Review of Number systems - Logic gates - Boolean
algebra - Boolean postulates and laws - De-Morgan’s
Theorem, Principle of Duality - Simplification using
Boolean algebra - Canonical forms, Sum of product and
Product of sum - Minimization using Karnaugh map -
NAND and NOR Implementation.
2. Types
• Binary Number System
• Decimal Number System
• Octal Number System
• Hexadecimal Number System
3. Binary Number System
• It uses only two digits. 0 & 1
• These digits (o & 1) are called binary Digits or
binary numbers.
• This is positional number system like Decimal
number system.
• Each position has a weight that is power of 2
• 100101 is converted to decimal form by:
• [(1) × 25
] + [(0) × 24
] + [(0) × 23
] + [(1) × 22
] + [(0) × 21
] + [(1) × 20
] =
• [1 × 32] + [0 × 16] + [0 × 8] + [1 × 4] + [0 × 2] + [1 × 1] = 37
4. Decimal Number System
• These are Base 10 numbers.
• It is also positional number system.
• We can also write numbers with fractional parts
in the system.
• These numbers are from 0 to 9
Position 4 3 2 1 0 -1 -2
Face Value 5 7 2 3 1 . 2 1
Weights 104
103
102
101
100
10-1
10-2
5. Octal Number System
• These numbers have Base 8.
• These numbers are from 0 to 7.
• 751(8) is a valid Octal number but 821 can not be
a member of this number system.
• 630.4(8) = 6x82
+ 3x81
+ 0x80
+ 4x8-1
=408.5(10)
Position 2 1 0 -1
Face Value 6 3 0 . 4
Weight 82
81
80
8-1
6. Hexadecimal Number System
• This number system uses Base 16.
• Numbers are from 0 to 9 and A to F
• 758(16) is different from 758(10)
• 758(10) will be called as Seven hundred and fifty
eight
• But 758(16) will be called Seven Five Eight Base
Sixteen.
• 758.D1(16) = 7x162
+ 5x161
+ 8x160
+ Dx16-1
+ 1x16-2
= 1880.8164(10)
Position 2 1 0 -1 -2
Face Value 7 5 8 . D 1
Weight 162
161
160
16-1
16-2
8. Decimal to Binary
• Convert 27 into binary
Number Remainder
2 27
2 13 1
2 6 1
2 3 0
2 1 1
0 1
= 011011(2)
9. Fractional Decimal to Binary
• Convert 0 . 56 into binary.
Result Fractional Part Integral Part
2 X 0.56 1.12 12 1
2 X 0.12 0.24 24 0
2 X 0.24 0.48 48 0
2 X 0.48 0.96 96 0
2 X 0.96 1.92 92 1
2 X 0.92 1.84 84 1
2 X 0.84 1.68 68 1
2 X 0.68 1.36 36 1
= 10001111(2)
10. Real Number into Binary
• Convert 56 . 25(10) = 0111000 . 01(2)
Number Remainder
2 56
2 28 0
2 14 0
2 7 0
2 3 1
2 1 1
0 1
56=0111000(2)
Result Fractional Part Integral Part
2x0.25 0.5 5 0
2x0.5 1.0 0 1
0 . 25=01
14. Hexadecimal into Binary
• Convert 10A8(16) into Binary
• Convert each digit into Binary separately and write in 4 bits.
• Step 1
– 1 = 0001(2)
– 0 = 0000(2)
– A = 1010(2)
– 8 = 1000(2)
• Step 2 : Replace each digit of Hexadecimal number with four bits obtained
• 10A8(16) = 0001 0000 1010 1000 (2)
15. Binary to Hexadecimal
• Convert 10010011(2) into Hexadecimal
Step 1: Divide your number into groups of 4 bits starting from right side.
10010011(2) is divided into 1001 0011
Step 2: Convert each group into hexadecimal
1001 = 9(16) and 0011= 3(16)
Step 3: Replace each group by its hexadecimal equivalent
1001 0011(2) = 93(16)
17. Octal into Decimal
• Convert 0271(8) into Decimal
0271(8) = 0x83
+ 2x82
+ 7x81
+ 1x80
= 185(10)
• Convert 107(8) into Binary
Convert each digit independently into Binary
1 = 001(2)
0 = 000(2)
7 = 111(2)
107(8) = 001 000 111 (2)
18. Binary into Octal
• Convert 10010011(2) into Octal
Step 1: First divide the number into groups of 3 bits starting from right
side.
010 , 010 and 011
Step 2: Convert each group into Octal
010(2) = 2(8) 010(2) = 2(8) 011 = 2(8)
Step 3: Replace each group by its Octal equivalent.
010 010 011(2) = 223(8)
19. 1’s Complement Method
• Method 1: 1’s complement of an 8-bit binary number is obtained by
subtracting the number from 11111111(2)
11111111
- 10011001
---------------------
1’s Complement 01100110
• Method 2: It can directly be obtained by changing all 0’s to 1’s and
all 1’s to 0’s.
Original Number 01100110
1’s Complement 10011001
20. Representation of negative numbers
using 1’s Complement
• To represent the negative number in 1’s complement form, we perform
following steps.
– Determine the number of bits to represent the number
– Convert the modules of the given number in Binary
– Place a 0 in MSB
– Take 1’s complement of the result.
