1. Synapse

2. Outline
 Review the Action Potential
 What happens when the action potential reaches the
axon terminal?
 Synaptic Connections
 Neurotransmission
 Types of Receptors
 Ionotropic vs. Metabotropic
 Excitation vs. Inhibition
 Temporal vs. Spatial Summation
 Neurotransmitters

3. Action Potential Demonstration

5. 3 Types of Synaptic Connections Between
Neurons

6. Neurotransmission at the Synapse

7. Lifecycle of Synaptic Vesicle

8. Two Types of Receptors
Ionotropic Metabotropic
 Channel opens in
response to ion binding
 Contains 4-5 subunits that
make up the receptor
structure
 Fast speed of action
• Channel opens in
response to second
messengers
• Contains 1 subunit that
makes up the receptor
structure
• Slow speed of action

9. Ionotropic Receptor

10. Metabotropic Receptor

11. Second Messenger Systems
 Downstream
effects through a
series of
enzymatic
reactions
 Nitric oxide

12. Receptors can have an excitatory or
inhibitory effect.
Excitatory Postsynaptic
Potential (EPSP)
Inhibitory Postsynaptic
Potential (IPSP)
 Promotes excitation of
the postsynaptic
membrane
 Graded potential that
decays over time and
space
 Cumulative effect of EPSPs
are the basis for temporal
and spatial summation
 Temporary
hyperpolarization of a
membrane- prevent action
potentials
 How?

13. Summation
Temporal Summation Spatial Summation
 Many stimuli in a close
span of time
 Repeated stimuli can have
a cumulative effect and
can produce a nerve
impulse when a single
stimuli is too weak
 Many neurons firing
simultaneously in the
same location
 Synaptic input from
several locations can have
a cumulative effect and
trigger a nerve impulse

15. Temporal Summation

16. Excitation or Inhibition of a Muscle

17. Long Term Potentiation (LTP)
 Creating new or stronger synapses
 Occurs by repeated stimulation, an increase in dendritic
receptors, an increase in neurotransmitters
 New synapses can be formed in the olfactory system and
in the hippocampus

18. Review of the Synapse

19. Neurotransmitters
Small Molecule Large Molecule
 Glutamate
 GABA
 Dopamine
 Norepinephrine
 Serotonin
 Acetylcholine
 Neuropeptides
 Lipids
 Gases
