This NACE standard provides material requirements for metallic materials used in oil and gas equipment to resist sulfide stress cracking (SSC) in hydrogen sulfide environments. It includes requirements for ferrous metals like carbon steels, stainless steels, and nonferrous metals. The standard applies to components exposed to sour environments where a SSC failure could compromise safety or functionality. It is the user's responsibility to determine if the environmental conditions meet the standard's criteria and if the materials are suitable for the intended application. The standard will be revised as needed to include new materials and address changes in technology.
This document provides an overview of welding inspection including:
- Typical duties of welding inspectors such as visual inspection, reviewing documentation, and checking welding processes
- Terms and definitions used in welding inspection
- Features that inspectors examine on completed welds such as penetration and types of joints
- Conditions required for visual inspection including lighting and access
- Stages when inspection is typically required including before, during, and after welding
- Records and documentation that inspectors are responsible for collecting and maintaining
The document serves as a reference for welding inspectors, outlining their key responsibilities and areas of focus.
The document discusses weld defect acceptance criteria according to different codes such as ASTM B31.1, ASME VIII, ASME B31.3, and AWS D1.1. It provides details on acceptance limits for various weld defects depending on the examination method, material thickness, loading conditions, and material application. Defects discussed include cracks, lack of fusion, incomplete penetration, undercuts, porosity, and reinforcement. Acceptance criteria include maximum defect sizes, numbers of defects allowed, cumulative lengths of defects, and distances between defects.
This document provides instructions for installing underground graphite reinforced plastic (GRP) pipes. It describes how to transport, store, prepare, and lay the pipes in trenches. Key steps include handling pipes carefully to avoid damage, preparing pipe ends with couplings at the storage area, and using lubricant and pullers to join pipes in the trench. Backfilling should start immediately using approved granular materials in thin layers, compacting as the fill rises to properly support the pipes.
The document discusses standards for selecting materials resistant to cracking in sour oil and gas environments containing hydrogen sulfide (H2S). It describes NACE MR0175/ISO 15156, which establishes requirements for materials used in H2S-containing oil and gas production. It is comprised of three parts addressing different material types and qualifications. The document also discusses NACE MR0103, which specifies material requirements for resistance to sulfide stress cracking in sour refinery environments. Both standards aim to select materials that reduce risks from failures posed by H2S exposure.
This document outlines the 8 steps to produce a Procedure Qualification Record (PQR) according to the ASME Section IX code. The steps are: 1) identify essential variables for the welding process, 2) add remaining essential variables from construction codes, 3) fill out the PQR format, 4) choose a qualified welder, 5) record welding parameters, 6) perform visual and mechanical tests, 7) record test results on the PQR, and 8) sign and date the completed PQR.
