposed to identify a number of cache lines and cache line size for the L1 instruction cache that will offer best or nearly best IPC. Cache size is derived, at a higher abstraction level, from basic block analysis in the Low Level Virtual Machine (LLVM) environment. The cache size estimated from the LLVM environment is cross validated by simulating the set of benchmark applications with different cache sizes in SimpleScalar’s out-of-order simulator. The proposed method seems to be superior in terms of estimation accuracy and/or estimation time as compared to the existing methods for estimation of optimal cache size parameters (cache line size, number of cache lines).
Dominant block guided optimal cache size estimation to maximize ipc of embedd...ijesajournal
Embedded system software is highly constrained from performance, memory footprint, energy consumption
and implementing cost view point. It is always desirable to obtain better Instructions per Cycle (IPC).
Instruction cache has major contribu
tion in improving IPC. Cache memories are realized on the same chip
where the processor is running. This considerably increases the system cost as well. Hence, it is required to
maintain a trade
-
off between cache sizes and performance improvement offered.
Determining the number
of cache lines and size of cache line are important parameters for cache designing. The design space for
cache is quite large. It is time taking to execute the given application with different cache sizes on an
instruction set simula
tor (ISS) to figure out the optimal cache size. In this paper, a technique is proposed to
identify a number of cache lines and cache line size for the L1 instruction cache that will offer best or
nearly best IPC. Cache size is derived, at a higher abstract
ion level, from basic block analysis in the Low
Level Virtual Machine (LLVM) environment. The cache size estimated from the LLVM environment is cross
validated by simulating the set of benchmark applications with different cache sizes in SimpleScalar’s out
-
of
-
order simulator. The proposed method seems to be superior in terms of estimation accuracy and/or
estimation time as compared to the existing methods for estimation of optimal cache size parameters (cache
line size, number of cache lines).
DESIGNED DYNAMIC SEGMENTED LRU AND MODIFIED MOESI PROTOCOL FOR RING CONNECTED...Ilango Jeyasubramanian
• Improved speedup by 3.2%, CPI by 7.68% from regular LRU policy by a new Dynamic SLRU policy Implementation on Gem5 simulator.
• Dynamic segmentation of each cache set was done with cache line access probability based LRU insertion policy and performed block replacement by normal SLRU policy.
• Achieved hit-rate improvement by 2.97%, power reduction by 11% with modified Gem5 Ruby memory system by added instructions in the X86 ISA and additional states in the MOESI protocol for coherence in round-robin ordered ring connected filter caches on Intel X86 processor.
PERFORMANCE ENHANCEMENT WITH SPECULATIVE-TRACE CAPPING AT DIFFERENT PIPELINE ...caijjournal
Simultaneous Multi-Threading (SMT) processors improve system performance by allowing concurrent execution of multiple independent threads with sharing key datapath components and better utilization of resources. Speculative execution allows modern processors to fetch continuously and reduce the delays of control instructions. However, a significant amount of resources is usually wasted due to miss-speculation, which could have been used by other valid instructions, and such a waste is even more pronounced in an SMT system. In order to minimize the waste of resources, a speculative trace capping technique [1] was proposed to limit the number of speculative instructions in the system. In this paper, a thorough analysis is given to investigate the trade-offs among applying this capping mechanism at different pipeline stages so as to maximize its benefits. Our simulations show that the best choice can improve overall system throughput by a very significant margin (up to 46%) without sacrificing execution fairness among the threads.
LATENCY-AWARE WRITE BUFFER RESOURCE CONTROL IN MULTITHREADED CORESijmvsc
In a simultaneous multithreaded system, a core’s pipeline resources are sometimes partitioned and
otherwise shared amongst numerous active threads. One mutual resource is the write buffer, which acts as
an intermediary between a store instruction’s retirement from the pipeline and the store value being written
to cache. The write buffer takes a completed store instruction from the load/store queue and eventually
writes the value to the level-one data cache. Once a store is buffered with a write-allocate cache policy, the
store must remain in the write buffer until its cache block is in level-one data cache. This latency may vary
from as little as a single clock cycle (in the case of a level-one cache hit) to several hundred clock cycles
(in the case of a cache miss). This paper shows that cache misses routinely dominate the write buffer’s
resources and deny cache hits from being written to memory, thereby degrading performance of
simultaneous multithreaded systems. This paper proposes a technique to reduce denial of resources to
cache hits by limiting the number of cache misses that may concurrently reside in the write buffer and
shows that system performance can be improved by using this technique.
LATENCY-AWARE WRITE BUFFER RESOURCE CONTROL IN MULTITHREADED CORESijdpsjournal
In a simultaneous multithreaded system, a core’s pipeline resources are sometimes partitioned and
otherwise shared amongst numerous active threads. One mutual resource is the write buffer, which acts as
an intermediary between a store instruction’s retirement from the pipeline and the store value being written
to cache. The write buffer takes a completed store instruction from the load/store queue and eventually
writes the value to the level-one data cache. Once a store is buffered with a write-allocate cache policy, the
store must remain in the write buffer until its cache block is in level-one data cache. This latency may vary
from as little as a single clock cycle (in the case of a level-one cache hit) to several hundred clock cycles
(in the case of a cache miss). This paper shows that cache misses routinely dominate the write buffer’s
resources and deny cache hits from being written to memory, thereby degrading performance of
simultaneous multithreaded systems. This paper proposes a technique to reduce denial of resources to
cache hits by limiting the number of cache misses that may concurrently reside in the write buffer and
shows that system performance can be improved by using this technique.
In a simultaneous multithreaded system, a core’s pipeline resources are sometimes partitioned and otherwise shared amongst numerous active threads. One mutual resource is the write buffer, which acts as an intermediary between a store instruction’s retirement from the pipeline and the store value being written to cache. The write buffer takes a completed store instruction from the load/store queue and eventually writes the value to the level-one data cache. Once a store is buffered with a write-allocate cache policy, the store must remain in the write buffer until its cache block is in level-one data cache. This latency may vary from as little as a single clock cycle (in the case of a level-one cache hit) to several hundred clock cycles (in the case of a cache miss). This paper shows that cache misses routinely dominate the write buffer’s resources and deny cache hits from being written to memory, thereby degrading performance of simultaneous multithreaded systems. This paper proposes a technique to reduce denial of resources to cache hits by limiting the number of cache misses that may concurrently reside in the write buffer and shows that system performance can be improved by using this technique.
Dominant block guided optimal cache size estimation to maximize ipc of embedd...ijesajournal
Embedded system software is highly constrained from performance, memory footprint, energy consumption and implementing cost view point. It is always desirable to obtain better Instructions per Cycle (IPC). Instruction cache has major contribution in improving IPC. Cache memories are realized on the same chip where the processor is running. This considerably increases the system cost as well. Hence, it is required to maintain a trade-off between cache sizes and performance improvement offered. Determining the number of cache lines and size of cache line are important parameters for cache designing. The design space for cache is quite large. It is time taking to execute the given application with different cache sizes on an instruction set simulator (ISS) to figure out the optimal cache size. In this paper, a technique is proposed to identify a number of cache lines and cache line size for the L1 instruction cache that will offer best or nearly best IPC. Cache size is derived, at a higher abstraction level, from basic block analysis in the Low Level Virtual Machine (LLVM) environment. The cache size estimated from the LLVM environment is cross validated by simulating the set of benchmark applications with different cache sizes in SimpleScalar’s out-of-order simulator. The proposed method seems to be superior in terms of estimation accuracy and/or estimation time as compared to the existing methods for estimation of optimal cache size parameters (cache line size, number of cache lines).
Dominant block guided optimal cache size estimation to maximize ipc of embedd...ijesajournal
Embedded system software is highly constrained from performance, memory footprint, energy consumption
and implementing cost view point. It is always desirable to obtain better Instructions per Cycle (IPC).
Instruction cache has major contribu
tion in improving IPC. Cache memories are realized on the same chip
where the processor is running. This considerably increases the system cost as well. Hence, it is required to
maintain a trade
-
off between cache sizes and performance improvement offered.
Determining the number
of cache lines and size of cache line are important parameters for cache designing. The design space for
cache is quite large. It is time taking to execute the given application with different cache sizes on an
instruction set simula
tor (ISS) to figure out the optimal cache size. In this paper, a technique is proposed to
identify a number of cache lines and cache line size for the L1 instruction cache that will offer best or
nearly best IPC. Cache size is derived, at a higher abstract
ion level, from basic block analysis in the Low
Level Virtual Machine (LLVM) environment. The cache size estimated from the LLVM environment is cross
validated by simulating the set of benchmark applications with different cache sizes in SimpleScalar’s out
-
of
-
order simulator. The proposed method seems to be superior in terms of estimation accuracy and/or
estimation time as compared to the existing methods for estimation of optimal cache size parameters (cache
line size, number of cache lines).
DESIGNED DYNAMIC SEGMENTED LRU AND MODIFIED MOESI PROTOCOL FOR RING CONNECTED...Ilango Jeyasubramanian
• Improved speedup by 3.2%, CPI by 7.68% from regular LRU policy by a new Dynamic SLRU policy Implementation on Gem5 simulator.
• Dynamic segmentation of each cache set was done with cache line access probability based LRU insertion policy and performed block replacement by normal SLRU policy.
• Achieved hit-rate improvement by 2.97%, power reduction by 11% with modified Gem5 Ruby memory system by added instructions in the X86 ISA and additional states in the MOESI protocol for coherence in round-robin ordered ring connected filter caches on Intel X86 processor.
PERFORMANCE ENHANCEMENT WITH SPECULATIVE-TRACE CAPPING AT DIFFERENT PIPELINE ...caijjournal
Simultaneous Multi-Threading (SMT) processors improve system performance by allowing concurrent execution of multiple independent threads with sharing key datapath components and better utilization of resources. Speculative execution allows modern processors to fetch continuously and reduce the delays of control instructions. However, a significant amount of resources is usually wasted due to miss-speculation, which could have been used by other valid instructions, and such a waste is even more pronounced in an SMT system. In order to minimize the waste of resources, a speculative trace capping technique [1] was proposed to limit the number of speculative instructions in the system. In this paper, a thorough analysis is given to investigate the trade-offs among applying this capping mechanism at different pipeline stages so as to maximize its benefits. Our simulations show that the best choice can improve overall system throughput by a very significant margin (up to 46%) without sacrificing execution fairness among the threads.
Computer Applications: An International Journal (CAIJ)caijjournal
Computer Applications: An International Journal (CAIJ) is a Quarterly open access peer-reviewed journal that publishes articles which contribute new results in all areas of the Computer Science Applications. The journal is devoted to the publication of high quality papers on theoretical and practical aspects of computer science applications. The goal of this journal is to bring together researchers and practitioners from academia and industry to focus on Computer science application advancements, and establishing new collaborations in these areas. Original research papers, state-of-the-art reviews are invited for publication in all areas of Computer Science Applications.
Authors are solicited to contribute to the journal by submitting articles that illustrate research results, projects, surveying works and industrial experiences that describe significant advances in the areas of Computer Science Applications.
PERFORMANCE ENHANCEMENT WITH SPECULATIVE-TRACE CAPPING AT DIFFERENT PIPELINE ...caijjournal
Simultaneous Multi-Threading (SMT) processors improve system performance by allowing concurrent execution of multiple independent threads with sharing key datapath omponents and better utilization of resources. Speculative execution allows modern processors to fetch continuously and reduce the delays of control instructions. However, a significant amount of resources is usually wasted due to miss- peculation,
which could have been used by other valid instructions, and such a waste is even more pronounced in an SMT system. In order to minimize the waste of resources, a speculative trace capping technique [1] was proposed to limit the number of speculative instructions in the system. In this paper, a thorough analysis is given to investigate the trade-offs among applying this capping mechanism at different pipeline stages so as
to maximize its benefits. Our simulations show that the best choice can improve overall system throughput
by a very significant margin (up to 46%) without sacrificing execution fairness among the threads.
STUDY OF VARIOUS FACTORS AFFECTING PERFORMANCE OF MULTI-CORE PROCESSORSijdpsjournal
Advances in Integrated Circuit processing allow for more microprocessor design options. As Chip Multiprocessor system (CMP) become the predominant topology for leading microprocessors, critical components of the system are now integrated on a single chip. This enables sharing of computation resources that was not previously possible. In addition the virtualization of these computation resources exposes the system to a mix of diverse and competing workloads. On chip Cache memory is a resource of primary concern as it can be dominant in controlling overall throughput. This Paper presents analysis of various parameters affecting the performance of Multi-core Architectures like varying the number of cores, changes L2 cache size, further we have varied directory size from 64 to 2048 entries on a 4 node, 8 node 16 node and 64 node Chip multiprocessor which in turn presents an open area of research on multicore processors with private/shared last level cache as the future trend seems to be towards tiled architecture executing multiple parallel applications with optimized silicon area utilization and excellent performance.
IRJET-A Review on Trends in Multicore Processor Based on Cache and Power Diss...IRJET Journal
K.Aruli, B.Nivetha, G.N.Jayabhavani, M.Saravanan "A Review on Trends in Multicore Processor Based on Cache and Power Dissipation", International Research Journal of Engineering and Technology (IRJET), Volume2,issue-01 April 2015.e-ISSN:2395-0056, p-ISSN:2395-0072. www.irjet.net
Abstract
A multi-core processor is an integrated circuit to which two or more processors attached for enhanced performance, reduced power consumption, and more efficient simultaneous processing of multiple tasks. Multi-core processing is a growing industrial trend as single core processors rapidly reach the physical limits of complexity and speed. It exploits increased feature-size and density. It increases functional units per chip and limit energy consumption per operation. This paper provides the review of various papers in multicore architecture, discussing various parameters like number of cores, cache coherence and power dissipation.
The processor-memory bandwidth in modern generation
processors is the important bottleneck due to a number of
processor cores dealing it through with the same bus/ processor-
memory interface. Caches take a significant amount
of energy in current microprocessors. To design an energyefficient
microprocessor, it is important to optimize cache
energy economic consumption. Powerful utilization of this
resource is consequently an important view of memory hierarchy
design of multi core processors. This is presently an
important field of research on a large number of research
issues that have suggested a number of techniques to figure
out the problem. The better contribution of this theme is the
assessment of effectiveness of some of the proficiencies that
were enforced in recent chip multiprocessors. Cache optimization
techniques that were named for single core processors
but have not been implemented in multi core processors
are as well tested to forecast their effectiveness.
International Journal of Engineering Research and Development (IJERD)IJERD Editor
journal publishing, how to publish research paper, Call For research paper, international journal, publishing a paper, IJERD, journal of science and technology, how to get a research paper published, publishing a paper, publishing of journal, publishing of research paper, reserach and review articles, IJERD Journal, How to publish your research paper, publish research paper, open access engineering journal, Engineering journal, Mathemetics journal, Physics journal, Chemistry journal, Computer Engineering, Computer Science journal, how to submit your paper, peer reviw journal, indexed journal, reserach and review articles, engineering journal, www.ijerd.com, research journals,
yahoo journals, bing journals, International Journal of Engineering Research and Development, google journals, hard copy of journal
Abstract— Cloud storage is usually distributed infrastructure, where data is not stored in a single device but is spread to several storage nodes which are located in different areas. To ensure data availability some amount of redundancy has to be maintained. But introduction of data redundancy leads to additional costs such as extra storage space and communication bandwidth which required for restoring data blocks. In the existing system, the storage infrastructure is considered as homogeneous where all nodes in the system have same online availability which leads to efficiency losses. The proposed system considers that distributed storage system is heterogeneous where each node exhibit different online availability. Monte Carlo Sampling is used to measure the online availability of storage nodes. The parallel version of Particle Swarm Optimization is used to assign redundant data blocks according to their online availability. The optimal data assignment policy reduces the redundancy and their associated cost.
An octa core processor with shared memory and message-passingeSAT Journals
Abstract This being the era of fast, high performance computing, there is the need of having efficient optimizations in the processor architecture and at the same time in memory hierarchy too. Each and every day, the advancement of applications in communication and multimedia systems are compelling to increase number of cores in the main processor viz., dual-core, quad-core, octa-core and so on. But, for enhancing the overall performance of multi processor chip, there are stringent requirements to improve inter-core synchronization. Thus, a MPSoC with 8-cores supporting both message-passing and shared-memory inter-core communication mechanisms is implemented on Virtex 5 LX110T FPGA. Each core is based on MIPS III (Microprocessor without interlocked pipelined stages) ISA, handling only integer type instructions and having six-stage pipeline with data hazard detection unit and forwarding logic. The eight processing cores and one central shared memory core are inter connected using 3x3 2-D mesh topology based Network-on-chip (NoC) with virtual channel router. The router is four stage pipelined supporting DOR X-Y routing algorithm and with round robin arbitration technique. For verification and functionality test of above fully synthesized multi core processor, matrix multiplication operation is mapped onto the above said. Partitioning and scheduling of multiple multiplications and addition for each element of resultant matrix has been done accordingly among eight cores to get maximum throughput. All the codes for processor design are written in Verilog HDL. Keywords: MPSoC, message-passing, shared memory, MIPS, ISA, wormhole router, network-on-chip, SIMD, data level parallelism, 2-D Mesh, virtual channel
Design of storage benchmark kit framework for supporting the file storage ret...IJECEIAES
An open-source software framework called the storage benchmark kit (SBK) is used to store the system benchmarking performance framework. The SBK is designed to perform any storage client or device using any data type as a payload. SBK simultaneously helps number of readers as well as writes to the storage system of large amounts of data as well as allows end-to-end latency benchmarking for multiple writers and readers. The SBK uses standardized performance measures for comparing and evaluating various storage systems and their combinations. Distributed file systems, distributed database systems, single or local node databases, systems of object storage, platforms of distributed streaming and messaging, and systems of key-value storage are the storage solutions supported by SBK. The SBK supports various storage systems like XFS, Kafka streaming storage systems, and Hadoop distributed file system (HDFS) performance benchmarking. The experimental results show that a proposed method achieves execution time of 65.530 s, 40.826 s and 30.351 s for the 100k, 500k and 1000k files respectively which ensures better improvement than the existing methods such as simple data interface and distributed data protection system.
A Framework for Design of Partially Replicated Distributed Database Systems w...ijdms
For partially replicated distributed database systems to function efficiently, the data (relations) and operations (subquery) of the database need to be located, judiciously at various sites across the relevant communications network.The problem of allocating relations and operations to the most appropriate sites is a difficult one to solve so that genetic algorithms based on migration are proposed in this research. In partially replicated distributed database systems, the minimization of total time usually attempts to minimize resource consumption and therefore to maximize the system throughput. On the other hand, the minimization of response time may be obtained by having a large number of parallel executions to different
sites, requiring a higher resource consumption, which means that the system throughput is reduced. Workload balancing implies the reduction of the average time that queries spend waiting for CPU and I/O service at a network site, but its effect on the performance of partially replicated distributed database
systems cannot be isolated from other distributed database design factors. In this research, the total cost refers to the combination of total time and response time. This paper presents a framework for total cost minimization and workload balancing for partially replicated distributed database systems considering important database design objectives together. The framework incorporates both local processing, including CPU and I/O, and communication costs. To illustrate its suitability, experiments are conducted, and results demonstrate that the proposed framework provides effective partially replicated distributed database design.
International Journal of Engineering and Science Invention (IJESI)inventionjournals
International Journal of Engineering and Science Invention (IJESI) is an international journal intended for professionals and researchers in all fields of computer science and electronics. IJESI publishes research articles and reviews within the whole field Engineering Science and Technology, new teaching methods, assessment, validation and the impact of new technologies and it will continue to provide information on the latest trends and developments in this ever-expanding subject. The publications of papers are selected through double peer reviewed to ensure originality, relevance, and readability. The articles published in our journal can be accessed online.
Architecture and implementation issues of multi core processors and caching –...eSAT Publishing House
IJRET : International Journal of Research in Engineering and Technology is an international peer reviewed, online journal published by eSAT Publishing House for the enhancement of research in various disciplines of Engineering and Technology. The aim and scope of the journal is to provide an academic medium and an important reference for the advancement and dissemination of research results that support high-level learning, teaching and research in the fields of Engineering and Technology. We bring together Scientists, Academician, Field Engineers, Scholars and Students of related fields of Engineering and Technology
Hardback solution to accelerate multimedia computation through mgp in cmpeSAT Publishing House
IJRET : International Journal of Research in Engineering and Technology is an international peer reviewed, online journal published by eSAT Publishing House for the enhancement of research in various disciplines of Engineering and Technology. The aim and scope of the journal is to provide an academic medium and an important reference for the advancement and dissemination of research results that support high-level learning, teaching and research in the fields of Engineering and Technology. We bring together Scientists, Academician, Field Engineers, Scholars and Students of related fields of Engineering and Technology
Vaccine management system project report documentation..pdfKamal Acharya
The Division of Vaccine and Immunization is facing increasing difficulty monitoring vaccines and other commodities distribution once they have been distributed from the national stores. With the introduction of new vaccines, more challenges have been anticipated with this additions posing serious threat to the already over strained vaccine supply chain system in Kenya.
More Related Content
Similar to WRITE BUFFER PARTITIONING WITH RENAME REGISTER CAPPING IN MULTITHREADED CORES
Computer Applications: An International Journal (CAIJ)caijjournal
Computer Applications: An International Journal (CAIJ) is a Quarterly open access peer-reviewed journal that publishes articles which contribute new results in all areas of the Computer Science Applications. The journal is devoted to the publication of high quality papers on theoretical and practical aspects of computer science applications. The goal of this journal is to bring together researchers and practitioners from academia and industry to focus on Computer science application advancements, and establishing new collaborations in these areas. Original research papers, state-of-the-art reviews are invited for publication in all areas of Computer Science Applications.
Authors are solicited to contribute to the journal by submitting articles that illustrate research results, projects, surveying works and industrial experiences that describe significant advances in the areas of Computer Science Applications.
PERFORMANCE ENHANCEMENT WITH SPECULATIVE-TRACE CAPPING AT DIFFERENT PIPELINE ...caijjournal
Simultaneous Multi-Threading (SMT) processors improve system performance by allowing concurrent execution of multiple independent threads with sharing key datapath omponents and better utilization of resources. Speculative execution allows modern processors to fetch continuously and reduce the delays of control instructions. However, a significant amount of resources is usually wasted due to miss- peculation,
which could have been used by other valid instructions, and such a waste is even more pronounced in an SMT system. In order to minimize the waste of resources, a speculative trace capping technique [1] was proposed to limit the number of speculative instructions in the system. In this paper, a thorough analysis is given to investigate the trade-offs among applying this capping mechanism at different pipeline stages so as
to maximize its benefits. Our simulations show that the best choice can improve overall system throughput
by a very significant margin (up to 46%) without sacrificing execution fairness among the threads.
STUDY OF VARIOUS FACTORS AFFECTING PERFORMANCE OF MULTI-CORE PROCESSORSijdpsjournal
Advances in Integrated Circuit processing allow for more microprocessor design options. As Chip Multiprocessor system (CMP) become the predominant topology for leading microprocessors, critical components of the system are now integrated on a single chip. This enables sharing of computation resources that was not previously possible. In addition the virtualization of these computation resources exposes the system to a mix of diverse and competing workloads. On chip Cache memory is a resource of primary concern as it can be dominant in controlling overall throughput. This Paper presents analysis of various parameters affecting the performance of Multi-core Architectures like varying the number of cores, changes L2 cache size, further we have varied directory size from 64 to 2048 entries on a 4 node, 8 node 16 node and 64 node Chip multiprocessor which in turn presents an open area of research on multicore processors with private/shared last level cache as the future trend seems to be towards tiled architecture executing multiple parallel applications with optimized silicon area utilization and excellent performance.
IRJET-A Review on Trends in Multicore Processor Based on Cache and Power Diss...IRJET Journal
K.Aruli, B.Nivetha, G.N.Jayabhavani, M.Saravanan "A Review on Trends in Multicore Processor Based on Cache and Power Dissipation", International Research Journal of Engineering and Technology (IRJET), Volume2,issue-01 April 2015.e-ISSN:2395-0056, p-ISSN:2395-0072. www.irjet.net
Abstract
A multi-core processor is an integrated circuit to which two or more processors attached for enhanced performance, reduced power consumption, and more efficient simultaneous processing of multiple tasks. Multi-core processing is a growing industrial trend as single core processors rapidly reach the physical limits of complexity and speed. It exploits increased feature-size and density. It increases functional units per chip and limit energy consumption per operation. This paper provides the review of various papers in multicore architecture, discussing various parameters like number of cores, cache coherence and power dissipation.
The processor-memory bandwidth in modern generation
processors is the important bottleneck due to a number of
processor cores dealing it through with the same bus/ processor-
memory interface. Caches take a significant amount
of energy in current microprocessors. To design an energyefficient
microprocessor, it is important to optimize cache
energy economic consumption. Powerful utilization of this
resource is consequently an important view of memory hierarchy
design of multi core processors. This is presently an
important field of research on a large number of research
issues that have suggested a number of techniques to figure
out the problem. The better contribution of this theme is the
assessment of effectiveness of some of the proficiencies that
were enforced in recent chip multiprocessors. Cache optimization
techniques that were named for single core processors
but have not been implemented in multi core processors
are as well tested to forecast their effectiveness.
International Journal of Engineering Research and Development (IJERD)IJERD Editor
journal publishing, how to publish research paper, Call For research paper, international journal, publishing a paper, IJERD, journal of science and technology, how to get a research paper published, publishing a paper, publishing of journal, publishing of research paper, reserach and review articles, IJERD Journal, How to publish your research paper, publish research paper, open access engineering journal, Engineering journal, Mathemetics journal, Physics journal, Chemistry journal, Computer Engineering, Computer Science journal, how to submit your paper, peer reviw journal, indexed journal, reserach and review articles, engineering journal, www.ijerd.com, research journals,
yahoo journals, bing journals, International Journal of Engineering Research and Development, google journals, hard copy of journal
Abstract— Cloud storage is usually distributed infrastructure, where data is not stored in a single device but is spread to several storage nodes which are located in different areas. To ensure data availability some amount of redundancy has to be maintained. But introduction of data redundancy leads to additional costs such as extra storage space and communication bandwidth which required for restoring data blocks. In the existing system, the storage infrastructure is considered as homogeneous where all nodes in the system have same online availability which leads to efficiency losses. The proposed system considers that distributed storage system is heterogeneous where each node exhibit different online availability. Monte Carlo Sampling is used to measure the online availability of storage nodes. The parallel version of Particle Swarm Optimization is used to assign redundant data blocks according to their online availability. The optimal data assignment policy reduces the redundancy and their associated cost.
An octa core processor with shared memory and message-passingeSAT Journals
Abstract This being the era of fast, high performance computing, there is the need of having efficient optimizations in the processor architecture and at the same time in memory hierarchy too. Each and every day, the advancement of applications in communication and multimedia systems are compelling to increase number of cores in the main processor viz., dual-core, quad-core, octa-core and so on. But, for enhancing the overall performance of multi processor chip, there are stringent requirements to improve inter-core synchronization. Thus, a MPSoC with 8-cores supporting both message-passing and shared-memory inter-core communication mechanisms is implemented on Virtex 5 LX110T FPGA. Each core is based on MIPS III (Microprocessor without interlocked pipelined stages) ISA, handling only integer type instructions and having six-stage pipeline with data hazard detection unit and forwarding logic. The eight processing cores and one central shared memory core are inter connected using 3x3 2-D mesh topology based Network-on-chip (NoC) with virtual channel router. The router is four stage pipelined supporting DOR X-Y routing algorithm and with round robin arbitration technique. For verification and functionality test of above fully synthesized multi core processor, matrix multiplication operation is mapped onto the above said. Partitioning and scheduling of multiple multiplications and addition for each element of resultant matrix has been done accordingly among eight cores to get maximum throughput. All the codes for processor design are written in Verilog HDL. Keywords: MPSoC, message-passing, shared memory, MIPS, ISA, wormhole router, network-on-chip, SIMD, data level parallelism, 2-D Mesh, virtual channel
Design of storage benchmark kit framework for supporting the file storage ret...IJECEIAES
An open-source software framework called the storage benchmark kit (SBK) is used to store the system benchmarking performance framework. The SBK is designed to perform any storage client or device using any data type as a payload. SBK simultaneously helps number of readers as well as writes to the storage system of large amounts of data as well as allows end-to-end latency benchmarking for multiple writers and readers. The SBK uses standardized performance measures for comparing and evaluating various storage systems and their combinations. Distributed file systems, distributed database systems, single or local node databases, systems of object storage, platforms of distributed streaming and messaging, and systems of key-value storage are the storage solutions supported by SBK. The SBK supports various storage systems like XFS, Kafka streaming storage systems, and Hadoop distributed file system (HDFS) performance benchmarking. The experimental results show that a proposed method achieves execution time of 65.530 s, 40.826 s and 30.351 s for the 100k, 500k and 1000k files respectively which ensures better improvement than the existing methods such as simple data interface and distributed data protection system.
A Framework for Design of Partially Replicated Distributed Database Systems w...ijdms
For partially replicated distributed database systems to function efficiently, the data (relations) and operations (subquery) of the database need to be located, judiciously at various sites across the relevant communications network.The problem of allocating relations and operations to the most appropriate sites is a difficult one to solve so that genetic algorithms based on migration are proposed in this research. In partially replicated distributed database systems, the minimization of total time usually attempts to minimize resource consumption and therefore to maximize the system throughput. On the other hand, the minimization of response time may be obtained by having a large number of parallel executions to different
sites, requiring a higher resource consumption, which means that the system throughput is reduced. Workload balancing implies the reduction of the average time that queries spend waiting for CPU and I/O service at a network site, but its effect on the performance of partially replicated distributed database
systems cannot be isolated from other distributed database design factors. In this research, the total cost refers to the combination of total time and response time. This paper presents a framework for total cost minimization and workload balancing for partially replicated distributed database systems considering important database design objectives together. The framework incorporates both local processing, including CPU and I/O, and communication costs. To illustrate its suitability, experiments are conducted, and results demonstrate that the proposed framework provides effective partially replicated distributed database design.
International Journal of Engineering and Science Invention (IJESI)inventionjournals
International Journal of Engineering and Science Invention (IJESI) is an international journal intended for professionals and researchers in all fields of computer science and electronics. IJESI publishes research articles and reviews within the whole field Engineering Science and Technology, new teaching methods, assessment, validation and the impact of new technologies and it will continue to provide information on the latest trends and developments in this ever-expanding subject. The publications of papers are selected through double peer reviewed to ensure originality, relevance, and readability. The articles published in our journal can be accessed online.
Architecture and implementation issues of multi core processors and caching –...eSAT Publishing House
IJRET : International Journal of Research in Engineering and Technology is an international peer reviewed, online journal published by eSAT Publishing House for the enhancement of research in various disciplines of Engineering and Technology. The aim and scope of the journal is to provide an academic medium and an important reference for the advancement and dissemination of research results that support high-level learning, teaching and research in the fields of Engineering and Technology. We bring together Scientists, Academician, Field Engineers, Scholars and Students of related fields of Engineering and Technology
Hardback solution to accelerate multimedia computation through mgp in cmpeSAT Publishing House
IJRET : International Journal of Research in Engineering and Technology is an international peer reviewed, online journal published by eSAT Publishing House for the enhancement of research in various disciplines of Engineering and Technology. The aim and scope of the journal is to provide an academic medium and an important reference for the advancement and dissemination of research results that support high-level learning, teaching and research in the fields of Engineering and Technology. We bring together Scientists, Academician, Field Engineers, Scholars and Students of related fields of Engineering and Technology
Similar to WRITE BUFFER PARTITIONING WITH RENAME REGISTER CAPPING IN MULTITHREADED CORES (20)
Vaccine management system project report documentation..pdfKamal Acharya
The Division of Vaccine and Immunization is facing increasing difficulty monitoring vaccines and other commodities distribution once they have been distributed from the national stores. With the introduction of new vaccines, more challenges have been anticipated with this additions posing serious threat to the already over strained vaccine supply chain system in Kenya.
NO1 Uk best vashikaran specialist in delhi vashikaran baba near me online vas...Amil Baba Dawood bangali
Contact with Dawood Bhai Just call on +92322-6382012 and we'll help you. We'll solve all your problems within 12 to 24 hours and with 101% guarantee and with astrology systematic. If you want to take any personal or professional advice then also you can call us on +92322-6382012 , ONLINE LOVE PROBLEM & Other all types of Daily Life Problem's.Then CALL or WHATSAPP us on +92322-6382012 and Get all these problems solutions here by Amil Baba DAWOOD BANGALI
#vashikaranspecialist #astrologer #palmistry #amliyaat #taweez #manpasandshadi #horoscope #spiritual #lovelife #lovespell #marriagespell#aamilbabainpakistan #amilbabainkarachi #powerfullblackmagicspell #kalajadumantarspecialist #realamilbaba #AmilbabainPakistan #astrologerincanada #astrologerindubai #lovespellsmaster #kalajaduspecialist #lovespellsthatwork #aamilbabainlahore#blackmagicformarriage #aamilbaba #kalajadu #kalailam #taweez #wazifaexpert #jadumantar #vashikaranspecialist #astrologer #palmistry #amliyaat #taweez #manpasandshadi #horoscope #spiritual #lovelife #lovespell #marriagespell#aamilbabainpakistan #amilbabainkarachi #powerfullblackmagicspell #kalajadumantarspecialist #realamilbaba #AmilbabainPakistan #astrologerincanada #astrologerindubai #lovespellsmaster #kalajaduspecialist #lovespellsthatwork #aamilbabainlahore #blackmagicforlove #blackmagicformarriage #aamilbaba #kalajadu #kalailam #taweez #wazifaexpert #jadumantar #vashikaranspecialist #astrologer #palmistry #amliyaat #taweez #manpasandshadi #horoscope #spiritual #lovelife #lovespell #marriagespell#aamilbabainpakistan #amilbabainkarachi #powerfullblackmagicspell #kalajadumantarspecialist #realamilbaba #AmilbabainPakistan #astrologerincanada #astrologerindubai #lovespellsmaster #kalajaduspecialist #lovespellsthatwork #aamilbabainlahore #Amilbabainuk #amilbabainspain #amilbabaindubai #Amilbabainnorway #amilbabainkrachi #amilbabainlahore #amilbabaingujranwalan #amilbabainislamabad
Water scarcity is the lack of fresh water resources to meet the standard water demand. There are two type of water scarcity. One is physical. The other is economic water scarcity.
Democratizing Fuzzing at Scale by Abhishek Aryaabh.arya
Presented at NUS: Fuzzing and Software Security Summer School 2024
This keynote talks about the democratization of fuzzing at scale, highlighting the collaboration between open source communities, academia, and industry to advance the field of fuzzing. It delves into the history of fuzzing, the development of scalable fuzzing platforms, and the empowerment of community-driven research. The talk will further discuss recent advancements leveraging AI/ML and offer insights into the future evolution of the fuzzing landscape.
COLLEGE BUS MANAGEMENT SYSTEM PROJECT REPORT.pdfKamal Acharya
The College Bus Management system is completely developed by Visual Basic .NET Version. The application is connect with most secured database language MS SQL Server. The application is develop by using best combination of front-end and back-end languages. The application is totally design like flat user interface. This flat user interface is more attractive user interface in 2017. The application is gives more important to the system functionality. The application is to manage the student’s details, driver’s details, bus details, bus route details, bus fees details and more. The application has only one unit for admin. The admin can manage the entire application. The admin can login into the application by using username and password of the admin. The application is develop for big and small colleges. It is more user friendly for non-computer person. Even they can easily learn how to manage the application within hours. The application is more secure by the admin. The system will give an effective output for the VB.Net and SQL Server given as input to the system. The compiled java program given as input to the system, after scanning the program will generate different reports. The application generates the report for users. The admin can view and download the report of the data. The application deliver the excel format reports. Because, excel formatted reports is very easy to understand the income and expense of the college bus. This application is mainly develop for windows operating system users. In 2017, 73% of people enterprises are using windows operating system. So the application will easily install for all the windows operating system users. The application-developed size is very low. The application consumes very low space in disk. Therefore, the user can allocate very minimum local disk space for this application.
Courier management system project report.pdfKamal Acharya
It is now-a-days very important for the people to send or receive articles like imported furniture, electronic items, gifts, business goods and the like. People depend vastly on different transport systems which mostly use the manual way of receiving and delivering the articles. There is no way to track the articles till they are received and there is no way to let the customer know what happened in transit, once he booked some articles. In such a situation, we need a system which completely computerizes the cargo activities including time to time tracking of the articles sent. This need is fulfilled by Courier Management System software which is online software for the cargo management people that enables them to receive the goods from a source and send them to a required destination and track their status from time to time.
Student information management system project report ii.pdfKamal Acharya
Our project explains about the student management. This project mainly explains the various actions related to student details. This project shows some ease in adding, editing and deleting the student details. It also provides a less time consuming process for viewing, adding, editing and deleting the marks of the students.
About
Indigenized remote control interface card suitable for MAFI system CCR equipment. Compatible for IDM8000 CCR. Backplane mounted serial and TCP/Ethernet communication module for CCR remote access. IDM 8000 CCR remote control on serial and TCP protocol.
• Remote control: Parallel or serial interface.
• Compatible with MAFI CCR system.
• Compatible with IDM8000 CCR.
• Compatible with Backplane mount serial communication.
• Compatible with commercial and Defence aviation CCR system.
• Remote control system for accessing CCR and allied system over serial or TCP.
• Indigenized local Support/presence in India.
• Easy in configuration using DIP switches.
Technical Specifications
Indigenized remote control interface card suitable for MAFI system CCR equipment. Compatible for IDM8000 CCR. Backplane mounted serial and TCP/Ethernet communication module for CCR remote access. IDM 8000 CCR remote control on serial and TCP protocol.
Key Features
Indigenized remote control interface card suitable for MAFI system CCR equipment. Compatible for IDM8000 CCR. Backplane mounted serial and TCP/Ethernet communication module for CCR remote access. IDM 8000 CCR remote control on serial and TCP protocol.
• Remote control: Parallel or serial interface
• Compatible with MAFI CCR system
• Copatiable with IDM8000 CCR
• Compatible with Backplane mount serial communication.
• Compatible with commercial and Defence aviation CCR system.
• Remote control system for accessing CCR and allied system over serial or TCP.
• Indigenized local Support/presence in India.
Application
• Remote control: Parallel or serial interface.
• Compatible with MAFI CCR system.
• Compatible with IDM8000 CCR.
• Compatible with Backplane mount serial communication.
• Compatible with commercial and Defence aviation CCR system.
• Remote control system for accessing CCR and allied system over serial or TCP.
• Indigenized local Support/presence in India.
• Easy in configuration using DIP switches.
Hybrid optimization of pumped hydro system and solar- Engr. Abdul-Azeez.pdffxintegritypublishin
Advancements in technology unveil a myriad of electrical and electronic breakthroughs geared towards efficiently harnessing limited resources to meet human energy demands. The optimization of hybrid solar PV panels and pumped hydro energy supply systems plays a pivotal role in utilizing natural resources effectively. This initiative not only benefits humanity but also fosters environmental sustainability. The study investigated the design optimization of these hybrid systems, focusing on understanding solar radiation patterns, identifying geographical influences on solar radiation, formulating a mathematical model for system optimization, and determining the optimal configuration of PV panels and pumped hydro storage. Through a comparative analysis approach and eight weeks of data collection, the study addressed key research questions related to solar radiation patterns and optimal system design. The findings highlighted regions with heightened solar radiation levels, showcasing substantial potential for power generation and emphasizing the system's efficiency. Optimizing system design significantly boosted power generation, promoted renewable energy utilization, and enhanced energy storage capacity. The study underscored the benefits of optimizing hybrid solar PV panels and pumped hydro energy supply systems for sustainable energy usage. Optimizing the design of solar PV panels and pumped hydro energy supply systems as examined across diverse climatic conditions in a developing country, not only enhances power generation but also improves the integration of renewable energy sources and boosts energy storage capacities, particularly beneficial for less economically prosperous regions. Additionally, the study provides valuable insights for advancing energy research in economically viable areas. Recommendations included conducting site-specific assessments, utilizing advanced modeling tools, implementing regular maintenance protocols, and enhancing communication among system components.
Immunizing Image Classifiers Against Localized Adversary Attacksgerogepatton
This paper addresses the vulnerability of deep learning models, particularly convolutional neural networks
(CNN)s, to adversarial attacks and presents a proactive training technique designed to counter them. We
introduce a novel volumization algorithm, which transforms 2D images into 3D volumetric representations.
When combined with 3D convolution and deep curriculum learning optimization (CLO), itsignificantly improves
the immunity of models against localized universal attacks by up to 40%. We evaluate our proposed approach
using contemporary CNN architectures and the modified Canadian Institute for Advanced Research (CIFAR-10
and CIFAR-100) and ImageNet Large Scale Visual Recognition Challenge (ILSVRC12) datasets, showcasing
accuracy improvements over previous techniques. The results indicate that the combination of the volumetric
input and curriculum learning holds significant promise for mitigating adversarial attacks without necessitating
adversary training.
CFD Simulation of By-pass Flow in a HRSG module by R&R Consult.pptxR&R Consult
CFD analysis is incredibly effective at solving mysteries and improving the performance of complex systems!
Here's a great example: At a large natural gas-fired power plant, where they use waste heat to generate steam and energy, they were puzzled that their boiler wasn't producing as much steam as expected.
R&R and Tetra Engineering Group Inc. were asked to solve the issue with reduced steam production.
An inspection had shown that a significant amount of hot flue gas was bypassing the boiler tubes, where the heat was supposed to be transferred.
R&R Consult conducted a CFD analysis, which revealed that 6.3% of the flue gas was bypassing the boiler tubes without transferring heat. The analysis also showed that the flue gas was instead being directed along the sides of the boiler and between the modules that were supposed to capture the heat. This was the cause of the reduced performance.
Based on our results, Tetra Engineering installed covering plates to reduce the bypass flow. This improved the boiler's performance and increased electricity production.
It is always satisfying when we can help solve complex challenges like this. Do your systems also need a check-up or optimization? Give us a call!
Work done in cooperation with James Malloy and David Moelling from Tetra Engineering.
More examples of our work https://www.r-r-consult.dk/en/cases-en/
Industrial Training at Shahjalal Fertilizer Company Limited (SFCL)MdTanvirMahtab2
This presentation is about the working procedure of Shahjalal Fertilizer Company Limited (SFCL). A Govt. owned Company of Bangladesh Chemical Industries Corporation under Ministry of Industries.
WRITE BUFFER PARTITIONING WITH RENAME REGISTER CAPPING IN MULTITHREADED CORES
1. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
DOI: 10.5121/ijdps.2023.14603 33
WRITE BUFFER PARTITIONING WITH RENAME
REGISTER CAPPING IN MULTITHREADED CORES
Allan Diaz and Wei-Ming Lin
Department of Electrical and Computer Engineering, The University of Texas at San
Antonio, San Antonio, 78249-0669, TX, USA
ABSTRACT
In simultaneous multithreaded systems, there are several pipeline resources that are shared amongst multiple
threads concurrently. Some of these mutual resources to mention are the register-file and the write buffer.
The Physical Register file is a critical shared resource in these types of systems due to the limited number of
rename registers available for renaming. The write buffer, another shared resource, is also crucial since it
serves as an intermediary between the retirement of a store instruction and the writing of its value to cache.
Both components, if not configured accurately, can serve as a bottleneck in inefficient usage of the resources
and output undesirable performance.
However, when configuring both shared components concurrently, there is potential to all eviate common
performance congestion. This paper shows that when implementing a static register capping algorithm
(limiting the number of physical register entries for each thread), there is a byproduct of increased variety
in source for the write buffer. This also presents an opportunity for the write buffer to have a higher variety
to potentially choose for a better suitable thread asit’s source at certain clock cycles. With this presented
opportunity, this paper proposes a technique to allow the write buffer to both prioritize and enforce the
choice for low-latency threads by partitioning the write buffer in two sections; cache-hit priority and cache-
hit only partitions, showing that system performance and resource efficiency can be further improved by
using this technique in a modified SMT environment.
KEYWORDS
Write Buffer, Simultaneous Multithreading, Physical Register File, Register Renaming
1. INTRODUCTION
A Simultaneous Multi-Threading processor (SMT) is a superscalar processor architecture that
provides an enhanced method for improving overall system performance by processing instructions
from many threads concurrently, termed thread-level parallelism (TLP) [1], [2]. With the
characteristic of having parallel pipeline structures, various threads can occupy through separate
pipeline paths in the processor concurrently in the same clock cycle(s), which allows for better
resource utilization throughout the system. Subsequently, some pipeline resources are shared and
may be occupied by various threads at the same time as well. Figure 1 models the pipeline
organization of a 4-threaded SMT system and accurately depicts the visual difference of the parallel
and shared components. Shared components, if not configured accurately, can serve as a bottleneck
in inefficient usage of the resources and output undesirable performance. Therefore, to maximize
the overall system throughput, its shared resources must be properly managed to avoid newly
introduced bottle necks due to concurrent execution of threads.
Among the shared components in an SMT system, the shared Physical Rename Register, is
regarded as the most crucial of mutual components since these registers would be held for the
2. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
34
longest time until the respective instruction is ultimately committed. Another shared resource to
mention is the write buffer, which lies between a core’s pipeline and cache memory, serving as an
intermediary between the retirement of a store instruction and the writing of its value to cache.
These two shared components, when not individually designed correctly, can cause inefficient
resource utilization and poor performance. Modifying both components separately can relieve of a
probable bottleneck effect, however, later sections will show that there is potential for performance
increase when both shared components are configured concurrently.
This paper will introduce a technique known as register capping, the effects it has on the write
buffer, and present an opportunity to modify the write buffer into different partitions for better
response to the effect. The proposed technique will also rearrange the commit stage allowing a
difference in priority amongst the threads at different clock cycles. Thus, the primary focus of this
paper is to determine the maximal portion of physical registers that can be allocated, paired with
the combination of different partition values in the write buffer for a more latency free and efficient
SMT system. This combination in turn will maximize IPC throughput and the proposed method
will show very significant improvement up to 70.6% in a 4-threaded SMT system, and 65.9% in an
8-threaded SMT system.
Fig 1. Pipeline stages in a 4-threaded simultaneous multithreaded system.
2. RELATED WORKS
There is ample research on different methods of improving an SMT system and enhancing its
components. Some to mention explore several techniques of resource control at various stages of
the pipeline. In [3], a resource allocation algorithm is presented that is designed to optimize the
performance of the physical register file in a computer system. By providing a real-time cap value
based on each thread’s activity and effectiveness in occupying the registers, the resource is utilized
more efficiently, leading to an overall improvement of system performance. According to Hily and
Seznec [4], there is an ideal value pairing for the cache size and workload size in an SMT system.
In their work, they demonstrated how several cache parameters, such as block size and size relative
to thread count, could exhibit advantageous behavior when configured differently from usual
3. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
35
architectural setups. By employing the technique presented in [5], a dynamic limit is set on how
many instructions can be occupied in the issue queue (IQ) by a thread to prevent the queue from
becoming clogged by slower threads.
The ICOUNT policy mentioned in [6] is a method of fetching instructions based on how many
instructions are in the system before execution, where the thread with the fewest instructions is
given higher priority. Having multiple threads being executed concurrently makes this fetch policy
ideal for SMT systems. To prevent performance degradation, [7] allows each thread to use a portion
of the write buffer rather than all threads having access to all of it, in a sense partitioning. A
scheduling algorithm presented in [8], prioritizes the order of write buffer commits among threads
to maximize itsutilization of resources, allowing equal opportunity for all threads to retire their
instructions.
A multithreading algorithm in [9] prevents some threads from starving while others consume all of
the processor cycles by implementing a fairness metric into a multithreading method named
Switch-On Event. This method improves processor throughput by switching threads on execution
stalls enforced by a fairness ratio of the individual threads' speedups and performance. This
technique replying on this ration value guarantees fairness at different levels of strictness and
improved the weighted speedup amongst threads. In [10], to diminish the waste of cores resources
on instructions that do not need resources that can lead to false ordering dependences, this technique
efficiently scales instructions through a hybrid microarchitecture that can dispatch instructions in
in-order scheduling mechanisms. This measures the opportunity to better organize a dispatch and
evaluate a practical dispatch mechanism. [11] proposes several schemes to improve scalability and
increase scheduling throughput with a method called "2OP_BLOCK”. This technique takes another
method called "instruction packing" a step further and completely avoids sending an instruction
with two source operands that are not ready. This reduces scheduling complexity byeliminating the
logic required to support instructions with two unprepared source operands. On [12], a method is
introduced based on a memory monitoring framework that centers the concept ofactivity vectors
for threads. This allows asystem scheduler to predict cache utilization and inter-thread contention
using a dynamically tracking program on phase behavior in an autoregressive model.
A register file capping technique in [13] and [14] is applied on the rename stage that limits the
number of additional physical registers that a thread is allowed to occupy at any point of time with
a so-called “cap value”. By capping the integer physical register usage of each thread, utilization
of this critically shared resource can be vastly improved and consequently leads to a very
considerable performance gain.
Regarding the specific impact on commit stage and the shared write buffer component, [15]
proposesthat by limiting the number of cache misses that may concurrently occupy the write buffer,
it can reduce rejection of resources to cache hits. The paper first dissectsthe effect of cache misses
in the write buffer and its behavior, showing a shared write buffer is routinely occupied by many
long-latency cache misses in an SMT system. This behavior greatly increases the probability of the
write buffer being fully occupied, stalling threads that have cache hits ready to commit. The
proposed technique then aims to limiting the number of cache misses in the write buffer by
suspending threads which have a cache miss at the head of their ROB when the write buffer is
heavily occupied can significantly improve system performance in a multithreaded environment.
With specifically concentrating on works [13], [14] and [15], these related works serve as
motivation to the proposed technique that works in conjunction in this paper.
4. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
36
3. SIMULATION ENVIRONMENT
3.1. Simulator
M-Sim, a simultaneous multi-threaded microarchitectural simulator, was used as the environment
model for the performance analysis of the proposed technique. M-Sim includes accurate models of
the pipeline structures of an SMT system, however namely the Register File and Write Buffer will
be the focus for this paper. The simulation configuration parameters are outlined in Table 1. In this
paper, buffer sizes of both 16 and 32 entries and register file sizes of 160 and 320 will be used for
both 4-threaded and 8-threaded workloads respectively.
3.2. Workloads
The multi-threaded workloads used for simulations are chosen from the SPEC CPU 2006
benchmark suite that consists of programs with a combination of ILP levels that present a variety
of workloads. These benchmarks are chosen in sets of 4 and 8 to simulate the 4-threaded and 8-
threaded workloads and can be referred on their combinations to a corresponding “MIX” number
identifier. Benchmarks are rated based on their ILP classification also shown in the corresponding
Tables. The chosen workloads are based upon having a variety of ILP level combinations and the
following Mixes are shown in Table 2 for 4-threaded workloads, and Table 3 for 8-threaded
workloads.
3.3. Metrics
To evaluate the performance of this proposed algorithm, combined IPC (Instruction Per Cycle) is
a typical metric used to measure the overall performance throughput for each mix, which is defined
as the sum of each individual thread’s IPC:
(1)
where N denotes the number of threads per mix. The new over all IPC of a modified SMT system
will then be compared to that of the baseline overall IPC measured in the simulation environment
with no modifications or different adjustments from the new. Both baseline and new overall IPC
measurements will then serve as variables to find the average IPC improvement defined as function:
(2)
where M is number of mixes. Throughout this paper, these two formulas (1) and (2) will be used
to denote the change in performance of each stage in modifying the SMT system.
5. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
37
Table 1. Simulated Processor Configuration Setup
Table 2. 4-Threaded Workloads For Simulation, Chosen From Spec Cpu2006 Suite
Table 3. 8-Threaded Workloads For Simulation, Chosen From Spec Cpu2006 Suite
6. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
38
4. BACKGROUND
4.1. Physical Register File
As a result of the limited number of rename registers available in SMT systems, the Physical
Register file is one of the most critical shared resources. Instructions in some threads with high
latency block the progress of other fast threads, resulting in inefficient use of resources and poor
performance. Which is why, to avoid bottlenecks during the renaming process, SMT systems
typically require a much larger physical register file to accommodate multiple threads renaming
the registers. Simply adding more registers, however, can be a cost-effective solution.
As mentioned, one specific fixed cap technique is proposed in [13] and [14] that gives each thread
in the system an allotted portion of the additional registers to use for register renaming. This limited
portion is referred to in this paper as a cap value. Such a cap value, if selected properly, can prevent
a long-latency thread from dominating the physical register file; that is, faster threads are still
allowed to proceed with their allotted registers. The technique provides a significant performance
improvement over a default system. It was found that an optimal fixed cap was usually around 9.
Renaming physical registers will be limited if the size of the physical register file is not much larger
than the size of the architectural registers. In an SMT system, this limitation is aggravated even
further as resource sharing among several threads is intended to allow for a reduced number of
resources than would be required in multiple single-threaded superscalar systems. In our SMT
simulation, a 4-threaded system requires a minimum of 32 registers for every thread. This equates
to 128 (4 x 32) physical registers as the baseline with which no renaming is possible. For renaming
to be possible, allocation of additional registersfor renaming is needed. If a total of 160 physical
registers are used, 32 registers (160 - (32 x 4) = 32) are available among the 4 threads for renaming.
Applying the [14] technique of register capping with regards to having 32 rename registers
available is a reasonable starting parameter. To keep the same ratio of register to threads, the total
amount of physical register for 4-threads will be 160 and 8-threads will work with 320.
4.2. Write Buffer
When a store instruction is retired from the pipeline, the result that will be written to memory is
first transferred to the write buffer. A write-allocate cache strategy moves the cache line of the write
instruction to data level-one (DL1) cache while the value is temporarily kept in a write buffer entry
[15]. This buffering period in DL1 might range from a single clock cycle for a cache hit to hundreds
of clock cycles for a cache miss. Due to the low latency in a cache-hit scenario, favoring the write
buffer to choose a cache-hit will increase performance. The focus is to implement a write buffer
partitioning algorithm with a modified fixed cap on resource allocation of the rename registers.
5. PROPOSED METHOD
5.1. Approach
A first step to improving a capping environment would be to find a good cap value that will give
us the highest average IPC gain as a starting ground. A simple application of every different value
within the range of available registers is shown in Figure 2. As shown, the varying cap values in a
4-threaded workload also vary in average IPC Improvement percentages. The range with the
highest improvement is between cap value 7 and 12, but more specifically the highest is when cap
equal to 9 with IPC Improvement of 37.75%. Therefore, continuing to analyze the effects of register
capping in other resources with a cap value of 9 is an understanding and straightforward approach.
7. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
39
5.2. Analysis
The next phase is to see how capping affects the source of the write buffer, the Re-Order Buffers
(ROBs) of each thread and visually depict a difference in variety of resources. Figure 3 and 4 both
show a direct comparison in the different number of threads that are ready to commit for their
corresponding 9 and 32 cap value. Visually, there is a shift from right to left from having less red
and orange sections to more and also almost little to no blue in certain mixes, already inferring
there is transfer in number of threads. Particularly, mixes 4, 7, 8, 10 reveal the most shift in color.
Fig 2. Average IPC Change for 10 4-threaded mixes with varying cap values.
Fig 3. Number of unique threads ready to commit in a default system (Cap = 32)
Fig 4. Number of unique threads ready to commit in a capped system (Cap = 9)
8. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
40
Comparing the combined average number of threads for all mixes would tell us the overall average
of what the write buffer would encounter throughout the simulation. In that perspective, in a default,
no capping environment, there is 14.8% of the simulation having 0 threads ready to commit, 27.3%
having only 1 thread ready to commit, 31.8% for 2 threads, 21.2% with 3 threads, and only 4.9%
for 4 threads. When applying cap value to 9, there are 0, 1, 2, 3, and 4 threads ready to commit
through the whole simulation with 11.6%, 19.4%, 29.2%, 29.2%, and 10.7% respectively.
Comparing both scenarios with having a no capping as a baseline, there is a decrease of 3.2% of 0
threads ready to commit, 7.9% decrease of 1 thread, 2.6% decrease for 2 threads, a healthy 7.9%
increase for 3 threads, and great 5.8% increase on 4 threads which is a significant difference
considering any change on 4 threads supersedes other number of threads. The shift from a default
variety of threads to a larger one throughout the simulation infers that the write buffer now has a
bigger variety pool source of ROB heads to choose from. Having a higher variety provides not only
a higher chance to encounter a cache hit entry among the threads, but also an opportunity to filter
out threads at any given time. This choice of exclusion comes at a smaller risk of inefficiency
compared to default, again, due to the higher variety and number of entries flowing into the write
buffer. When capping to 9, rather than having a write buffer have a first come first serve through a
round robin selection, the write buffer is allowed to choose which thread to choose from to commit.
This gives the opportunity to prioritize threads having potential cache hit instruction over their non-
cache hit thread counter parts. A thing to note on how capping affects the source of a write buffer
is the actual size of the ROBs for each thread in every mix. Analyzing the ROB size in Figure 4
and 5, with no capping, the average for each mix barely reaches 20, the max size with around 50-
55 occurred twice, and the highest total number of entries for a mix was 94 on mix 7. In comparison,
with cap value 9, the average size exceeds 20 numerously, the max size exceeding 55 occurred 8
times, and the highest total number of entries for a mix was 145 on mix 6. Although the proposed
algorithm does not manipulate ROB size as a factor, it directly affects the potential of improvement.
Fig. 5. Size of ROB for each thread and average size per Mix for a default system. (Cap = 32)
Fig .6. Size of ROB for each thread and average size per Mix for a capped system. (Cap = 9)
9. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
41
6. PROPOSED ALGORITHM
Previously, it has been shown that when register capping with 9, both the variety of the threads and
average size of ROB increase. Therefore, the proposed algorithm aims to filter in the higher variety
as the most suitable threads with a cache-hit at the head of ROB. The approach to this is to first
depict the process of a default commit process.
Figure 7 visually depicts the normal process used in an SMT system during the commit stage where
a store instruction gets committed in a round robin-ordered fashion for each thread. Figure 8 also
shows the pseudo code associated with Figure 7 and additional detailed actions associated in the
commit phase of an SMT system. In this commit portion, a thread is selected to be the new current
thread as a source for the rest of the commit cycle, chosen by round robin formula, c modulo N,
having c depict the current clock cycle of commit initiation and N representing the number of
concurrent threads. Once a thread is selected, the first entry (head) of the ROB of the selected thread
must be committed first, assuming this entry is ready to be committed. If the current thread does
not have an ROB head ready to be committed, the thread is immediately excluded for consideration
for that clock cycle and checks to see if a next thread is available to repeat the process of checking
if the ROB head is ready to be committed. Once a ROB entry is verified to be ready and commit
bandwidth is available, the next step is ensuring the ROB head is a store is crucial as it is the only
way the entry can be entered into the write buffer. If the entry is not a store, there is no need for a
write buffer, so the instruction immediately gets committed to commit stage. Now, available
commit bandwidth is decremented, and the next entry in the same thread that is now the new ROB
head is checked. Finally, if ROB instruction has been verified to be a store and if the write buffer
is not full to even have the availability to accept an entry, the store value will be written to the write
buffer and the workflow continues until commit bandwidth is used up or there are no more threads
remaining to choose from. One thing to emphasize is that if the write buffer is full, the thread is
completely disregarded and no longer in consideration for the rest of the commit process cycle.
With the presented byproduct of increased variety or number of different threads ready to commit
when register capping to the most efficient cap value, the current default algorithm in the commit
stage does not take full advantage to be able to choose which thread is best to choose from. In other
words, with this default algorithm, the write buffer does not discriminate if the current ROB entry
of the thread is a cache hit/miss and regardless if ROB head of the thread will potentially degrade
performance of by having a long latency write buffer entry for several hundred clock cycles, the
write buffer will always choose the first entry when it gets to that section of the commit process.
The goal of this technique is to allow the write buffer to choose what ROB head entry from a certain
threadto prioritize cache hit entries, prevent potentially blocked cache hits, and maximize commit
bandwidth, before filling up and decreasing efficiency. Therefore, modifying the commit stage and
partitioning the write buffer into prioritized sections along with finding the optimal prioritizing
level values for each partition will be the key with this technique.
Applying the proposed method, Figure 9 in illustration form now shows the modified process
during the commit stage where a store instruction still gets committed in a round robin ordered
fashion for each thread. Figure 10 again, also shows the associated pseudo code with Figure 9, with
detailed actions in incorporating modifications. In this redesigned commit stage, a thread is still
selected by round robin formula, c modulo N. The process of checking to see if the ROB head of a
thread is a store and requirements before that are still the same as default, but the algorithm starts
to change once the process starts to involve the write buffer. Instead of the non-full write buffer
simply allowing the instruction to commit once it gets to that point, it checks to see if the entry is
a data cache level 1 hit. If a cache-hit is true, then entry will be committed to write buffer and
written to cache within the next few clock cycles. If entry is not a cache-hit, this is where the
10. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
42
partition values come into play. Condition functions 3 and 4 below are the conditions of the
proposed partitioned write buffer and the M and N values that trigger different paths in the new
modified commit stage.
Fig. 7. Unmodified round robin commit stage algorithm.
Fig. 8. Pseudocode for unmodified commit stage.
11. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
43
Fig. 9. Modified round robin commit stage algorithm with write buffer partitioning.
12. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
44
Fig. 10. Modified round robin commit stage algorithm with write buffer partitioning
Initially, if the write buffer encounters a non-cache hitting thread when the cache hit priority
condition is met, meaning the current size of the write buffer is greater or equal to the maximum
size a write buffer can be minus value of M, the thread in question starts a process. Rather than
completely disregarding the thread in a default commit stage, a thread is first suspended to a
different pool of suspended threads and removed from the original pool of non-suspended threads.
Suspended threads are still accounted for but are held at a lower priority than non- suspended
(untouched or unvisited) threads. To ensure every thread is considered, a suspended thread, as
shown in the Figure 9, is only considered when either all non-suspended threads have been
suspended, or there are no more non-suspended threads to choose from. Although this M partition
gives priority to thread with ROB head as cache hit, if no cache-hit thread is available or all have
already been committed, suspended threads have another opportunity to be considered. Assuming
bandwidth is available and all threads have been accounted for and suspended, the pool of
suspended threads can now re-enter the commit stage at with the condition that they now follow a
different path. Since they are marked as suspended and have been filtered before, they now follow
the cache hit only partition that is dependent on the value N. This partition is comparable to [15],
in which this section forces the write buffer to only accept cache-hit threads if capacity and
condition is met. If the N partition however has not been met but a thread has is currently suspended
and filtered by the M partition, the thread is committed regardless as to not waste commit bandwidth
on enforcing a cache-hit that is not available at the current clock cycle. This methodology in turn
prioritizes threads with cache hit but also allows threads with no cache-hit at a given clock cycle
and second opportunity to be able to commit the store instruction. As explained, the only way a
thread is suspended is when it encounters the write buffer at M partition value. Therefore, the only
viable values for M and N are that M must always be greater than N. In other words, a thread must
13. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
45
first be given a second chance in order to be considered in the second phase. The difference between
M and N is a inevitable buffer on how many threads will be given a second opportunity.
The focus is to determine the maximal number of rename registers that can be issued to each thread,
paired with the combination of M and N partitioning values that can maximize IPC. The process to
maximal M and N values involves simulating the fixed capped system and extrapolating every
possible M and N value. With the established cap value of 9 for 4-threaded workloads to combine
this algorithm with, Figure 11-14 plot all the possible combinations of partition M and N values as
the x and y axis, and the average increase percentage as z-axis.
Fig. 11. 3D Representation of the varying partition values M and N when cap = 9
Fig. 12. Cache-hit only partition N as x-axis, & percentage improvement as y-axis.
14. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
46
Fig. 13. Cache-hit priority partition M in the x-axis, & percentage improvement as y-axis.
Fig. 14. Cache-hit priority partition M as x-axis, & cache-hit only partition N as y-axis
What can be inferred for the 3-D surface graphs (Figure 11-14) is that the usual peak at to get the
highest percentage is when the cache-hit only partition value N reaches 2 with having the cache-hit
priority partition M value range between 3 and 16. According to the actual raw data, the actual
15. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
47
combination that gave the highestaverage IPC value was M = 15 and N = 2. In other words, in a 4-
threaded SMT system with a 16-entry write buffer, the highest performance increase when
implementing the modified commit and write buffer partitioned algorithm with a static when 15
out of the 16 entries of the write buffer are prioritized for cache-hit threads (not enforced), and 2
entries are reserved only for cache-hit threads (enforced).
7. SIMULATION RESULTS
The proposed algorithm will be tested with the following different parameters of an SMT system.
As mentioned before, the register file size will remain at 160 registers for 4-threaded workloads,
and 320 for 8-threaded workloads, keeping the same ratio of number of registers per thread.
The same guided process of choosing a cap value for the system and finding M and N partition
values in the write buffer will be done for each system configuration. The following results will be
listed showing the following data, in order. First, a per-mix IPC change percentage between a
capping plus write buffer algorithm, and mixes with a capping adjustment only (no algorithm).
Second, an average IPC change percentage, with a default system with no capping (cap = 32) as
baseline, for varying cap values applying the best combination of M and N in the write buffer
partitioning algorithm (tested with the best cap value).
7.1. 4-Threaded Workloads | 16 Write Buffer Entry
Fig. 15. Per-mix IPC change with capping = 9, M=15, and N=2, compared to just capping = 9.
As guided, the best cap value that was tested to bring the highest IPC average was 9, and the best
partition values were M=15 and N=2. The average IPC (improvement) change for the above figure
was 20.5% when in contrast to a just capping system with value 9. In Figure 15, visual analysis
16. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
48
tells the specific mixes that had the most change, namely 5, 7, 8, and 10. These mixes are also
depicted in Figure 3 and 4 to have the most “shift” on the number of different threads ready to
commit which corresponds to our initial inference.
With Figure 16, as the cap value nears a default state, the write buffer algorithm does not perform
very well and does not produce an additional improvement. This is entirely because as the cap value
digresses from the optimal value (cap = 9), the variety of threads and ROB size decrease. Since the
source of the algorithm suffers depletion, so does the algorithm itself. Together with capping and
the proposed algorithm, there was a peak 70.6% increase compared to default with no modification.
Fig. 16. Both capping only and capping with algorithm compared to default system
7.2. 4-Threaded Workloads | 32 Write Buffer Entry
The best cap value tested to bring the highest IPC average was 9. After, it was tested that the best
values of M and N were 30 and 2 respectively. The average IPC improvement for the above figure
was 7.25% compared to just capping with value 9. In Figure 17, the same specific mixes that had
the most change (5, 7, 8, and 10), also showing around the same ratios as before. However,
compared to its 16-entry counterpart with the same 4-threaded workload, the percentage for each
significant thread has decreased significantly, by a bouthalf.
As reflected from the per-mix analysis previously, Figure 18 shows how much of a difference in
the size limitof the write buffer can affect the algorithm results. With double the write buffer entries
with same 4 threaded workload, the algorithm gains little throughout the varying cap values, but
barely significant enough in certain cap range.
17. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
49
Fig. 17. Per-mix IPC change with capping = 9, M=30, and N=2, compared to just capping = 9.
Fig. 18. Both capping only and capping with algorithm compared to default system.
7.3. 8-Threaded Workloads | 16 Write BufferEntry
The best cap value tested to bring the highest IPC average was 9. After, it was tested that the best
values of M and N were 16 and 2. In Figure 19, there is a significant increase in IPC percentage
among all Mixes. In the previous scenarios for a 4-threaded system, only 3 Mixes were able to
exceed a minimum percentage increase of 40%, but in this result, there is nearly 50 percent of all
mixes reaching or exceeding 40%. The average IPC improvement for this section was 35.8% which
is a huge bump in gain so far.
18. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
50
Figure 20 shows the biggest margin of difference between only capping and capping plus algorithm.
Although it is the biggest increase due to the proposed algorithm being implemented, it does not
hold to be the highest increase percentage with capping and write buffer algorithm combined when
compared to default c= 32.
Fig. 19. Per-mix IPC change with cap=9, M=16, and N=2, compared to just capping c=9.
Fig. 20. Both capping only and capping with algorithm compared to default system
19. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
51
7.4. 8-Threaded Workloads | 32 Write Buffer Entry
The best cap value tested to for the highest IPC average was again, 9. It was then tested for the best
values of M and N, which was found to be 32 and 2.
Fig. 21. Per-mix IPC change with cap=9, M=32, and N=2, compared to just capping c=9.
In Figure 21, the average IPC improvement above was 13.02%. Figure 22 shows that even though
ourpreliminary testing on deciding which cap value is best, when applying M = 32 and N = 2, even
though the values were tailored for a cap value of 9, there is a higher IPC percentage gain on cap
value number 10, having 28.2% and 28.35% for 9 and 10, respectively.
Fig. 22. Both capping only and capping with algorithm compared to default system.
20. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
52
7.5. Results Summary
Table 4. Highest peak performance compared to default for each system configuration.
In Table 4, the different results for each configured system are shown. In workload 1, comparison
from default shows the highest overall IPC improvement percentage with 70.6%. This includes
both capping and write buffer/commit modifications combined and working concurrently.
However, when showing the marginal difference from just capping, there is a decent 20.49%. This
infers that in this environment, the capping algorithm does most of the improvement and the
proposed algorithm adds a decent improvement as well. In workload 2, overall IPC improvement
percentage was 60.3%, but only 7.75% with capping as baseline. This marginal increase is the
lowest in the bunch in terms of just capping comparison. In workload 3, the overall IPC
improvement percentage with 65.93%, and a healthy and highest marginal difference compared to
cap only of 35.8% This infers that in this environment, the capping algorithm, and the proposed
algorithm work cohesively and efficiently together and both add around the same effort and gain.
In workload 4, IPC improvement percentage with 28.35% and marginal difference from just
capping at 13.02%. Although the worst in overall gain from default, the marginal percent difference
is not the lowest.
8. CONCLUSION
In simultaneous multithreaded systems, there are several pipeline resources shared among multiple
threads con- currently. If these shared resources are not configured correctly, they can serve as a
bottleneck in inefficientresource usage and generate undesirable performance. As shown in this
paper, there is the potential to alleviate common performance congestion by configuring the mutual
resources, register file and write buffer, concurrently.
This paper has shown that when implementing a static register capping algorithm, that is limiting
the number of per-thread physical register entries, a byproduct of increased variety in the source to
the write buffer. This allowed for an algorithm for the write buffer to have a higher variety to
potentially choose a more suitable thread as it’s source at certain clock cycles. Partitioning the write
buffer into two sections; cache-hit priority and cache-hit only, has shown that system performance
can be further improved by using this technique. Essentially having all of the write buffer entries
to prioritize cache hit and leaving one or two entries for cache-hits only resulted in the best
improvement in a capped system. The one drawback of this proposal, however, is that depending
on the parameters of the system, the algorithm may be limited to improvement. In comparison to a
default SMT system, peak overall IPC was increased by nearly 71% with this proposed method.
21. International Journal of Distributed and Parallel systems (IJDPS) Vol 14, No. 1/2/3/4/5/6, November 2023
53
REFERENCES
[1] H. Hirate, K. Kimura, S. Nagamine, Y. Mochizuki, A. Nishimura, Y. Nakase, and T. Nishizawa, “An
Elementary Processor Architecture with Simultaneous Instruction Issuing from Multiple Threads,” the
Proceedings of the 19th Annual International Symposiumon Computer Architecture, 1992.
[2] D. Tullsen, S. J. Eggers, and H. M. Levy, “Simultaneous Multithreading: Maximizing On-Chip
Parallelism,” the Proceedings of the 22nd Annual International Symposium on Computer Arch., 1995.
[3] M. Sheikh and W.-M Lin, “Dynamic capping of rename registers for SMT processors,” Journal of
Systems Architecture, vol. 99, 2019
[4] Hily, Sébastien and André Seznec. “Contention on 2nd Level Cache May Limit the Effectiveness of
Simultaneous Multithreading.” (1997).
[5] A.Sahba, Y. Zhang, M. Hays, and W. Lin, “A Real-Time Per-Thread IQ Capping Technique for
Simultaneous Multi-threading (SMT) Processors,” in 11thInternational Conference on Information
Technology: New Generations, 2014,pp.413–418.
[6] D. M. Tullsen, S. J. Emer, H. M. Levy, J. L. Lo, and R. L. Stamm, “Exploiting Choice: Instruction
Fetch and Issue on an Implementable Simultaneous Multi-Threading Processor,” the Proceedings of
the 23rd Annual International Symposium on Computer Architecture, pp. 191–202,1996.
[7] Y. Zhang and W. M. Lin, “Write buffer sharing control in SMT processors,” in PDPTA’13: The 19th
International Conference on Parallel and Distributed Processing Techniques and Applications,2013.
[8] S. Lawal, Y. Zhang, and W. M. Lin, “Prioritizing write buffer occupancy in simultaneous multi-
threading processors,” J. Emerg. Trends Computer. Inf. Sci, vol.6, no. 10, pp.515–522,2015.
[9] Gabor, R., Weiss, S., & Mendelson, A. “Fairness enforcement in switch on event multithreading.”
ACM Transactions on Architecture and Code Optimization. Association for Computing Machinery
(ACM), vol. 4, no. 3, 2007
[10] Sleiman, Faissal M., & Wenisch, T. F. “Efficiently Scaling Out-of-Order Cores for Simultaneous
Multithreading.” ACM SIGARCH Computer Architecture News, vol. 44, no. 3, Association for
Computing Machinery (ACM), June 2016
[11] J. J. Sharkey and D. V. Ponomarev, "Exploiting Operand Availability for Efficient Simultaneous
Multithreading," in IEEE Transactions on Computers, vol. 56, no. 2, Feb. 2007
[12] Kihm, J.L., Janiszewski, A., & Connors, D.A. “Predictable Fine-Grained Cache Behavior for
Enhanced Simultaneous Multithreading (SMT) Scheduling.” International Conference on
Communication Control and Computing Technologies (2004).
[13] Y. Zhang and W. M. Lin, “Efficient physical register file allocation in simultaneous multi-threading
CPUs,” in 33rd IEEE International PerformanceComputingandCommunicationsConference,2007.
[14] Y. Zhang and W.-M Lin, “Efficient resource sharing algorithm for physical register file in
simultaneous multi-threading processors,” Microprocess and Microsystems, 2016.
[15] S. Carroll and W. M. Lin, “Latency-aware write buffer resource control in multi-threaded cores,” Int.
J. DistributedParallel Syst. (IJDPS), vol. 1, pp. 7–7, 2016
AUTHORS
Allan Diaz received his B.S. and M.S. degrees in Computer Engineering from the
University of Texas at San Antonio. He studied integrated design, and his research interests
include computer architecture, parallel and distributed computing, artificial intelligence,
and machine learning.
Wei-Ming Lin received the Ph.D. degree in Electrical Engineering from the University of
Southern California in 1991. He is a professor of Electrical Engineering, and also the
Associate Dean for Graduate Studies of the College of engineering in the University of
Texas at San Antonio. His research interests include distributed and parallel computing,
computer architecture, computer networks and internet security.
