2. OVERVIEW
■ Modular programming is a technique of developing software by
separating the functionality of a program into independent
interchangeable modules that are combined together to get the final
working software.
■ Modular programming is a technique used to divide program into many
small, manageable, logical and functional modules or blocks.
■ Modular programming is a software design technique that emphasizes
separating the functionality of a program into independent,
interchangeable modules, such that each contains everything necessary
to execute only one aspect of the desired functionality.
Modular Programming
3. Cont……..
■ Every modular program consist of one main module and one or more
sub modules or procedures.
■ Each module has a unique name.
■ Main module is the top level module in which program entry and exist
takes place.
■ The main module is the controlling section of a modular programming.
■ Sub modules is a block of statement that is used for specific task and is
written under the main module.
■ It allows the user to divide into manageable and functional modules or
blocks with the help of sub procedure and function procedure.
Modular Programming
4. Cont……
■ QBASIC programs consists of one or more modules.
■ A module is a block of statement that solve particular
problem.
■ A module may contain SUB and FUNCTION
procedure, as well as code not part of SUB or
FUNCTION
Modular Programming
6. Advantages
■ Different programmers can design different program modules independently, which is
required in a large and complex program.
■ it is easy to design code and test the program modules independently.
■ It is possible to use a single module in different places which reduces program codes.
■ Reduce redundancy
■ Improving the readability of a program.
■ Program maintenance becomes easier.
■ Saving the time.
■ Encourages re-use of code.
Modular Programming
7. Types of Procedures
■ In QBASIC, a programmer can name a block of code which
can be executed by simply calling out that name.These name
blocks of code are called procedures.
■ The two types of procedures are:
i. SUB Procedure
ii. Function Procedure
Modular Programming
8. SUB Procedure
■ SUB procedure is a block of statements which is identified by
a unique name that performs a specific task.
■ The block of statements is placed with a pair of SUB … END
SUB statements and can be called by its name.
■ A SUB-procedure is a small, logical and manageable
functional part of program which performs specific task and
does not return any value.
Modular Programming
9. Features of SUB Procedures
■ SUB procedure does not return any value.
■ SUB procedure can be recursive.They may call
themselves.
■ Sub procedure do not have data types.
Modular Programming
10. SYNTAX (Parameterized)
■ Declaration
DECLARE SUB <name> (parameter list)
■ Definition
SUB <name> (parameter list)
` procedure variable definitions and
statements
END SUB
■ Calling
CALL <name>(argument list)
Modular Programming
11. SYNTAX(Non Parameterized)
■ DECLARE SUB <name> ()
■ CALL <name>
■ SUB <name>
` procedure variable definitions and
statements
■ END SUB
Modular Programming
12. Declaring SUB Procedure
■ The DECLARE statements is used to declare a SUB
procedure.
■ The syntax for the DECLARE statements is as follows:
DECLARE SUB <name>(parameter list)
Example:
DECLARE SUB AOR(L,B)
Sub procedure AOR with two parameter L and B
DECLARE SUB AOR
Sub procedure AOR with no parameters
Modular Programming
13. Defining a SUB procedure
■ The SUB …… END SUB statements is a procedure statements
that marks the beginning and ending of a sub program.The
syntax is:
SUB <name>(parameter list)
procedure variable definitions and statements
END SUB
Modular Programming
14. Calling a SUB Procedure
■ The CALL statements is used to transfer control to
another procedure, a BASIC SUB program.
■ The syntax is :
CALL <name> (argument list)
Example:
CALL AOR(L,B)
Modular Programming
15. Function Procedure
■ A function procedure is a small, logical and functional part of a program
which performs the specific tasks and it returns a single value to the
main program or calling module.
■ The returned value may be string or number.
■ It is either called by using PRINT statement or storing a returned value
into a variable.
Modular Programming
16. SYNTAX(Parameterized)
■ Declaration
DECLARE FUNCTION <name> (parameter list)
■ Definition
FUNCTION <name> (parameter list)
` procedure variable definitions and statements
<name> = Expression
END FUNCTION
■ Calling
PRINT <name>(argument list)
OR
variable = <name>(argument list)
Modular Programming
17. SYNTAX(Non-Parameterized)
■ Declaration
DECLARE FUNCTION <name> ()
■ Definition
FUNCTION <name>
` procedure variable definitions and statements
<name> = Expression
END FUNCTION
■ Calling
PRINT <name>
OR
variable = <name>
Modular Programming
18. Differences
SUB Procedure Function Procedure
The block of statements placed under SUB/END SUB
statements and can be called by its name.
The block of statements placed under
FUNCTION/END FUNCTION statements and can be
invoked from the reference of the function name.
It does not return any value to the calling module It returns a single value to calling module.
It does not have any datatype in its name. It have datatype in its name which is the return value
of a function.
Modular Programming
19. ARGUMENTAND PARAMETER
■ The constants or variables enclosed in the parentheses are supplied to a procedure are
known as Arguments.
■ Argument are also known as Actual Parameter.
■ The variables in a procedure which accepts data or variable passed to them from the
calling module are known as Parameters.
■ Parameter are also known as Formal Parameter.
Modular Programming
20. LOCAL AND GLOBALVARIABLE
■ A variable which is declared inside a module and cannot be accessed by other module
is known as local variable.
■ All variables that are declared either implicitly or explicitly without using SHARED
attribute are local variable.
■ The variable in main module which ca be accessed from any module or procedure of a
program is known as Global variable.
■ A Global variable is declared in the main module by two methods.
Modular Programming
21. 1. Declaring by using COMMON Statement.
Syntax:
COMMON SHARED Variable list
where,
SHARED indicates that variable are shared with all procedures.
variable list A list of one or more variables to be shared in the program.
e.g. COMMON SHARED A, B, C
2. Declaring using DIM statement.
Syntax:
DIM SHARED variable list
e.g. DIM SHARED A$
Modular Programming
23. ■ Variables can be shared among parts of a module without making the variables global
by using the SHARED statement.
Syntax:
SHARED variable list
e.g.
DECLARE SUBTEMPERATURE()
INPUT”ENTERTEMPERATURE IN CELCIUS”;C
CALLTEMPERATURE
END
SUBTEMPERATURE
SHARED C
F= 9 * C/5 + 32
PRINT “TEMPERATURE IN FAHRENHEIT”;F
END SUB
Modular Programming
