This document describes the history and capabilities of JMD, a manufacturer of RFID tags. It outlines JMD's evolution since 1974 and current profile as a 36-year old company with 6 million Euros in turnover. The document also provides details on JMD's RFID manufacturing process, from the RFID tag to reader software, and highlights applications in defense/arming and energy/petrochemical industries.

1. RFID Creation
Radio Frequency Tags

2. Supratec Group
6 core business groups
15 subsidiaries
50 M€ in sales
250 employees
2

3. Adhesives & Labels Division
3

4. Evolution
Tailor-made technical tag manufacturer !
Launching RFID Offer.
2010
Full membership to Supratec Group
New investments: C02 laser cutting, digital printing.
2008
Industrial traceability and identification solutions
1997-2003
Laser & numeric cutting
1993
Printing press
1986
Screen-printing
1980
Aluminum tags manufacturing
1974
Aluminum tags manufacturing…
4

5. JMD Today
36 years of existence
6 M € turnover
47 employees
1200 cases per month
5

6. RFID Process
Technological environment
RFID Tag
The tag contains a
unique
identification
code.
6
RFID range
Antenna
The antenna
collects the
information in the
Tag
Industrials resources
Reader
The reader
transfers the
information to the
software interface
Sofware
The software
converts the date
for the User
RFID applications
Data Server
The server stores
and provides the
received data

7. RFID Tag Assembly
Technological environment
Antenna
Copper, aluminum
+
Chip
7
RFID range
Assembly
Chip + Antenna
Industrials resources
RFID applications
Encapsulation
Lamination
Packaging

8. RFID Value Chain
Technological environment
RFID range
Industrials resources
RFID applications
Production
Production
Commercial
Commercial
After‐Sales
After‐Sales
Customer needs
Customer needs
Research
Research
Manufacturing
Manufacturing
Technical advice
Technical advice
Technical support
Technical support
1
8
R&D
R&D
2
3
4
5
CUSTOMER BENEFITS
Purchase
Purchase

9. JMD Profile
Technological environment
RFID range
Industrials resources
Wholesaler ‐‐ Retailers
Wholesaler Retailers
Integrators ‐‐ Solution providers
Integrators Solution providers
9
Inlays manufacturers
Inlays manufacturers
Customers
Customers
RFID applications

10. 3 Passives RFID Technologies
Technological environment
RFID range
Low frequency
Low frequency
Reading
distance
Memory
Frequency
10
0
50 cm
< 2 kbits
125 – 134 Khz
Industrial ressources
High frequency
High frequency
0
1 m
< 10 kbits
ISO 15693, 18000‐3, 14443
ISO 15693, 18000‐3, 14443
13,56 Mhz
RFID applications
Ultra‐high frequency
Ultra‐high frequency
0
8 m
< 512 bits
ISO 18000‐6, EPC, CLASS 1, GEN 2
ISO 18000‐6, EPC, CLASS 1, GEN 2
840 – 960 Mhz

11. RFID Range
Technological environment
RFID range
Industrials resources
RFID applications
3 RFID Tags ‐‐ 5 protection processes
3 RFID Tags 5 protection processes
Coated resin
Lamination
Injection press
Resin dome
Embossing
11

12. FlatTag ®
Technological environment
Laminated tag
Embossed tag
12
RFID range
Industrials resources
RFID applications

13. InjecTag ®
Technological environment
Injected tag
13
RFID range
Industrials resources
RFID applications

14. ResinTag ®
Technological environment
Coated tag
Domed tag
14
RFID range
Industrials resources
RFID applications

15. RFID Tag Lamination Line
RFID range
Technological environment
Industrials resources
RFID applications
Coil of packaged inlays
Cutting
Bonding
Inlay protection
Coil of untreated inlays
RFID Quality control
15

16. Defense & Arming Application
Technological environment
RFID range
Industrials resources
Integrated tag configuration management and
management of production flows
• D 10.5 mm injected Tag for high mechanical
strength and long-term durability (30 years min.)
• ISO 15693 HF RFID tag, 10 kB memory, contact
reading
• Undetectable tag for maximum data security
16
RFID applications

17. Energy & Petrochemical Application
Technological environment
RFID range
RFID management of logistics flows
and gas bottle filling cycles.
• UHF GEN 2 class 1 tag
• Long distance omnidirectional
reading of information
• IP68 protection and high energy
adhesive for maximum durability
over time (25 years)
17
Industrials resources
RFID applications
