2. OBJECTIVES
• Describe/outline good troubleshooting practices
• troubleshoot common hardware/software problems
• Monitor system performance via command-line
• Identify and fix common performance problems
• Describe the different facets of Linux security
• Increase the security of a Linux computer
• Measures & utilities to detect a security breach
2
4. TROUBLESHOOTING
METHODOLOGY
• Monitoring: observing log files and running
performance utilities system to identify problems
and their causes
• Proactive maintenance: minimizing chance of
future problems
• e.g., perform regular system backups
4
5. TROUBLESHOOTING
METHODOLOGY (CONT)
• Reactive maintenance: correcting problems when
they arise
• Documenting solutions
• Developing better proactive maintenance methods
• Documentation: system information stored in a
log book for future references
• All maintenance actions should be documented
• Troubleshooting procedures: tasks performed
when solving system problems
5
7. TROUBLESHOOTING
METHODOLOGY (CONTINUED)
• Two troubleshooting golden rules:
• Prioritize problems according to severity
• Spend reasonable amount of time on each problem
given its priority
• Ask for help if you can’t solve the problem
• Try to solve the root of the problem
• Avoid missing underlying cause
• Justify why a certain solution is successful
7
9. HARDWARE-RELATED
PROBLEMS
• Often involve improper hardware or software
configuration
• SCSI termination
• Video card and monitor configuration
• All hardware is on Hardware Compatibility List
• POST test alerts
• Loose hardware connections
• Problems specific to the type of hardware
• View output of dmesg command
• View content of /var/log/boot.log, /var/log/messages
9
10. HARDWARE-RELATED
PROBLEMS (CONTINUED)
• Absence of device drivers prevent OS from using
associated devices
• dmesg command: displays the hardware that is detected
by the Linux kernel
• lsusb command: displays a list of USB devices detected
by the Linux kernel
• lspci command: displays a list of PCI devices detected
by the Linux kernel
• Compare outputs of commands to output of lsmod to
determine if driver module is missing from kernel
10
16. LSMOD
• same as cat /proc/modules
• shows currently loaded kernel modules (LKMs)
• modules are pieces of code loaded into the kernel during boot (minus ext .o or
.ko… added with insmod)
• size of memory used by module
• used by: number of instances of module used
16
compare output
with dmesg, etc to
see if driver
module is missing
17. HARDWARE-RELATED
PROBLEMS (CONTINUED)
• Hardware failure can render a device unusable
• HDDs most common hardware components to fail
• If HDD containing partitions mounted on noncritical directories fails:
• Power down computer and replace failed HDD
• Boot Linux system
• Use fdisk (or LVM) to create partitions on new HDD
• Use mkfs to create filesystems
• Restore original data
• Ensure /etc/fstab has appropriate entries to mount filesystems
17
18. HARDWARE-RELATED
PROBLEMS (CONTINUED)
• If HDD containing / filesystem fails:
• Power down computer and replace failed HDD
• Reinstall Linux on new HDD
• Restore original configuration and data files
18
19. SOFTWARE-RELATED PROBLEMS:
APPLICATION-RELATED
PROBLEMS
• Missing program libraries/files, process
restrictions, or conflicting applications
• Dependencies: prerequisite shared libraries or
packages required for program execution
• Programs usually check at installation
• Package files may be removed accidentally
19
20. SOFTWARE-RELATED PROBLEMS:
APPLICATION-RELATED
PROBLEMS (CONTINUED)
• rpm –V command: identify missing files in a
package or package dependency
• dpkg –V bash (for ubuntu)
• ldd command: display shared libraries used by a
program
• ldconfig command: updates list of shared
library directories (/etc/ld.so.conf) and list of
shared libraries (/etc/ld.so.cache)
20
21. $LDD /BIN/BASH
• .so files are “shared object” files
• similar to Windows DLL
21
22. SOFTWARE-RELATED PROBLEMS:
APPLICATION-RELATED
PROBLEMS (CONTINUED)
• Too many running processes
• Solve by killing parent process of zombie processes
• Filehandles: connections programs make to files
• ulimit command: modify process limit parameters
in current shell
• Can also modify max number of filehandles
• by default it’s 1024
• ulimit –n 5000 (increases file handles)
• ulimit –u 30000 (increases max # of user processes in
shell)
22
23. SOFTWARE-RELATED PROBLEMS:
APPLICATION-RELATED
PROBLEMS (CONTINUED)
• /var/log directory: contains most system log files
• Some are hard linked to /var/log directory
• If applications stop functioning due to difficulty
gaining resources, restart using SIGHUP
• Do determine if another process trying to access the
same resources attempt to start application in Single User
Mode
• If resource conflict is the cause of the problem,
download newer version of app or application fix
23
24. SOFTWARE-RELATED PROBLEMS:
OPERATING SYSTEM-RELATED
PROBLEMS
• Most software-related problems related to OS
• X windows, boot loader, and filesystem problems
• Problem detecting video card or monitors by the
kernel
• To isolate problem starting X Windows or gdm:
• View /var/log/Xorg.0.log file
• Execute xwininfo or xdpyinfo
24
25. SOFTWARE-RELATED PROBLEMS:
OS-RELATED PROBLEMS
(CONTINUED)
• LILO (Linux Loader) problems: place “linear” in,
remove “compact” from /etc/lilo.conf file
• ubuntu: /etc/grub.d/10_linux, /etc/default/grub,
/boot/grub/grub.cfg
• GRUB problems: typically result of missing files in
/boot directory
• Ensure Linux kernel resides before 1024th cylinder
and lba32 (large block addressing) keyword is in
configuration file
• Eliminates BIOS problems with large HDDs
25
26. SOFTWARE-RELATED PROBLEMS:
OS-RELATED PROBLEMS
(CONTINUED)
• If filesystem on partition mounted to noncritical
directory becomes corrupted:
• Unmount filesystem
• Run fsck command with –f (full) option
• If fsck command cannot repair filesystem, use mkfs
command to re-create the filesystem
• Restore filesystem’s original data
26
27. SOFTWARE-RELATED PROBLEMS:
OS-RELATED PROBLEMS
(CONTINUED)
• If / filesystem is corrupted:
• Boot from Fedora installation media and enter System
Rescue
• At shell prompt within System Rescue:
• Use mkfs to recreate the filesystem
• Use backup utility to restore original data to the re-
created / filesystem (ie: tar, cpio, dump, restore, etc)
• Exit System Rescue and reboot system
• Knoppix Linux and BBC Linux: bootable Linux
distributions with many filesystem repair utilities
27
28. SOFTWARE-RELATED PROBLEMS:
USER INTERFACE-RELATED
PROBLEMS
• Assistive technologies: tools that users can use to
modify their desktop experience
• Assistive Technologies Preference utility within GNOME
Desktop Environment
• Preferred Applications to configure Web browser,
multimedia player and terminal applications to be
opened automatically
• Mouse Accessibility to configure speed and click
behavior
• Keyboard Accessibility to configure keyboard
related assistive technologies
28
30. PERFORMANCE MONITORING
• Jabbering: failing hardware components send
large amounts of information to CPU when not in
use
• Other causes of poor performance:
• Software monopolizes system resources
• Too many processes
• Too many read/write requests to HDD
• Rogue processes
30
31. PERFORMANCE MONITORING
(CONTINUED)
• To solve software performance issues:
• Remove software from the system
• Move software to another Linux system
• Add CPU or otherwise alter hardware
• Bus mastering: peripheral components perform
tasks normally executed by CPU
31
32. PERFORMANCE MONITORING
(CONTINUED)
• To increase performance:
• Add RAM (reduces swap time with HDD)
• Upgrade to faster HDDs
• Disk Striping RAID
• Keep CD/DVD drives on a separate HDD controller
• Run performance utilities on a regular basis
• Record results in a system log book
• Eases identification of performance problems
• Baseline: measure of normal system activity
32
33. MONITORING PERFORMANCE
WITH SYSSTAT UTILITIES
• System Statistics (sysstat) package: contains
wide range of system monitoring utilities
• Use apt-get install sysstat command
• includes: mpstat, iostat, sar
33
34. MPSTAT
• multiple processor stats
• Used to monitor CPU performance
• Can specify interval and number of measurements rather than displaying
average values
• %sys should be smaller than %usr and %nice combined
34
35. MONITORING PERFORMANCE
WITH SYSSTAT UTILITIES
(CONTINUED)
• iostat (Input/Output Statistics) command:
measures flow of information to and from disk
devices
• Displays CPU statistics similar to mpstat
• Displays statistics for each disk device on the system
• Output includes:
• Transfers per second
• Number of blocks read and written per second
• Total number of blocks read and written for the
device
35
37. MONITORING PERFORMANCE
WITH SYSSTAT UTILITIES
(CONTINUED)
• sar (System Activity Reporter) command:
displays various system statistics taken in the last
day
• Provides more information than mpstat and iostat
• By default scheduled to run every 10 minutes
• Output logged to a file in /var/log/sa directory
• -f option:View statistics from a specific file
• Can be used to take current system measurements
37
38. sar –q 1 5
• # of processes in q. runq-sz (run queue size)
• 2 or less is normal for Intel architectures
38
sar 2 4
• 4 CPU stats taken every 2 seconds
39. MONITORING PERFORMANCE
WITH SYSSTAT UTILITIES
(CONTINUED)
• Additional sar options:
• -q option: Displays processor queue statistics
• runq -sz value: Number of processes waiting for
execution on processor run queue
• plist -sz value: Indicates number of processes
currently running
• ldavg values: Represent average CPU load
• -W option: Displays number of pages sent to and taken from
swap partition
• Large number causes slower performance
• Add RAM to resolve
39
41. OTHER PERFORMANCE
MONITORING UTILITIES
• top command: displays CPU statistics, swap usage,
memory usage and average CPU load
• free command: displays total amounts of physical
and swap memory and their utilizations
• Can be used to indicate whether more physical memory is
required
• vmstat command: displays memory, CPU, and swap
statistics
• Can be used to indicate whether more physical memory is
required
41
44. SECURITY
• Linux systems typically made available across
networks such as the Internet
• More prone to security loopholes and attacks
• Should improve local and network security
• Understand how to detect intruders who breach
the system
44
45. SECURING THE LOCAL
COMPUTER
• Limit access to physical computer itself
• Prevent malicious users from accessing files by directly
booting the computer with their own device
• Server closet: secured room to store servers
• Remove floppy, CD, and DVD drives from
workstations
• Ensure BIOS prevents booting from USB ports
45
46. SECURING THE LOCAL
COMPUTER (CONTINUED)
• Ensure BIOS password is set
• Set boot loader password in LILO (linux loader) or
GRUB configuration file
• Prevents intruder from interacting with boot loader
• Limit access to graphical desktops and shells
• Exit command-line shell before leaving computer
• nohup command: prevents background processes from
being killed when parent shell is killed or exited
• Lock screen using GNOME or KDE
46
47. SECURING THE LOCAL
COMPUTER (CONTINUED)
• Minimize root user’s time logged in
• su (switch user) command: switch current
user account to another
• Used to switch between root user and regular user
• sudo command: perform commands as another
user if you have the rights to do that listed in
/etc/sudoers file
47
49. PROTECTING AGAINST
NETWORK ATTACKS
• Always a possibility that hackers can manipulate a
network service by interacting with it in unusual
ways
• Buffer overrun: program information for a network
service altered in memory
49
50. NETWORK SECURITY
ESSENTIALS
• Minimize number of running network services
• nmap (network mapper) command: scans
ports on network computers
• User can determine what network services are running
• Ensure that services that are not needed are not
automatically started when entering the runlevel
50
51. NETWORK SECURITY
ESSENTIALS (CONTINUED)
• Ensure network service daemons for essential
services not run as root user when possible
• Ensure that shell listed in /etc/passwd for
daemons is set to /sbin/nologin
• Hacker will not be able to get BASH shell
• New network service versions usually include
fixes for known network attacks
• Keep network services up-to-date
51
52. NETWORK SECURITY
ESSENTIALS (CONTINUED)
• TCP wrapper: program that can start a network
daemon
• Checks /etc/hosts.allow and /etc/hosts.deny files before
starting a network daemon
• Examine permissions for files and directories
associated with system and network services
52
53. CONFIGURING A FIREWALL
• netfilter/iptables: used to configure a firewall
• Discard network packets according to chains of rules
• Chains: specify general type of network traffic to apply rules to
• Rules: match network traffic to be allowed or dropped
• Three chain types:
• INPUT: incoming packets
• FORWARD: packets passing through computer
• OUTPUT chain: outgoing packets
53
54. CONFIGURING A FIREWALL
(CONTINUED)
• iptables command: creates rules for a chain
• Can be based on source IP, destination IP, protocol used,
or packet status
• Stateful packet filter: Remembers traffic allowed
in an existing session and adjust rules
appropriately
• Easier to use graphical utility to configure
firewalls
54
57. CONFIGURING SELINUX
• SELinux: Security Enhanced Linux
• By default, configured and enabled during Fedora installation
• Series of kernel patches and utilities created by NSA
• Enforces role-based security
• To enable, edit /etc/selinux/config file
• Configure SELINUXTYPE option
• Reboot and relabel the system
• sestatus command: view current SELinux status
57
58. USING ENCRYPTION TO
PROTECT NETWORK DATA
• Use encryption algorithms to protect data before
it is transmitted on a network
• Asymmetric encryption: uses a pair of keys
uniquely generated on each system
• Public key: freely distributed
• Private key: used only by the system, never distributed
• Can be used to authenticate messages
• Digital signature: message that has been
encrypted using a private key
58
59. WORKING WITH SSH
• By default, SSH uses RSA to encrypt data and DSA to
digitally sign data
• System wide RSA and DSA key pairs are generated
the first time SSH daemon is started
• Tunneling: enclosing network traffic within encrypted SSH
packets
• SSH identity: used to automatically authenticate to
other computers using digital signatures
• Manage keys using Password and Encryption Keys
utility
59
61. WORKING WITH GPG
• Open source version of PGP
• Each user has a key pair used for encryption and
authentication
• Authentication uses trust model
• Typically uses RSA and DSA key pairs for
asymmetric encryption and digital signing
• Can manage GPG keys and encrypt data using:
• gpg command
• Graphical utility such as Passwords and Encryption Keys
utility
61
62. DETECTING INTRUSION
• Log files can contain information or irregularities
indicating an intrusion
• Review log files in /var/log associated with network
services
• At minimum, review system log files associated with
authentication
• Pluggable Authentication Module (PAM): handles
authentication requests by network applications
• Log file in /var/log/secure
62
63. DETECTING INTRUSION
(CONTINUED)
• Check /var/log/wtmp log file
• Lists users who receive BASH shells
• Use who command to view the file
• lsof (list open files) command: lists files
that are currently being edited
• Periodically search for files that have SUID bit set
• Tripwire: monitors important files and directories
• Intrusion Detection System (IDS): program used to
detect intruders on a Linux system
63
66. SUMMARY
• Administrators monitor the system, perform
proactive/reactive maintenance, and document
system information
• Common troubleshooting procedures involve:
• Isolating and determining the cause of system problems and
implementing and testing solutions that can be documented
for future use
• Invalid hardware settings, absence of device drivers,
and hard disk failure are common hardware-related
problems
66
67. SUMMARY (CONTINUED)
• Software-related problems can be application-
related or OS-related
• Users can use assistive technologies to modify
their desktop experience
• System performance is affected by a variety of
hardware and software factors
• Using performance monitoring utilities to create a
baseline is helpful for diagnosing future performance
problems
67
68. SUMMARY (CONTINUED)
• Securing a Linux computer involves:
• Improving local and network security and monitoring to
detect intruders
• Greatly improve local security by:
• Restricting access to the computer and using root account
only when required via su and sudo commands
68
69. SUMMARY (CONTINUED)
• Reduce chance of network attacks by:
• Reducing number of network services, implementing
firewalls, SELinux, service updates, encryption, and TCP
wrappers, and restricting services from running as root
user and permissions on key files
• Analyzing log files and key system files and
running IDS applications can be used to detect
intruders
69
