ROTARY MICROTOME ERMA TYPE :
J-6: The ERMA type is a simple but versatile Rotary Microtome for cutting of uniform sections
upto 25 microns in steps of 1 micron each. The internal structure is completely encased in a
metallic cover. The selected alloys are used in fabrication of the machine and razor.
Accessories supplied with equipment:-
Ÿ Razor-120 mm with back & handle-one
Ÿ Object holders-set of three
Ÿ Honing plate-one
Ÿ Oilcan-one
Ÿ Packed in card board box and thermocol packing
ROTARY SENIOR MICROTOME:
J-8: Rotary Senior Microtome (Spencer 820 type):most modern and reliable sectioning
equipment designed for very precise sectioning of tissues upto 1 micron thickness. The feed
indicator, located in front of microtome is operated by the latest 'CAM DRIVE SYSTEM' for
accurate feed setting from 1-50 microns in steps of one micron. It is graduated in microns, is
conveniently located in the front for instant references and its setting is controlled by a knurled
knob at the back of the microtomes. The interior mechanism rests on a heavy cast iron base and
is covered with a full swing protective cover for easier cleaning and lubrication. The Salient
features include independent feed mechanism with automatic safety device, universal knife
holder with lateral movements permitting use of the entire knife edge, universal vice type object
holder for accurate centering of the specimen. The instrument ensures life -long smooth
operation .Individual components are fabricated and assembled using latest technology and
selected materials. The knife supplied with the microtome is fabricated from imported fine grain
steel tested for micro-structure and is heat treated for optimum rigidity and sharpness.
Technical features:-
Ÿ Feed adjustment -1-50 microns
Ÿ Total feed excursion - 28 mm
Ÿ Opening of object clamps : 37x27 mm
Ÿ Razor-120 mm-one
Ÿ Oilcan-one.
Ÿ Packed in card board box and thermocol packing
J-8C (Deluxe): Micron setting is in front for quick glance.
J-6
J-8

J-8ED
SEMI-AUTOMATIC-MICROTOME :
J-8ED: A sturdy microtome usable in sectioning slime and sensitive incision from tissues.
Semi automatic cut sections from 0.25~60μ.
Product Description:
Ÿ Advanced driving systems, functions of section, trimming, fast forward, backward etc
Ÿ LCD screen shows section and trimming thickness range, numbers of section and trimming
Exchange between section and trimming mode can be finshed by controlling systems
Ÿ Handwheel can be locked at any position to assure user's safety
Ÿ Large waste tray is easy to clean and unload
Ÿ Universal cassette clamp and standard specimen clamp; Emergency stop systems
Ÿ Section thickness range: 0.25~60μ M
Ÿ Trimming thickness range: 0.25~60μ M
Ÿ Minimum setting value: 0.25μ M
Ÿ Object feed: 28mm
Ÿ Vertical stroke: 60mm
Ÿ Maximum specimen size: 50 X 50mm
AUTOMATIC MICROTOME :
J-8E:
Semi automatic cut sections from 0.5 p to 100 p. Sample feed of the microtome is automatically
and perform the Manually and sectioning process manually.
Section And Trim Function Made By Pressing Button In Control Panel, Section Speed Can Be
Adjusted By Speed Control Key.With Function Of Emergency Stop.
This is microproccessor controlled with LCD screen on the sections and status of error. Having
command control module to control the proposed device.
Also having an integrated waste collection folder.. A standard sample holder is provided with
the proposed device optionally a glass knife holder
Features:
Ÿ Section Range From 0.5micron To 100micron Meter.
Ÿ Min. Set Value Is 0.50micron Meter.
Ÿ Trimming Range From 1--600micron Meter.
Ÿ Max. Specimen Size: 50 X 50mm.
Accessories supplied with the Microtome:
Disposable blades ( 50 ) and blade holders,
Ÿ A set of Block holders.
A sturdy microtome usable in sectioning slime and sensitive incision from tissues.
J-8E

SLIDING MICROTOME :
J-11: Sliding Microtome is a jung type sturdy sectioning equipment for paraffin, cellodine &
embedded specimen or in natural form. It is suitable to cut sections upto 40 microns in steps of
2 microns each.
Ÿ Length of sliding track : 27 cms
Ÿ Total feed excursion : 25 mm
Ÿ Object stage opening : 31X26 mm
Accessories supplied with Equipment:-
Ÿ Razor-120 mm-one
Ÿ Oilcan-one
WOOD MICROTOME :
J-11A: Wood Microtome (Jung Type) is a heavy duty microtome for sectioning hard materials
like wood, bone etc. upto 8 x 5 cm size in steps of 1 micron each upto 30 microns.
Ÿ Feed adjustment - 30 microns
Ÿ Vertical object displacement - 30mm
Ÿ Opening of object vice - 80x50 mm
Ÿ Length of slide ways - 42 cm
Ÿ Overall dimensions (horizontal) 85x40 cm
Ÿ Accessories supplied with equipment:- Special heavy duty razor with back one
Ÿ Vices-two
Ÿ Spanner for tightening razor-one
Ÿ l-keys-two
Ÿ Screw driver-one
Ÿ Oilcan-one
SLEDGE MICROTOME :
J-11S: These are designed for cutting large blocks of paraffin and resin embedded material
including whole organs, for light microscopy. The knife holding clamps allow the knife to be offset
to the direction of cut, a major advantage when sectioning large, hard blocks. The microtome,
which is very heavy for stability and not usually subject to vibration, can also be used to cut
materials from various industrial applications (wood, plastics, textile fibers).
Ÿ Length of sliding track : 27 cms
Ÿ Total feed excursion : 25 mm
Ÿ Object stage opening : 31X26 mm
Accessories supplied with Equipment:-
Ÿ Razor-120 mm-on
Ÿ Oilcan-one
J-11
J-11A
J-11S

CRYOSTAT MICROTOME :
JCR-1: Cryostat Microtome : Most versatile section cutting machine for quick sectioning of
tissues. Instantly freezes on built-in rapid freeze stage for biological, veterinary and medical
diagnostic biopsies etc. The Microtome is completely made of brass & stainless steel and is
placed in stainless steel cold chamber with an observation glass window.
Provided with a hermetically sealed compressor unit with 'A' grade components to achieve quick
cooling of up to -40ºC. It is provided with feed range from 0-40microns in steps of 2 microns
each.
Ÿ Object holder-set of three
Ÿ Honing Stone-one
Ÿ Oilcan with low temperature-one
Ÿ Dust cover-one
o
JCR-1: Temp. range -40 C with Digital Temp. Controller & Indicator.
CRYOSTAT MICROTOME :
JCR-1B: Most versatile section cutting machine for quick sectioning of tissues. Instantly
freezes on built-in rapid freeze stage for biological, veterinary and medical diagnostic biopsies
etc. The Microtome is completely made of brass & stainless steel and is placed in stainless steel
cold chamber with an observation glass window.
Provided with a hermetically sealed compressor unit with 'A' grade components to achieve quick
o
cooling of up to -80 C. It is provided with feed range from 0-40microns in steps of 2 microns
each.
Ÿ Object holder-set of three
Ÿ Honing Stone-one
Ÿ Oilcan with low temperature-one
Ÿ Dust cover-one
FREEZING MICROTOME :
J-10: Freezing Microtome (ERMA Type): Versatile sectioning machine for quick processing of
frozen material by carbon dioxide freezing attachment. Table clamping is provided. Suitable to
cut sections upto 40 microns in steps of 5 microns each.
Ÿ Freezing stage : 35 mm diameter
Ÿ Feed range : 5-40 microns
Ÿ Total feed excursion : 25mm
Accessories Supplied with Equipment:-
Ÿ Razor 120 mm with back & handle-one
Ÿ Honing plate-one
Ÿ CO2 freezing attachment & stage-one
Ÿ Oilcan-one
Ÿ Spanner for attachment to CO2 Cylinder-one
Ÿ Without CO2 Cylinder
J-10
JCR-1
JCR-1B

SLIDE WARMING TABLE:
JP-1: Slide Warming Table is useful for slow but uniform heating of slides to flatten sections
below melting point of wax. S.S. top plate mounted on metallic stand with a thermostat to
control temperature upto 70°C.
Supplied completely with Pilot Lamp, Temperature Control Knob, Cord-Plug etc. to work on
220V AC 50Hz single phase.
Stainless Steel top:
30 x 25 cm
40 x 25 cm
45 x 30 cm
60 x 15 cm
AUTOMATIC RAZOR SHARPNER (Arthur Thomas Type) :
J-9A: A heavy duty sharpening machine for razors upto 300 mm length. It is equipped with
large round hard surface plate with one side ground and other side polished for various
sharpening operations. Complete with universal knife holder having automatic reversing device
and dust cover without abrasives.
Optional :
Micro abrasives for coarse & fine honing are available in 200 gm.
JP-1
J-9A
AUTOMATIC RAZOR SHARPNER (SPENCER TYPE) :
J-9: A streamlined automatic microtome knife sharpner with electric timer coupled with simple
operation for razors upto 150 mm on both the wedges. Working machanism encased in metal
cover and front portion covered with clear acrylic canopy to observe safe and dustfree honing.
Supplied complete with glass honing plate, coarse & fine abrassives and dust cover.
J-9
MICROTOME ACCESSORIES:
JP-16: Microtome Accessories : (At extra cost)
Ÿ Razor Attachment : ( For use of safety blades).
Ÿ Microtome Razor : Fabricated out of grain tool steel heat treated and tested for micro
structures, both side wedges with back & handle in wooden box.
Size : 120 mm, 140 mm, 160 mm.
Ÿ Object Holders: (Set of 3 for Rotary Microtome).
Ÿ Leather Strap : Special quality leather size 12 x 2" fitted on wooden base for final
strapping of razors.
Ÿ Honing Stone : Special quality stone in a box.
Ÿ L-Moulds : It is used for making different size wax blocks (in pairs)
I.e. 37 x 25x 15 mm, 50 x 25 x 15 mm, 75 x 30 x 15 mm.
Ÿ Tissue Cassette: Made of reinforced stainless steel mesh. JP-16

PARAFFIN DISPENSER( EMBEDDING BATH-SINGLE):
JP-4: Paraffin Dispenser is embedding bath-single type dispenser which is double walled, both
made of stainless steel sheet, gap filled with glass wool for temp. Insulation. Temperature range
ambient to 70°C controlled by hydraulic type thermostat. Completely supplied with Pilot Lamp,
Temp. Control Knob, Cord-Plug etc. To work on 220V AC 50Hz, single phase.
Available in capacity : 1 litre, 2 litre & 5 litre.
Optional: Stainless steel basket.
PARAFFIN EMBEDDING BATH :
JP-3: Paraffin Embedding Bath : The body is made of mild steel sheet which is duly painted.
The top is made of M.S. / S.S. sheet. Completed with wax pots with covers. Temperature
ambient is upto 70°C controlled by a thermostat to work on 220V AC 50Hz single phase. The
following compositions are available:-
I) 4 cups and 6 glass tube.
II) 6 cups and 8 glass tubes.
III) 12 cups and 12 glass tubes.
JP-3
JP-4
TISSUE FLOTATION BATH:
JP-2: Tissue Flotation Bath is useful to float tissue wax sections to flatten for staining process.
Double Walled chamber, inner made of black anodised aluminum and outer wall made of mild
steel sheet duly painted. Gap between two insulated with glass wool. Temperature ambient to
70ºC ± 2ºC controlled by a thermostat.
It is supplied completely with Pilot Lamp, Temperature Control Knob, Cord-Plug etc. to work on
220V AC 50Hz single phase.
Chamber Size : Diameter 225 mm, Depth 70 mm, Rim 40 mm.
Optional Accessories:
Digital microprocessor PID temperature controller cum indicator.
JP-2

JP-5
AUTOMATIC TISSUE PROCESSOR :
JP-5: Automatic Tissue Processor is a compact and versatile equipment for staining process
atomization from stage one of fixation of tissue and dehydration process to paraffin wax
saturation. Glass door with locking arrangement provides easy viewing and safety from
tempering. Continuous agitation is provided by rotating S.S. Tissue basket to make process
more effective. A superior thermostat maintains desired temperature of wax bath.
Accessories :
1 - S.S. Basket rotor
1 - Tissue basket12 - S.S. Tissue capsules
10 - 1 litre glass beakers
11 - beaker covers
2 - S.S. Wax baths each fitted with thermostat, 5-24 hrs
Calibrated timing discs
One-notch plier for programming time discs
It works suitably on 220V ac 50Hz single phase
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
TISSUE CULTURE STATION SINGLE UNIT :
JP-5S: Compact model, suitable for use in small Laboratories.
Supplied with
One S.S. Basket Rotor,
One S.S. Tissue Basket,
One S.S. Wax Bath,
12 Nos. S.S Tissue Capsules,
1 Nos. S-type Dividers.
Suitable to work on 220 V, single phase, 50 Hz, AC supply.
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
JP-5S
JP-5D
DIGITAL TISSUE PROCESSOR :
JP-5D:
Ÿ Feather touch key pad
Ÿ Digital display for adjusting time sequence
Ÿ Battery backup to retain data
Ÿ 12 stage timing sequence can be programmed with each step of 1 minute to 16 hours 39
minutes (999 min.)
Ÿ Delay action of 1 hour to 99 hours
Ÿ 2 Electronically Controlled wax bath 10°C to 80°C
Ÿ 1or 2 Stainless Steel Basket
Ÿ 24 tissue containers (Cassettes)
Ÿ 1 or 2 Stainless steel Basket Rotors
Ÿ 10 without lip glass beakers ('/2 kr, 1 kr or 2 It)
ACCESSORIES (Optional):
Ÿ Additional Basket Rotor
Ÿ Tissue Capsule Basket SS
Ÿ Tissue Capsule with Sliding Cover
Ÿ S Shape divider for Tissue Capsule
Ÿ V Shape divider for Tissue Capsule
Ÿ Additional Wax bath

SLIDE STORAGE CABINET (FLAT POSITION):
JP-15: Cabinet structure as Model-JP-13. The slides are stored in flat position in Aluminium
trays The trays slide in wooden groves and have puller devices Dust-proof door has locking
arrangement.
Capacity :
500 slides with 25 trays
Note : Cabinets with higher capacities in model : JP-13, 15 can be fabricated on demand.
SPECIMEN JAR:
JP-17: Specimen Jar made of clear acrylic sheet chemically welded to prevent from leakage and
is rectangular in shape with covering. It can be fabricated in any size.
JP-15
JP-13
SLIDE STORAGE CABINET :
JP-13: Cabinet fabricated out of thick board. Exterior clad in laminated sheet. Drawers and
slide holding grooves made of seasoned Teakwood/aluminium serially numbered. Each drawer
has index card and puller knobs. An extra drawer has been provided at bottom for keeping index
cards etc. Dust proof door has locking arrangement.
Capacity : 1000 2000 3000 5000 10000slides
TISSUE WAX BLOCK STORAGE CABINET:
JP- 10: Cabinet made out of Duro-board, externally clad in laminated sheet. Dust-proof door is
lockable. Provided with smoothly sliding drawers with compartments each of size 4x4x2" and
have puller knobs. Each compartment can store blocks in two rows.
Capacity : 4 drawers (2000 blocks)
6 drawers (3000 blocks)
10 drawers (5000 blocks)
JP-10
JP-17

OUR OTHER PRODUCT RANGE :
VISUAL EQUIPMENTS
MICROTOMY EQUIPMENTS
WATER STILLS
CLEAN AIR SYSTEM
HEAT & REFRIGERATION
SYSTEM
BLOOD BANKING
GENERAL LABORATORY
SYSTEM
PHARMACEUTICAL
PHARMACOLOGY EQUIPMENTS
ANALYTICAL INSTRUMENTS
INCINERATORS
ENGINEERING COLLEGE
EQUIPMENTS
MICROTEKNIK
2759, Timber Market Ambala Cantt 133001 Haryana (INDIA)
Phone : 0171-2640855, 2644991, 4006791
E-mail: info@microteknik.com, microteknik@gmail.com
Website : www.microteknik.net, www.microteknik.com,
www.microtomesindia.com

Guide to Microtomes and Laboratory Equipment

Recommended

Recommended

More Related Content

What's hot

What's hot (20)

Similar to Guide to Microtomes and Laboratory Equipment

Similar to Guide to Microtomes and Laboratory Equipment (20)

More from Microteknik - A Symbol of Quality

More from Microteknik - A Symbol of Quality (11)

Recently uploaded

Recently uploaded (20)

Guide to Microtomes and Laboratory Equipment
