Serverless Architecture at iRobot

•Download as PPTX, PDF•

1 like•1,317 views

This document discusses iRobot's adoption of serverless architecture and the reasons for choosing it. Some key benefits identified are lower latency and cost compared to monolithic or microservices architectures. Specific challenges addressed by serverless include deployment, service discovery, and security. While serverless addresses many issues, the document notes there is still room for improvement from cloud providers in areas like deployment models and integration testing.

Engineering

Serverless Architecture at iRobot
Ben Kehoe, Cloud Robotics Research Scientist
@ben11kehoe
2016-10-27

How and why did we
choose serverless?
Choosing serverless
https://commons.wikimedia.org/wiki/File:Grasshopper_in_green_field.jpghttps://commons.wikimedia.org/wiki/File:Connochaetes_taurinus_-Wildebeest_crossing_river_-East_Africa.jpg
@ben11kehoe

Monolithic/layered Microservices
@ben11kehoe

• Latency
• Cost
• Deployment
• Discovery
• Security
@ben11kehoe

Latency & Cost
https://www.prerender.cloud/lambda-latency
@ben11kehoe

• Separation of concerns??
• Microservice SDKs
– Well-separated code
• Downside: instead of HTTP API
hiding, say, DB schema, it’s now
hidden in the SDK…on the client
side
– If I change the DB schema, I
need to update the callers as
well
– Highly-coupled deployments
• Bear with me
Latency & Cost @ben11kehoe

• So: deployments of highly-
coupled microservices
• …this is a monolith
• That’s ok!
• Code is still well-separated
• What does deployment look like?
Latency & Cost @ben11kehoe

Security
Allow: dynamodb:GetItem
@ben11kehoe

Security
record.pop('SensitiveKey')Allow: execute-api:Invoke
@ben11kehoe

• Microservices directly accessing
each other’s resources
• Red/black deployments
• CloudFront (+WAF) in front of API
Gateway
@ben11kehoe
• Latency
• Cost
• Deployment
• Discovery
• Security

• Serverless as an identity
• Testing
• What’s missing from providers
Soapbox @ben11kehoe

0 1
Soapbox
How much effort is it to provision and scale?
@ben11kehoe

• No need for complicated
abstraction layer
• Use SDK mocking
– placebo, aws-mock, etc.
– Microservice SDKs that just
use the AWS SDK to talk to
resources are now mocked
for free
Unit Testing @ben11kehoe

• Lambda env vars
• Service discovery (aaS?)
• VPC endpoints
• Automatic hash-based/ETag
versioning of Lambda
– Hash based purely on inputs
so it’s predictable
• Deployment
What’s still missing? @ben11kehoe

Proxy Stages
/red/v1/path/to/resource
red
/v1/path/to/resource
black
/v1/path/to/resource/black/v1/path/to/resource
@ben11kehoe

Proxy Stages
prod
/prod/v1/path/to/resource
red
/v1/path/to/resource
black
/v1/path/to/resource
@ben11kehoe

• Architecture: skip API Gateway
between microservices
– Lots of implications, pro and
con
– Primary driver for us is cost
• Security: CloudFront WAF is
possible for API Gateway
– A little bit of a Rube Goldberg
• Severless is a spectrum
• Integration testing only on deployed
systems
• Providers should support better
deployment models
Conclusion @ben11kehoe

Serverless operations allow iRobot to focus on building applications rather than managing infrastructure. They migrated to AWS in 2016 and now run their home production application using AWS Lambda, API Gateway, and other serverless services without any unmanaged EC2 instances. This reduces costs and improves agility compared to managing their own servers. While serverless still requires operations work, outsourcing infrastructure to AWS allows their small team to support thousands of daily Lambda deployments and the large scale of iRobot's connected robot fleet.
