The document provides specifications for the LGA-340 single cylinder engine, including a bore and stroke of 84mm x 64mm, rated power of 8kW at 4400rpm, and max torque of 19Nm at 3000rpm. It describes the engine layout, dimensions, intake and exhaust systems, lubrication system, and electric system. Modifications made to the engine for the Indian market are also listed, along with special instructions for welding, the intake system, filling oil, and using fuel pipes.

1. Engine Operations LGA-340 Prashant Sisodiya 10 th Aug 2008

2. Engine Specifications LGA-340 Bore x Stroke : 84 mm x 64 mm, Single cylinder, Air Cooled Swept Volume : 338 cc Compression ratio : 8:1 Rated Power : 8 kW @ 4400 rpm Max Torque : 19 Nm @ 3000 rpm Valve Timing System : Belt Driven Single Overhead Camshaft Lubrication : Forced Lubrication Vane Pump Luboil : 15W40 CF4 multi grade oil Luboil Capacity : 1.7 ltrs Starting System : Electric Start with Auto-Decomp on Camshaft Electric System : 12V, 18 amps flywheel mounted alternator, Recommended Battery : 12 V, 44 Ah Weight of Engine : 30.5 kg

3. Engine Layout

4. Overall Dimensions

5. Intake System

6. Exhaust System

7. Lubrication System

8. Fuel Circuit To Carburettor Return Line to Tank Petrol Filter Electric Feed Pump The petrol feed pump will be supplied in loose condition. Use of feed pump will allow locating fuel tank at bottom portion of vehicle with negative head. This will ensure the continuous flow of fuel to engine as and when demanded which is essential for good performance of vehicle. This also will ensure better safety during fuel filling operation, since fuel spilt will not be on the vehicle hot or electrical parts. The spillage tray can be eliminated and better packaging is possible.

9. Engine Electrical System LOMBARDINI SCOPE

10. Modifcations in Engine At Lombardini, continuous improvement in products through R&D is carried out for end customer delightment. Following are major modifications in LGA340 engines are made. Modification in Piston Profile for Indian Market, CNG / LPG application Chrome Plated Rings, Spark Timing modification, Higher Power Starter Motor for better start ability, Increased Main Journal Diameter of Crankshaft for durability, Carburettor modification with drain arrangement, Wear Resistant Valve Seat

11. Special Instruction Before carrying any welding activity, ensure spark plug cable removed and remove Battery terminal cables. This will prevent burning of wiring harness and HT Coil. Do not tamper Engine Intake System including Air Filter & it’s Position. Tampering Intake system will reduce power and may yield in misfiring during vehicle retardation. In case, if the silencer position need to be modified because of packaging constraints, ensure back pressure does not exceed 450 mm of Water Column. Fill the measured quantity of luboil from the Rocker Cover Filling Cap, wait for 10 minutes to allow oil to reach bottom portion in crankcase and then measure the level. If necessary, drain the excess oil by loosening side drain plugs. Luboil level must be between lower and upper mark of Dipstick. Level to be checked when vehicle on horizontal road. Fuel Pipes to be used should be of good quality petrol hoses.

12. Thanks! Contact Details: Prashant Sisodiya email : [email_address] Mobile : 9922504066 Devendra Nene email : [email_address] Mobile : 9922504064
