1. engineering your designswww.pro-sim.com
SIMPACK- MBD
Technology Forum
SIMPACK – MBD Technology Forum
12th
August 2015 Bangalore

2. engineering your designswww.pro-sim.com
SIMPACK- MBD
Technology Forum
Your partners for design validation and optimisation using
Realistic Smulation
Simulated. Designed. Delivered.

3. engineering your designswww.pro-sim.com
ProSIM – Business Offerings
• Simulation based R&D Services,
Collaborative Engineering Services
• Simulation Software Technology
Solutions
• Corporate Training

4. engineering your designswww.pro-sim.com
Simulation Software Solutions – 3DS
• 3DS Simulia Portfolio
• SIMPACK – MBD Technology
• Abaqus – comprehensive FEM analysis
• Fesafe – fatigue life and durability assessment
• Tosca – Shape and topology optimisation
• Isight
– Parametric Optimisation, DoE, Design Process
Automation

5. engineering your designswww.pro-sim.com
Simulation Software Solutions
• Zencrack
• 3D Crack Propagation Software
• True Load
• Load spectra from far field strain data
• Z-Set
• Materials and damage modeling
• Adstefan
• Casting simulation Software
• JMAG
• Electro-magnetic Analysis

6. engineering your designswww.pro-sim.com
ProSIM expertise in
Simulation based design validation
• FEM Analysis
• Stress / Non-linear/ transient and dynamic, coupled thermal
• Fatigue, Fracture, durability
• Creep, thermo-mechanical fatigue, warranty assessment
• Electro-magnetic simulation
• Materials Modelling
• Composites, honey comb structures, constitutive and damage
modelling, coatings, porous media, creep
• Multi-body dynamic simulation (MBD/ MBS)
• Flexible bodies, SiL / HiL / MiL
• Computational Fluid Dynamics
• Conjugate heat transfer, fluid structure interaction

7. engineering your designswww.pro-sim.com
Story of a key…..
Dynamic simulation of the lock mechanism and determine the key
insertion force

8. engineering your designswww.pro-sim.com
Key Insertion Force
Simpack predicted
the trends in the
load displacement
accurately.
Model with contact
and flex bodies
was set up in less
than 4 hours.
SIMPACK Took
28 minutes run
time to complete
the MBD
simulation
Competing multi-body dynamic software tools, took more time to create model. Some
MBD softwares took more than 26 hours to converge. (results were not matching).
Many competing software could not even converge the solution

9. engineering your designswww.pro-sim.com
Highlights of SIMPACK
-Core Technology and algorithms Developed
in DLR Germany
-Relative Coordinate Systems
-Accurate and Robust
-User-friendly
-Easy to learn - Documentation
-Continuous development and R&D
-Good Technical Support from ProSIM (in
India) and SIMPACK HQ
-User Forum

10. engineering your designswww.pro-sim.com
Application Area
-Automotive
-Engine
-Railways
-Aerospace
-Bio-mechanics
-SiL/ HiL
-Wind Trubines
-Industrial Equipment and Machinery

11. engineering your designswww.pro-sim.com
About the event
• Today will be technically loaded day.
• We will have an open forum and
discussion at the end.
• Interact in all the sessions.
• program informal and flexible
• Software Demo and interaction arranged
during breaks.

12. engineering your designswww.pro-sim.com
Simulated. Designed. Delivered.
Thank You
