Eccentric reducers and straight runs of pipe at pump suction
09.01.2010 | Bloch, H. P., Hydrocarbon Processing Staff,
Keywords:
Questions relating to proper reducer application in centrifugal pump suction lines date back many decades. Until
his death (at age 84, in 1995), world-renowned pump expert Igor Karassik frequently corresponded with the writer
and other pump users on pump-related subjects. We rarely pass up an opportunity to highlight some of his
experience-based comments.
Once, a pump user referred to Fig. 1 and noted that this was quite typical of illustrations found in many textbooks.
In essence, Fig. 1 indicates that, with a suction line entering the pump in the horizontal plane, the eccentric reducer
is placed with the flat at the top. Available texts often give no indication as to whether the pumpage came from
above or below the pump.
Fig. 1. Illustration of eccentric reducer mounting from
Hydraulic Institute Standards.
Igor Karassik agreed that, if the supply source was from above the pump, the eccentric reducer should be installed
with the flat (horizontal) surface at the bottom. Entrained vapor bubbles could then migrate back into the source
instead of staying near the pump suction. If the pump suction piping entered after a long horizontal run or from
below the pump, the flat of the eccentric reducer should be at the top.1
Still, in many older texts it has been assumed that the pumpage source originated at a level below the pump suction
nozzle. Karassik reminded us that older Hydraulic Institute Standards commented on the suction pipe slope:
“...Any high point in the suction pipe will become filled with air and thus prevent proper operation of the pump. A
straight taper reducer should not be used in a horizontal suction line as an air pocket is formed in the top of the
reducer and the pipe. An eccentric reducer should be used instead.”
This instruction applies regardless of where the pumpage originates. Depending on the particulars of an installation,
trapped vapors can reduce the effective suction line cross-sectional area. Should that be the case, flow velocities
would tend to be higher than anticipated. Higher friction losses would occur and pump performance would be
adversely affected.
Page 1 of 4Eccentric reducers and straight runs of pipe at pump suction | Hydrocarbon Processing | S...
3/22/2013http://www.hydrocarbonprocessing.com/Article/2663961/Eccentric-reducers-and-straight-r...
3. In the case of a liquid source above the pump suction, and particularly where the suction line consists of an eccentric
reducer followed by an elbow turned vertically upward and a vertical pipe length—all assembled in that sequence
from the pump suction flange upstream—it will be mandatory for the eccentric reducer flat side to be at the bottom.
That said, Fig. 2 should clarify what reliability-focused users need to implement.
Fig. 2. Suggested modifications for eccentric reducer
mountings.
Also, whenever vapors must be vented against the flow direction, the line size upstream of any low point must be
governed by an important criterion. The line must be a diameter that will limit the pumpage velocity to values below
those where bubbles will rise through the liquid.
In general, it can be stated that wherever a low point exists in a suction line, the horizontal piping run at that point
should be kept as short as possible. In a proper installation, the reducer flange will thus be located at the pump
suction nozzle and there is usually no straight piping between reducer outlet and pump nozzle. Straight pipe lengths
are, however, connected to the eccentric reducer inlet flange. On most pumps, one usually gets away with five
diameters of straight length next to the reducer. In the case of certain unspecified velocities and other interacting
variables (e.g., viscosity, NPSH margin, pump style, etc.), it might be wise to install as many as 10 diameters of
straight length next to the reducer inlet flange. The two different rules-of-thumb explain seeming inconsistencies in
the literature, where both the 5 and 10-D rules can be found. HP
