Shifter: Containers in HPC environments
HPC Advisory Council Switzerland
Miguel Gila, CSCS
March 21, 2016
Docker
What is Docker and how does it work?
§ “Docker containers wrap up a piece of software in a complete filesystem that
contains everything it needs to run: code, runtime, system tools, system libraries
– anything you can install on a server. This guarantees that it will always run the
same, regardless of the environment it is running in.” [*]
Shifter: Containers in HPC environments 3
Virtual Machines Containers
[*] https://www.docker.com/what-docker
[*]
[*]
What is Docker and how does it work?
§ A Docker image is a file that contains a filesystem within it. It can be a full
filesystem (i.e. CentOS) or partial (i.e. python3.4-slim). Images are stored either
on a public registry (Docker hub) or private
§ Docker leverages the namespaces feature of the kernel to isolate processes
§ On its simplest form, Docker basically
1. Pulls an image to the local system
2. Creates a chrooted environment with the image (=container)
3. Runs our application in the container (’isolated’ from the host thanks to kernel namespaces)
§ However, it can also do other things:
§ Isolate network by creating NAT or bridge devices
§ Can use a nice GUI
Shifter: Containers in HPC environments 4
Docker in HPC environments
§ Docker is a nice tool, but it’s not built for HPC environments, because:
§ Does not integrate well with workload managers
§ Does not isolate users on shared filesystems
§ Requires running a daemon on all nodes
§ Not designed to run on diskless clients
§ Network is, by default, ‘NATed’
§ Building Docker is done within a Docker container. It can be done outside, but is a complex
task (Go language, seriously??)
§ But after all, a sysadmin can make anything to work on a cluster, right?
§ We can create (and hopefully maintain) monstrous wrappers to run Docker containers…
Shifter: Containers in HPC environments 5
Shifter
What is Shifter and how does it work?
§ Shifter is a container-based solution thought from the ground up for HPC
environments
§ It leverages the current Docker environment and can use Docker images to
create containers
§ Shifter basically
1. Pulls an image to a shared location (/scratch)
2. Creates a loop device with the image (=container)
3. Creates a chrooted environment on the loop device
4. Runs our application in chrooted environment
§ Designed to work on HPC clusters and, particularly, on Cray systems
§ It is possible to choose which filesystems to expose to the containers
Shifter: Containers in HPC environments 7
External nodeCompute node
Architecture of Shifter
§ Shifter consists on two parts
§ udiRoot is responsible for creating the loop devices, doing chroot and cleaning up after the
binary execution is done. Workload manager plugins are available. Written in C
§ imageGateway is responsible for fetching a Docker image, converting it to a squashfs file and
transfer it to a shared location on a filesystem. It also keeps track of the images and tells
udiRoot which are available. Written in Python
Shifter: Containers in HPC environments 8
scratch
udiRoot imageGateway
query
restful API
db
Docker
Hub
Or private
registry
Workflow
1. User creates an image on his/her computer and pushes it to Docker Hub
Shifter: Containers in HPC environments 9
Docker
1 2
$ docker build .
Uploading context 10240 bytes
Step 1 : FROM busybox
Pulling repository busybox
---> e9aa60c60128MB/2.284 MB (100%) endpoint: https://cdn-registry-
1.docker.io/v1/
Step 2 : RUN ls -lh /
---> Running in 9c9e81692ae9
total 24
drwxr-xr-x 2 root root 4.0K Mar 12 2013 bin
drwxr-xr-x 5 root root 4.0K Oct 19 00:19 dev
drwxr-xr-x 2 root root 4.0K Oct 19 00:19 etc
drwxr-xr-x 2 root root 4.0K Nov 15 23:34 lib
lrwxrwxrwx 1 root root 3 Mar 12 2013 lib64 -> lib
dr-xr-xr-x 116 root root 0 Nov 15 23:34 proc
lrwxrwxrwx 1 root root 3 Mar 12 2013 sbin -> bin
dr-xr-xr-x 13 root root 0 Nov 15 23:34 sys
drwxr-xr-x 2 root root 4.0K Mar 12 2013 tmp
drwxr-xr-x 2 root root 4.0K Nov 15 23:34 usr
---> b35f4035db3f
Step 3 : CMD echo Hello world
---> Running in 02071fceb21b
---> f52f38b7823e
Successfully built f52f38b7823e
Removing intermediate container 9c9e81692ae9
Removing intermediate container 02071fceb21b
docker build docker push
$ docker push miguelgila/wlcg_wn:20161212
Docker
Hub
Or private
registry
Workflow
1. User creates an image on his/her computer and pushes it to Docker Hub
2. User tells imageGateway to pull his image and make it available
Shifter: Containers in HPC environments 10
$ ssh santis01
$ module load shifter
$ shifterimg pull docker:ubuntu:14.04
$ sleep 300 # :-)
$ shifterimg images
santis docker READY 2934337e50 2015-12-10T09:03:38 python:2.7-slim
santis docker READY a4f04f71be 2015-12-10T09:47:17 python:3.5-slim
santis docker READY b0197931ac 2015-12-10T09:53:54 python:3.2-slim
santis docker READY 0bb6b50d84 2015-12-10T10:34:24 python:3.3-slim
santis docker READY cd86406b32 2015-12-10T10:36:55 python:3.5.1
santis docker READY 48bc52cc28 2015-12-10T10:47:35 python:3.4.3
santis docker READY 0b92f1735f 2015-12-10T11:17:26 python:3.4-slim
santis docker READY 3fba104814 2015-12-10T11:31:23 centos:6.7
santis docker READY 12c9d795d8 2015-12-10T11:37:35 centos:6.6
santis docker READY 3e0c71ada2 2015-12-10T15:19:24 ubuntu:15.10
santis docker READY e751d10964 2015-12-10T13:38:05 miguelgila/wlcg_wn:20151125v2
santis docker READY d55e68e6cc 2015-12-10T15:52:09 ubuntu:14.04
shifterimg pull
/scratch/
santis
imageGateway
1
2
3 4
Docker
Shifter
Shifter
Docker
Hub
Or private
registry
Compute node
Workflow
1. User creates an image on his/her computer and pushes it to Docker Hub
2. User tells imageGateway to pull his image and make it available
3. User runs SBATCH and prepends shifter to his/her executable
Shifter: Containers in HPC environments 11
#!/bin/bash –l
#SBATCH --job-name="shifter_osversion”
#SBATCH --nodes=1
#SBATCH --ntasks-per-node=1
#SBATCH --time=00:30:00
#SBATCH --exclusive
#SBATCH --output=/users/miguelgi/jobs/out/shifter_hostname.stdout.log.%j
#SBATCH --error=/users/miguelgi/jobs/out/shifter_hostname.stdout.log.%j
#SBATCH --image=docker:miguelgila/wlcg_wn:20151218
#SBATCH --imagevolume=/users/miguelgi:/users/miguelgi
#SBATCH --imagevolume=/apps:/apps
#SBATCH --imagevolume=/scratch/santis:/scratch/santis
module load slurm
module load shifter/15.12.0
srun shifter --volume=/scratch/santis:/scratch/santis --volume=/users:/users cat
/etc/redhat-release
sbatch
/scratch/
santis
SRUN/SPANK
1
3
udiRoot
Loop device
/dev/loopY
Shifter
Create loop dev
shifter binary
Run bin in loop dev
/users
2
Use cases
Full OS containers
§ Cray compute nodes run CLE (a version of SLES 11)
§ With Shifter it is possible to run applications built for specific OS:
Shifter: Containers in HPC environments 13
[miguelgi@santis01]-[11:34:45]-[~/examples]:-($ salloc -t 00:15:00 -N1 --image=docker:centos:6.7
salloc: Granted job allocation 16313
salloc: Waiting for resource configuration
salloc: Nodes nid00012 are ready for job
[miguelgi@santis01]-[11:34:50]-[~/examples]:-)$ srun shifter cat /etc/redhat-release
CentOS release 6.7 (Final)
[miguelgi@santis01]-[11:35:03]-[~/examples]:-)$ srun shifter yum --version |head -4
3.2.29
Installed: rpm-4.8.0-47.el6.x86_64 at 2015-08-19 18:25
Built : CentOS BuildSystem <http://bugs.centos.org> at 2015-07-24 11:28
Committed: Lubos Kardos <lkardos@redhat.com> at 2015-06-15
CentOS 6 – non-interactive session
[miguelgi@santis01]-[10:52:40]-[~/examples]:-)$ salloc -t 00:15:00 -N1 --image=docker:debian:7.9
salloc: Granted job allocation 16294
salloc: Waiting for resource configuration
salloc: Nodes nid00012 are ready for job
[miguelgi@santis01]-[10:58:29]-[~/examples]:-($ srun --pty shifter /bin/bash
[miguelgi@nid00012]-[10:58:31]-[~/examples]:-)$ cat /etc/debian_version
7.9
[miguelgi@nid00012]-[10:58:33]-[~/examples]:-)$ uname –a
Linux nid00012 3.0.101-0.46.1_1.0502.8871-cray_ari_c #1 SMP Tue Aug 25 21:41:26 UTC 2015 x86_64 GNU/Linux
[miguelgi@nid00012]-[10:59:46]-[~/examples]:-)$ apt-get --version |head -n1
apt 0.9.7.9 for amd64 compiled on Oct 17 2014 09:15:56
Debian 7.9 – interactive session
Application containers: Python/Ruby
Shifter: Containers in HPC environments 14
[miguelgi@santis01]-[09:57:23]-[~]:-)$ salloc -t 01:00:00 -n1 --image=docker:python:3.5.1
salloc: Granted job allocation 16274
salloc: Waiting for resource configuration
salloc: Nodes nid00012 are ready for job
[miguelgi@santis01]-[10:00:51]-[~]:-)$ srun --pty shifter /bin/bash
[miguelgi@nid00012]-[09:01:04]-[~]:-)$ python –V
Python 3.5.1
[miguelgi@nid00012]-[09:01:08]-[~]:-)$ which python
/usr/local/bin/python
Python 3.5.1 – interactive session
[miguelgi@santis01]-[10:16:35]-[~]:-)$ salloc -t 01:00:00 -n1 --image=docker:python:3.2-slim
salloc: Granted job allocation 16278
salloc: Waiting for resource configuration
salloc: Nodes nid00012 are ready for job
[miguelgi@santis01]-[10:19:34]-[~/tmp]:-)$ srun shifter ./myscript.py
3.2.6
Python 3.2 – non-interactive session
$ cat myscript.py
#! /usr/bin/env python
import platformprint(platform.python_version())
myscript.py
[miguelgi@santis01]-[09:57:23]-[~]:-)$ salloc -t 01:00:00 -n1 --image=docker:ruby:2.1.8
salloc: Granted job allocation 16280
salloc: Waiting for resource configuration
salloc: Nodes nid00012 are ready for job
[miguelgi@santis01]-[10:22:14]-[~]:-)$ srun --pty shifter /bin/bash
miguelgi@nid00012]-[09:22:28]-[~]:-)$ ruby –v
ruby 2.1.8p440 (2015-12-16 revision 53160) [x86_64-linux
Ruby 2.1.8 – interactive session
[miguelgi@santis01]-[10:22:05]-[~]:-)$ salloc -t 01:00:00 -n1 --image=docker:ruby:2.1.8
salloc: Granted job allocation 16280
salloc: Waiting for resource configuration
salloc: Nodes nid00012 are ready for job
[miguelgi@santis01]-[10:22:08]-[~/tmp]:-)$ srun shifter ./myscript.rb
2.1.8
Ruby 2.1.8 – non-interactive session
$ cat myscript.rb
#!/usr/bin/env ruby
puts RUBY_VERSION
myscript.rb
§ Can run application specific containers:
Multi-node containers
§ It is possible to run the same container across multiple nodes:
§ Working on getting MPI across nodes to function
§ Working on getting GPUs to be accessible to containers with good results so far (native
performance!)
Shifter: Containers in HPC environments 15
lucasbe@santis01 ~/shifter-gpu> sbatch ./nvidia-docker/samples/cuda-stream/benchmark.sbatch
Submitted batch job 496
lucasbe@santis01 /scratch/santis/lucasbe/jobs> cat shifter-gpu.out.log
Launching GPU stream benchmark on nid00012 ...
STREAM Benchmark implementation in CUDA
Array size (double precision) = 1073.74 MB
using 192 threads per block, 699051 blocks
Function Rate (GB/s) Avg time(s) Min time(s) Max time(s)
Copy: 184.3169 0.01167758 0.01165104 0.01170397
Scale: 183.1849 0.01175387 0.01172304 0.01178598
Add: 180.3075 0.01790012 0.01786518 0.01792288
Triad: 180.1056 0.01790700 0.01788521 0.01794291
GPU
#! /usr/bin/env python
import platform
import socket
print(platform.python_version())
print(socket.gethostname())
hostname.py
[miguelgi@santis01]-[10:39:43]-[~/examples]:-)$ salloc -t 00:15:00 -N2 -w nid00013,nid00014 --image=docker:python:3.2-slim
salloc: Granted job allocation 16285
salloc: Waiting for resource configuration
salloc: Nodes nid000[13-14] are ready for job
[miguelgi@santis01]-[10:41:21]-[~/examples]:-)$ srun shifter ./hostname.py
3.2.6
nid00013
3.2.6
nid00014
Python 3.2 – non-interactive session
Practical use case: WLCG Swiss Tier-2
§ CSCS operates the cluster Phoenix on behalf of CHIPP, the Swiss Institute of
Particle Physics
§ Phoenix runs Tier-2 jobs for ATLAS, CMS and LHCb, 3 experiments of the LHC
at CERN and part of WLCG (Worldwide LHC Computing Grid)
§ WLCG jobs need and expect RHEL-compatible OS. All software is precompiled
and exposed in a cvmfs[*] filesystem
§ But Cray XC compute nodes run CLE, a modified version of SLES 11 SP3
§ So, how do we get these jobs to run on a Cray?
Shifter: Containers in HPC environments 16 [*] https://cernvm.cern.ch/portal/filesystem
Practical use case: WLCG Swiss Tier-2
§ Using Shifter, we are able to run unmodified ATLAS,
CMS and LHCb production jobs on a Cray XC40 TDS
§ Jobs see standard CentOS 6 containers
§ Nodes are shared: multiple single-core and multi-core
jobs, from different experiments, can run on the same
compute node
§ Job efficiency is comparable in both systems
Shifter: Containers in HPC environments 17
JOBID USER ACCOUNT NAME NODELIST ST REASON START_TIME END_TIME TIME_LEFT NODES CPU
82471 atlasprd atlas a53eb5f8_34f0_ nid00043 R None 15:03:33 Thu 15:03 1-23:54:18 1 8
82476 cms04 cms gridjob nid00043 R None 15:08:39 Tomorr 03:08 11:59:24 1 2
82451 lhcbplt lhcb gridjob nid00043 R None 15:00:10 Tomorr 03:00 11:50:55 1 2
82447 lhcbplt lhcb gridjob nid00043 R None 14:59:31 Tomorr 02:59 11:50:16 1 2
82448 lhcbplt lhcb gridjob nid00043 R None 14:59:31 Tomorr 02:59 11:50:16 1 2
82449 lhcbplt lhcb gridjob nid00043 R None 14:59:31 Tomorr 02:59 11:50:16 1 2
82450 lhcbplt lhcb gridjob nid00043 R None 14:59:31 Tomorr 02:59 11:50:16 1 2
82446 lhcbplt lhcb gridjob nid00043 R None 14:49:01 Tomorr 02:49 11:39:46 1 2
82444 lhcbplt lhcb gridjob nid00043 R None 14:48:01 Tomorr 02:48 11:38:46 1 2
82445 lhcbplt lhcb gridjob nid00043 R None 14:48:01 Tomorr 02:48 11:38:46 1 2
Wrap-up
§ Can isolate network by creating NAT or
bridge devices. What about IB?
§ Users can write as root on exposed RW
filesystems
§ Needs a local daemon running
§ Isn’t SLURM-friendly
§ Can run on multiple nodes with own tool
(Swarm)
§ Can use GPUs?
§ MPI?
§ Can run images on private registry
§ It shows all /dev, /sys and /proc to the
container environment. Easy
§ Users can write as their $USER on any
exposed RW filesystem
§ Does not need a local daemon on CN
§ Is SLURM-friendly (SPANK plugin)
§ Can run on multiple nodes with WLM
integration
§ Can use GPUs. Working on it!
§ MPI on its way!
§ Can run images on private registry
Shifter: Containers in HPC environments 19
Docker vs. Shifter
Docker
Conclusion
§ Shifter works very well on our HPC environment
§ It’s being constantly developed and new features are appearing on a weekly
basis
§ It’s open source and developed by the HPC community
§ It needs some additional work to cover basic HPC use cases (MPI)
§ Interacting with some parts of Shifter is not very user-friendly:
§ The process of pulling images is easy, but has no visual feedback
§ At times, error messages are difficult to understand
§ No ACLs yet
Shifter: Containers in HPC environments 20
Reference links
§ NERSC info: http://www.nersc.gov/research-and-development/user-defined-images/
§ The code: https://github.com/NERSC/shifter
Shifter: Containers in HPC environments 21
Questions?
Thank you for your attention.

More Related Content

What's hot

Introduction to Docker
Introduction to DockerIntroduction to Docker
Introduction to Docker
Luong Vo

Gitlab CI : Integration et Déploiement Continue
Gitlab CI : Integration et Déploiement ContinueGitlab CI : Integration et Déploiement Continue
Gitlab CI : Integration et Déploiement Continue
Vincent Composieux

Introduction to Docker
Introduction to DockerIntroduction to Docker
Introduction to Docker
Pubudu Jayawardana

Introduction to Git and Github
Introduction to Git and GithubIntroduction to Git and Github
Introduction to Git and Github
Roland Emmanuel Salunga

Ansible Automation to Rule Them All
Ansible Automation to Rule Them AllAnsible Automation to Rule Them All
Ansible Automation to Rule Them All
Tim Fairweather

Kafka Tutorial - DevOps, Admin and Ops
Kafka Tutorial - DevOps, Admin and OpsKafka Tutorial - DevOps, Admin and Ops
Kafka Tutorial - DevOps, Admin and Ops
Jean-Paul Azar

Why Docker
Why DockerWhy Docker
Why DockerdotCloud

Présentation Git & GitHub
Présentation Git & GitHubPrésentation Git & GitHub
Présentation Git & GitHub
Thibault Vlacich

oVirt and OpenStack
oVirt and OpenStackoVirt and OpenStack
oVirt and OpenStack
Dave Neary

Docker Compose by Aanand Prasad
Docker Compose by Aanand Prasad Docker Compose by Aanand Prasad
Docker Compose by Aanand Prasad
Docker, Inc.

Docker 101: An Introduction
Docker 101: An IntroductionDocker 101: An Introduction
Docker 101: An Introduction
POSSCON

OpenSCAP Overview(security scanning for docker image and container)
OpenSCAP Overview(security scanning for docker image and container)OpenSCAP Overview(security scanning for docker image and container)
OpenSCAP Overview(security scanning for docker image and container)
Jooho Lee

Introducción a Docker
Introducción a DockerIntroducción a Docker
Introducción a Docker
Open Canarias

A Hands-on Introduction to Docker
A Hands-on Introduction to DockerA Hands-on Introduction to Docker
A Hands-on Introduction to Docker
CodeOps Technologies LLP

GitLab for CI/CD process
GitLab for CI/CD processGitLab for CI/CD process
GitLab for CI/CD process
HYS Enterprise

Git Version Control System
Git Version Control SystemGit Version Control System
Git Version Control System
KMS Technology

Formation autour de git et git lab
Formation autour de git et git labFormation autour de git et git lab
Formation autour de git et git lab
Abdelghani Azri

containerD
containerDcontainerD
containerD
strikr .

版本控制 使用Git & git hub
版本控制   使用Git & git hub版本控制   使用Git & git hub
版本控制 使用Git & git hub維佋 唐


What's hot (20)

Introduction to Docker
Introduction to DockerIntroduction to Docker
Introduction to Docker

Gitlab CI : Integration et Déploiement Continue
Gitlab CI : Integration et Déploiement ContinueGitlab CI : Integration et Déploiement Continue
Gitlab CI : Integration et Déploiement Continue

Introduction to Docker
Introduction to DockerIntroduction to Docker
Introduction to Docker

Introduction to Git and Github
Introduction to Git and GithubIntroduction to Git and Github
Introduction to Git and Github

Ansible Automation to Rule Them All
Ansible Automation to Rule Them AllAnsible Automation to Rule Them All
Ansible Automation to Rule Them All

Kafka Tutorial - DevOps, Admin and Ops
Kafka Tutorial - DevOps, Admin and OpsKafka Tutorial - DevOps, Admin and Ops
Kafka Tutorial - DevOps, Admin and Ops

Why Docker
Why DockerWhy Docker
Why Docker

Présentation Git & GitHub
Présentation Git & GitHubPrésentation Git & GitHub
Présentation Git & GitHub

oVirt and OpenStack
oVirt and OpenStackoVirt and OpenStack
oVirt and OpenStack

Docker Compose by Aanand Prasad
Docker Compose by Aanand Prasad Docker Compose by Aanand Prasad
Docker Compose by Aanand Prasad

Docker 101: An Introduction
Docker 101: An IntroductionDocker 101: An Introduction
Docker 101: An Introduction

OpenSCAP Overview(security scanning for docker image and container)
OpenSCAP Overview(security scanning for docker image and container)OpenSCAP Overview(security scanning for docker image and container)
OpenSCAP Overview(security scanning for docker image and container)

Introducción a Docker
Introducción a DockerIntroducción a Docker
Introducción a Docker

A Hands-on Introduction to Docker
A Hands-on Introduction to DockerA Hands-on Introduction to Docker
A Hands-on Introduction to Docker

GitLab for CI/CD process
GitLab for CI/CD processGitLab for CI/CD process
GitLab for CI/CD process

Git Version Control System
Git Version Control SystemGit Version Control System
Git Version Control System

Doxygen
DoxygenDoxygen
Doxygen

Formation autour de git et git lab
Formation autour de git et git labFormation autour de git et git lab
Formation autour de git et git lab

containerD
containerDcontainerD
containerD

版本控制 使用Git & git hub
版本控制   使用Git & git hub版本控制   使用Git & git hub
版本控制 使用Git & git hub


Viewers also liked

Using Xeon + FPGA for Accelerating HPC Workloads
Using Xeon + FPGA for Accelerating HPC WorkloadsUsing Xeon + FPGA for Accelerating HPC Workloads
Using Xeon + FPGA for Accelerating HPC Workloads
inside-BigData.com

Containers and HPC
Containers and HPCContainers and HPC
Containers and HPC
Olli-Pekka Lehto

HPC in a Box - Docker Workshop at ISC 2015
HPC in a Box - Docker Workshop at ISC 2015HPC in a Box - Docker Workshop at ISC 2015
HPC in a Box - Docker Workshop at ISC 2015
inside-BigData.com

Docker for HPC in a Nutshell
Docker for HPC in a NutshellDocker for HPC in a Nutshell
Docker for HPC in a Nutshell
inside-BigData.com

HSA HSAIL Introduction Hot Chips 2013
HSA HSAIL Introduction  Hot Chips 2013 HSA HSAIL Introduction  Hot Chips 2013
HSA HSAIL Introduction Hot Chips 2013
HSA Foundation

On Docker and its use for LHC at CERN
On Docker and its use for LHC at CERNOn Docker and its use for LHC at CERN
On Docker and its use for LHC at CERN
Sebastien Goasguen

Streamlining HPC Workloads with Containers
Streamlining HPC Workloads with ContainersStreamlining HPC Workloads with Containers
Streamlining HPC Workloads with Containers
Dustin Kirkland

O que são Quantifiers
O que são Quantifiers O que são Quantifiers
O que são Quantifiers
Wesley Araújo

FPGAアクセラレータの作り方
FPGAアクセラレータの作り方FPGAアクセラレータの作り方
FPGAアクセラレータの作り方
Mr. Vengineer

Quantifiers
QuantifiersQuantifiers
Quantifiers
jeselen

Quantifiers
QuantifiersQuantifiers
Quantifierscarme73

Using Docker for GPU Accelerated Applications
Using Docker for GPU Accelerated ApplicationsUsing Docker for GPU Accelerated Applications
Using Docker for GPU Accelerated Applications
NVIDIA

Relative Pronouns
Relative PronounsRelative Pronouns
Relative Pronouns
JoshBCN


Viewers also liked (15)

Using Xeon + FPGA for Accelerating HPC Workloads
Using Xeon + FPGA for Accelerating HPC WorkloadsUsing Xeon + FPGA for Accelerating HPC Workloads
Using Xeon + FPGA for Accelerating HPC Workloads

Containers and HPC
Containers and HPCContainers and HPC
Containers and HPC

HPC in a Box - Docker Workshop at ISC 2015
HPC in a Box - Docker Workshop at ISC 2015HPC in a Box - Docker Workshop at ISC 2015
HPC in a Box - Docker Workshop at ISC 2015

Docker for HPC in a Nutshell
Docker for HPC in a NutshellDocker for HPC in a Nutshell
Docker for HPC in a Nutshell

HSA HSAIL Introduction Hot Chips 2013
HSA HSAIL Introduction  Hot Chips 2013 HSA HSAIL Introduction  Hot Chips 2013
HSA HSAIL Introduction Hot Chips 2013

On Docker and its use for LHC at CERN
On Docker and its use for LHC at CERNOn Docker and its use for LHC at CERN
On Docker and its use for LHC at CERN

Streamlining HPC Workloads with Containers
Streamlining HPC Workloads with ContainersStreamlining HPC Workloads with Containers
Streamlining HPC Workloads with Containers

O que são Quantifiers
O que são Quantifiers O que são Quantifiers
O que são Quantifiers

FPGAアクセラレータの作り方
FPGAアクセラレータの作り方FPGAアクセラレータの作り方
FPGAアクセラレータの作り方

Quantifiers
QuantifiersQuantifiers
Quantifiers

QUANTIFIERS
QUANTIFIERSQUANTIFIERS
QUANTIFIERS

Quantifiers
QuantifiersQuantifiers
Quantifiers

Quantifiers
QuantifiersQuantifiers
Quantifiers

Using Docker for GPU Accelerated Applications
Using Docker for GPU Accelerated ApplicationsUsing Docker for GPU Accelerated Applications
Using Docker for GPU Accelerated Applications

Relative Pronouns
Relative PronounsRelative Pronouns
Relative Pronouns


Similar to Shifter: Containers in HPC Environments

Présentation de Docker
Présentation de DockerPrésentation de Docker
Présentation de Docker
Proto204

Docker and the Container Ecosystem
Docker and the Container EcosystemDocker and the Container Ecosystem
Docker and the Container Ecosystem
psconnolly

Rooting Out Root: User namespaces in Docker
Rooting Out Root: User namespaces in DockerRooting Out Root: User namespaces in Docker
Rooting Out Root: User namespaces in Docker
Phil Estes

O'Reilly Software Architecture Conference London 2017: Building Resilient Mic...
O'Reilly Software Architecture Conference London 2017: Building Resilient Mic...O'Reilly Software Architecture Conference London 2017: Building Resilient Mic...
O'Reilly Software Architecture Conference London 2017: Building Resilient Mic...
Ambassador Labs

Introducing Docker
Introducing DockerIntroducing Docker
Introducing Docker
Francesco Pantano

ExpoQA 2017 Using docker to build and test in your laptop and Jenkins
ExpoQA 2017 Using docker to build and test in your laptop and JenkinsExpoQA 2017 Using docker to build and test in your laptop and Jenkins
ExpoQA 2017 Using docker to build and test in your laptop and Jenkins
ElasTest Project

Automate drupal deployments with linux containers, docker and vagrant
Automate drupal deployments with linux containers, docker and vagrant Automate drupal deployments with linux containers, docker and vagrant
Automate drupal deployments with linux containers, docker and vagrant Ricardo Amaro

Docker 1 0 1 0 1: a Docker introduction, actualized for the stable release of...
Docker 1 0 1 0 1: a Docker introduction, actualized for the stable release of...Docker 1 0 1 0 1: a Docker introduction, actualized for the stable release of...
Docker 1 0 1 0 1: a Docker introduction, actualized for the stable release of...
Jérôme Petazzoni

Introduction to Docker at the Azure Meet-up in New York
Introduction to Docker at the Azure Meet-up in New YorkIntroduction to Docker at the Azure Meet-up in New York
Introduction to Docker at the Azure Meet-up in New York
Jérôme Petazzoni

Docker Ecosystem on Azure
Docker Ecosystem on AzureDocker Ecosystem on Azure
Docker Ecosystem on Azure
Patrick Chanezon

Docker - A Ruby Introduction
Docker - A Ruby IntroductionDocker - A Ruby Introduction
Docker - A Ruby Introduction
Tyler Johnston

Docker for mere mortals
Docker for mere mortalsDocker for mere mortals
Docker for mere mortals
Henryk Konsek

JDD2014: Docker.io - versioned linux containers for JVM devops - Dominik Dorn
JDD2014: Docker.io - versioned linux containers for JVM devops - Dominik DornJDD2014: Docker.io - versioned linux containers for JVM devops - Dominik Dorn
JDD2014: Docker.io - versioned linux containers for JVM devops - Dominik Dorn
PROIDEA

Linux containers & Devops
Linux containers & DevopsLinux containers & Devops
Linux containers & Devops
Maciej Lasyk

Powercoders · Docker · Fall 2021.pptx
Powercoders · Docker · Fall 2021.pptxPowercoders · Docker · Fall 2021.pptx
Powercoders · Docker · Fall 2021.pptx
IgnacioTamayo2

Dockerizing a Symfony2 application
Dockerizing a Symfony2 applicationDockerizing a Symfony2 application
Dockerizing a Symfony2 application
Roman Rodomansky

Docker Intro
Docker IntroDocker Intro
Docker Intro
Ruben Taelman

Docker 1.11 Presentation
Docker 1.11 PresentationDocker 1.11 Presentation
Docker 1.11 Presentation
Sreenivas Makam

Real-World Docker: 10 Things We've Learned
Real-World Docker: 10 Things We've Learned  Real-World Docker: 10 Things We've Learned
Real-World Docker: 10 Things We've Learned
RightScale

Docker and friends at Linux Days 2014 in Prague
Docker and friends at Linux Days 2014 in PragueDocker and friends at Linux Days 2014 in Prague
Docker and friends at Linux Days 2014 in Prague
tomasbart


Similar to Shifter: Containers in HPC Environments (20)

Présentation de Docker
Présentation de DockerPrésentation de Docker
Présentation de Docker

Docker and the Container Ecosystem
Docker and the Container EcosystemDocker and the Container Ecosystem
Docker and the Container Ecosystem

Rooting Out Root: User namespaces in Docker
Rooting Out Root: User namespaces in DockerRooting Out Root: User namespaces in Docker
Rooting Out Root: User namespaces in Docker

O'Reilly Software Architecture Conference London 2017: Building Resilient Mic...
O'Reilly Software Architecture Conference London 2017: Building Resilient Mic...O'Reilly Software Architecture Conference London 2017: Building Resilient Mic...
O'Reilly Software Architecture Conference London 2017: Building Resilient Mic...

Introducing Docker
Introducing DockerIntroducing Docker
Introducing Docker

ExpoQA 2017 Using docker to build and test in your laptop and Jenkins
ExpoQA 2017 Using docker to build and test in your laptop and JenkinsExpoQA 2017 Using docker to build and test in your laptop and Jenkins
ExpoQA 2017 Using docker to build and test in your laptop and Jenkins

Automate drupal deployments with linux containers, docker and vagrant
Automate drupal deployments with linux containers, docker and vagrant Automate drupal deployments with linux containers, docker and vagrant
Automate drupal deployments with linux containers, docker and vagrant

Docker 1 0 1 0 1: a Docker introduction, actualized for the stable release of...
Docker 1 0 1 0 1: a Docker introduction, actualized for the stable release of...Docker 1 0 1 0 1: a Docker introduction, actualized for the stable release of...
Docker 1 0 1 0 1: a Docker introduction, actualized for the stable release of...

Introduction to Docker at the Azure Meet-up in New York
Introduction to Docker at the Azure Meet-up in New YorkIntroduction to Docker at the Azure Meet-up in New York
Introduction to Docker at the Azure Meet-up in New York

Docker Ecosystem on Azure
Docker Ecosystem on AzureDocker Ecosystem on Azure
Docker Ecosystem on Azure

Docker - A Ruby Introduction
Docker - A Ruby IntroductionDocker - A Ruby Introduction
Docker - A Ruby Introduction

Docker for mere mortals
Docker for mere mortalsDocker for mere mortals
Docker for mere mortals

JDD2014: Docker.io - versioned linux containers for JVM devops - Dominik Dorn
JDD2014: Docker.io - versioned linux containers for JVM devops - Dominik DornJDD2014: Docker.io - versioned linux containers for JVM devops - Dominik Dorn
JDD2014: Docker.io - versioned linux containers for JVM devops - Dominik Dorn

Linux containers & Devops
Linux containers & DevopsLinux containers & Devops
Linux containers & Devops

Powercoders · Docker · Fall 2021.pptx
Powercoders · Docker · Fall 2021.pptxPowercoders · Docker · Fall 2021.pptx
Powercoders · Docker · Fall 2021.pptx

Dockerizing a Symfony2 application
Dockerizing a Symfony2 applicationDockerizing a Symfony2 application
Dockerizing a Symfony2 application

Docker Intro
Docker IntroDocker Intro
Docker Intro

Docker 1.11 Presentation
Docker 1.11 PresentationDocker 1.11 Presentation
Docker 1.11 Presentation

Real-World Docker: 10 Things We've Learned
Real-World Docker: 10 Things We've Learned  Real-World Docker: 10 Things We've Learned
Real-World Docker: 10 Things We've Learned

Docker and friends at Linux Days 2014 in Prague
Docker and friends at Linux Days 2014 in PragueDocker and friends at Linux Days 2014 in Prague
Docker and friends at Linux Days 2014 in Prague


More from inside-BigData.com

Major Market Shifts in IT
Major Market Shifts in ITMajor Market Shifts in IT
Major Market Shifts in IT
inside-BigData.com

Preparing to program Aurora at Exascale - Early experiences and future direct...
Preparing to program Aurora at Exascale - Early experiences and future direct...Preparing to program Aurora at Exascale - Early experiences and future direct...
Preparing to program Aurora at Exascale - Early experiences and future direct...
inside-BigData.com

Transforming Private 5G Networks
Transforming Private 5G NetworksTransforming Private 5G Networks
Transforming Private 5G Networks
inside-BigData.com

The Incorporation of Machine Learning into Scientific Simulations at Lawrence...
The Incorporation of Machine Learning into Scientific Simulations at Lawrence...The Incorporation of Machine Learning into Scientific Simulations at Lawrence...
The Incorporation of Machine Learning into Scientific Simulations at Lawrence...
inside-BigData.com

How to Achieve High-Performance, Scalable and Distributed DNN Training on Mod...
How to Achieve High-Performance, Scalable and Distributed DNN Training on Mod...How to Achieve High-Performance, Scalable and Distributed DNN Training on Mod...
How to Achieve High-Performance, Scalable and Distributed DNN Training on Mod...
inside-BigData.com

Evolving Cyberinfrastructure, Democratizing Data, and Scaling AI to Catalyze ...
Evolving Cyberinfrastructure, Democratizing Data, and Scaling AI to Catalyze ...Evolving Cyberinfrastructure, Democratizing Data, and Scaling AI to Catalyze ...
Evolving Cyberinfrastructure, Democratizing Data, and Scaling AI to Catalyze ...
inside-BigData.com

HPC Impact: EDA Telemetry Neural Networks
HPC Impact: EDA Telemetry Neural NetworksHPC Impact: EDA Telemetry Neural Networks
HPC Impact: EDA Telemetry Neural Networks
inside-BigData.com

Biohybrid Robotic Jellyfish for Future Applications in Ocean Monitoring
Biohybrid Robotic Jellyfish for Future Applications in Ocean MonitoringBiohybrid Robotic Jellyfish for Future Applications in Ocean Monitoring
Biohybrid Robotic Jellyfish for Future Applications in Ocean Monitoring
inside-BigData.com

Machine Learning for Weather Forecasts
Machine Learning for Weather ForecastsMachine Learning for Weather Forecasts
Machine Learning for Weather Forecasts
inside-BigData.com

HPC AI Advisory Council Update
HPC AI Advisory Council UpdateHPC AI Advisory Council Update
HPC AI Advisory Council Update
inside-BigData.com

Fugaku Supercomputer joins fight against COVID-19
Fugaku Supercomputer joins fight against COVID-19Fugaku Supercomputer joins fight against COVID-19
Fugaku Supercomputer joins fight against COVID-19
inside-BigData.com

Energy Efficient Computing using Dynamic Tuning
Energy Efficient Computing using Dynamic TuningEnergy Efficient Computing using Dynamic Tuning
Energy Efficient Computing using Dynamic Tuning
inside-BigData.com

HPC at Scale Enabled by DDN A3i and NVIDIA SuperPOD
HPC at Scale Enabled by DDN A3i and NVIDIA SuperPODHPC at Scale Enabled by DDN A3i and NVIDIA SuperPOD
HPC at Scale Enabled by DDN A3i and NVIDIA SuperPOD
inside-BigData.com

State of ARM-based HPC
State of ARM-based HPCState of ARM-based HPC
State of ARM-based HPC
inside-BigData.com

Versal Premium ACAP for Network and Cloud Acceleration
Versal Premium ACAP for Network and Cloud AccelerationVersal Premium ACAP for Network and Cloud Acceleration
Versal Premium ACAP for Network and Cloud Acceleration
inside-BigData.com

Zettar: Moving Massive Amounts of Data across Any Distance Efficiently
Zettar: Moving Massive Amounts of Data across Any Distance EfficientlyZettar: Moving Massive Amounts of Data across Any Distance Efficiently
Zettar: Moving Massive Amounts of Data across Any Distance Efficiently
inside-BigData.com

Scaling TCO in a Post Moore's Era
Scaling TCO in a Post Moore's EraScaling TCO in a Post Moore's Era
Scaling TCO in a Post Moore's Era
inside-BigData.com

CUDA-Python and RAPIDS for blazing fast scientific computing
CUDA-Python and RAPIDS for blazing fast scientific computingCUDA-Python and RAPIDS for blazing fast scientific computing
CUDA-Python and RAPIDS for blazing fast scientific computing
inside-BigData.com

Introducing HPC with a Raspberry Pi Cluster
Introducing HPC with a Raspberry Pi ClusterIntroducing HPC with a Raspberry Pi Cluster
Introducing HPC with a Raspberry Pi Cluster
inside-BigData.com

Overview of HPC Interconnects
Overview of HPC InterconnectsOverview of HPC Interconnects
Overview of HPC Interconnects
inside-BigData.com


More from inside-BigData.com (20)

Major Market Shifts in IT
Major Market Shifts in ITMajor Market Shifts in IT
Major Market Shifts in IT

Preparing to program Aurora at Exascale - Early experiences and future direct...
Preparing to program Aurora at Exascale - Early experiences and future direct...Preparing to program Aurora at Exascale - Early experiences and future direct...
Preparing to program Aurora at Exascale - Early experiences and future direct...

Transforming Private 5G Networks
Transforming Private 5G NetworksTransforming Private 5G Networks
Transforming Private 5G Networks

The Incorporation of Machine Learning into Scientific Simulations at Lawrence...
The Incorporation of Machine Learning into Scientific Simulations at Lawrence...The Incorporation of Machine Learning into Scientific Simulations at Lawrence...
The Incorporation of Machine Learning into Scientific Simulations at Lawrence...

How to Achieve High-Performance, Scalable and Distributed DNN Training on Mod...
How to Achieve High-Performance, Scalable and Distributed DNN Training on Mod...How to Achieve High-Performance, Scalable and Distributed DNN Training on Mod...
How to Achieve High-Performance, Scalable and Distributed DNN Training on Mod...

Evolving Cyberinfrastructure, Democratizing Data, and Scaling AI to Catalyze ...
Evolving Cyberinfrastructure, Democratizing Data, and Scaling AI to Catalyze ...Evolving Cyberinfrastructure, Democratizing Data, and Scaling AI to Catalyze ...
Evolving Cyberinfrastructure, Democratizing Data, and Scaling AI to Catalyze ...

HPC Impact: EDA Telemetry Neural Networks
HPC Impact: EDA Telemetry Neural NetworksHPC Impact: EDA Telemetry Neural Networks
HPC Impact: EDA Telemetry Neural Networks

Biohybrid Robotic Jellyfish for Future Applications in Ocean Monitoring
Biohybrid Robotic Jellyfish for Future Applications in Ocean MonitoringBiohybrid Robotic Jellyfish for Future Applications in Ocean Monitoring
Biohybrid Robotic Jellyfish for Future Applications in Ocean Monitoring

Machine Learning for Weather Forecasts
Machine Learning for Weather ForecastsMachine Learning for Weather Forecasts
Machine Learning for Weather Forecasts

HPC AI Advisory Council Update
HPC AI Advisory Council UpdateHPC AI Advisory Council Update
HPC AI Advisory Council Update

Fugaku Supercomputer joins fight against COVID-19
Fugaku Supercomputer joins fight against COVID-19Fugaku Supercomputer joins fight against COVID-19
Fugaku Supercomputer joins fight against COVID-19

Energy Efficient Computing using Dynamic Tuning
Energy Efficient Computing using Dynamic TuningEnergy Efficient Computing using Dynamic Tuning
Energy Efficient Computing using Dynamic Tuning

HPC at Scale Enabled by DDN A3i and NVIDIA SuperPOD
HPC at Scale Enabled by DDN A3i and NVIDIA SuperPODHPC at Scale Enabled by DDN A3i and NVIDIA SuperPOD
HPC at Scale Enabled by DDN A3i and NVIDIA SuperPOD

State of ARM-based HPC
State of ARM-based HPCState of ARM-based HPC
State of ARM-based HPC

Versal Premium ACAP for Network and Cloud Acceleration
Versal Premium ACAP for Network and Cloud AccelerationVersal Premium ACAP for Network and Cloud Acceleration
Versal Premium ACAP for Network and Cloud Acceleration

Zettar: Moving Massive Amounts of Data across Any Distance Efficiently
Zettar: Moving Massive Amounts of Data across Any Distance EfficientlyZettar: Moving Massive Amounts of Data across Any Distance Efficiently
Zettar: Moving Massive Amounts of Data across Any Distance Efficiently

Scaling TCO in a Post Moore's Era
Scaling TCO in a Post Moore's EraScaling TCO in a Post Moore's Era
Scaling TCO in a Post Moore's Era

CUDA-Python and RAPIDS for blazing fast scientific computing
CUDA-Python and RAPIDS for blazing fast scientific computingCUDA-Python and RAPIDS for blazing fast scientific computing
CUDA-Python and RAPIDS for blazing fast scientific computing

Introducing HPC with a Raspberry Pi Cluster
Introducing HPC with a Raspberry Pi ClusterIntroducing HPC with a Raspberry Pi Cluster
Introducing HPC with a Raspberry Pi Cluster

Overview of HPC Interconnects
Overview of HPC InterconnectsOverview of HPC Interconnects
Overview of HPC Interconnects


Recently uploaded

The Future of Platform Engineering
The Future of Platform EngineeringThe Future of Platform Engineering
The Future of Platform Engineering
Jemma Hussein Allen

20240605 QFM017 Machine Intelligence Reading List May 2024
20240605 QFM017 Machine Intelligence Reading List May 202420240605 QFM017 Machine Intelligence Reading List May 2024
20240605 QFM017 Machine Intelligence Reading List May 2024
Matthew Sinclair

GraphRAG is All You need? LLM & Knowledge Graph
GraphRAG is All You need? LLM & Knowledge GraphGraphRAG is All You need? LLM & Knowledge Graph
GraphRAG is All You need? LLM & Knowledge Graph
Guy Korland

By Design, not by Accident - Agile Venture Bolzano 2024
By Design, not by Accident - Agile Venture Bolzano 2024By Design, not by Accident - Agile Venture Bolzano 2024
By Design, not by Accident - Agile Venture Bolzano 2024
Pierluigi Pugliese

GraphSummit Singapore | Graphing Success: Revolutionising Organisational Stru...
GraphSummit Singapore | Graphing Success: Revolutionising Organisational Stru...GraphSummit Singapore | Graphing Success: Revolutionising Organisational Stru...
GraphSummit Singapore | Graphing Success: Revolutionising Organisational Stru...
Neo4j

LF Energy Webinar: Electrical Grid Modelling and Simulation Through PowSyBl -...
LF Energy Webinar: Electrical Grid Modelling and Simulation Through PowSyBl -...LF Energy Webinar: Electrical Grid Modelling and Simulation Through PowSyBl -...
LF Energy Webinar: Electrical Grid Modelling and Simulation Through PowSyBl -...
DanBrown980551

Free Complete Python - A step towards Data Science
Free Complete Python - A step towards Data ScienceFree Complete Python - A step towards Data Science
Free Complete Python - A step towards Data Science
RinaMondal9

Transcript: Selling digital books in 2024: Insights from industry leaders - T...
Transcript: Selling digital books in 2024: Insights from industry leaders - T...Transcript: Selling digital books in 2024: Insights from industry leaders - T...
Transcript: Selling digital books in 2024: Insights from industry leaders - T...
BookNet Canada

Pushing the limits of ePRTC: 100ns holdover for 100 days
Pushing the limits of ePRTC: 100ns holdover for 100 daysPushing the limits of ePRTC: 100ns holdover for 100 days
Pushing the limits of ePRTC: 100ns holdover for 100 days
Adtran

FIDO Alliance Osaka Seminar: Passkeys and the Road Ahead.pdf
FIDO Alliance Osaka Seminar: Passkeys and the Road Ahead.pdfFIDO Alliance Osaka Seminar: Passkeys and the Road Ahead.pdf
FIDO Alliance Osaka Seminar: Passkeys and the Road Ahead.pdf
FIDO Alliance

A tale of scale & speed: How the US Navy is enabling software delivery from l...
A tale of scale & speed: How the US Navy is enabling software delivery from l...A tale of scale & speed: How the US Navy is enabling software delivery from l...
A tale of scale & speed: How the US Navy is enabling software delivery from l...
sonjaschweigert1

GraphSummit Singapore | The Art of the Possible with Graph - Q2 2024
GraphSummit Singapore | The Art of the  Possible with Graph - Q2 2024GraphSummit Singapore | The Art of the  Possible with Graph - Q2 2024
GraphSummit Singapore | The Art of the Possible with Graph - Q2 2024
Neo4j

GraphSummit Singapore | Enhancing Changi Airport Group's Passenger Experience...
GraphSummit Singapore | Enhancing Changi Airport Group's Passenger Experience...GraphSummit Singapore | Enhancing Changi Airport Group's Passenger Experience...
GraphSummit Singapore | Enhancing Changi Airport Group's Passenger Experience...
Neo4j

GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...
GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...
GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...
Neo4j

Observability Concepts EVERY Developer Should Know -- DeveloperWeek Europe.pdf
Observability Concepts EVERY Developer Should Know -- DeveloperWeek Europe.pdfObservability Concepts EVERY Developer Should Know -- DeveloperWeek Europe.pdf
Observability Concepts EVERY Developer Should Know -- DeveloperWeek Europe.pdf
Paige Cruz

The Art of the Pitch: WordPress Relationships and Sales
The Art of the Pitch: WordPress Relationships and SalesThe Art of the Pitch: WordPress Relationships and Sales
The Art of the Pitch: WordPress Relationships and Sales
Laura Byrne

Securing your Kubernetes cluster_ a step-by-step guide to success !
Securing your Kubernetes cluster_ a step-by-step guide to success !Securing your Kubernetes cluster_ a step-by-step guide to success !
Securing your Kubernetes cluster_ a step-by-step guide to success !
KatiaHIMEUR1

FIDO Alliance Osaka Seminar: FIDO Security Aspects.pdf
FIDO Alliance Osaka Seminar: FIDO Security Aspects.pdfFIDO Alliance Osaka Seminar: FIDO Security Aspects.pdf
FIDO Alliance Osaka Seminar: FIDO Security Aspects.pdf
FIDO Alliance

GDG Cloud Southlake #33: Boule & Rebala: Effective AppSec in SDLC using Deplo...
GDG Cloud Southlake #33: Boule & Rebala: Effective AppSec in SDLC using Deplo...GDG Cloud Southlake #33: Boule & Rebala: Effective AppSec in SDLC using Deplo...
GDG Cloud Southlake #33: Boule & Rebala: Effective AppSec in SDLC using Deplo...
James Anderson

PHP Frameworks: I want to break free (IPC Berlin 2024)
PHP Frameworks: I want to break free (IPC Berlin 2024)PHP Frameworks: I want to break free (IPC Berlin 2024)
PHP Frameworks: I want to break free (IPC Berlin 2024)
Ralf Eggert


Recently uploaded (20)

The Future of Platform Engineering
The Future of Platform EngineeringThe Future of Platform Engineering
The Future of Platform Engineering

20240605 QFM017 Machine Intelligence Reading List May 2024
20240605 QFM017 Machine Intelligence Reading List May 202420240605 QFM017 Machine Intelligence Reading List May 2024
20240605 QFM017 Machine Intelligence Reading List May 2024

GraphRAG is All You need? LLM & Knowledge Graph
GraphRAG is All You need? LLM & Knowledge GraphGraphRAG is All You need? LLM & Knowledge Graph
GraphRAG is All You need? LLM & Knowledge Graph

By Design, not by Accident - Agile Venture Bolzano 2024
By Design, not by Accident - Agile Venture Bolzano 2024By Design, not by Accident - Agile Venture Bolzano 2024
By Design, not by Accident - Agile Venture Bolzano 2024

GraphSummit Singapore | Graphing Success: Revolutionising Organisational Stru...
GraphSummit Singapore | Graphing Success: Revolutionising Organisational Stru...GraphSummit Singapore | Graphing Success: Revolutionising Organisational Stru...
GraphSummit Singapore | Graphing Success: Revolutionising Organisational Stru...

LF Energy Webinar: Electrical Grid Modelling and Simulation Through PowSyBl -...
LF Energy Webinar: Electrical Grid Modelling and Simulation Through PowSyBl -...LF Energy Webinar: Electrical Grid Modelling and Simulation Through PowSyBl -...
LF Energy Webinar: Electrical Grid Modelling and Simulation Through PowSyBl -...

Free Complete Python - A step towards Data Science
Free Complete Python - A step towards Data ScienceFree Complete Python - A step towards Data Science
Free Complete Python - A step towards Data Science

Transcript: Selling digital books in 2024: Insights from industry leaders - T...
Transcript: Selling digital books in 2024: Insights from industry leaders - T...Transcript: Selling digital books in 2024: Insights from industry leaders - T...
Transcript: Selling digital books in 2024: Insights from industry leaders - T...

Pushing the limits of ePRTC: 100ns holdover for 100 days
Pushing the limits of ePRTC: 100ns holdover for 100 daysPushing the limits of ePRTC: 100ns holdover for 100 days
Pushing the limits of ePRTC: 100ns holdover for 100 days

FIDO Alliance Osaka Seminar: Passkeys and the Road Ahead.pdf
FIDO Alliance Osaka Seminar: Passkeys and the Road Ahead.pdfFIDO Alliance Osaka Seminar: Passkeys and the Road Ahead.pdf
FIDO Alliance Osaka Seminar: Passkeys and the Road Ahead.pdf

A tale of scale & speed: How the US Navy is enabling software delivery from l...
A tale of scale & speed: How the US Navy is enabling software delivery from l...A tale of scale & speed: How the US Navy is enabling software delivery from l...
A tale of scale & speed: How the US Navy is enabling software delivery from l...

GraphSummit Singapore | The Art of the Possible with Graph - Q2 2024
GraphSummit Singapore | The Art of the  Possible with Graph - Q2 2024GraphSummit Singapore | The Art of the  Possible with Graph - Q2 2024
GraphSummit Singapore | The Art of the Possible with Graph - Q2 2024

GraphSummit Singapore | Enhancing Changi Airport Group's Passenger Experience...
GraphSummit Singapore | Enhancing Changi Airport Group's Passenger Experience...GraphSummit Singapore | Enhancing Changi Airport Group's Passenger Experience...
GraphSummit Singapore | Enhancing Changi Airport Group's Passenger Experience...

GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...
GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...
GraphSummit Singapore | The Future of Agility: Supercharging Digital Transfor...

Observability Concepts EVERY Developer Should Know -- DeveloperWeek Europe.pdf
Observability Concepts EVERY Developer Should Know -- DeveloperWeek Europe.pdfObservability Concepts EVERY Developer Should Know -- DeveloperWeek Europe.pdf
Observability Concepts EVERY Developer Should Know -- DeveloperWeek Europe.pdf

The Art of the Pitch: WordPress Relationships and Sales
The Art of the Pitch: WordPress Relationships and SalesThe Art of the Pitch: WordPress Relationships and Sales
The Art of the Pitch: WordPress Relationships and Sales

Securing your Kubernetes cluster_ a step-by-step guide to success !
Securing your Kubernetes cluster_ a step-by-step guide to success !Securing your Kubernetes cluster_ a step-by-step guide to success !
Securing your Kubernetes cluster_ a step-by-step guide to success !

FIDO Alliance Osaka Seminar: FIDO Security Aspects.pdf
FIDO Alliance Osaka Seminar: FIDO Security Aspects.pdfFIDO Alliance Osaka Seminar: FIDO Security Aspects.pdf
FIDO Alliance Osaka Seminar: FIDO Security Aspects.pdf

GDG Cloud Southlake #33: Boule & Rebala: Effective AppSec in SDLC using Deplo...
GDG Cloud Southlake #33: Boule & Rebala: Effective AppSec in SDLC using Deplo...GDG Cloud Southlake #33: Boule & Rebala: Effective AppSec in SDLC using Deplo...
GDG Cloud Southlake #33: Boule & Rebala: Effective AppSec in SDLC using Deplo...

PHP Frameworks: I want to break free (IPC Berlin 2024)
PHP Frameworks: I want to break free (IPC Berlin 2024)PHP Frameworks: I want to break free (IPC Berlin 2024)
PHP Frameworks: I want to break free (IPC Berlin 2024)


Shifter: Containers in HPC Environments

  • 1. Shifter: Containers in HPC environments HPC Advisory Council Switzerland Miguel Gila, CSCS March 21, 2016
  • 3. What is Docker and how does it work? § “Docker containers wrap up a piece of software in a complete filesystem that contains everything it needs to run: code, runtime, system tools, system libraries – anything you can install on a server. This guarantees that it will always run the same, regardless of the environment it is running in.” [*] Shifter: Containers in HPC environments 3 Virtual Machines Containers [*] https://www.docker.com/what-docker [*] [*]
  • 4. What is Docker and how does it work? § A Docker image is a file that contains a filesystem within it. It can be a full filesystem (i.e. CentOS) or partial (i.e. python3.4-slim). Images are stored either on a public registry (Docker hub) or private § Docker leverages the namespaces feature of the kernel to isolate processes § On its simplest form, Docker basically 1. Pulls an image to the local system 2. Creates a chrooted environment with the image (=container) 3. Runs our application in the container (’isolated’ from the host thanks to kernel namespaces) § However, it can also do other things: § Isolate network by creating NAT or bridge devices § Can use a nice GUI Shifter: Containers in HPC environments 4
  • 5. Docker in HPC environments § Docker is a nice tool, but it’s not built for HPC environments, because: § Does not integrate well with workload managers § Does not isolate users on shared filesystems § Requires running a daemon on all nodes § Not designed to run on diskless clients § Network is, by default, ‘NATed’ § Building Docker is done within a Docker container. It can be done outside, but is a complex task (Go language, seriously??) § But after all, a sysadmin can make anything to work on a cluster, right? § We can create (and hopefully maintain) monstrous wrappers to run Docker containers… Shifter: Containers in HPC environments 5
  • 7. What is Shifter and how does it work? § Shifter is a container-based solution thought from the ground up for HPC environments § It leverages the current Docker environment and can use Docker images to create containers § Shifter basically 1. Pulls an image to a shared location (/scratch) 2. Creates a loop device with the image (=container) 3. Creates a chrooted environment on the loop device 4. Runs our application in chrooted environment § Designed to work on HPC clusters and, particularly, on Cray systems § It is possible to choose which filesystems to expose to the containers Shifter: Containers in HPC environments 7
  • 8. External nodeCompute node Architecture of Shifter § Shifter consists on two parts § udiRoot is responsible for creating the loop devices, doing chroot and cleaning up after the binary execution is done. Workload manager plugins are available. Written in C § imageGateway is responsible for fetching a Docker image, converting it to a squashfs file and transfer it to a shared location on a filesystem. It also keeps track of the images and tells udiRoot which are available. Written in Python Shifter: Containers in HPC environments 8 scratch udiRoot imageGateway query restful API db Docker Hub Or private registry
  • 9. Workflow 1. User creates an image on his/her computer and pushes it to Docker Hub Shifter: Containers in HPC environments 9 Docker image 1 2 $ docker build . Uploading context 10240 bytes Step 1 : FROM busybox Pulling repository busybox ---> e9aa60c60128MB/2.284 MB (100%) endpoint: https://cdn-registry- 1.docker.io/v1/ Step 2 : RUN ls -lh / ---> Running in 9c9e81692ae9 total 24 drwxr-xr-x 2 root root 4.0K Mar 12 2013 bin drwxr-xr-x 5 root root 4.0K Oct 19 00:19 dev drwxr-xr-x 2 root root 4.0K Oct 19 00:19 etc drwxr-xr-x 2 root root 4.0K Nov 15 23:34 lib lrwxrwxrwx 1 root root 3 Mar 12 2013 lib64 -> lib dr-xr-xr-x 116 root root 0 Nov 15 23:34 proc lrwxrwxrwx 1 root root 3 Mar 12 2013 sbin -> bin dr-xr-xr-x 13 root root 0 Nov 15 23:34 sys drwxr-xr-x 2 root root 4.0K Mar 12 2013 tmp drwxr-xr-x 2 root root 4.0K Nov 15 23:34 usr ---> b35f4035db3f Step 3 : CMD echo Hello world ---> Running in 02071fceb21b ---> f52f38b7823e Successfully built f52f38b7823e Removing intermediate container 9c9e81692ae9 Removing intermediate container 02071fceb21b docker build docker push $ docker push miguelgila/wlcg_wn:20161212 Docker Hub Or private registry
  • 10. Workflow 1. User creates an image on his/her computer and pushes it to Docker Hub 2. User tells imageGateway to pull his image and make it available Shifter: Containers in HPC environments 10 $ ssh santis01 $ module load shifter $ shifterimg pull docker:ubuntu:14.04 $ sleep 300 # :-) $ shifterimg images santis docker READY 2934337e50 2015-12-10T09:03:38 python:2.7-slim santis docker READY a4f04f71be 2015-12-10T09:47:17 python:3.5-slim santis docker READY b0197931ac 2015-12-10T09:53:54 python:3.2-slim santis docker READY 0bb6b50d84 2015-12-10T10:34:24 python:3.3-slim santis docker READY cd86406b32 2015-12-10T10:36:55 python:3.5.1 santis docker READY 48bc52cc28 2015-12-10T10:47:35 python:3.4.3 santis docker READY 0b92f1735f 2015-12-10T11:17:26 python:3.4-slim santis docker READY 3fba104814 2015-12-10T11:31:23 centos:6.7 santis docker READY 12c9d795d8 2015-12-10T11:37:35 centos:6.6 santis docker READY 3e0c71ada2 2015-12-10T15:19:24 ubuntu:15.10 santis docker READY e751d10964 2015-12-10T13:38:05 miguelgila/wlcg_wn:20151125v2 santis docker READY d55e68e6cc 2015-12-10T15:52:09 ubuntu:14.04 shifterimg pull /scratch/ santis imageGateway 1 2 3 4 Docker image Shifter image Shifter image Docker Hub Or private registry
  • 11. Compute node Workflow 1. User creates an image on his/her computer and pushes it to Docker Hub 2. User tells imageGateway to pull his image and make it available 3. User runs SBATCH and prepends shifter to his/her executable Shifter: Containers in HPC environments 11 #!/bin/bash –l #SBATCH --job-name="shifter_osversion” #SBATCH --nodes=1 #SBATCH --ntasks-per-node=1 #SBATCH --time=00:30:00 #SBATCH --exclusive #SBATCH --output=/users/miguelgi/jobs/out/shifter_hostname.stdout.log.%j #SBATCH --error=/users/miguelgi/jobs/out/shifter_hostname.stdout.log.%j #SBATCH --image=docker:miguelgila/wlcg_wn:20151218 #SBATCH --imagevolume=/users/miguelgi:/users/miguelgi #SBATCH --imagevolume=/apps:/apps #SBATCH --imagevolume=/scratch/santis:/scratch/santis module load slurm module load shifter/15.12.0 srun shifter --volume=/scratch/santis:/scratch/santis --volume=/users:/users cat /etc/redhat-release sbatch /scratch/ santis SRUN/SPANK 1 3 udiRoot Loop device /dev/loopY Shifter image Create loop dev shifter binary Run bin in loop dev /users 2
  • 13. Full OS containers § Cray compute nodes run CLE (a version of SLES 11) § With Shifter it is possible to run applications built for specific OS: Shifter: Containers in HPC environments 13 [miguelgi@santis01]-[11:34:45]-[~/examples]:-($ salloc -t 00:15:00 -N1 --image=docker:centos:6.7 salloc: Granted job allocation 16313 salloc: Waiting for resource configuration salloc: Nodes nid00012 are ready for job [miguelgi@santis01]-[11:34:50]-[~/examples]:-)$ srun shifter cat /etc/redhat-release CentOS release 6.7 (Final) [miguelgi@santis01]-[11:35:03]-[~/examples]:-)$ srun shifter yum --version |head -4 3.2.29 Installed: rpm-4.8.0-47.el6.x86_64 at 2015-08-19 18:25 Built : CentOS BuildSystem <http://bugs.centos.org> at 2015-07-24 11:28 Committed: Lubos Kardos <lkardos@redhat.com> at 2015-06-15 CentOS 6 – non-interactive session [miguelgi@santis01]-[10:52:40]-[~/examples]:-)$ salloc -t 00:15:00 -N1 --image=docker:debian:7.9 salloc: Granted job allocation 16294 salloc: Waiting for resource configuration salloc: Nodes nid00012 are ready for job [miguelgi@santis01]-[10:58:29]-[~/examples]:-($ srun --pty shifter /bin/bash [miguelgi@nid00012]-[10:58:31]-[~/examples]:-)$ cat /etc/debian_version 7.9 [miguelgi@nid00012]-[10:58:33]-[~/examples]:-)$ uname –a Linux nid00012 3.0.101-0.46.1_1.0502.8871-cray_ari_c #1 SMP Tue Aug 25 21:41:26 UTC 2015 x86_64 GNU/Linux [miguelgi@nid00012]-[10:59:46]-[~/examples]:-)$ apt-get --version |head -n1 apt 0.9.7.9 for amd64 compiled on Oct 17 2014 09:15:56 Debian 7.9 – interactive session
  • 14. Application containers: Python/Ruby Shifter: Containers in HPC environments 14 [miguelgi@santis01]-[09:57:23]-[~]:-)$ salloc -t 01:00:00 -n1 --image=docker:python:3.5.1 salloc: Granted job allocation 16274 salloc: Waiting for resource configuration salloc: Nodes nid00012 are ready for job [miguelgi@santis01]-[10:00:51]-[~]:-)$ srun --pty shifter /bin/bash [miguelgi@nid00012]-[09:01:04]-[~]:-)$ python –V Python 3.5.1 [miguelgi@nid00012]-[09:01:08]-[~]:-)$ which python /usr/local/bin/python Python 3.5.1 – interactive session [miguelgi@santis01]-[10:16:35]-[~]:-)$ salloc -t 01:00:00 -n1 --image=docker:python:3.2-slim salloc: Granted job allocation 16278 salloc: Waiting for resource configuration salloc: Nodes nid00012 are ready for job [miguelgi@santis01]-[10:19:34]-[~/tmp]:-)$ srun shifter ./myscript.py 3.2.6 Python 3.2 – non-interactive session $ cat myscript.py #! /usr/bin/env python import platformprint(platform.python_version()) myscript.py [miguelgi@santis01]-[09:57:23]-[~]:-)$ salloc -t 01:00:00 -n1 --image=docker:ruby:2.1.8 salloc: Granted job allocation 16280 salloc: Waiting for resource configuration salloc: Nodes nid00012 are ready for job [miguelgi@santis01]-[10:22:14]-[~]:-)$ srun --pty shifter /bin/bash miguelgi@nid00012]-[09:22:28]-[~]:-)$ ruby –v ruby 2.1.8p440 (2015-12-16 revision 53160) [x86_64-linux Ruby 2.1.8 – interactive session [miguelgi@santis01]-[10:22:05]-[~]:-)$ salloc -t 01:00:00 -n1 --image=docker:ruby:2.1.8 salloc: Granted job allocation 16280 salloc: Waiting for resource configuration salloc: Nodes nid00012 are ready for job [miguelgi@santis01]-[10:22:08]-[~/tmp]:-)$ srun shifter ./myscript.rb 2.1.8 Ruby 2.1.8 – non-interactive session $ cat myscript.rb #!/usr/bin/env ruby puts RUBY_VERSION myscript.rb § Can run application specific containers:
  • 15. Multi-node containers § It is possible to run the same container across multiple nodes: § Working on getting MPI across nodes to function § Working on getting GPUs to be accessible to containers with good results so far (native performance!) Shifter: Containers in HPC environments 15 lucasbe@santis01 ~/shifter-gpu> sbatch ./nvidia-docker/samples/cuda-stream/benchmark.sbatch Submitted batch job 496 lucasbe@santis01 /scratch/santis/lucasbe/jobs> cat shifter-gpu.out.log Launching GPU stream benchmark on nid00012 ... STREAM Benchmark implementation in CUDA Array size (double precision) = 1073.74 MB using 192 threads per block, 699051 blocks Function Rate (GB/s) Avg time(s) Min time(s) Max time(s) Copy: 184.3169 0.01167758 0.01165104 0.01170397 Scale: 183.1849 0.01175387 0.01172304 0.01178598 Add: 180.3075 0.01790012 0.01786518 0.01792288 Triad: 180.1056 0.01790700 0.01788521 0.01794291 GPU #! /usr/bin/env python import platform import socket print(platform.python_version()) print(socket.gethostname()) hostname.py [miguelgi@santis01]-[10:39:43]-[~/examples]:-)$ salloc -t 00:15:00 -N2 -w nid00013,nid00014 --image=docker:python:3.2-slim salloc: Granted job allocation 16285 salloc: Waiting for resource configuration salloc: Nodes nid000[13-14] are ready for job [miguelgi@santis01]-[10:41:21]-[~/examples]:-)$ srun shifter ./hostname.py 3.2.6 nid00013 3.2.6 nid00014 Python 3.2 – non-interactive session
  • 16. Practical use case: WLCG Swiss Tier-2 § CSCS operates the cluster Phoenix on behalf of CHIPP, the Swiss Institute of Particle Physics § Phoenix runs Tier-2 jobs for ATLAS, CMS and LHCb, 3 experiments of the LHC at CERN and part of WLCG (Worldwide LHC Computing Grid) § WLCG jobs need and expect RHEL-compatible OS. All software is precompiled and exposed in a cvmfs[*] filesystem § But Cray XC compute nodes run CLE, a modified version of SLES 11 SP3 § So, how do we get these jobs to run on a Cray? Shifter: Containers in HPC environments 16 [*] https://cernvm.cern.ch/portal/filesystem
  • 17. Practical use case: WLCG Swiss Tier-2 § Using Shifter, we are able to run unmodified ATLAS, CMS and LHCb production jobs on a Cray XC40 TDS § Jobs see standard CentOS 6 containers § Nodes are shared: multiple single-core and multi-core jobs, from different experiments, can run on the same compute node § Job efficiency is comparable in both systems Shifter: Containers in HPC environments 17 JOBID USER ACCOUNT NAME NODELIST ST REASON START_TIME END_TIME TIME_LEFT NODES CPU 82471 atlasprd atlas a53eb5f8_34f0_ nid00043 R None 15:03:33 Thu 15:03 1-23:54:18 1 8 82476 cms04 cms gridjob nid00043 R None 15:08:39 Tomorr 03:08 11:59:24 1 2 82451 lhcbplt lhcb gridjob nid00043 R None 15:00:10 Tomorr 03:00 11:50:55 1 2 82447 lhcbplt lhcb gridjob nid00043 R None 14:59:31 Tomorr 02:59 11:50:16 1 2 82448 lhcbplt lhcb gridjob nid00043 R None 14:59:31 Tomorr 02:59 11:50:16 1 2 82449 lhcbplt lhcb gridjob nid00043 R None 14:59:31 Tomorr 02:59 11:50:16 1 2 82450 lhcbplt lhcb gridjob nid00043 R None 14:59:31 Tomorr 02:59 11:50:16 1 2 82446 lhcbplt lhcb gridjob nid00043 R None 14:49:01 Tomorr 02:49 11:39:46 1 2 82444 lhcbplt lhcb gridjob nid00043 R None 14:48:01 Tomorr 02:48 11:38:46 1 2 82445 lhcbplt lhcb gridjob nid00043 R None 14:48:01 Tomorr 02:48 11:38:46 1 2
  • 19. § Can isolate network by creating NAT or bridge devices. What about IB? § Users can write as root on exposed RW filesystems § Needs a local daemon running § Isn’t SLURM-friendly § Can run on multiple nodes with own tool (Swarm) § Can use GPUs? § MPI? § Can run images on private registry § It shows all /dev, /sys and /proc to the container environment. Easy § Users can write as their $USER on any exposed RW filesystem § Does not need a local daemon on CN § Is SLURM-friendly (SPANK plugin) § Can run on multiple nodes with WLM integration § Can use GPUs. Working on it! § MPI on its way! § Can run images on private registry Shifter: Containers in HPC environments 19 Docker vs. Shifter Docker
  • 20. Conclusion § Shifter works very well on our HPC environment § It’s being constantly developed and new features are appearing on a weekly basis § It’s open source and developed by the HPC community § It needs some additional work to cover basic HPC use cases (MPI) § Interacting with some parts of Shifter is not very user-friendly: § The process of pulling images is easy, but has no visual feedback § At times, error messages are difficult to understand § No ACLs yet Shifter: Containers in HPC environments 20
  • 21. Reference links § NERSC info: http://www.nersc.gov/research-and-development/user-defined-images/ § The code: https://github.com/NERSC/shifter Shifter: Containers in HPC environments 21
  • 23. Thank you for your attention.
