The document presents a method for localizing and recognizing vehicle number plates from images. It involves three main stages:
1. Localization of the number plate using binarization combining global and local thresholding, followed by connected component analysis to filter noise.
2. Character segmentation using projection profiles and an approximation algorithm to separate characters from the plate.
3. Character recognition using SVM to classify segmented characters into letter and number classes.
The method achieves 97.1% accuracy for localization, 95.4% for segmentation, and 95.72% for recognition when tested on 560 images.
